Cooper Lighting FAIL-SAFE FMR12 User manual

Cooper Lighting

Cooper Lighting FAIL-SAFE FMR12 User manual

Cooper Lighting Portfolio 828 User manual

Cooper Lighting

Cooper Lighting Portfolio 828 User manual

Cooper Lighting METALUX VT2 User manual

Cooper Lighting

Cooper Lighting METALUX VT2 User manual

Cooper Lighting Shaper 624 Series User manual

Cooper Lighting

Cooper Lighting Shaper 624 Series User manual

Cooper Lighting INVUE Vision Site User manual

Cooper Lighting

Cooper Lighting INVUE Vision Site User manual

Cooper Lighting Power Failure Emergecny Light ENC User manual

Cooper Lighting

Cooper Lighting Power Failure Emergecny Light ENC User manual

Cooper Lighting 1270 Series User manual

Cooper Lighting

Cooper Lighting 1270 Series User manual

Cooper Lighting Metalux 124T5HO User manual

Cooper Lighting

Cooper Lighting Metalux 124T5HO User manual

Cooper Lighting AMETRIX SSI01 User manual

Cooper Lighting

Cooper Lighting AMETRIX SSI01 User manual

Cooper Lighting HALO L1731 User manual

Cooper Lighting

Cooper Lighting HALO L1731 User manual

Cooper Lighting Metalux 2HB25 User manual

Cooper Lighting

Cooper Lighting Metalux 2HB25 User manual

Cooper Lighting FAIL-SAFE FMS12CR User manual

Cooper Lighting

Cooper Lighting FAIL-SAFE FMS12CR User manual

Cooper Lighting Fail-Safe RC User manual

Cooper Lighting

Cooper Lighting Fail-Safe RC User manual

Cooper Lighting Shaper 497-RP User manual

Cooper Lighting

Cooper Lighting Shaper 497-RP User manual

Cooper Lighting Interior Wall Luminaire 693 Series User manual

Cooper Lighting

Cooper Lighting Interior Wall Luminaire 693 Series User manual

Cooper Lighting 850 User manual

Cooper Lighting

Cooper Lighting 850 User manual

Cooper Lighting Portfolio 841 User manual

Cooper Lighting

Cooper Lighting Portfolio 841 User manual

Cooper Lighting Metalux 2HB65 User manual

Cooper Lighting

Cooper Lighting Metalux 2HB65 User manual

Cooper Lighting PORTFOLIO 844 User manual

Cooper Lighting

Cooper Lighting PORTFOLIO 844 User manual

Cooper Lighting Lumiere Boca 605 User manual

Cooper Lighting

Cooper Lighting Lumiere Boca 605 User manual

Cooper Lighting 1487 User manual

Cooper Lighting

Cooper Lighting 1487 User manual

Cooper Lighting Shaper 420-RP User manual

Cooper Lighting

Cooper Lighting Shaper 420-RP User manual

Popular Indoor Furnishing manuals by other brands

Regency LWMS3015 Assembly instructions

Regency

Regency LWMS3015 Assembly instructions

Furniture of America CM7751C Assembly instructions

Furniture of America

Furniture of America CM7751C Assembly instructions

Safavieh Furniture Estella CNS5731 manual

Safavieh Furniture

Safavieh Furniture Estella CNS5731 manual

PLACES OF STYLE Ovalfuss Assembly instruction

PLACES OF STYLE

PLACES OF STYLE Ovalfuss Assembly instruction

Trasman 1138 Bo1 Assembly manual

Trasman

Trasman 1138 Bo1 Assembly manual

Costway JV10856 manual

Costway

Costway JV10856 manual

moss DESIGN Caisson Credenza Assembly instructions

moss DESIGN

moss DESIGN Caisson Credenza Assembly instructions

Aquaglide FULL DECK 15.0 owner's manual

Aquaglide

Aquaglide FULL DECK 15.0 owner's manual

AREBOS AR-HE-SW30 user manual

AREBOS

AREBOS AR-HE-SW30 user manual

Till-Hilft Fulda 87005.330 Assembly instructions

Till-Hilft

Till-Hilft Fulda 87005.330 Assembly instructions

