1200 SERIES
High Performance
Pendant Luminaire
Indirect or Indirect/Direct
Flat Pan with
Double Ring Trim
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
The 1200 Direct/Indirect or Indirect High Performance Pendant
features a 2-1/2" H. Solid (S), Open (OB) or Frosted Glass (OBG)
center design with a double trim ring and is available in three
diameters with multiple mounting options.
SPECIFICATION FEATURES
Material/Mounting
Solid (S) or Open (OB) painted
and plated cold rolled steel or
natural aluminum. Frosted Glass
Lense (OBG).
Tri-Pod (TP) 26" and 36" and
Quad-Pod (QP) 44" (Standard):
3/8" stem with a standard hang
height of 26" (OA) for the 26"
dia., 30" (OA) for the 36" dia. and
38" (OA) for the 44" dia.
Minimum overall hang height is
18" (OA) for the 26" dia., 24" (OA)
for the 36" dia., and 31" (OA) for
the 44" dia. Maximum overall
hang height is 8' (OA). Contact
factory for lengths above 8'.
Specify SCA for sloped ceilings
up to 0°-45°.
Finish
Standard: Matte White (MW).
Premium: Natural Aluminum
(NA) [Sustainable Design] , Satin
Chrome (SC), Polished Chrome
(PC), Satin Brass (SB), Polished
Brass (PB), Oxidized Brass
(OBRS), Lacquered Satin
Aluminum (SAL), Satin Copper
(SCP), Polished Copper (PCP),
Satin Nickel (SN), Polished Nickel
(PN), Oxidized Copper (OCP),
Gun Metal (GNM), Lacquered
Satin Chrome (SCL), Lacquered
Satin Nickel (SNL) or Custom
Color (CC). Regressed solid edge
(between rings) will be satin
finish with all polished finishes.
Custom Decorative Metals:
(Specify a Color and Pattern)
Colors - Clear (CLR), Cabernet
(CBT), Sapphire (SPE), Sage
(SGE), Brass (BRS), Copper
(CPR), Black Pearl (BPL), Slate
Green (SGN), Champagne (CMP),
Chocolate (CLE), Indigo (IDO),
Royal Blue (RBE), or Pewter
(PWR). Patterns - Coral (COL),
Seashell (SHL) or Smooth (SMT).
Note: Select a standard or
premium finish for the stem(s)
and canopy. Example: SGE (Sage
color finish)-SMT (smooth
pattern) - SC (Satin Chrome)
stem (s) and canopy. Minimum
quantity is 5 of one color/pattern.
Contact the factory for lead time.
Optics
Dedicated lamp optics with a
"kick reflector" formed out of
94% reflective specular anodized
aluminum.
Ballast
Integral CFL electronic HPF,
multi-volt 120/277V (347V
Canada), thermally protected
with end-of-life circuitry to
accommodate the specified lamp
wattage.
Lamp/Socket
26" -Three (3) or six (6) 27W
(2G11) high lumen CFL lamps.
36" -Three (3) or six (6) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps.
44" - Four (4) or eight (8) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps. CFL
socket injection molded plastic.
Lamps furnished by others.
Installation
Installation requires 1/4-20 UNC-
2A AllThread rod. AllThread
(supplied by others) through a
standard J-box to an integral
support canopy support system.
The 1/4-20 UNC-2A AllThread
rod must be attached to the
building structure to support the
fixture's weight.
Options
Dimming Ballast - Except 27W,
contact factory for ballast
options (DM), Sloped Ceiling
Adaptor - Specify up to 45°
(SCA), Single Stem (1S - Solid
Only),Triple Stem (3S - Solid
only), Single Stem with Aircraft
Cable (1SAC), Aircraft Cable with
White SJ Cord (SJWAC), Aircraft
Cable with Clear SJ Cord
(SJCAC), Remote Emergency
Battery (REM) - contact factory,
Separate Switching (SSW),
Factory Fuse (FF), Damp Location
(DL): All Painted Finishes,
Lacquered Satin Chrome (SCL)
and Lacquered Satin Nickel (SNL)
finishes only. Contact factory for
Multi-bowl and alternative
mounting options.
Labels
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard High
Performance Pendant luminaires
for project specific solutions.
Contact the factory regarding
scale options, unique finishes,
mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
New Custom
Decorative Metals Finish
ADS051189
2008-09-08 13:25:49
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Shaper offers a line of products that
offer optically-engineered, high
performance optics for compact
fluorescent, metal halide and halogen
sources.
HIGH PERFORMANCE
OPTICS
Refer to the Icon Legend
Link on shaperlighting.com.

