Cooper Lighting Quantum Series CQA User manual

13.50"
13.50"
Added
Wall
Support
Added
Ceiling
Support
via Cable
15.00" Standard
Custom Lengths 
Available
15.00" Standard
Custom Lengths 
Available
3.00" (Low Voltage Canopy)
0.19" (Coverplate)
*
*
Catalog #
Type
Project
Lamp Group 1
8.88"
Lamp Group 2
12.94"
Lamp Group 3
13.44"
Lamp Group 1
3.94"
Lamp Group 2
5.50"
Lamp Group 3
6.00"
SPECIFY -
Optional Accessories - Details on Other Side
Baffle Snoots Louvers Lenses
A
COMBOLIGHT®QUANTUM Series • CQA
TWO (2) Light Adjustable Wall or Ceiling Mounted Luminaire
Fixture Configuration “A” • Lamp Groups 1, 2 & 3
Low Voltage, Line Voltage or Metal Halide
DESCRIPTION:
Awall / ceiling mounted fixture
with adjustable arm construction
featuring four separate pivot points
for maximum flexibility in display
illumination.
CONSTRUCTION:
All aluminum construction with
durable powder coat finish.
LAMP ASSEMBLY:
Two lamps mounted in adjustable
double gimbal lamp holders. Dual
axis 90º x 90º locking adjustability.
Lamp column swivels 50º.
ELECTRICAL:
Low voltage and metal halide mod-
els are wired for use with remote
transformers or ballasts. Custom
configurations are available for
integral transformers or ballasts -
consult RSA factoryfor details.
Low voltage and Line Voltage mod-
els are dimmable.
ALL RSA COMBOLIGHT PRODUCTS
ARE MADE IN THE U.S.A.
Label: UL, CSA and New York
Calendar
Cat. # / Description Lamp Type Grid Configuration Finish
CQA - Adjustable Wall / Ceiling
Mounted Luminaire Lamp Group 1 11 - MR16 12V 50W A - Two Light BK - Black
12 - MR16 12V 75W
13 - AR70 12V 20W WH - White
14 - AR70 12V 50W
15 - PAR16 120V S - Silver
16 - PAR20 120V
Lamp Group 2 21 - PAR20MH 39W PC - Polished
Chrome
22 - PAR30 120V
23 - PAR30MH 39W PT - Custom
24 - PAR30MH 70W
25 - PAR36 12V 50W
26 - AR111 12V 35W
27 - AR111 12V 50W
28 - AR111 12V 75W
29 - AR111 12V 100W
Lamp Group 3 31 - PAR38 120V
32 - PAR38MH 70W
33 - PAR38MH 100W
GRID CONFIGURATION “A”
This sheet is for Grid Configuration
“A”. To see other grid configura-
tions, consult other ComboLight
Quantum Series spec sheets.
USING THIS SPEC SHEET
This fixture is dimensioned
according to lamp type. Please
select lamp from either Lamp
Group 1, 2 or 3 - and then refer to
the appropriate dimensions of fix-
ture as shown above.
Custom configurations areavailable for integral transformers or
metal halide ballasts - consult RSA factory for details.
13.50" 
Standard
(ustom lengths available)
4.63" 
15.00" 
Standard
(Custom lengths available)
Adjustable double gimbal 
lamp holder accepts up to 
two optical accessories
90º
90º
Standard lamp back cover for
AR111 models hides lamp
terminals and connections.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
