DESCRIPTION
ARMS SPECIFICATIONS
Pole mount arms are designed to fit both medium EMM/ECM and large
EML/ECL series housings. Arms feature a precision welded cast
aluminum mounting hub for attachment of fixture head to arm with
four (4) stainless steel fasteners. Wall mount arms compliment pole
mount luminaires and attractively transition fixture scale in lower
mounting height pedestrian environments. Wall mount arms are
designed to fit both medium EMM/ECM and large EML/ECL series
housings. Arms feature a precision welded cast aluminum mounting
hub for attachment of fixture head to arm with four (4) stainless steel
fasteners.
BISHOP SINGLE POLE
MOUNT ARM
[VA6105, VA6154, VA6005,
VA6054] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 24 lbs. E.P.A: .92
BISHOP SINGLE POLE MOUNT
ARM WITH CROSS ROD
[VA6106, VA6155, VA6006,
VA6055] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 25 lbs. E.P.A: .98
BISHOP TWIN POLE MOUNT
ARM
[VA6107, VA6156, VA6007,
VA6056] Slipfits over 4" round
straight pole, or 4" O.D. by 6"
tall tenon.
Weight: 37 lbs. E.P.A: 1.43
Radius
12''
[304 mm]
54 3/16''
[1376 mm]
33 1/2" [852 mm]
2''
[51 mm]
Radius
12''
[304 mm]
54 3/16''
[1376 mm]
33 1/2" [852 mm]
2''
[51 mm]
Radius
12''
[304 mm]
62" [1575 mm]
54 3/16''
[1376 mm]
2''
[51 mm]
BISHOP TWIN POLE MOUNT
ARM WITH CROSS RODS
[VA6108, VA6157, VA6008,
VA6057] Slipfits over 4" round
straight pole, or 4" O.D. by 6"
tall tenon.
Weight: 39 lbs. E.P.A: 1.55
TRADITIONAL SINGLE POLE
MOUNT ARM
[VA6109, VA6158, VA6009,
VA6058] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 20 lbs. E.P.A: .86
TRADITIONAL SINGLE POLE
MOUNT ARM WITH ROUNDED
UPPER BAR
[VA6110, VA6159, VA6010, VA6059]
Slipfits over 4" round straight pole,
or 4" O.D. by 6" tall tenon.
Weight: 28 lbs. E.P.A: 1.4
Radius
12''
[304 mm] 54 3/16''
[1376 mm]
62" [1575 mm]
2''
[51 mm]
18 7/8"
[480 mm]
30 15/16" [786 mm]
26 3/4" [679 mm]
35 7/8"
[911 mm]
30 15/16" [786 mm]
26 3/4" [679 mm]
TRADITIONAL SINGLE POLE
MOUNT ARM WITH ROUNDED
LOWER BAR
[VA6111, VA6160, VA6011,
VA6060] Slipfits over 4" round
straight pole only.
Weight: 25 lbs. E.P.A: 1.16
TRADITIONAL SINGLE POLE
MOUNT ARM WITH 45°
UPPER BAR
[VA6112, VA6161, VA6012,
VA6061] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 28 lbs. E.P.A: 1.38
TRADITIONAL SINGLE POLE MOUNT
ARM WITH 45° LOWER BAR
[VA6113, VA6162, VA6013, VA6062]
Slipfits over 4" round straight pole only.
Weight: 25 lbs. E.P.A: 1.14
35 7/16"
[900 mm]
18 7/8"
[480 mm]
30 15/16" [786 mm]
26 3/4" [679 mm]
35 7/8"
[911 mm]
30 15/16" [786 mm]
26 3/4" [679 mm]
35 7/16"
[900 mm]
18 7/8"
[480 mm]
30 15/16" [786 mm]
26 3/4" [679 mm]
EPIC
COLLECTION
MEDIUM AND
LARGE ARM
SPECIFICATIONS

AVU070422
INVUE • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]
EPIC ARMS
ARMS SPECIFICAITONS (CON’T.)
TRADITIONAL SINGLE POLE
MOUNT ARM WITH 45°
UPPER STRAP
[VA6114, VA6163, VA6014,
VA6063] Slipfits over 4" round
straight pole, or 4" O.D. by 6"
tall tenon.
