124 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
ROADWAY
ACCESSORIES (order separately)
RA1003=Cutoff Visor
OA/RA1013=Photocontrol Shorting Cap
OA/RA1014=120V Photocontrol
OA/RA1016=105V-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1028=Field Installed PCR Kit
OA1215=TufGuard Vandal Shield
OVY LOW-PROFILE DROP PRISMATIC 150-400W MH/HPS/MERCURY
HOUSING
Die-cast aluminum housing with
stainless steel bail latch. Standard
grey polyester powder coat finish.
Other finish colors available.
Consult your Streetworks
Representative. Optional NEMA
twistlock photocontrol receptacle
also available.
SOCKET
Adjustable mogul-base porcelain
socket.
DOOR
Die-cast aluminum door frame with
integral hinges for hands free
installation, relamping and
maintenance. ANSI wattage/source
label.
LENS
Removable borosilicate glass
refractor for use with High Pressure
Sodium, Metal Halide and Mercury
lamp sources. Low profile glass
provides 65% less glare than typical
drop lens reflectors.
OPTICAL ASSEMBLY
The optical system is a
hydroformed anodized aluminum
reflector with a Dacron polyester
filter.
BALLAST ASSEMBLY
Hard mounted ballast with
encapsulated starter for protection
from environmental abuse.
Standard two position tunnel type
compression terminal block.
Optional swing-down ballast bridge
also available (Not available for 3G
applications).
MOUNTING
Two-bolt/one bracket slipfitter with
cast-in pipe stop and leveling steps.
Fixed-in-place birdguard seals
around 1 1/4" or 2" mounting arms.
(Birdguard not needed for 2" arm.)
NOTE: 1 150W units are for S55 lamp. 2400W Metal Halide requires ED28 lamp. 3Refer to technical section for lamp/ballast/voltage compatibility. 4Not available in 400W. 5Other distributions & cutoffs available. Consult your
Streetworks Representative. 6MOV option is not available for any system requiring a three position terminal block (Example—240V with PCR wired 120V). In order for MOV option to function center terminal of three
position terminal block must be connected to “Earth” ground.
ROADWAY LUMINAIRE
EPA:
Effective Projective Area: .51
SHIPPING DATA
Approximate Net Weight:
33 lbs. (15 kgs.)
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted (120 or 277V)
2=Double Fuse, Internally Mounted (208, 240, or 480V)
4=Photocontrol Receptacle
WH=White
BK=Black
BZ=Bronze
E=150W/100V/HPS Ballast
H=Plug-in Starter Receptacle
K=Level Indicator
L=Lamp
M=MOV Lightning Surge Protector 6
T=Swing-down Ballast Bridge
U=UL/CSA Listed
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™
ORDERING INFORMATION
SAMPLE NUMBER: OVY15SWW2D4
OPTIONS +
ACCESSORIES
(See Below)
PRODUCT
FAMILY
OVY
LAMP WATTAGE
15=50W 1
20=200W
25=250W
31=310W
40=400W 2
24=250/400
wired 250W 2
42=400/250W
wired 400W 2
LAMP TYPE 3
S=High
Pressure
Sodium
V=Mercury 4
M=Metal Halide
BALLAST TYPE 3
C=CWI
M=Mag. Reg.
W=CWA
R=Reac./NPF
P=Hi. Reac./HPF
H=Reac./HPF
N=Hi. Reac./NPF
K=10KV CWA
VOLTAGE3
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
F=120/240 wired 120V
P=240 w/PCR wired 120V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
DISTRIBUTION 5
2=Type II
3=Type III
4=Type IV
CUTOFF
D=MCO
E=MSCO
J=LNCO
30" [762mm]
9 3/4"
[248mm]
16 15/16" [430mm]
NOTE: In select distributions only.
OPTIONAL COLORS [Standard color is grey, other finish colors available. Consult your Cooper Lighting representative]
WH
White BK
Black BZ
Bronze

STREETWORKS Outdoor Lighting Solutions 125Cooper Lighting
OVY LOW-PROFILE DROP PRISMATIC ROADWAY
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
OVY40S2D.IES
400-Watt HPS
50,000-Lumen Clear Lamp
Type II-Medium Cutoff
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
AB
C
D
E
FOOTCANDLE TABLE
Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABC D E
OVY40S2D.IES
25' 3.92 1.96 0.98 0.49 0.20
30' 2.72 1.36 0.68 0.34 0.14
35' 2.00 1.00 0.50 0.25 0.10
40' 1.52 0.76 0.38 0.19 0.08
OVY40S3E.IES
25' 3.92 1.96 0.98 0.49 0.20
30' 2.72 1.36 0.68 0.34 0.14
35' 2.00 1.00 0.50 0.25 0.10
40' 1.52 0.76 0.38 0.19 0.08
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
AB
CDE
OVY40S3E.IES
400-Watt HPS
50,000-Lumen Clear Lamp
Type III-Medium Semi-Cutoff
Light Lens
Wattage Source1 Type III MSCO IV MSCO II MCO III MCO
150 HPS Low N/A N/A OVY15S2D OVY15S3D
Profile (150W) (150W)
200-400 HPS Low OVY40S3E OVY40S4E OVY40S2D N/A
Profile (400W) (400W) (400W)
250-400 MH Low N/A N/A OVY40M2D OVY40M3D
(ED28) Profile (400W) (400W)
250 MV Low N/A N/A OVY25V2D OVY25V3D
(ED28) Profile (250W) (250W)
NOTE: 1 All light sources are clear unless noted otherwise.
PHOTOMETRIC DISTRIBUTION [Curve Number]
SWING-DOWN BALLAST MODULE