Twoey Outside 2010 quick start guide

Twoey Outside

Twoey Outside 2010 quick start guide

Hettich Easys 200 operating instructions

Hettich

Hettich Easys 200 operating instructions

The bedboss RELAX 404 Series owner's manual

The bedboss

The bedboss RELAX 404 Series owner's manual

Oeseder Möbelindustrie Bern 991 720 Assembly instructions

Oeseder Möbelindustrie

Oeseder Möbelindustrie Bern 991 720 Assembly instructions

Costway HW68469 user manual

Costway

Costway HW68469 user manual

Next ALIX A27743 Assembly instructions

Next

Next ALIX A27743 Assembly instructions

BROSA Hans Assembly guide

BROSA

BROSA Hans Assembly guide

Prodigg MINIKA PBA015T-FUR installation manual

Prodigg

Prodigg MINIKA PBA015T-FUR installation manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.

271 SERIES
Surface Luminaire
"Craftsman"
Luminous Square
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
271 "Craftsman" Luminous Square features direct/indirect
illumination and is available in two sizes.
SPECIFICATION FEATURES
Material
Painted and plated cold rolled
steel, stainless steel or solid
bronze with matte white acrylic
panels.
Finish (Frame and Mounting
Pan)
Standard: Matte White (MW) or
Matte Black (MB).
Premium: Hand Oxidized Bronze
(OBZ), Satin Stainless Steel
(SSS), Satin Brass (SB), Satin
Bronze (SBZ) or Custom Color
(CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
14":Two (2)13W (2GX7) 4-pin low
wattage CFL lamps or two (2)
26W (GX24q-3) 4-pin quad CFL
lamps or two (2) 60W A-19
lamps.
18":Two (2) 26W (GX24q-3) 4-pin
quad CFL lamps or two (2) 75W
A-19 lamps. CFL socket injection
molded plastic. INC socket fired
ceramic rated for 660W-250V.
Lamps furnished by others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Hand Painted Faux Alabaster
Panels (FP), Hand Painted Faux
Linen Panels (LNP), CFL
Dimming Ballast - Contact the
factory for ballast options (DM),
Mica Side Panels (MSP), 4 Panel
(4P), 5 Panel with DoubleTrim
Bars (5P2TB), Opal Glass (OG),
Modified Integral Emergency
Battery (MEM), Damp Location
(DL): All Painted Finishes only.
Energy Star Rating - Consult
Factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
ADS042713
2008-09-05 10:47:18
Sample Number: 271-18-INC/2/75-120V-SBZ
Voltage
120V
277V 3
347V 3
Finish
Standard
MB Matte Black=
MW Matte White=
Premium
CC Custom Color=
OBZ Hand Oxidized
Bronze
=
SB Satin Brass=
SBZ Satin Bronze=
SSS Satin Stainless
Steel
=
Options
4P Four Panel
=
5P2TB 5 Panel w/
=
DL Damp Location=
DM CFL Dimming Ballast 4
5
=
MEM Modified Integral
Emergency Battery
=
OG Opal Glass=
FP Hand Painted Faux
Alabaster Panels
=
MSP Mica Side Panels=
LNP Hand Painted Faux
Linen Panels
=
Series
271 Craftmen
Square
Surface
=
Size
14"
18"
Lamp
CFL/2/13 1
CFL/2/26
INC/2/60 1
INC/2/75 2
1Available in 14".
Notes:
2Available in 18".
3Available with CFL only.
4C
5Interior use only.
onsult the factory for
available options.
Double Trim Bars
ORDERING INFORMATION
Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax 510.234.2371
240 440 472
607 640 672-WP
COMPANION PRODUCTS
18" SQ.
271 - 18" SQ. STANDARD
5"
7"
8" SQ.
271 TRIM OPTIONS
MODIFIED INTEGRAL
EMERGENCY BATTERY (MEM)
5 PANEL WITH DOUBLE
TRIM BARS (5P2TB)
4 PANEL (4P)
14" SQ.
271 - 14" SQ. STANDARD
6" 4"
8" SQ.
5"
2"
7"
13"
DIMENSIONS
ADS042713
2008-09-05 10:47:18
271 SERIES SURFACE LUMINAIRE
