PM614cbi
60 Amp Busway
Catalog #
Type
Project
A machined aluminum track fixture for low voltage
AR111 lamps from 35 to 100 watts. For use with RSA
Profile Series 60 Amp Busway, 20 Amp 1 or 2 Circuit
Track or 20 Amp 2 Circuit / 2 Neutral Track.
Integral low voltage electronic transformer in alu-
minum housing.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
AR111 12V
Closed Back Machined Fixture w/ Integral Transformer
PM614cbi | PM414cbi | PM214cbi | PM114cbi
Ordering Example: PM614cbi-50-AL-120
PM414cbi
20 Amp Track
2 Cct. 2 Ntl.
PM114cbi
PM214cbi
20 Amp Track
1 or 2 Cct.
Closed Back Machined Fixture w/ Integral Transformer Lamp Wattage Finish Voltage
❑ PM614cbi - AR111 for 60 Amp Busway
❑ PM114cbi - AR111 for 20 Amp 1 Circuit Track
❑ PM214cbi - AR111 for 20 Amp 2 Circuit Track
❑ PM414cbi - AR111 for 20 Amp 2 Circuit / 2 Neutral Track
❑ 35 35 Watt 12V AR111 ❑ WH White ❑ 120 120 Volts primary
❑ 50 50 Watt 12V AR111 ❑ BK Black ❑ 277 277 Volts primary
❑ 75 75 Watt 12V AR111 ❑ AL Natural Alum.
❑ 100 100 Watt 12V AR111 ❑ PT Custom Finish

PM53
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
AR111 12V Halogen G53
35 AR111 /SSP4 OSI 13 266 1.3 1.3 12 234 1.5 1.3 6.9 6 313 2.0 1.2 10.4 9 278 1.6 1.3 9.0
Beam Spread = 4° x 4° 18 139 1.6 1.6 16 132 1.9 1.7 9.2 9 139 2.9 1.6 15.6 13 133 2.2 1.6 13.0
CBCP = 45,000 23 85 2.0 2.0 20 84 2.2 2.0 11.5 12 78 3.7 2.0 20.8 17 78 2.7 2.0 17.0
Rated Life = 3,000 Hrs. 28 57 2.3 2.3 24 59 2.6 2.3 13.9 15 50 4.6 2.5 26.0 21 51 3.3 2.4 21.0
35 AR111 /SP8 OSI 7 286 1.3 1.3 6 292 1.5 1.3 3.5 4 219 2.6 1.5 6.9 5 280 1.8 1.4 5.0
Beam Spread = 8° x 8° 10 140 1.8 1.8 8 164 1.9 1.7 4.6 5 140 3.2 1.8 8.7 7 143 2.3 1.7 7.0
CBCP = 14,000 13 83 2.2 2.2 10 105 2.2 2.0 5.8 6 97 3.8 2.0 10.4 9 86 2.9 2.1 9.0
Rated Life = 3,000 Hrs. 16 55 2.6 2.6 12 73 2.6 2.3 6.9 7 71 4.3 2.3 12.1 11 58 3.5 2.5 11.0
35 AR111 /FL25 OSI 3 278 1.7 1.7 3 208 2.2 1.9 1.7 2 156 4.5 2.1 3.5 3 139 3.2 2.2 3.0
Beam Spread = 25° x 25° 4 156 2.1 2.1 4 117 2.8 2.4 2.3 3 69 6.6 3.0 5.2 4 78 4.1 2.9 4.0
CBCP = 2,500 5 100 2.6 2.6 5 75 3.4 2.9 2.9 4 39 8.7 3.9 6.9 5 50 5.0 3.5 5.0
Rated Life = 3,000 Hrs. `` 6 69 3.0 3.0 6 52 4.0 3.4 3.5 5 25 10.8 4.8 8.7 6 35 6.0 4.1 6.0
50 AR111 /SSP4 OSI 12 347 1.4 1.4 12 260 1.6 1.5 6.9 7 255 2.5 1.5 12.1 8 391 1.6 1.3 8.0
Beam Spread = 4° x 4° 18 154 1.8 1.8 16 146 2.0 1.8 9.2 9 154 3.0 1.8 15.6 12 174 2.2 1.7 12.0
CBCP = 50,000 24 87 2.2 2.2 20 94 2.4 2.1 11.5 11 103 3.6 2.1 19.1 16 98 2.8 2.1 16.