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
Sample Number: 1200-OB-26-CFL/3/27-120V-CBT/COL-PC-26
Options
1S Single Stem 3
=
1SAC Single Stem
Aircraft Cable
=
3S Three Stem 3
=
SJCAC Aircraft Cable
w/ Clear SJ Cord
=
SJWAC Aircraft Cable
w/ White SJ Cord
=
DL Damp Location=
DM CFL Dimming Ballast
7
=
FF Factory Fuse=
REM Remote
Emergency Battery
=
SCA Sloped Ceiling Adapter=
SSW Separate Switching=
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass 1
=
PC Polished Chrome 1
=
PCP Polished Copper 1
=
PN Polished Nickel 1
=
SAL Lacquered
Satin Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered
Satin Chrome
=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered
Satin Nickel
=
Custom Decorative Metals
CLR Clear=
CBT Cabernet=
SPE Sapphire=
SGE Sage=
BRS Brass=
CPR Copper=
BPL Black Pearl=
SGN Slate Green=
CMP Champagne=
CLE Chocolate=
IDO Indigo=
RBE Royal Blue=
PWR Pewter=
Pattern 2
COL Coral=
SHL Seashell=
SMT Smooth=
Lamp
Series
Stem and Canopy Finish
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass 1
=
PC Polished Chrome 1
=
PCP Polished Copper 1
=
PN Polished Nickel 1
=
SAL Lacquered
Satin Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
Size
26"
36"
44"
Suspension Height
26'' (OA) - 26'' dia.
30'' (OA) - 36'' dia.
38'' (OA) - 44'' dia.
or Specify
Voltage
120V
277V
347V
1
Notes:
2
Available in 26" Only. Available with Custom Decorative Metal Finish only. 3Available in Solid Type only. Not available in 27W.
26"
CFL/3/27
CFL/6/27
36"
CFL/3/27
CFL/3/39
CFL/3/40
CFL/3/50
CFL/3/55
CFL/6/27
CFL/6/39
CFL/6/40
CFL/6/50
CFL/6/55
44"
CFL/4/27
CFL/4/39
CFL/4/40
CFL/4/50
CFL/4/55
CFL/8/27
CFL/8/39
CFL/8/40
CFL/8/50
CFL/8/55
Color
56
7
Interior applications only. Select a standard or premium finish for the stem(s) and canopy.
Supplied by others.
LNB =Hand Painted Faux
Linen Bowl
Example: SGE (Sage color) - SMT
Minimum quantity is 5 for one color/pattern.
4
5
4
(Smooth pattern) for the double trim rings - SC (Satin Chrome) for the stem(s) and canopy.
Contact the factory for lead-time.
6
1200-S
1200-OB
1200-OBG 3
ORDERING INFORMATION
ADS051189
2008-09-08 13:25:49
1200 SERIES HP PENDANT
1200 - SOLID (S)
26-1/8"
1200 - OPEN BOTTOM (OB)
26-1/8" 9"
1200 - OPEN BOTTOM W/ GLASS (OBG)
26-1/8" 9"
1200 - BOTTOM OPTIONS STANDARD
26"
2-3/8"
1200 - 36" - TRI-POD STANDARD
30"
2-3/8"
38"
2-3/8"
1200 - 26" - TRI-POD STANDARD 1200 - 44" - QUAD-POD STANDARD
DIMENSIONS

Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
44"
36"
26"
HIGH LUMEN CFL
1200 OPTIC DRAWINGS STANDARD
1200 - SINGLE STEM
AIRCRAFT CABLE (1SAC)
26"
2-3/8"
1200 - TRIPLE STEM (3S)
26"
2 3/8"
1200 - AIRCRAFT CABLE
WITH SJ CORD (SJAC)
26"
2-3/8"
1200 - SINGLE STEM (1S)
26"
2-3/8"
1200 - SUSPENSION OPTIONS STANDARD
Single Stem (1S): 5” stacked canopy with a 1-1/2”
swivel ball. One 5/8” stem with a standard hang
height of 24” (OA), minimum 18” (OA).
Maximum
overall hang height for one-piece stem assembly
is 8’ (OA) . For 8’ to 30’ (OA) the stems are supplied
in multiple sections. Solid Bottom only.
Triple Stem (3S): 5” stacked canopy with a 1-1/2”
swivel ball. One 5/8” stem with a standard hang
height of 24” (OA), minimum 18” (OA). Maximum
overall hang height for one-piece stem assembly
is 5’ (OA). For lengths from 5’ to 25’, a collector
body (CB) will be provided. Solid Bottom only.
Aircraft Cable with a SJ Cord (SJAC): One
5/8” stem and 3/32“ cables with a standard hang
height of 24” (OA), minimum 18” (OA).
Single Stem Aircraft Cable (1SAC): Three or four
3/8” stem with a standard hang height of 24” (OA),
minimum 18” (OA). Maximum overall hang height
is 8’ (OA). Contact factory for lengths above 8’.
Specify SCA for sloped ceilings up to 45°. Solid
Bottom only.
INSTALLATION
Contractor to provide appropriate structural support
for fixture weight. Refer to the installation drawings
for details. Integral safety cable provided.
SUSPENSION OPTIONS
1200 - SUSPENSION OPTIONS STANDARD 1200 SERIES HP PENDANT
ADS051189
2008-09-08 13:25:49
494-RP 444 494-S 494 610 693 693-S