Weight: 24 lbs. E.P.A: 1.17
TRADITIONAL TWIN POLE
MOUNT ARM
[VA6116, VA6165, VA6016,
VA6065] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 30 lbs. E.P.A: 1.44
TRADITIONAL TWIN POLE
MOUNT ARM WITH
ROUNDED UPPER BARS
[VA6117, VA6166, VA6017,
VA6066] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 43 lbs. E.P.A: 2.28
35 7/16 "
[900 mm]
57" [1448 mm]
26 3/4" [679 mm]
57" [1448 mm]
53 1/2" [1359 mm]
26 3/4" [679 mm]
18 7/8"
[480 mm]
35 7/16 "
[900 mm]
57" [1448 mm]
53 1/2" [1359 mm]
26 3/4" [679 mm]
TRADITIONAL TWIN POLE
MOUNT ARM WITH
ROUNDED LOWER BARS
[VA6118, VA6167, VA6018,
VA6067] Slipfits over 4" round
straight pole only.
Weight: 40 lbs. E.P.A: 2.04
35 7/16 "
[900 mm]
18 7/8"
[480 mm]
57" [1448 mm]
53 1/2" [1359 mm]
26 3/4" [679 mm]
TRADITIONAL TWIN POLE
MOUNT ARM WITH 45°
UPPER BARS
[VA6119, VA6168, VA6019,
VA6068] Slipfits over 4" round
straight pole, or 4" O.D. by 6"
tall tenon.
Weight: 43 lbs. E.P.A: 2.24
TRADITIONAL TWIN POLE
MOUNT ARM WITH 45°
LOWER BARS
[VA6120, VA6169, VA6020,
VA6069] Slipfits over 4" round
straight pole only.
Weight: 40 lbs. E.P.A: 2.0
TRADITIONAL TWIN POLE
MOUNT ARM WITH 45°
UPPER STRAPS
[VA6121, VA6170, VA6021,
VA6070] Slipfits over 4" round
straight pole, or 4" O.D.
by 6" tall tenon.
Weight: 37 lbs. E.P.A: 1.81
35 7/16 "
[900 mm]
57" [1448 mm]
53 1/2" [1359 mm]
26 3/4" [679 mm]
35 7/16"
[900 mm]
18 7/8"
[480 mm]
57" [1448 mm]
53 1/2" [1359 mm]
26 3/4" [679 mm]
35 7/16 "
[900 mm]
57" [1448 mm]
53 1/2" [1359 mm]
26 3/4" [679 mm]
BISHOP WALL MOUNT ARM
[VA6101, VA6150, VA6001,
VA6050] Mounts to wall with
four (4) stainless steel lag
bolts (provided by other).
Weight: 16 lbs.
BISHOP WALL MOUNT ARM
WITH CROSS ROD
[VA6102, VA6151, VA6002,
VA6051] Mounts to wall with
four (4) stainless steel lag
bolts (provided by other).
Weight: 17 lbs.
TRADITIONAL WALL MOUNT
ARM
[VA6103, VA6152, VA6003,
VA6052] Mounts to wall with
four (4) stainless steel lag
bolts (provided by other).
WEIGHT: 17 LBS.
30 5/8" [777 mm]
51 3/8''
[1306 mm]
2''
[51 mm]
Radius
12''
[304 mm]
30 5/8" [777 mm]
51 3
[1306
2''
[51 mm]
Radius
12''
[304 mm]
10 1/2"
[267 mm]
28 1/2" [723 mm]
11
[29
TRADITIONAL WALL MOUNT
ARM WITH 45° STRAP
[VA6104, VA6153, VA6004,
VA6053] Mounts to wall with
four (4) stainless steel
lag bolts (provided by other).
Weight: 18 lbs.
35 7/16"
[900 mm]
28 1/2" [723 mm]
11 3/4"
[298 mm]
MAST ARM ADAPTER
[VA6122, VA6171, VA6022,
VA6071] Secures fixture to
nominal 2" pipe (2 3/8"
horizontal O.D.)
Weight: 4 lbs.
8 3/8"
[211 mm]
8 3/8" [211 mm]
