Continental Refrigerator TPMS Go User manual

www.continental-aftermarket.com/tpmsgo
TPMS Go
User Manual

TPMS GO User Guide
Page 1/31
TABLE OF CONTENTS
TPMS GO TOOL................................................................................................................................................................................................................................2
1. SPECIFICATIONS..............................................................................................................................................................................................................................................................2
2. IMPORTANT SAFETY INSTRUCTIONS...................................................................................................................................................................................................3
3. CAUTION...................................................................................................................................................................................................................................................................................4
4. FUNCTION KEYS..............................................................................................................................................................................................................................................................5
5. POWER ON.............................................................................................................................................................................................................................................................................6
6. OPERATING INSTRUCTIONS.............................................................................................................................................................................................................................7
TPMS GO USE......................................................................................................................................................................................................................................8
1. CHECK SENSOR................................................................................................................................................................................................................................................................8
2. PROGRAM A BLANK SENSOR....................................................................................................................................................................................................................11
3. PART LOOKUP..............................................................................................................................................................................................................................................................17
SETTINGS.............................................................................................................................................................................................................................................19
1. SETTINGS MENU........................................................................................................................................................................................................................................................19
ABOUT......................................................................................................................................................................................................................................................23
1. THE ABOUT MENU..................................................................................................................................................................................................................................................23
LANGUAGE.........................................................................................................................................................................................................................................24
1. LANGUAGE MENU...................................................................................................................................................................................................................................................24
RECENT SENSOR DATA.....................................................................................................................................................................................................25
1. RECENT SENSOR DATA.....................................................................................................................................................................................................................................25
MISCELLANEOUS.......................................................................................................................................................................................................................26
1. CHARGE ............................................................................................................................................................................................................................................26
2. TROUBLESHOOTING............................................................................................................................................................................................................................................27
3.. INSTALL WEBTPM...................................................................................................................................................................................................................................................28
4. WARRANTY.......................................................................................................................................................................................................................................................................29
5. BATTERY/SAFETY......................................................................................................................................................................................................................................................29
6. CE STATEMENTS........................................................................................................................................................................................................................................................30
7. FCC STATEMENTS....................................................................................................................................................................................................................................................31
8. RCM STATEMENTS..................................................................................................................................................................................................................................................31
9. RECYCLING.......................................................................................................................................................................................................................................................................31

TPMS GO User Guide
Page 2/31
User Guide
TPMSGO
1. SPECIFICATIONS
Battery Type:
Rechargeable Li-Po (Lithium-Polymer).
Battery Life:
Approximately 400 activations per full charge.
Dimensions (Max. L,W,D):
16.5 cm x 9.5 cm x 3.8 cm (6.5" x 3.7" x 1.5")
Housing Material:
High Impact ABS.
Response Frequency:
Main frequencies: 315 MHz and 433.92 MHz.
(supporting most specific frequencies).
Low Battery Indication:
LCD bar graph display.
Weight:
0,35 Kg (0,7 lbs.)
Temperature:
Operating: -4° F to 131° F (-20° C to +55° C).
Storage: -40°F to 140° F (-40° C to +60° C).
Operating Altitude:
Up to 2 000 m (6 560 ft).
Device accessories:
USB cable
Power supply
USB stick with WebTPM PC software, driver program and
user manual

TPMS GO User Guide
Page 3/31
2. IMPORTANT SAFETY INSTRUCTIONS
Do not discard. Retain for future reference.
This device complies with:
- CE standards
- FCC rules
- RCM standards
- ROHS standards
Operation is subject to the following two conditions:
(1) This device will not cause harmful interference, and
(2) This device will accept any interference received, including interference that may cause
undesired or improper operation.
WARNING: This product emits electromagnetic and electronically generated
waves that may interfere with the safe operation of pacemakers.
Individuals that have pacemakers should never use this product.
WARNING:
Do not use onlive electrical circuits.
Must read instructions before use.
Wear safety goggles. (User and bystanders).
Risk of entanglement.
Read the Warranty, Safety and Recycling information at the end of this user guide.

