Cooper Lighting VRM User manual

FAIL-SAFE®
ARCHITECTURAL VANDAL RESISTANT
COOPER LIGHTING
DIMENSIONS DESCRIPTION
The Fail-Safe VRMC, VRM and
2VRM Series fluorescent
luminaires combine a low
profile, surface modular design
with the latest in energy-
efficient technology. Their
Energy Saving Ballast
complies with Federal Energy
Efficiency Standards while a
dihedral recessed top allows
for cooler operation. Other
features include a die-formed
housing, surface or stem
mounting (single or
continuous row), full seam-
welded corners and a broad
selection of attractive door
frames. U.L. listed and C.S.A.
certified.
VRMC
VRM
2VRM
1' x 4', 2' x 2', 2' x 4'
2, 3, OR 4 LAMPS
VANDAL RESISTANT
LUMINAIRE
• Housing is die-formed code
gauge prime CRS. Smooth
sides permit flush joints
when continuous row
mounting. Die-formed
captive lampholder
brackets
• Ballasts are CBM/ETL Class
“P” and positively secured
by mounting by mounting
bolts. Pressure lock
lampholders
• Electrostatically applied
baked white polyester
powder enamel finish
• Positive cam action steel
latches with baked white
enamel finish
• Die formed, heavy gauge,
flat steel door with
reinforced mitered corners
and baked white enamel
finish. Positive light seals.
Frame and lens are secured
to housing with 4 or 6
stainless steel TORX®
screws
For additional options, consult your Cooper Lighting Representative.
Specifications and Dimensions subject to change without notice.
B
C
B
C
B
C
MOUNTING
B
C
C
C
B
B
ABC
VRMC 3 15/16" 12" 48"
1' x 4' (100mm) (305mm) (1219mm)
(2 lamp)
VRM 3 15/16" 12" 48"
1' x 4' (100mm) (305mm) (1219mm)
(3 lamp)
2VRM 3 15/16" 24" 24"
2' x 2' (100mm) (610mm) (610mm)
2VRM 3 15/16”" 24" 48"
2' x 4' (100mm) (610mm) (1219mm)
A
B
Ballast Type
LE3= Energy Saving
Ballast
LEOC8= Energy Saving
Ballast
(T-8 Lamp Only)
EB_ _= Generic Electronic
Ballast
No. of Ballasts
1or 2
Lamp Size
2=T12
8=T8
5=T5 Biax
(For specific electronic
ballast specify brand and
catalog number)
ORDERING INFORMATION
SAMPLE NUMBER: 2VRM-232A-120V-EB81-U
Width
Blank=1'
2=2'
Series
VRMC=1' Width (2 Lamp)
VRM=1' Width (3 Lamp)
2VRM=2' Width
Number of
Lamps
2, 3, or 4lamps
(Not Included)
LTS=Low
Trigger Start
(20 Watt)
HTS=High
Trigger Start
(20 Watt)
Voltage
120=120V
277=277V
347=347V
UNV=Universal
Voltage 120-277
Wattage (Length)
U6=40W (24")
U6T8=32W (24")
20=20W (24")
17=17W T8 (24")
U1-5/8=31W
T8 (24")
BX40=40W
Biax (24")
40=40W (48")
32=32W T8 (48")
Lens Type
ACTF140 = .140 Thick
ACTF187 = .187 Thick
PA375 = .250 polycarbonate with
.125 prismatic overlay
(standard with 6S
option)
Door Type
Standard=Flat White Steel
Door (Leave Blank)
Options
(add as suffix)
GL=Internal Single
Element Fusing
GM=Dual Element
Fusing
EL4=Emergency Lighting
self-contained
SMB=Side Mounted
Ballast For Stem
Applications .
(Recommended For 4
Point Suspension)
RIF1=Radio Interference
Suppressor
EKO=End Plate with 7/8"
KO (Required for
Continuous Row
Mounting)
RLS=Rotor-Lock Socket
(T8 Lamps Only)
6S=Six TORX-head
Screws(3 per side)
SC=Safety Chain
