NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
749
COOPER LIGHTING
RECESSED
SYMBIO
294
292
194
DIRECT-INDIRECT
24" [610mm]
5"
[127mm]
12" [305mm]
5"
[127mm]
• Recessed Mounting for T-grid,
sheet rock ceiling and 9/16"
slot T-grid.
• Can be mounted end-to-end
and ide-to-side.
• 20 ga. steel housing,
• 24 ga. steel reflector.
• Baked on low gloss, white,
powder coated acrylic finish.
• 1'x4', 2'x2', 2'x4' fixture
configurations.
• Louver shielding options:
perforated, frosted acrylic or
tannenbaum cross blades.
• T5, T5HO lamps (not by
NEO-RAY).
• Consult factory for dimming
and emergency options.
• UL Listed, C-ULListed
ORDERING INFORMATION:
Sample number: 292R-2T5HO-ETG-2EB-SI-S17
Series
194=Symbio 1’x4’ 292=Symbio 2’x2’ 294=Symbio 2’x4’
Options 2
A=Air Return T=Tannenbaum Reflector
C=Chicago Plenum
Mounting
R=Recessed
Number of Lamps (per cross section) (not included)
1=1 Lamp 2=2 Lamps 3=3 Lamps (T5 only)
Lamp Type
T8 T5 T5HO BX40W BX50W
(2x2 only) (2x2 only)
Ceiling Type
ETG=Exposed T-Grid STG=Slot T-Grid SR=Sheet Rock
Voltage 1
1=120V 2=277V 3=347V U=Universal
Ballast
EB=Electronic Ballast (Standard) DB=Dimming Ballast
Switching
SI=Single Switching DU=Dual Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR GMF
Shielding
S17=White Louver with Perforated Metal Blades
S17A=White Louver with Perforated Metal Blades and Acrylic Overlay
S17B=White Louver with Frosted Acrylic Blades
S17C=White Louver with Frosted Acrylic Blades and Acrylic Overlay
S17F=1100G Satin Aluminum Louver with Tannenbaum Blades
S17G=1100G Satin Aluminum Louver with Tannenbaum Blades and
Acrylic Overlay
Lens Options
S28A=Ribbed Clear Plastic
S28B=Ribbed Textured Clear Plastic
S28C=Ribbed Blue Plastic
S28D=Ribbed Green Plastic
1 Due to various constraints, some options may not be combined with others.
2 Can be left blank or more than one option may be available, consult factory.
Construction
20-gauge steel housing.
Shielding
Louver shielding options: white perforated metal,
frosted acrylic or Tannenbaum cross blades.
Electrical
120, 277, 347 or Universal Voltage electronic ballast.
Fixtures and electrical components certified to UL
and CUL standards.
Finish
Durable, low gloss, white, powder coated acrylic
finish.
Mounting
Recessed.
STANDARD LUMINAIRE PLAN – VIEW – VIEW
24" x 48"
(610mm x 1219mm)
NOMINAL
(1, 2 or 3 Lamps)
294 292 194
EXPOSED TEE GRID
ETG STG SR
SLOT TEE GRID SHEET ROCK
MOUNTING INFORMATION
12" x 48"
(305mm x 1219mm)
NOMINAL
(1 or 2 Lamps)
24" x 24"
(610mm x 610mm)
NOMINAL
(1, 2 or 3 Lamps)
Tannenbaum Reflector
NEO-RAY™
194
294/292
294/292 Lens Option
