INDUSTRIAL & HAZARDOUS LOCATION Exit Lights
COOPER LIGHTING
COOPER LIGHTING - SURE-LITES®
DIMENSIONS
DESCRIPTION
The Sure-Lites UX NEMA 4X Exit combines the strength and
durability of die cast aluminum with architecturally pleasing
aesthetics. Designed for the most severe environments, the UX
exit will provide maximum performance against rain, moisture,
cold, corrosives and dust. Universal configurations (single and
double face) and universal mounting provide the ease of one
product specifying for any job. Additional designed-in features
such as LED technology provide the customer with a long life,
low maintenance, dependable exit sign in those conditions
when reliability is crucial. The injection molded, clear,
polycarbonate shield not only provides protection against
moisture and rain, but vandalism as well. (4) Torx®head
tamperproof screws with center-pin reject provide additional
vandal-proof security. The unique design and features make the
UX Exit compatible in food processing facilities, outdoor
parking garages, walk-in freezers and other indoor/outdoor
severe environments. The UX Exit is approved for ambient
environments rated from -45°C (-49°F) up to +60°C (+140°F).
• NEMA 4X Listed
• Operating temperature
-45°C (-49°F) to 60°C (+140°F)
• Dual voltage input 120/277
VAC, 60Hz Isolation
Transformer
• Die Cast aluminum housing
• Powder coat finish
• LED Lamping
• Exit can be universally
mounted ceiling, wall or end
• Universal pattern knockouts
on rear of single face housing
for direct mounting to junction
box
• Pendant Mount
• Watchguard EMS
Self-diagnostic system
• Laser Testing
• Premium Nickel Cadmium
batteries
• T6 HAZ lamp rating
• IP66, Ingress Protection from
IEC (International Electrical
Commission)
• UL844, Hazardous Locations
(Class 1, Division 2, Groups A,
B, C, D) with “HAZ” option
• UL FTBR Listed when specified
with the “2C” option
• Suitable for Floor Proximity
Installation, UL Listed, ADA
(American Disabilities Act)
• NSF National Sanitation
Foundation / Splash Zone
(for Food Processing)
• Cleanrooms Class 10,000
• UL 924, UL 924 Wet Location
(Suitable for wet and damp
locations), NEC/OSHA, Life
Safety NFPA 101, Meets most
state and local codes
• Patents Pending
UX SERIES
Ultimate Exit
AC Only
Self-Powered
EXIT LIGHTING
5.50
13.72
3.80
2.13
8.35
0.88
5.50
9.21
ORDERING INFORMATION
SAMPLE NUMBER: UX61R
Family
UX=Nema
4X Exit
Series
6=AC Only, LED
7=Self-powered
Face Options
0=Universal (single and
double face)(1)
1=Single Letter Colors
R=Red
G=Green
Housing
Finishes
Blank=Silver
BK=Black
WH=White
SD=Self-
Diagnostics
(Standard
for UX7
only)
Accessories (Order Separately)
UXUK=Converts single face exit to
double face exit. Contains (1) red lens,
(1) green lens, (1) Standard Silver Exit
Stencil, (1) Vandal Shield &
Tamperproof Screws
UXUKWH=Converts single face exit to
double face exit. Contains (1) red lens,
(1) green lens, (1) White Exit Stencil,
(1) Vandal Shield & Tamperproof
Screws
UXUKBK=Converts single face exit to
double face exit. Contains (1) red lens,
(1) green lens, (1) Black Exit Stencil,
(1) Vandal Shield & Tamperproof
Screws
UXPKA=Pendant Kit Adapter (fitting
adapts exit to 1/2" NPT threaded
pendant "supplied by others")
VRSD=Vandal Resistant Screwdriver
LASER=Key Chain, Laser pointer (UX7
only), (activated at 30 ft.)
(1) Contains one single face exit and one UXUK.
Factory
Options
95=AC Only
Fire
Alarm
Interface
90=DC Only
Fire
Alarm
Interface
Options
2C=Two Circuit
Operation,
FTBR
HAZ=Hazardous
Locations
(Class 1,
Division 2,
Groups A,
B, C, D)
(Both can
be ordered)
Energy Data — AC Only Exits
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 120V 277V 120V 277V 120V 277V
LED Exits
LED Exits -Red Letters 2.7W 3.2W .07A .04A > .30 > .39 < 56% < 69%
LED Exits -Green Letters 2.3W 3.0W .08A .03A > .26 > .36 < 54% < 67%
Self-Diagnostics
The self-diagnostic unit will automatically
perform all tests required by UL924 and
NFPA 101. The system indicates the status of
the unit at all times using the LED indicator
near the test switch on the side of the unit. A
90 minute battery power (emergency mode)
simulation test will occur randomly once
every six months.
A 30 second battery power simulation test
will occur every 30 days.
SPLASH ZONE
-49°F to +140°F