Rated Life = 3,000 Hrs. 30 56 2.6 2.6 26 55 2.9 2.6 15.0 13 74 4.2 2.3 22.5 20 63 3.3 2.5 20.0
50 AR111 /SP8 OSI 10 200 1.8 1.8 8 234 1.9 1.7 4.6 5 200 3.2 1.8 8.7 7 204 2.3 1.7 7.0
Beam Spread = 8° x 8° 15 89 2.5 2.5 12 104 2.6 2.3 6.9 7 102 4.3 2.3 12.1 10 100 3.2 2.3 10.0
CBCP = 20,000 20 50 3.2 3.2 14 77 3.0 2.6 8.1 9 62 5.5 2.9 15.6 13 59 4.0 2.9 13.0
Rated Life = 3,000 Hrs. 25 32 3.9 3.9 16 59 3.4 2.9 9.2 11 41 6.6 3.4 19.1 16 39 4.9 3.5 16.0
50 AR111 /FL25 OSI 4 219 2.1 2.1 3 292 2.2 1.9 1.7 2 219 4.5 2.1 3.5 3 194 3.2 2.2 3.0
Beam Spread = 25° x 25° 5 140 2.6 2.6 4 164 2.8 2.4 2.3 3 97 6.6 3.0 5.2 4 109 4.1 2.9 4.0
CBCP = 3,500 6 97 3.0 3.0 5 105 3.4 2.9 2.9 4 55 8.7 3.9 6.9 5 70 5.0 3.5 5.0
Rated Life = 3,000 Hrs. 7 71 3.5 3.5 6 73 4.0 3.4 3.5 5 35 10.8 4.8 8.7 6 49 6.0 4.1 6.0
75 AR111 /SP8 OSI 10 300 1.8 1.8 9 278 2.0 1.8 5.2 5 300 3.2 1.8 8.7 8 234 2.6 1.9 8.0
Beam Spread = 8° x 8° 14 153 2.3 2.3 12 156 2.6 2.3 6.9 7 153 4.3 2.3 12.1 11 124 3.5 2.5 11.0
CBCP = 30,000 18 93 2.9 2.9 15 100 3.2 2.8 8.7 9 93 5.5 2.9 15.6 14 77 4.3 3.1 14.0
Rated Life = 3,000 Hrs. 22 62 3.4 3.4 18 69 3.7 3.3 10.4 11 62 6.6 3.4 19.1 17 52 5.1 3.7 17.0
75 AR111 /FL25 OSI 5 212 2.6 2.6 4 248 2.8 2.4 2.3 3 147 6.6 3.0 5.2 3 294 3.2 2.2 3.0
Beam Spread = 25° x 25° 6 147 3.0 3.0 5 159 3.4 2.9 2.9 4 83 8.7 3.9 6.9 4 166 4.1 2.9 4.0
CBCP = 5,300 7 108 3.5 3.5 6 110 4.0 3.4 3.5 5 53 10.8 4.8 8.7 5 106 5.0 3.5 5.0
Rated Life = 3,000 Hrs. 8 83 3.9 3.9 7 81 4.6 3.9 4.0 6 37 12.8 5.7 10.4 6 74 6.0 4.1 6.0
75 AR111 /WFL45 OSI 3 189 2.8 2.8 3 142 3.9 3.2 1.7 2 106 14.0 3.7 3.5 2 213 4.4 2.7 2.0
Beam Spread = 45° x 45° 4 106 3.7 3.7 4 80 5.1 4.2 2.3 3 47 20.8 5.3 5.2 3 94 6.4 3.9 3.0
CBCP = 1,700 5 68 4.5 4.5 5 51 6.2 5.1 2.9 4 27 27.7 7.0 6.9 4 53 8.4 5.1 4.0
Rated Life = 3,000 Hrs. 6 47 5.3 5.3 6 35 7.4 6.1 3.5 5 17 34.5 8.6 8.7 5 34 10.4 6.2 5.0
