Cooper Lighting IRiS E7QT4 User manual

CATALOG#: TYPE:
Specification grade quartz T4 fixture rated for
direct contact with insulation. The 50° cutoff
to lamp and lamp image provides a glare free,
concentrated distri ution of light. Halogen lamps
provide excellent color and long life. Lamp
module and optical element can be changed after
installation to provide a variet of lamp sources
and distributions. e.g. into a PAR36 Adjustable.
A...Reflector
.040 thick aluminum spun para olic upper and lower
reflector. Upper reflector is specular clear, lower
reflector availa le in iridescent free Clear, Gold,
Black, Haze, Warm Haze Alzak®, or painted gloss
white finish. Special cone colors listed elow.
B...Flange
Self flange reflector or Die-cast flange with either
matte white or clear coat finish. Die-cast flanges
are easily removed for field painting. Elements are
keyed for proper insertion.
C...Attachment
Positive torsion springs pull flange tight to
ceiling. Mechanical light trap eliminates spill light
at edge of flange or reflector.
D...Socket
Mini candela ra nickel plated porcelain finish.
Fixed socket height ensures consistent lamp
position.
E...Lamp Shield
.125 thick tempered etched glass lens is retained
during relamping and provides ultra-smooth eam
pattern.
F...Electrical
Keyed quick connect provides easy lamp module
installation.
G...Frame/Housing
Hot dipped galvanized 20 gauge steel frame
with uilt in 1/2 inch plaster lip. Gunsights allow
for consistent alignment. Aluminum .032 thick
housing allows for heat dissipation and reduces
weight. Top is removable for above-ceiling access.
H...Junction Box
18 cu ic inches, listed for 4#12 AWG or 6#14 AWG
90° C additional feed through conductors, has six
1/2 inch pryouts.
I...Bar Hangers
No Flex®ar hangers with positive locking, for use
with wood, engineered wood and steel frame
joists spaced up to 24" O.C. shipped with platform.
For use in T- ar ceilings order accessory MBCLP.
Nailess ar and locator lip provide consistent
installation height.
Codes
Thermally protected, IP la eled, for use in direct
contact with insulation. Meets Washington State
Air tight requirements, 1995 CABO Model Energy
Code.
Labels
UL and cUL listed, standard wet la el,
IBEW union made.
ADI030679
SPECIFICATION FEATURES
H
B
A
D
G
I
C
E
F
MQT4= 7"
QT4 Mini-
Candela ra
Socket
ORDERING INFORMATION
Complete unit consists of a platform, module and element
P7
P7=7"
Airtight IC
Rated
housing
MQT4
Lamp
ModulePlatform
COOPER LIGHTING
P7
MQT4
E7QT4
150W T4
7" DOWNLIGHT
63/4"
For additional options
please consult factory.
DESCRIPTION
11"
[280mm]
12 1/4"
[312mm]
8 1/4"
[210mm]
16 3/4"
[426mm]
6 3/4"
[172mm]
7 3/4"
[197mm]
Finish Accessories
MBCLP=40 Push
On T Bar Clips
(for 10 Units)
PLE7=Plaster
Lip Extension
for Max 2" Thick
Ceiling
Flange
Blank=White
die-cast
SF=Self Flange
RAW=Natural
Die-cast
SFWF=Self
Flange Painted
White
Optical
Element
E7QT4= 7"
QT4
Downlight
Reflector
Standard
B=Black
C=Clear
H=Haze
G=Gold
WMH=Warm Haze
W=Gloss White
MW=Matte White
Custom
K=Cognac
KH=Cognac Haze
CC=Chocolate
Custom Cont.
CCH=Chocolate
Haze
BU=Blush
BUH=Blush Haze
GP=Graphite
GPH=Graphite
Haze
PN=Pine
PNH=Pine Haze
SK=Sky
SKH=Sky Haze
8 1/4"
[210mm]
Ceiling Cutout
7 3/4" (197mm)

PHOTOMETRICS
P7-MQT4-E7QT4C
Test No. H35085
Lamp: Q150T4/Frosted
Lumens: 2700
Cutoff: 50°
Spacing: 0.6
Efficiency: 60.1%
Unit LPW: 10.8
Unit Num er: P7-MQT4-E7QT4_
Candelas
Vertical CD
Angle
90 0
85 0
75 0
65 0
55 0
45 42
35 662
25 1116
15 1607
5 2612
0 2818
Luminance
Degree cd/m2
85˚0
75˚0
65˚0
55˚0
45˚2593
4'6"
5'6"
6'6"
8'0"
10'0"
12'0"
2'6"
3'0"
3'6"
4'0"
5'0"
6'0"
143
96
69
45
29
20
Cone of Light
Distance to Initial Nadir Beam
Illuminated Plane Footcandles Diameter
Notes and Formulas:
Luminance: To convert cd/m2to footlam erts, multiply y 0.2919
Cone of Light:
• Beam diameter is to 50% of maximum footcandles, rounded to the nearest half-foot.
• Footcandle values are initial. Apply appropriate light loss factors where necessary.
See page 64-65 of catalog.
CU Notes/Formulas:
• maintained illuminance=lamp lumens x CU x light loss factors
room area
• total num er of luminaires=total room area x maintained illuminance
lamp lumens x CU x light loss factors
• CU data ased on 20% effective floor cavity reflectance.
80% 70% 50% 30% 0%
70 50 30 10 50 10 50 10 50 10 0
72 72 72 72 70 70 67 67 64 64 60
66 63 61 59 62 58 60 56 57 55 52
63 59 56 54 58 53 56 52 54 51 49
60 56 52 49 55 49 53 48 52 47 46
57 52 48 46 51 45 50 45 49 44 43
54 49 45 42 48 42 47 42 46 41 40
52 46 42 40 46 39 45 39 44 39 38
49 43 40 37 43 37 42 37 41 36 35
47 41 37 35 40 34 40 34 39 34 33
45 39 35 32 38 32 38 32 37 32 31
42 36 33 30 36 30 36 30 35 30 29
Ceiling Reflectance
Wall Reflectance
Room Cavit Ratio
0
1
2
3
4
5
6
7
8
9
10
Coefficient of UtilizationZonal Lumen Summar
Zone Lumens %Lamp %Luminaire
0-30 1199 44.4 73.8
0-40 1570 58.1 96.7
0-60 1624 60.1 100.0
0-90 1624 60.1 100.0
90-180 0 0.0 0.0
0-180 1624 60.1 100.0
Distribution
0°
Lamp Wattage Multiplier
100W x 0.74
90W x 0.75
75W x 0.60
60W x 0.67
Note: Specifications and Dimensions su ject to change without notice.
