DESCRIPTION
The Medical Task Undercabinet Series provides effective task and
enhancement lighting solutions for any application. This wraparound lens
specification grade fluorescent undercabinet series incorporates the latest
energy efficient technology with fluorescent lamps and electronic ballasts to
efficiently improve the appearance and productivity of the illuminated
environment.
The unique low profile wraparound lens design conforms to various
applications such as nursing stations, modular offices, laboratories,
computer work centers and practically any under-counter installation where
high light levels are required below and forward of the luminaire.
A ... Lens
Extruded opal acrylic linear ribbed
diffuser.
B ... Internal Reflector
Standard white painted housing
reflector for improved efficiency.
C ... Housing
Available in 1.1" deep heavy 20
gauge seam welded CRS
construction with no exposed
fasteners. Keyhole mounting slots
are located on top of housing for
ease of installation. Knock-outs are
provided on ends for continuous
row mounting.
D ... Lamps
(By Others)
E ... Finish
Standard white high reflectance
polyester powder coat finish
applied after fabrication.
F ... Ballast
Electronic Class P CBM/ETL.
G ... Electrical
Suitable for through wiring when
installed in continuous rows.
H ... Labels
UL listed for use in USA and
Canada. Standard damp location
label.
MST
14W - 35W
Fluorescent
ULTRA LOW PROFILE
MEDICAL/TASK
UNDERCABINET
LUMINAIRE
Wraparound Lens
T5 Technology
E N E R G Y D A T A
Input Watts:
(Electronic Ballasts and Standard Lamps)
(1) 8W T5 Fluorescent: 9W
(2) 8W T5 Fluorescent: 19W
(1) 8W + (1) 13W T5 Fluorescent: 23W
(1) 13W T5 Fluorescent: 13W
(2) 13W T5 Fluorescent: 26W
(1) 14W T5 Fluorescent: 15W
(1) 21W T5 Fluorescent: 21W
(1) 28W T5 Fluorescent: 27W
(1) 35W T5 Fluorescent: 33W
5.0 "
[127.0 mm]
2.2"
[55.9 mm]
1.1"
[27.9 mm]
3.2"
[81.3 mm]
1.5"
[38.1 mm]
1.5"
[38.1 mm]
1.5"
[38.1 mm]
1.5"
[38.1 mm]
.8"
[20.3 mm]
.6"
[15.2 mm]
.8"
[20.3 mm]
.6"
[15.2 mm]
Housing Length
Dimension A
5/8 X 37/64 D.D K.O. (8)
3/16 Keyhole (2)
Housing
Length Dimension A Lamp
12.2" [ 309.9mm] 7.4" [ 188.0 mm] 8WT5
24.4" [ 619.8 mm] 19.6" [ 497.8 mm] 8WT5 (2)
33.4" [ 848.4 mm] 28.6" [ 726.4 mm] 8WT5 (1) + 13WT5 (1)
21.2" [538.5 mm] 16.4" [ 416.6 mm] 13WT5
42.4" [1077.0 mm] 37.6" [ 955.0 mm] 13WT5 (2)
22.6" [574.0 mm] 17.8" [ 452.1 mm] 14WT5
34.4" [873.8 mm] 29.6" [ 751.8 mm] 21WT5
46.3" [1176.0 mm] 41.5" [ 1054.1 mm] 28WT5
58.3" [1480.8 mm] 53.5" [ 1358.9 mm] 35WT5
2.4"
[61.0 mm]
FAIL-SAFE ®

Fail-Safe • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2007 9:04:50 AM
Specifications and Dimensions subject to change without notice.
ADC051101
PHOTOMETRICS
ORDERING INFORMATION
MST
6 in.
30 in.
16 in.
18 in.
1-1/2 in.
12 in.
18 in.
24 in.
30 in.
24 in.
18in.
12 in.
6 in.
0 in.
6 in.
12 in.
18 in.
24 in.
30 in.
