PENDANTS
958
SHAPER™
COOPER LIGHTING
MATERIAL
Painted and plated cold
rolled steel or aluminum.
Optional Caming Trim,
luminous dome. Matte
white acrylic Luminous
Upper Dome (LUD),
Perforated Upper Dome
with acrylic liner and
caming trim (PUD) or
Solid Upper Dome (SUD)
that is supplied with a
painted white interior,
exterior as per finish
specification. Three
stem is standard
suspension. Minimum
18” (OA).
Notes:
1. Available in 28".
2. Available in 36".
3. Available with CFL only.
4. LUD and 28" SUD only.
5. 28" SUD only.
6. LUD only.
7. Consult the factory for available options.
8. Supplied by others.
9. Specify up to 45°.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
28": Two (2) 26W, 32W
(GX24q-3) or 42W
(GX24q-4) 4-pin triple CFL
lamps or two (2) 75W
A-19 lamps.
36": Four (4) 26W, 32W
(GX24q-3) or 4-pin triple
CFL lamps or three (3)
75W A-19 lamps. CFL
socket injection molded
plastic. INC socket fired
ceramic rated for 660W-
250V. Lamps furnished by
others.
INSTALLATION
Supplied with a universal
circular strap for a
standard 4" J-box or
plaster ring. Safety cable
provided.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
406 Direct/Indirect Pendant features
a luminous, perforated or solid upper
dome with an indirect solid lower
bowl and is available in two
diameters with multiple mounting
options.
406 SERIES
36" ø 14-1/2" ø
14-1/2" ø
4-1/2"
32"
14"
1-1/8"
28" ø 10" ø
28" STANDARD
36" STANDARD
24"
4"
11"
6" ø 6" ø
1-1/8"
10" ø
Sample Number: 406-LUD-36-CFL/4/26-347V-OBRS-__
Series
406=Direct/Indirect
Dome
Lamp
CFL/2/261
CFL/2/321
CFL/2/421
CFL/4/262
CFL/4/322
INC/2/751
INC/3/752
Voltage
120V
277V3
347V3
MATERIAL
Painted and plated cold
rolled steel, solid brass
or aluminum with a matte
white acrylic bowl.
Optional cold rolled steel,
solid brass or stainless
steel caming ring. Three
stem is standard
suspension. Minimum 18”
(OA).
Notes:
1. Available in 28".
2. Available in 36".
3. Available in 42".
4. Available with CFL only.
5. Not available in 13W.
6. Not available in 27W.
7. Consult the factory for available options.
8. Supplied by others.
9. Not available with 1SAC, SJWAC or SJCAC. Specify up to 45°.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
28": Four (4) 13W (2GX7)
4-pin low wattage CFL
lamps, 26W or 32W
(GX24q-3) triple 4-pin CFL
lamps or three (3) 75W
A-19 lamps.
36": Four (4) or eight (8)
27W (2G11) high lumen
CFL lamps, four (4) 42W
(GX24q-4) 4-pin triple CFL
lamps or six (6) 75W A-19
lamps.
42": Four (4) or eight (8)
39W (2G11) high lumen
CFL lamps, four (4) or
eight (8) 42W (GX24q-4)
4-pin triple CFL lamps or
six (6) 100W A-19 lamps.
CFL socket injection
molded plastic. INC
socket fired ceramic
rated for 660W-250V.
Lamps furnished by
others.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
404 Direct/Indirect Pendant features a
low profile bowl and is available in
three diameters with multiple mounting
options.
404 SERIES
28" ø
24"
6-1/4"
28" STANDARD
6" ø
1-1/8"
28" ø
Sample Number: 404-36-CFL/4/26-347V-OBRS-__
Series
404=Luminous
Shallow Bowl
Size
28"
36"
42"
Lamp
CFL/4/131
CFL/4/261
CFL/4/272
CFL/4/321
CFL/4/393
CFL/4/422, 3
CFL/8/272
CFL/8/393
CFL/8/423
INC/3/751
INC/6/752
INC/6/1003
Voltage
120V
277V4
347V4
Finish
MW (standard),
CC, OBRS, PB, PC PCP,
PN, SAL, SB, SC, SCL,
SCP, SN, SNL
Size
28”
36”
Bowl
LUD = Luminous Upper Dome
PUD = Perforated Upper Dome
SUD = Solid Upper Dome
36" ø
24"
7-3/4"
36" STANDARD
6" ø
1-1/8"
36" ø
42" ø
24" 8-7/8"
42"STANDARD
6" ø
1-1/8"
42" ø
Options
1S
1SAC
QPB
SJCAC
SJWAC
TPB
TSS2B
TSS3B
TSS4B
2TBF
2TRB
TR
CT
DL
DM 5, 6, 7
CFL
IEM2, 3
REM8
SCA9
FB
Suspension
Height
24"
Or Specify
Options
1S
TSS2B
TSS3B
TSS4B
CT6
DL
DM7
REM8
SCA9
Suspension
Height
24"
Or Specify
Finish
MW (standard),
CC, OBRS, PB4,
PC4, PCP5, PN4,
SAL, SB, SC,
SCL, SCP, SN,
SNL
