Cooper Lighting Sure-Lites CAX Series User manual

634
EXIT LIGHTING Architectural
COOPER LIGHTING
COOPER LIGHTING - SURE-LITES®
DIMENSIONS
• 120 VAC or 277 VAC Input
wattage
• Die cast aluminum
housing with hinged face
plate and die cast canopy
for ceiling or end
mounting
• Screw-In LED Lamps: two
1W long life T6 1/2
intermediate base lamps
• Universal pattern
knockouts on rear of single
face housing for direct
mounting to junction box
• NFPA 101 compliant
knockout chevrons allow
quick conversion to
directional signs
• Damp Location Listed
(except exits with “2C”
Option), UL 924 Listed, Life
Safety NFPA 101, CSA
certified, NEC/OSHA, UL
FTBR Listed (consult your
Cooper Lighting
Representative for
applicable fixture types),
most state and local codes
DESCRIPTION
The Sure-Lites Pinnacle Family
of Surface Mounted Die Cast
Aluminum Exits combine
strength, durability and
aesthetics. The pleasing lines
and the range of
architecturally compatible
finishes will add a new
dimension to any design.
Unlike competitive units that
have a pronounced dot effect
from protruding diodes, the
Pinnacle LED offers unequalled
uniform illumination and
brightness.
Energy Data
Input Power: Input Current(Max.): Power Factor: T.H.D.:
120V 277V 347V 120V 277V 347V 120V 277V 120V 277V
Standard Power - LED Exits
Red Letters Single Face 5.6W 5.7W 6.0W .07A .03A .02A >.71 >.71 <36% <36%
Red Letters Double Face 7.3W 7.5W 8.3W .07A .03A .03A >.83 >.83 <33% <34%
Green Letters Single Face 6.7W 6.8W 6.8W .07A .03A .02A >.79 >.79 <30% <31%
Green Letters Double Face 9.5W 9.7W 9.9W .09A .04A .03A >.90 >.90 <26% <27%
LED Lite-Stix™ Screw-In Lamps
Red Letters 2.0W 4.3W .09A .03A >.19 >.58 <19% <22%
1 1/4" (32mm)
2 5/8" (67mm) (277V)
(conversion kit)
4 1/4" (108mm)
2 1/4"
(57mm)
8 1/4"
(210mm)
13 5/8" (346mm)
6 1/4" (159mm)
8 1/4" (210mm) (277V)(conversion kit)
5 3/4" (146mm) (277V)(conversion kit)
Family
CAX=Die Cast
Aluminum Exit
Surface Mount
Series
6=AC Only,LED
Face Options
1=Single
2=Double
Battery
00=No Battery
Factory
Options
00=No Options
65=Tamperproof Screws
85=Vandal Shield
Letter Colors
R=Red
G=Green
Housing
Finishes
Blank=Brushed
Aluminum
Face with
Black
Housing
W=White
B=Black
BZ=Bronze
Voltage
Blank=120/277V
47=120/347V
ORDERING INFORMATION- LED LAMP EXITS
SAMPLE NUMBER: CAX610065RB
ORDERING INFORMATION-SCREW-IN LED EXITS
SAMPLE NUMBER: CAX1LEDACR
Factory Options
2C= Two Circuit Operation
Accessories (Order Separately)
Screwdrivers
059012SP=Tamperproof Screwdriver Bit
VRSD=Vandal Resistant Screwdriver
WG10=Surface, Mount Wire Guard
