90 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
NOTE: 1 Fixture and arm standard color is black. Optional colors available. Consult your Streetworks Representative. 2All lamps are mogul-base. 3Use reduce envelope ED28 Lamp. 4Required for mounting fixtures at 90°
increments.
HOUSING
Heavy wall die-cast aluminum housing
maintains a nominal .120 thickness.
Vision is standard in black. Other
colors available. Consult your
Streetworks Representative. U.L.
Listed and CSA certified. ANSI
wattage/source label.
TOOLLESS ENTRY
Entrance to the housing utilizes a two
point, toolless latch mechanism that
blends into the fixture providing an
unobtrusive, yet secure attachment.
DOOR/LENS
Door is heavy wall die-cast aluminum
with integral insets for concealment of
hinging. Lens is thermal shock- and
impact-resistant clear tempered glass.
GASKETING
Extruded high temperature silicone
gasketing completely seals optical
system from dirt and debris.
REFLECTOR ASSEMBLY
Optional high efficiency segmented or
hydroformed reflectors available in a
range of distributions. Reflector
modules attach to the housing via
toolless fasteners. All reflectors are
field rotatable in 90° increments.
TOOLLESS POWER TRAY
Ballast and related electrical
componentry are mounted to a
reinforced tray with integral handle for
ease of maintenance. Quick electrical
disconnects allow the tray to be
completely removed from the housing
providing ample room for attachment
to the pole. Optional power tray fuse
connections offer a distinct and easy
to maintain alternative to common
inline fuse connections.
MOUNTING
Extruded aluminum arm available in
either 6" or 10" lengths. Integral
guides within arm allow fixture to be
easily secured to the pole or wall
mount plate. 10" arm required for 90°
mounting.
ORDERING INFORMATION
SAMPLE NUMBER: AVM40MWW3S
OPTIONS +
ACCESSORIES
(See Below)
ARCHITECTURAL AREA LUMINAIRE
OPTIONS (add as suffix)
1=Single Fuse (120, 277, or 347V)
2=Double Fuse (208, 240, or 480V)
4=NEMA Twistlock Photocontrol Receptacle
WH=White
BZ=Bronze
AP=Grey
DP=Dark Platinum
GM=Graphite Metallic
B=Terminal Block
H=House Side Shield
M=Metal Oxide Varistors (MOV)
Q=Quartz Standby
V=Vandal Shield
ACCESSORIES (order separately)
MA1050=6" Arm for Square Pole (.50 EPA)
MA1051=10" Arm for Square Pole (1.0 EPA) 4
MA1052=6" Arm for Round Pole (.50 EPA)
MA1053=10" Arm for Round Pole (1.0 EPA) 4
MA1054=Wall Bracket
MA1056=Direct Mounting Kit for Square Pole
MA1057=Direct Mounting Kit for Round Pole
MA1207=Mast Arm Adapter
OA1016=Photocontrol–105V-285V
OA1027=Photocontrol–480V
PRODUCT
FAMILY 1
AVM=Vision
Medium
LAMP
WATTAGE2
10=100W
15=150W
17=175W
20=200W
25=250W
40=400W 3
42=400/250W
LAMP TYPE
M=Metal Halide
S=High Pressure
Sodium
VOLTAGE
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
N=Multi-Tap wired 277V
W=Multi-Tap wired 120V
DISTRIBUTION
2F=Type II Formed
3F=Type III Formed
4F=Type IV Formed
5F=Type V Formed
2S=Type II Segmented
3S=Type III Segmented
4S=Type IV Segmented
5S=Type V Segmented
SL=Spill Light Eliminator
AVM VISION 100-400W MH/HPS
AREA
SHIPPING DATA
Approximate Net Weight:
52 lbs. (23.59 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™
BALLAST TYPE
C=CWI
H=Reac./HPF
K=10KV CW
M=Mag. Reg.
N=HIX/NPF
P=HIX/HPF
R=Reac./NPF
W=CWA
28" [724mm]
17" [432mm]
17"
[432mm]
OPTIONAL COLORS [Other finish colors available. Consult your Cooper Lighting representative]
WH
White BZ
Bronze AP
Grey DP Dark Platinum GM
Graphite Metallic

STREETWORKS Outdoor Lighting Solutions 91Cooper Lighting
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
AVM VISION AREA
FOOTCANDLE TABLE
Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCDE
AVM40M3S.IES
20' 3.00 1.50 0.75 0.30 0.15
25' 2.00 1.00 0.50 0.20 0.10
30' 1.38 0.69 0.34 0.13 0.06
AVM40MSL.IES
20' 4.50 2.25 1.13 0.45 0.23
25' 2.88 1.44 0.72 0.29 0.14
30' 2.00 1.00 0.50 0.20 0.10
ABCD E
4
3
2
1
0
1
2
3
4
4 3 2 1 0 1 2 3 4
4
3
2
1
0
1
2
3
4
4 3 2 1 0 1 2 3 4
ABCD E
AVM40MSL.IES
400-Watt MH
36,000-Lumen Lamp
SLE—Spill Light Eliminator
AVM40M3S.IES
400-Watt MH
36,000-Lumen Lamp
Type III
MOUNTING CONFIGURATIONS
Wall Mount Arm Mount Single Arm Mount 2 @ 180° Arm Mount 2 @ 90° Arm Mount 3 @ 120°
(Round Pole Only)
Arm Mount 4 @ 90°Arm Mount 3 @ 90°
E.P.A. TABLE SINGLE
DRILL PATTERN [W/Arm where applicable] 2 @ 180° 2 @ 90° 3 @ 90° 3 @ 120° 4 @ 90°
AVM “M” 1.6 3.2 3.2 4.5 4.5 5.55
NOTE: 1 Assumes 10" arm for 90° and 120° mounting configurations, 6" for all else.
DRILLING PATTERN
TYPE “M”
3/4'' [20mm]
dia. hole
(2) 5/8'' [16mm]
dia. holes
4 7/8'' [124mm]
2 7/16'' [124mm]
2 11/16''
[69mm]
