WALL BRACKETS
428 COOPER LIGHTING
DIMENSIONSDESCRIPTION
The BI Series meets the need for
a very low brightness wall
bracket. This specification grade
wall bracket with an injection
molded refractor produces
effective up, down or
combination lighting. This
energy efficient luminaire offers
up lighting, multi-level switching
and convenience outlets as
options. These design features
ensure that the BI Series will
provide ease of use and comfort.
The BI Series features
specification efficiency in a low
profile wall bracket. The Series is
an excellent choice for dressing
rooms, lavatories, hospital and
nursing homes, stairways and
task lighting.
BI/BIU SERIES
2', 3' or 4'
1 or 2 Lamps
STEEL WALL BRACKET
ORDERING INFORMATION
SAMPLE NUMBER: BI-232-120V-EB81-U
BI=Series
Light Distribution
Blank=Downlight
Only
U=Up and
Downlight
NOMINAL LENGTH A B
2', 3' ,4' 7-1/2" (190mm) 3-1/2" (89mm)
• Equipped with energy
saving ballasts/complies
with federal energy
efficiency standards
• Low profile design
• Die formed, steel housing
• Baked white enamel finish
• Down or combination
up/downlight
• Injection molded
diffuser/end plate
• Refractor slides forward for
easy installation and
maintenance
• Easy wiring access
• Convenience outlet and
switching available, see
Options page
• UL/CUL Listed. Suitable for
damp locations.
NOTES: (1)Products also available in non-US voltages and frequencies for international markets. (2)Not available when specifying emergencies, voltage must be specific.
(3)Non available for 2' version.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
Starting Type
LTS=Low Trigger Start (20 Watt only) (120V only)
HTS=High Trigger Start (20 Watt only)
Number of
Lamps
1or 2lamps
(Not Included)
Wattage (Length)
20=20W T12 (24")
17=17W T8 (24")
30=30W T12 (36")
25=25W T8 (36")
40=40W T12 (48")
32=32W T8 (48")
Voltage (1)
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal
Voltage 120-277(2)
Options
GL=Single Element Fuse
GM=Double Element Fuse
Emergency - for EM installed, see
EM options table(3)
Options
(See Options
Section)
Packaging
U=Unit Pack
Ballast Type (1)
Blank=Standard Magnetic Ballast
(20W only)
LE3=T12 Magnetic Energy Saving
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
EB2 =T12 Electronic Rapid Start.
(For complete details on generic or to specify
manufacturer’s ballast see pg. 469)
No. of Ballast
1, 2 or 3
No. of
Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1 or 2
COOPER LIGHTING - METALUX®
