INTERIOR WALL
987
COOPER LIGHTING
SHAPER™
MATERIAL
Painted, natural or plated
solid aluminum with a 1/8"
matte white acrylic panel.
Open top and bottom with
a regressed aluminum
perf shield.
Notes:
1 Available with CFL only.
2 Supplied by others.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
One (1) 13W (G24q-1) 4-
pin quad CFL lamp, one
(1) 26W (GX24q-3) triple
tube CFL lamp or one (1)
60W A-19 lamp. CFL
socket injection molded
plastic. INC socket fired
ceramic rated for 660W-
250V. Lamps furnished by
others.
INSTALLATION
Supplied with a universal
circular strap for a
standard 4" J-box or
plaster ring.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
683 Direct/Indirect Economical Wall
Sconce features an aluminum cylinder.
683/4 is ADA compliant.
683 & 683/4
SERIES
4"
683/4
5"
9"
4-1/2"
5"
3-1/2"
683
4"
9"
4-1/2"
Sample Number: 683/4-CFL/1/26-347V-BK
Series
683=Wall Sconce
683/4=ADA Compliant
Wall Sconce
Lamp
CFL/1/13
CFL/1/26
INC/1/60
Voltage
120V
277V 1
347V 1
Finish
NA (Interior standard),
CC, MW (Interior premium)
WH (Damp Location standard),
BK, BM, CC, DP, GM, GRM, GY,
SM (Damp Location premium)
Options
DL
REM2
MATERIAL
Painted, natural or plated
solid aluminum with a 1/8"
matte white acrylic panel.
Open top and bottom
with a regressed
aluminum perf shield.
Notes:
1 Available in 31".
2 Available in 43".
3 Available in 55".
4 Supplied by others.
BALLAST
Integral electronic HPF
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
31": Two (2) 14W T5
linear miniature bi-pin
fluorescent lamps.
43": Two (2) 21W T5
linear miniature bi-pin
fluorescent lamps.
55": Two (2) 28W T5
linear miniature bi-pin
fluorescent lamps.
Fluorescent socket
injection molded plastic.
Lamps furnished by
others.
INSTALLATION
Supplied with a universal
circular strap for a
standard 4" J-box or
plaster ring.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
674 Luminous Wall Sconce features
horizontal trim bars with a vertical fin
detail and is ADA compliant. Design
options, such as perforated metal,
colored acrylic, and different trim
bar configurations are available.
674 SERIES
4"
3/4"
31" 29" 25"
8-3/8" 4"
674
31" STANDARD
Sample Number: 674-55-T5/2/28-347V-OBRS
Series
674=
Interior Luminous
Wall Sconce
Size
31"
43"
55"
Lamp
T5/2/141
T5/2/212
T5/2/283
Voltage
120V
277V
347V
Finish
BK, BM, CC, DP,
GM, GRM, GY, MW,
NA, OBRS, PB, PCP,
PN, SAL, SB, SCP,
SM, SN, SNL, WH
Options
DL
GGA
IEM2, 3
REM4
FD
MATERIAL
Painted or plated cold-
rolled steel base metal.
Optional aluminum
cube cell louver, white.
Notes:
1. Available in 9".:
2. Available with 687/4 Series.
3. Available with 687 Series.
4. Available in 12".
5. CFL and MH only.
6. Available with CFL only.
7. MH only.
BALLAST
Integral Electronic HPF
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage. Metal Halide
Ballast are HPF core and
coil type, multi-volt
120/277V for the specified
wattage. Contact factory
for 347V.
LAMP/SOCKET
687 - 9": One (1) 26W or 32W (GX24q-3) 4-pin triple
CFL lamp or one (1) 75W A-19 lamp. 687/4 - 9": One (1)
13W (2GX7) 4-pin low wattage CFL lamp, one (1) 26W
(G24q-3) 4-pin quad CFL lamp or one (1) 75W A-19
lamp. 687 - 12": Two (2) 26W or 32W (GX24q-3) 4-pin
triple CFL lamps, two (2) 75W A-19 lamps, one (1)
300W double-ended T-3 halogen lamp or one (1) 50W,
70W or 100W ED-17 metal halide (open burn) lamp.
687/4 - 12": Two (2) 26W (G24q-3) quad CFL lamps or
two (2) 75W A-19 lamps. CFL socket injection molded
plastic. INC socket fired ceramic rated for 660W-
250V. Lamps furnished by others.
INSTALLATION
Supplied with a universal
circular strap for a
standard 4" J-box or
plaster ring.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
687 features classic Geometric Wedge
shape with indirect illumination. The
687-4 features similar geometry and is
ADA compliant.
687 SERIES
8"
9"
9"
1"
9"
687-9" STANDARD
10"
12"
1"
11"
687-12" STANDARD
11"
Sample Number: 687-12-HAL/1/300-120V-OBRS
Series
687 =
Geometric Wedge
687/4 =
Geometric Wedge
Size
9"
12"
Lamp
CFL/1/131, 2
CFL/1/261, 3, 2
CFL/1/321, 3
CFL/2/262, 3, 4
CFL/2/323, 4
INC/1/751, 2, 3
INC/2/752, 3, 4
HAL/1/3003, 4
MH/1/503, 4
MH/1/703, 4
MH/1/1003, 4
Voltage
120V
277V5
347V6
Finish
MB, MW
(standard),
CC, OBRS,
OBZ, PB, PC,
PCP, PN, SAL,
SB, SC, SCL,
SCP, SN, SNL
Options
BPP
GPP
RPP
WPP
YPP
CL
DL
MEM3, 4
QR3, 4
REM
TGL7
4"
8"
3/8"