TPMS GO User Guide
Page 4/31
3. CAUTION
READ THESE INSTRUCTIONS BEFORE USE
Your Tire Pressure Monitoring (TPM) tool has been designed to be durable, safe, and reliable
when properly used.
All CONTINENTAL TPMS TOOLS are intended to be used only by qualified and trained
automotive technicians or in a light industrial repair shop environment. Please read all
instructions below before using. Always follow these safety instructions. If you have any
questions pertaining to the safe or reliability use of this tool, please call your local dealer.
1. Read All Instructions
All warnings on the tool and in this manual should be adhered to. All operating instructions
should be followed.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Heed Warnings
User and bystanders must wear safety goggles and must read instructions before use. Do not
use on live electrical circuits, risk of entanglement.
4. Cleaning
Clean with a soft dry cloth, or if necessary, a soft damp cloth. Do not use any harsh chemical
solvents such as acetone, thinner, brake cleaner, alcohol, etc as this may damage the plastic
surface.
5. Water & Moisture
Do not use this tool where contact or immersion in water is a possibility. Never spill liquid of any
kind onto the tool.
6. Storage
Do not use or store the tool in an area where it is exposed to direct sunlight or excessive
moisture.
7. Use
To reduce the risk of fire, do not operate the tool in the vicinity of open containers or flammable
liquids. Do not use if the potential for explosive gas or vapors exists. Keep the tool away from
heat generating sources. Do not operate the tool with the battery cover removed.

TPMS GO User Guide
Page 5/31
4. FUNCTION KEYS
Power ON /OFF switch
Test or trigger sensor.
Next, continue or confirm.
Cancel, previous step.
Navigate to select "up
Navigate to down
left
right
Battery charge
indicator and
low bat. light
Trigger light
Result lights
Keyboard
Antenna

TPMS GO User Guide
Page 6/31
5. POWER ON
Press key to turn on the TPMS TOOL
➢Displays the Continental Logo as Fig. 1.
Fig. 1
➢The software version as Fig. 2.



Fig. 2
➢At first start or after a factory reset, the work zone
is asked as Fig. 3.

 

 
Fig. 3
➢Then reverts to the MAIN MENU as Fig. 4.



Fig. 4

TPMS GO User Guide
Page 7/31
6. OPERATING INSTRUCTIONS
6.1. TPMSTOOLOVERVIEW
Read and diagnose sensors.
Service Procedure
Read Sensor Test
Before servicing the tires/wheels, using your
TPMS TOOL, trigger each of the vehicle's sensors to
make sure they are working properly.
This will eliminate the liability associated with replacing
previously damaged or defective sensors.



This procedure will not change the vehicle settings because the vehicle has yet to be put into
learn/retraining mode. This procedure allows you to quickly identify damaged or defective
sensors, because some vehicles do not report a damaged or defective sensor condition on the
instrument cluster for up to 20 minutes.
Note:Ifthesensors donot trigger, pleaserefer to theTroubleshootingsection of this Guide.
Perform tire/wheel service.
Beginby triggering thedriver's left front (LF)wheel sensor.
The same procedure should be followed on all wheel sensors, in a
clockwiserotation.
We recommend you trigger each wheel sensor, one final time, to make
sure they are working correctly prior to releasing the vehicle to the
customer.
1 Start LF
4 End LR
RF 2
RR 3
Fig. 5

TPMS GO User Guide
Page 8/31
TPMS GO USE
IMPORTANT:
Vehicle specific information in this manual is used as an example and may not represent
specific instructions each make and model may require. When performing various functions
with the tool, it is important to refer to the on-screen prompts and/or repair manual
information.
1. CHECK SENSOR




 
 

 
1.1. SELECT CAR MANUFACTURER

 
 

 

 
 
 
 
1.2. SELECT CAR MODEL

 
 
 
 

 

TPMS GO User Guide
Page 9/31
1.3. SELECT YEAR

 

 

1.4. SELECT WHEEL NUMBER
This option does not appear for all vehicles.

 



▲
◄►
▼
SELECT TIRE
C:
: START
The tool is ready to trigger the sensors.
1.5. TEST SENSOR


▲
◄►
▼
SELECT TIRE
C:
: START
Use keypad for tire selection.


TRIGGER PROCESSING
C:
: START

TPMS GO User Guide
Page 10/31
1.6. TEST RESULTS


TRIGGER PROCESSING
C:
: START
1:PASS:press to go to nexttire.
2/5: FAIL.
1: PASS


F383834 25°C
2.50 bar BAT:OK
433 MHz
C:
: START
2: FAIL


NO SENSOR DETECTED
C:
: START
3: FAIL


DUPLICATE SENSOR
C:
: START
4: FAIL


REDUCE TIRE PRESSURE
C:
: START
5: FAIL


COM. ERROR
C:
: START

TPMS GO User Guide
Page 11/31
2. PROGRAM BLANK SENSOR
This feature allows to recover a sensor ID in order to enter it in the spare blank sensor. If the
"old" sensor can be read, use the "COPY ORIGINAL SENSOR" function to recover the ID. If it can't
be read, use the "CREATE NEW SENSOR" menu to create a randomized ID.




