94 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
NOTE: 1 Small up to 175W. Medium 250 to 400W. Large 1000W. 2Luminous dome available in 250W maximum and designed to fit 5" poles. Luminous units only available in 120 or 277V. 3Medium-base lamp. 4Refer to technical
section for lamp/ballast/voltage compatibility. 570-150W max. 6Segmented optics available on solid top designs and small/medium housings only. Max wattage on small segmented optics is Medium Base 175W. Reduce
jacket lamp required on 400W MH. 7Not available in 1000W. 8Available for small and medium units only. 9Not available in 250 HPS.
STRUCTURAL FRAME
Heavy-duty, die-cast aluminum frame
is the main load-bearing structure for
arm, yoke or spider mountings and
serves as a heat sink for cooler
operation and longer ballast life. Each
optional package seats within frame
for precise photometric repeatability.
HOUSING
Spun-aluminum top is finished in
polyester powder coat enamel. Round
shape reduces EPA and size of poles
required. ANSI wattage/source label.
OPTICAL SYSTEM
Credenza offers a broad selection of
premium performance segmented and
hydroformed optical systems
designed to optimize pole spacings
and curtail spill light.
DOOR
Die-cast aluminum door frame has
concealed hinges and is flush with the
bottom of the housing.
LENS
Thermal shock- and impact- resistant
clear tempered glass.
BALLAST ASSEMBLY
Long life core-and-coil HID ballast is
hard mounted for cooler operation.
Ballast must be mounted in pole for
all luminous domes.
SOCKET
Porcelain screw-shell socket fits
mogul-base HID lamps.
ORDERING INFORMATION
SAMPLE NUMBER: ZAD17MWW3D
ARCHITECTURAL AREA LUMINAIRE
OPTIONS (add as suffix)
1=Single Fused, Internally Mounted (120 or 277V)
2=Double Fused, Internally Mounted (208, 240, or 480V)
WH=White
BK=Black
AP=Grey
DP=Dark Platinum
GM=Graphite Metallic
B=House Side Shield
P=Button Photocontrol
ACCESSORIES (order separately)
MA1001=Wall Bracket for Solid Top Units 8
MA1003=Wall Bracket for Luminous Top Units 9
Z CREDENZA 70-1000W MH/HPS/SMH
AREA
SHIPPING DATA
Approximate Net Weight:
64 lbs. (29 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
OPTIONS +
ACCESSORIES
(See Below)
PRODUCT FAMILY 1
ZAD=Arm Dome
ZSD=Spider Dome
ZYD=Yoke Dome
ZAG=Arm Luminous Dome 2
ZSG=Spider Luminous Dome 2
ZYG=Yoke Luminous Dome 2
LAMP
WATTAGE
70=70W 3
10=100W 3
15=150W 3
17=175W
25=250W
40=400W
91=1000W
LAMP TYPE 4
S=High Pressure Sodium
M=Metal Halide
R=SMH
BALLAST TYPE 4
P=Hi. Reac./HPF
W=CWA
C=CWI
K=10KV CWA 5
VOLTAGE 4
2=120V
0=208V
4=240V
7=277V
8=480V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
DISTRIBUTION 6
1D=Type I MCO 7
2D=Type II MCO
3D=Type III MCO
4D=Type IV MCO
5D=Type V MCO 7
2S=Type II Segmented 7
3S=Type III Segmented 7
4S=Type IV Segmented 7
5S=Type V Segmented 7
SL=Spill Light Eliminator 7
STREETWORKS™IP55 RATED
FIXTURE A B C D
SMALL (in.) 20 1/2 10 1/4 11 6
S (mm) 521 260 279 152
MEDIUM (in.) 24 12 1/8 12 5/8 7 /2
(mm) 610 308 321 191
LARGE (in.) 28 14 1/4 16 9
(mm) 610 362 406 229
B
C
A
Yoke Mount Spider Mount / Arm Mount
D
NOTE: In solid top configuration only.
OPTIONAL COLORS [Standard color is bronze, other finish colors available. Consult your Cooper Lighting representative]
WH
White BK
Black AP
Grey GM
Graphite Metallic
DP
Dark Platinum

STREETWORKS Outdoor Lighting Solutions 95Cooper Lighting
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
Z CREDENZA AREA
ZXD40S3D.IES
400-Watt HPS
50,000-Lumen Lamp
Type III
FOOTCANDLE TABLE
Select mounting height and read across for footcandle values of
each isofootcandle line. Distance in units of Mounting Height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCD E
ZXD40S3D.IES
20' 11.25 4.50 2.25 1.12 0.56
25' 7.20 2.88 1.44 0.72 0.36
30' 5.00 2.00 1.00 0.50 0.25
35' 3.65 1.46 0.73 0.36 0.18
40' 2.80 1.12 0.56 0.28 0.14
ZXD40M3D.IES
20' 11.25 4.50 2.25 1.12 0.56
25' 7.20 2.88 1.44 0.72 0.36
30' 5.00 2.00 1.00 0.50 0.25
35' 3.65 1.46 0.73 0.36 0.18
40' 2.80 1.12 0.56 0.28 0.14
4
3
2
1
0
1
2
3
4 3 2 1 0 1 2 3 4
A B
C
D
E
ZXD40M3D.IES
400-Watt MH
36,000-Lumen Lamp
Type III
4
3
2
1
0
1
2
3
4 3 2 1 0 1 2 3 4
A B D
E
C
MOUNTING CONFIGURATIONS
Spider/Yoke Mount Arm Mount/Wall
Mount Single
Arm Mount 2 @ 180° Arm Mount 3 @ 90° Arm Mount 4 @ 90°
Arm Mount 2 @ 90° Arm Mount 3 @ 120°
DRILLING PATTERN
TYPE “Z”
3/4" [14mm]
dia. hole
5/8" [16mm]
dia. hole (2)
4 7/8" [124mm]
4"
[102mm]
2 4/8" [61mm]
E.P.A. TABLE SINGLE
DRILL PATTERN [W/Arm where applicable] 2 @ 180° 2 @ 90° 3 @ 90° 3 @ 120° 4 @ 90°
SMALL [Arm Mount] “Z” 1.19 2.38 2.38 3.57 3.57 4.165
SMALL [Spider/Yoke Mount] 4" or 5" 1.13 n/a n/a n/a n/a n/a
MEDIUM [Arm Mount] “Z” 1.7 3.4 3.4 5.1 5.1 5.95
MEDIUM [Spider/Yoke Mount] 5" 1.52 n/a n/a n/a n/a n/a
LARGE [Arm Mount] “Z” 2.36 4.72 4.72 7.08 7.08 8.26
LARGE [Spider/Yoke Mount] 6" 2.1 n/a n/a n/a n/a n/a