WGS11=Ceiling, End Mount Wire Guard
VS1=polycarbonate vandal shield
Pendant Kits
CAX18PK=Pendant Kit, white
CAX18PKHT=”Hang-true” Pendant Kit,
white
Family
CAX=Die Cast
Aluminum Exit
Surface Mount
Face Options
1=Single
2=Double
Factory
Options
65=Tamperproof
Screws
85=Vandal Shield
95=AC Only Fire
Alarm Interface
Lamp Type
LED=LED Lite Stix™
Screw-in LED Lamps
Emergency Operation
AC=AC Only
Letter Color
R=Red
Housing Finishes
Blank=Brushed Aluminum
Face with Black Housing
W=White
B=Black
BZ=Bronze
Voltage
Blank=120V
77=277V
Accessories (Order Separately)
DC Socket Kit
PDC6=Two 6V, 3.6W DC lamps
PDC12=Two 12V, 3.6W DC lamps
Emergency Power Pack
CAX3PP=Black
CAX3PPW=White
CAX3PPBZ=Bronze
277V Conversion Kit
AD277CAX=Black
AD277CAXW=White
AD277CAXBZ=Bronze
Vandal Resistant Screwdrivers
059012SP=Tamperproof
Screwdriver Bit
VRSD=Vandal Resistant Screwdriver
WG10=Surface, Mount Wire Guard
WGS11=Ceiling, End Mount Wire Guard
VS1=Polycarbonate Vandal Shield
CAX SERIES
AC Only
LED Lamping
EXIT LIGHTING
CAX
CAX

635
EXIT LIGHTING Architectural
COOPER LIGHTING - SURE-LITES®
DIMENSIONS
Energy Data
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 120V 277V 120V 277V 120V 277V
Incandescent Exits
Incandescent Exits 4.0W 4.2W .33A .16A - - - -
Fluorescent Exits
Fluorescent Exits - 5W Lamps14W 21W .29A .32A >.40 >.24 <14% <11%
Fluorescent Exits - 7W Lamps15W 23W .25A .30A >.50 >.27 <16% <12%
1 1/4" (32mm)
2 5/8" (67mm) (277V)
(conversion kit)
4 1/4" (108mm)
2 1/4"
(57mm)
8 1/4"
(210mm)
13 5/8" (346mm)
6 1/4" (159mm)
8 1/4" (210mm) (277V)(conversion kit)
5 3/4" (146mm) (277V)(conversion kit)
Family
CAX=Die Cast
Aluminum Exit
Series
2=AC Only, Incandescent
4=AC Only, Fluorescent
Face Options
1=Single
2=Double
Battery
00=No Battery
Factory
Options
00=No Options
65=Tamperproof Screws
85=Vandal Shield
95=AC Only Fire Alarm (2)
Interface
Letter Colors
R=Red
G=Green
RWO=Red on White (1)
GWO=Green on White (1)
WRO=White on Red (1)
WGO=White on Green (1)
O=Open Face (1)
Housing
Finishes
Blank=Brushed
Aluminum
Face with
Black
Housing
W=White
B=Black
BZ=Bronze
Voltage
Blank=120V
77=277V
ORDERING INFORMATION-INCANDESCENT, FLUORESCENT LAMP EXITS
SAMPLE NUMBER: CAX410065RB
Notes: AC compact fluorescent CAX Series Exits cannot be converted to self-powered emergency.
(1)RWO, GWO, WRO, and WGO are open face styles with “EXIT” legend. Use “O” option for ordering special wording-lenses ordered
separately (consult Cooper Lighting Representative). (2) AC Only Fire Alarm Interface Option available on incandescent lamp exits only.
