BOLLARDS
1046
LUMIERE®
COOPER LIGHTING
`
MODEL
1900-AA Adjustable
aperture
FINISH
Painted
BK
BZ
CS
VE
WT
Black
Bronze
City silver
Verde
White
FINISH
Painted
BK
BZ
CS
VE
WT
Black
Bronze
City silver
Verde
White
FINISH
Painted
BK
BZ
CS
VE
WT
Black
Bronze
City silver
Verde
White
OPTIONS
EL
IT
To ship anchor bolt/template kit in advance
LAB
Electronic HID ballast
(120/277V) in lieu of core
& coil
Integral transformer for
12V MR16 source
See "Accessories & Technical
Data" section of catalog for
remote transformers
Less anchor bolts &
template (order kit
separately - 7048PK)
VOLTS
120, 208
240, 277
347
120/12
277/12
FEATURES
• Includes anchor bolts & template
• Adjustable aperture w/ locking mechanism
• Patented LumaLevel™ mounting/leveling system
• Machined aluminum housing, cast base
• Stainless steel hardware
• UL / cUL listed
• Three (3) year warranty
FEATURES
• Includes anchor bolts & template
• Open (fixed) aperture
• Patented LumaLevel™ mounting/leveling system
• Machined aluminum housing, cast base
• Stainless steel hardware
• UL / cUL listed
• Three (3) year warranty
FEATURES
• Includes anchor bolts & template
• Low glare internal lens louver
• Patented LumaLevel™ mounting/leveling system
• Machined aluminum housing, cast base
• Stainless steel hardware
• UL / cUL listed
• Three (3) year warranty
SOURCE
Metal Halide
MH39PAR20
Includes integral core & coil ballast. Lamp not included.
Halogen
50MR16
12V remote or integral transformer required - not included
Lamp not included
39W / PAR20 / medium
50W / MR16 / GU5.3
SIZE
24
30
MODEL
1900-OA Open aperture
VOLTS
120, 208
240, 277
347
120/12
277/12
SOURCE
Metal Halide
MH39PAR20
Includes integral core & coil ballast. Lamp not included.
Halogen
50MR16
12V remote or integral transformer required - not included
Lamp not included
39W / PAR20 / medium
50W / MR16 / GU5.3
SIZE
24
30
MODEL
1900-IL Internal louver
VOLTS
120, 208
240, 277
SOURCE
Compact Fluorescent
CF42
Includes integral universal electronic ballast (120-277V)
Lamp not included
26W, 32W, or 42W / triple tube / universal GX24q
SIZE
24
30
ASPEN 1900-AA
39W (max) PAR20 Metal Halide
50W (max) MR16 Halogen
Low Voltage (12V)
ASPEN 1900-OA
39W (max) PAR20 Metal Halide
50W (max) MR16 Halogen
Low Voltage (12V)
ASPEN 1900-IL
42W (max)
Compact Fluorescent
Line Voltage
SAMPLE NUMBER: 1900-AA-24-MH39PAR20-120-BK
SAMPLE NUMBER: 1900-OA-24-MH39PAR20-120-BK
SAMPLE NUMBER: 1900-IL-24-CF42-120-BK
OPTIONS
EL
IT
To ship anchor bolt/template kit in advance
LAB
Electronic HID ballast
(120/277V) in lieu of core
& coil
Integral transformer for
12V MR16 source
See "Accessories & Technical
Data" section of catalog for
remote transformers
Less anchor bolts &
template (order kit
separately - 7048PK)
OPTIONS
To ship anchor bolt/template kit in advance
LAB Less anchor bolts &
template (order kit
separately - 7048PK)