12
5
10
4
7
3
11
4
5
3
19
7
20
7
17
6
12
5
17
7
8
4
27
11
34
12
37
12
32
11
20
8
11
6
43
17
57
20
66
23
58
20
35
13
16
8
61
24
84
31
98
38
87
32
49
20
22
12
68
27
95
37
113
47
98
39
55
23
24
12
12
5
60
24
82
31
98
38
87
32
51
20
22
11
43
17
57
20
66
23
57
20
34
13
17
8
27
11
33
12
37
12
32
11
20
8
12
6
17
7
19
7
20
7
17
6
12
5
8
4
5
3
7
3
10
4
12
5
12
5
11
4
2 in.
C
L
Point By Point Illumination Scale is
Exaggerated on Fixture Application
and Mounting.
Optional Mounting Heights
MOUNTING HEIGHT 15"
MST108EB51 - Report: MST108T5EB.IES
MST113EB51 - Report:MST113T5EB.IES
5 7 11 18 27 32 27 18 11 7 5
1-1/2"
11 18 28 45 63 71 63 45 28 17 11
5 8 13 23 39 48 37 23 13 8 5
6"
12 20 36 65 103 118 102 65 36 20 12
5 8 13 26 52 69 51 26 13 7 5
12"
12 21 41 84 140 165 139 83 40 21 12
4 6 11 22 42 55 40 22 11 6 4
18"
10 17 33 69 114 135 113 66 32 16 9
3 5 8 13 22 27 22 14 8 5 3
24"
7 11 19 34 52 58 53 32 19 11 7
2 3 5 8 11 13 11 8 5 3 2
30"
5 7 10 15 19 21 19 14 10 7 5
30" 24" 18" 12" 6" 0 6" 12" 18" 24" 30"
MOUNTING HEIGHT 24"
MST-08-120-EB51 - Report: MST108T5EB.IES
MST-13-120-EB51 - Report: MST113T5EB.IES
4 6 9 14 18 20 18 14 9 6 4
1-1/2"
8 13 19 26 33 36 33 26 19 12 8
5 7 11 16 21 24 21 16 10 7 4
6"
9 14 21 31 39 43 39 30 21 14 9
5 7 11 17 23 26 23 17 11 7 4
12"
9 14 22 32 43 47 42 32 21 14 9
4 6 10 15 21 24 21 15 10 6 4
18"
8 13 19 29 37 41 37 29 19 13 8
4 5 8 12 16 17 16 12 8 5 4
24"
7 10 16 22 28 30 28 22 16 10 7
3 4 6 8 10 11 11 8 6 4 3
30"
6 8 12 15 19 19 19 15 12 8 6
30" 24" 18" 12" 6" 0 6" 12" 18" 24" 30"
Fixture Application Illustration
MOUNTING HEIGHT 18"
MST-08-120-OPL-EB51
Report: MST108T5EB.IES
F8T5/CW Lamp
400 Lumens/8 Watts
MST-13-120-OPL-EB51
Report: MST113T5EB.IES
F13T5/CW Lamp
820 Lumens/13 Watts
Countertop 16" x 30"
C
L
C
L
SAMPLE NUMBER: MST-14-120-OFP-EB51
Notes:
For additional options consult Cooper Lighting Representative.
Specifications and Dimensions subject to change without notice.
Electronic ballast may cause interference with other electronic devices.
1For specific electronic ballast, specify brand and catalog number.
2For use with 120V only. GCO and RSW are mounted standard on the right side of the luminaire.
GLR=GLR Fuseholder with Fuse
6 C P =6ft. Cord with Grounded Plug2
GCO=Grounded Convenience Outlet (White)2
RSW=Rocker Switch (White)2
MST=
Medical Task
Undercabinet
Wraparound
Lens
OPL=Opal Linear Prism
120=120V
MST
T5 Fluorescents
0 8=(1) 08W
0 8 1 3=(1) 08W + (1) 13W
1 3=(1) 13W
1 4=(1) 14W
208=(2) 08W
2 1=(1) 21W
213=(2) 13W
2 8=(1) 28W
3 5=(1) 35W
Series Lamp Type Voltage Lens Type
Options
(Factory Installed)
EB51=(1) Electronic
Ballast for
use with T5
Lamp
Ballasts 1