Factory Options
2C= Two Circuit Operation
Accessories (Order Separately)
DC Socket Kit (Incandescent only)
PDC6=Two 6V, 3.6W DC lamps
PDC12=Two 12V, 3.6W DC lamps
Emergency Power Pack
(Incandescent Only)
CAX3PP=Black
CAX3PPW=White
CAX3PPBZ=Bronze
277V Conversion Kit
AD277CAX=Black
AD277CAXW=White
AD277CAXBZ=Bronze
Screwdrivers
0590-12SP=Tamperproof Screwdriver Bit
VRSD=Vandal Resistant Screwdriver
Wire Guard
WG1=Surface, Wire Guard
WGS11=Ceiling, End Wire Guard
VS1=Polycarbonate Vandal Shield
Pendant Kits
CAX18PK=Pendant Kit, white
CAX18PKHT=”Hang-true” Pendant Kit, white
• 120 VAC or 277 VAC
input voltage
• Die cast aluminum housing
with hinged face plate and
die-cast canopy for ceiling
or end mounting
• AC incandescent: two 20W
T6 1/2 intermediate base
lamps
• AC fluorescent: two 5W
F5TT compact fluorescent
lamps
• Universal pattern
knockouts on rear of single
face housing for direct
mounting to junction box
• NFPA 101 compliant
knockout chevrons allow
quick conversion to
directional signs
• Stencil and open face
signs available
• Downlight diffuser
• Damp Location Listed, UL
924 Listed, Life Safety
NFPA 101, CSA certified,
NEC/OSHA, UL FTBR Listed
(consult your Cooper
Lighting Representative for
applicable fixture types),
most state and local codes
DESCRIPTION
The Sure-Lites Pinnacle
Family of Surface Mounted
Die cast Aluminum Exits
combine a strength, durability
and aesthetics. The pleasing
lines and the range of
architecturally compatible
finishes will add a new
dimension to any design.
CAX SERIES
Die Cast
AC Only
Incandescent, Compact
Fluorescent Lamping
EXIT LIGHTING
CAX
COOPER LIGHTING

636
EXIT SIGNS Architectural
COOPER LIGHTING
COOPER LIGHTING - SURE-LITES®
DIMENSIONS
• Dual-voltage input
120/277VAC, 60Hz
• Die cast Aluminum
housing with hinged
faceplate and die cast
canopy for ceiling or end
mounting
• Screw-in LED lamps: two
1W long life T 6 1/2
intermediate base lamps
• Lead Calcium or Premium
Nickel Cadmium battery
• Universal pattern
knockouts on rear of single
face housing for direct
mounting to junction box
• NFPA 101 compliant
knockout chevrons allow
quick conversion to
directional signs
• Line-latching, Solid-State
voltage limited charger,
Solid-State switching, low-
voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator
light
• UL 924 Listed, Life Safety
NFPA 101, CSA certified,
NEC/OSHA, most state
and local codes
2 1/4"
(57mm)
8 1/4"
(210mm)
13 5/8" (346mm)
1 1/4" (32mm)
2 5/8" (67mm) (277V)
(conversion kit)
4 1/4" (108mm)
6" (152mm)
8 1/4" (210mm) (277V)(conversion kit) 5 3/4" (146mm) (277V)
(conversion kit)
Family
CAX=Die Cast Aluminum
Exit Surface Mount
Series
7=Self-Powered LED
Face Options
1=Single
2=Double
Battery
70=Nickel Cadmium
Factory Options
00=No Options
20=DC Flasher
30=DC Flasher/ Buzzer
65=Tamperproof Screws
85=Vandal Shield
90=DC Only Fire Alarm
Interface
Letter Colors
R=Red
G=Green
ORDERING INFORMATION-LED LAMP EXITS
SAMPLE NUMBER: CAX717020R
Wattage Ratings
Lead Calcium Battery=10.8W for 1 1/2 hrs., 7.2W for 2 hrs. Nickel Cadmium Battery=15.0W for 1 1/2 hrs.