 
 

 
2.1. PROGRAM BY SENSOR OR VEHICLE
This option offers to program a sensor, either by sensor brand or by vehicle.
2.1.1. Sensor selection mode

 
 

 
 
 
 

 
 
 
 

 
 

 
2.1.1. Vehicle selection mode

 
 

 
 

 

TPMS GO User Guide
Page 12/31
2.1. SELECT CAR MANUFACTURER

 
 

 

 
 
 
 
2.2. SELECT VEHICLE MODEL

 
 
 
 

 
2.3. SELECT YEAR

 

 
 
 
 
The list of compatible sensors depends
on the vehicle selected
2.4. SELECT BLANK SENSOR MODEL

 
 
 
 
TOYOTA
Use EU-Pro1 or EU-Pro
Hybrid
(C) STOP (OK) NEXT
The device displays the compatible
references of the selected brand
to continue.

TPMS GO User Guide
Page 13/31
2.5. SELECT THE OPTION
TOYOTA
Use EU-Pro1 or EU-Pro
Hybrid
(C) STOP (OK) NEXT

 
 
2.6. "COPY ORIGINAL SENSOR"

 
 


COPY ID
C:
: START


COPY ID
C:
: START


TRIGGER PROCESSING
C:
: START

TPMS GO User Guide
Page 14/31
2.6.1. Test results


TRIGGER PROCESSING
C:
: START
1:PASS:See "Sensor reprogramming"
section.
1: PASS


F383834 25°C
2.50 bar BAT:OK
433 MHz
C:
: START
2: FAIL: press to test again.
2: FAIL


NO SENSOR DETECTED
C:
: START
3: FAIL: reduce the tire pressure and
press to test again.
3: FAIL


REDUCE TIRE PRESSURE
C:
: START
4: FAIL: press to test again.
4: FAIL


COM. ERROR
C:
: START

TPMS GO User Guide
Page 15/31
2.7. PROGRAMMING SENSOR


F383834 25°C
2.50 bar BAT:OK
433 MHz
C:
: START
Hold the new programmable sensor
near the device antenna.


PROGRAM SENSOR
433 MHz
C:
: START
2.7.1. Results


PROGRAM SENSOR
433 MHz
C:
: START


UPLOADING…
C:
: START


V ER I FY ING
433 MHz
C:
: START


F383834 25°C
2.50 bar BAT:OK
433 MHz
C:
: START

TPMS GO User Guide
Page 16/31
2.8. "CREATE NEW SENSOR"


 


CREATE SENSOR
433 MHz
C:
: START
Hold the new programmable sensor
near the device antenna.
2.8.1. Results


CREATE SENSOR
433 MHz
C:
: START
Note: in this operation the ID is a random
number.


UPLOADING…
C:
: START


VERIF YING
433 MHz
C:
: START
.


EE995DD 25°C
2.50 bar BAT:OK
433 MHz
C:
: START

TPMS GO User Guide
Page 17/31
3. PART LOOKUP
This is a spare parts data base for all sensors available for each car.




 
 

 
3.1. SELECT CAR MANUFACTURER

 
 

 

 
 
 
 
3.2. SELECT VEHICLE MODEL

 
 
 
 

 

TPMS GO User Guide
Page 18/31
3.1. SELECT YEAR

 
PART# LOOKUP
> OE
OE Sensor ref
OE SERVICE KIT
OE SERVICE VALVE
3.1. SELECT PART NUMBER
PART# LOOKUP
> OE
OE Sensor ref
OE SERVICE KIT
OE SERVICE VALVE
OE
42607-20010
TOYOTA
RAV4 III
2005-2013

TPMS GO User Guide
Page 19/31
SETTINGS
1. SETTINGS MENU




 
 
 
 

 
 
 
 
 
 
Complete listing.
Scroll up and down to select function or settings.
Enter menu or validate settings by using OK.
Key functional descriptions:
ZONE: to select the area of work, AMERICA, EUROPE, KOREA or JAPAN.
UNITS: change the air pressure and temperature display (kPa, Bar or PSI with F° or C°).
FORMAT: change the format of sensor ID display.
BUZZER: turn buzzer to ON or OFF (YES or NO).
CONTRAST: adjust LCD backlight brightness level (0% to 100%).
AUTO OFF: time to turn off the device automatically after not being operated.
