Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
498-RP features a 24" Luminous Hand Crafted Textured Glass Pendant
designed for low ceiling applications with C82428350 horizontal downlight
Pendant: 24" Dia. textured bowl,
hand-crafted, Kokomo art glass.
Hand fused to an opaque white
glass for structure and lamp
uniformity. Solid brass, cold-rolled
steel or aluminum cable and bowl
finials. Solid aluminum mounting
ring and hardware with cable with
four aircraft cable attachments.
Downlight: Portfolio(TM) one piece
precision die cast aluminum 1-1/2"
deep collar accommodates varying
dimensions of ceiling materials.
Precisely formed one piece, clear
Alzak®, non-imaging optical
reflector ensures 55° cut-off to
Standard: Matte White (MW)
Premium: Natural Aluminum (NA)
[Sustainable Design], Lacquered
Satin Aluminum (SAL), Satin
Chrome (SC), Lacquered Satin
Chrome (SCL), Polished Chrome
(PC), Satin Nickel (SN), Lacquered
Satin Nickel (SNL), Polished Nickel
(PN), Oxidized Brass (OBRS), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Oxidized Copper
Gun Metal (GNM) or Custom
Colors (CC). Contact factory for
Glass Colors: Textured Warm
White Glass (WG) or Textured
Refer to www.shaperlighting.com
for complete photometrics.
One (1) integral, multi-voltage
(120V/277V), electronic CFL (347V
Canada) ballast for a 26W, 32W or
42W CFL lamps. Provides flicker
free and noise free operation and
Two (2) 26W, 32W (GX24q-3) or
42W (GX24q-4) 4-pin triple CFL
lamps. Universal 4-pin CFL socket
injection molded plastic with
fatigue free stainless steel lamp
spring ensures positive lamp
retention. Lamps furnished by
Decorative trim/finial/bowl
assembly is securely suspended
from the mounting ring by four
stainless steel cables (provided).
Listed for eight #12AWG (four in,
four out) 90°C conductors feed
through branch wiring. One 1/2"
and two 3/4" pry outs. Positioned
to allow straight conduit runs.
Access to junction box by
removing reflector. Accepts 1/2"
EMT, C Channel, T-bar fasteners,
and bar hangers. Adjusts 5" ver-
tically from above or below ceiling.
Positive reflector mounting,
without tools, pulls trim tight to
ceiling. No measuring, cutting or
adjustment of cables is required to
achieve standard overall height
and level mounting. Contractor to
provide appropriate structural
support for the fixture's weight.
Refer to the downlight spec sheet
for options, MH Lamping - Contact
U.L. and C.U.L. listed. Downlight is
Contact factory regarding scale
options, unique finishes,
mounting, additional materials/
colors, or decorative detailing.
Recessed Pendant Luminaire
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Sample Number: 498-RP-CFL/2-120V-SC-SC-WG
Trim/Hardware Finish
Standard
MW Matte White=
Premium
CC Custom Color=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered Satin Nickel=
Glass Color
WG = Textured
Warm White
Glass
CG = Textured
Carmel Swirl
Glass
Voltage
120V
277V
347V
Series
498-RP 24"
Pendant
=
Lamp
OCP = Oxidized Copper
OBRS Oxidized Brass
=
PN Polished Nickel
=
SAL Lacquered Aluminum=
NA Natural Aluminum=
GNM= Gun Metal
Finish/Trim/Finial
Standard
MW Matte White=
Premium
CC Custom Color=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered Satin Nickel=
OCP = Oxidized Copper
OBRS Oxidized Brass
=
PN Polished Nickel
=
SAL Lacquered Aluminum=
NA Natural Aluminum=
GNM= Gun Metal
CFL/2 (26/32/42W-Triple)