Housing Finishes
Blank=Brushed Aluminum
Face with Black Housing
W=White
B=Black
BZ=Bronze
Factory Options
SD=Self Diagnostics
Accessories (Order Separately)
Screwdrivers
0590-12SP=Tamperproof
Screwdriver Bit
VRSD=Vandal Resistant
Screwdriver
VS1=polycarbonate vandal shield
Pendant Kits
CAX18PK=Pendant Kit, white
CAX18PKHT=”Hang-true”
Pendant Kit, white
WG10=Surface
WGS11=Ceiling, end
ORDERING INFORMATION-SCREW-IN LED LAMPS
SAMPLE NUMBER: CAX1LEDSPR
Family
CAX=Die Cast Aluminum
Exit Surface Mount
Face Options
1=Single
2=Double
Battery
Blank=Lead Calcium
70=Nickel Cadmium
Factory Options
Blank=None
20=DC Flasher
30=DC Flasher/ Buzzer
65=Tamperproof Screws
85=Vandal Shield
90=DC Fire Alarm Interface
Emergency Operation
SP=Self-Powered
Letter Color
R=Red
Housing Finishes
Blank=Brushed Aluminum
Face with Black Housing
W=White
B=Black
BZ=Bronze
Factory Options
SD= Self-Diagnostics
Accessories (Order Separately)
059012SP=Tamperproof
Screwdriver Bit
VRSD=Vandal Resistant
Screwdriver
VS1=polycarbonate vandal shield
Pendant Kits
CAX18PK=Pendant Kit, white
CAX18PKHT=”Hang-true”
Pendant Kit, white
WG10=Surface
WGS11=Ceiling, end
Lamp Type
LED=LED Lite Stix™
Screw-in LED Lamps
Voltage
Blank=120V/277V
47=120/347V
DESCRIPTION
The Sure-Lites Pinnacle Family
of Surface Mounted Die cast
Aluminum Exits combine
strength, durability and
aesthetics. The pleasing lines
and the range of architecturally
compatible finishes will add a
new dimension to any design.
CAX SERIES
Die Cast
Self-Powered
LED Lamping
EXIT LIGHTING
Energy Data
Standard Power - Sealed Nickel Cadmium Battery - LED Exits
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 347V 120V 277V 347V 120V 277V 120V 277V
Red Letters Single Face 7.4W 7.5W 7.6W .08A .04A .03A >.72 >.72 <34% <34%
Red Letters Double Face 9.3W 9.5W 9.6W .09A .04A .03A >.84 >.84 <31% <32%
Green Letters Single Face 8.5W 8.7W 8.4W .09A .04A .03A >.79 >.79 <30% <31%
Green Letters Double Face 11.4W 11.7W 11.2W .11A .05A .04A >.90 >.90 <26% <26%
Standard Power with Self Diagnostics Option (Fully Discharged Battery) - LED Exits
Red Letters Single Face 8.4W 8.5W 8.6W .08A .04A .03A >.82 >.82 <31% <31%
Red Letters Double Face 9.8W 9.5W 9.7W .09A .04A .03A >.86 >.84 <30% <30%
Green Letters Single Face 9.1W 9.0W 9.2W .09A .04A .03A >.86 >.85 <27% <27%
Green Letters Double Face 11.2W 10.5W 10.5W .10A .05A .03A >.90 >.88 <25% <26%
Standby Mode (Fully Charged Battery) Sealed Nickel Cadmium Battery Input Power consumption is reduced by approximately 1.5 Watts
Self Diagnostic Option with Low Power Option (Operating in Low Power Mode) (Fully Discharged Battery) - LED Exits
Red Letters Single Face 6.5W 6.7W .07A .03A >.75 >.72 <37% <37%
Red Letters Double Face 7.8W 8.1W .08A .04A >.80 >.80 <33% <33%
Standby Mode (Fully Charged Battery) Sealed Nickel Cadmium Battery Input Power consumption is reduced by approximately 4 Watts
Charge Mode, Fully Discharged Battery): Sealed Lead Calcium Battery Screw-in LED Lamps
Red Letters 16.6W 17.5W .15A .07A >.90 >.91 <28% <28%
Standby Mode (Fully Charged Battery) Sealed Nickel Cadmium Battery Input Power consumption is reduced by approximately 10 Watts in
the standby operating mode
Sealed Nickel Cadmium Battery: Screw-in LED Lamps
Red Letters 8.4W 8.3W .08A .03A >.92 >.92 <35% <34%
CAX

DIMENSIONS
• Dual-voltage input
120/277VAC, 60Hz
• Die cast aluminum housing
with hinged faceplate and
die-cast canopy for ceiling
or end mounting
• AC incandescent: two 20W
T6 1/2 intermediate base
lamps
• AC fluorescent: two 5W
F5TT compact fluorescent
lamps
• Lead Calcium or Premium
Nickel Cadmium battery
• Universal pattern
knockouts on rear of single
face housing for direct
mounting to junction box
• NFPA 101 compliant
knockout chevrons allow
quick conversion to
directional signs
• Stencil and open face
signs available
• Downlight diffuser
• Line-latching, Solid-State
voltage limited charger,
Solid-State switching,
low-voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator
light
• UL 924 Listed, Life Safety
NFPA 101, CSA Certified,
NEC/OSHA, UL FTBR
Listed, most state and
local codes
DESCRIPTION
The Sure-Lites Pinnacle Family
of Surface Mounted Die Cast
Aluminum Exits combine
strength, durability and
aesthetics. The pleasing lines
and the range of architecturally
compatible finishes will add a
new dimension to any design.
8 1/4" (210mm)
2 5/8" (67mm)
(146mm)
5 3/4"
2 1/4"
(57mm)
8 1/4"
(210mm)
13 5/8" (346mm)
Family
CAX=Die Cast Aluminum
Exit Surface Mount
Series
3=Self-Powered, Incandescent
5=Self-Powered, Fluorescent
Face Options
1=Single
2=Double
Battery
00=Lead Calcium
70=Nickel Cadmium
Factory Options
00=No Options
20=DC Flasher (1)
30=DC Flasher/ Buzzer (1)
65=Tamperproof Screws
85=Vandal Shield
90=DC Only Fire Alarm (1)
Interface
Letter Colors
R=Red
G=Green
RWO=Red on White (2)
GWO=Green on White (2)
WRO=White on Red (2)
WGO=White on Green (2)
O=Open Face (2)
ORDERING INFORMATION-INCANDESCENT, FLUORESCENT EXITS
SAMPLE NUMBER: CAX310085R
(1)DC Flasher, DC Flasher/Buzzer and DC Fire Alarm Interface options available with Incandescent exits only.(2) RWO, GWO, WRO, and WGO
are open face styles with “Exit” legend. Use “O” option for ordering special wording-lenses ordered separately (consult Cooper Lighting
Representative).
Wattage Ratings
Lead Calcium Battery=10.8W for 1 1/2 hrs., 7.2W for 2 hrs. Nickel Cadmium Battery=15.0W for 1 1/2 hrs.
Energy Data
Charge Mode (Fully Discharged Battery): Sealed Lead Calcium Battery
Input Power: Input Current (Max.): Power Factor: T.H.D.:
120V 277V 120V 277V 120V 277V 120V 277V
Incandescent Exits-20W Lamps 53W 51W .45A .19A >.99 >.98 <9% <10%
Fluorescent Exits-5W Lamps 29W 30W .40A .16A >.61 >.66 <12% <11%
Standby Mode (Fully Charged Battery) Sealed Lead Calcium Battery Input Power consumption is reduced by approximately 12 Watts in the
standby operating mode
Sealed Nickel Cadmium Battery
Incandescent Exits-20W Lamps 45W 43W .38A .16A >.99 >.99 <7% <7%
Fluorescent Exits - 5W Lamps 20W 21W .36A .15A >.48 >.52 <15% <14%
Housing Finishes
Blank=Brushed Aluminum
Face with Black Housing
W=White
B=Black
BZ=Bronze
Voltage
Blank=120V/277V
Factory Options
SD=Self-Diagnostic
(Incandescent Only)
Accessories (Order Separately)
Screwdrivers
059012SP=Tamperproof
Screwdriver Bit
VRSD=Vandal Resistant
Screwdriver
Wire Guard
WG1=Surface, Wire Guard
WGS11=Ceiling, End Wire
Guard
VS1=Polycarbonate Vandal
Shield
Pendant Kits
CAX18PK=Pendant Kit, white
CAX18PKHT=”Hang-true”
Pendant Kit, white
CAX SERIES
Die Cast
Self-Powered
Incandescent, Compact
Fluorescent Lamping
EXIT LIGHTING
637
EXIT SIGNS Architectural
COOPER LIGHTING
COOPER LIGHTING - SURE-LITES®
CAX
