118 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
ROADWAY
NOTE: 1 150W units are for S55 lamp. 2Refer to technical section for lamp/ballast/voltage compatibility. 3Available in 120/240V dual voltage or single voltage only for 50-150W. 4Other distributions & cutoffs available. Consult
your Streetworks Representative. 5Acrylic is standard on units 50W through 150W HPS and 175W mercury. Glass standard for 200-250W. 6MOV option is not available for any system requiring a three position terminal
block (Example—240V with PCR with wired 120V). In order for MOV option to function center terminal of three position terminal block must be connected to “Earth” ground. 7Not available on 250W Mag. Reg. or 400W
units.
HOUSING
Die-cast aluminum housing and
latch. Standard grey polyester
powder coat finish. Other finish
colors available. Consult your
Streetworks Representative.
Optional NEMA twistlock
photocontrol receptacle also
available.
REFLECTOR
The optical system is a
hydroformed anodized aluminum
reflector with a Dacron polyester
filter.
DOOR
Die-cast aluminum door frame with
integral hinges for hands free
installation, relamping and
maintenance. ANSI wattage/source
label.
LENS
Removable prismatic refractor
for use with High Pressure Sodium,
Metal Halide and Mercury lamp
sources.
SOCKET
Adjustable mogul-base porcelain
socket.
BALLAST ASSEMBLY
Hard mounted ballast with
encapsulated starter for protection
from environmental abuse.
Standard two position tunnel type
compression terminal block.
Optional swing-down ballast bridge
also available (up to 250W).
MOUNTING
Two-bolt/one bracket slipfitter with
cast-in pipe stop and leveling steps.
Fixed-in-place birdguard seals
around 1 1/4" or 2" mounting arms.
ORDERING INFORMATION
SAMPLE NUMBER: OVX40SWW3E4
OPTIONS +
ACCESSORIES
(See Below)
ROADWAY LUMINAIRE
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted (120 or 277V)
2=Double Fuse, Internally Mounted (208, 240, or 480V)
4=Photocontrol Receptacle
WH=White
BK=Black
BZ=Bronze
E=150W/100V/HPS Ballast
F=Flat Glass (available only in MCO)
G=Borosilicate Glass Refractor (175W & below) 5
H=Plug-in Starter Receptacle
K=Level Indicator
M=MOV Lightning Surge Protector 6
P=Polycarbonate Refractor (250W Max.)
T=Swing-down Ballast Bridge 7
U=UL/CSA Listed
ACCESSORIES (order separately)
RA1001=Cutoff Visor
OA/RA1013=Photocontrol Shorting Cap
OA/RA1014=120V Photocontrol
OA/RA1016=105V-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1028=Field Installed PCR Kit
OA1217=TufGuard Vandal Shield
PRODUCT
FAMILY
OVX
LAMP WATTAGE
50=50W
70=70W
10=100W
15=150W 1
17=175W
20=200W
25=250W
24=250/400W
wired 250W
40=400W
42=400/250W
wired 400W
LAMP TYPE 2
S=High Pressure
Sodium
V=Mercury
M=Metal Halide
BALLAST TYPE 2
C=CWI
H=Reac./HPF
K=10KV CWA 3
M=Mag. Reg.
N=Hi. Reac./NPF
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
VOLTAGE2
2=120V
0=208V
4=240V
7=277V
8=480V
F=120/240 wired 120V
P=240 w/PCR wired 120V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
DISTRIBUTION4
2=Type II
3=Type III
CUTOFF4
D=MCO
E=MSCO
OVX DROP PRISMATIC REFRACTOR 50-400W MH/HPS/MERCURY
EPA:
Effective Projective Area: .87
SHIPPING DATA
Approximate Net Weight:
35 lbs. (16 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™
28 1/4" [718mm]
11 1/4"
[286mm]
13 1/4" [337mm]
NOTE: In flat glass applications only.
OPTIONAL COLORS [Standard color is grey, other finish colors available. Consult your Cooper Lighting representative]
WH
White BK
Black BZ
Bronze

STREETWORKS Outdoor Lighting Solutions 119Cooper Lighting
OVX DROP PRISMATIC REFRACTOR ROADWAY
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
OVX40S3E.IES
400-Watt HPS
50,000-Lumen Clear Lamp
Type III-Medium Semi-Cutoff
E
D
C
B
A
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
FOOTCANDLE TABLE
Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABC D E
OVX40S3E.IES
25' 3.92 1.96 0.98 0.49 0.20
30' 2.72 1.36 0.68 0.34 0.14
35' 2.00 1.00 0.50 0.25 0.10
40' 1.52 0.76 0.38 0.19 0.08
OVX25S2E.IES
25' 3.92 1.96 0.98 0.49 0.20
30' 2.72 1.36 0.68 0.34 0.14
35' 2.00 1.00 0.50 0.25 0.10
40' 1.52 0.76 0.38 0.19 0.08
OVX25S2E.IES
250-Watt HPS
27,500-Lumen Clear Lamp
Type II-Medium Semi-Cutoff
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
A B CDE
Light Lens
Wattage Source1Type2II MSCO III MSCO II MCO III MCO II 4 WAY
50-150 HPS Acrylic N/A OVX15S3E N/A N/A N/A
(ED23 1/2) (150W)
50-150 HPS Glass OVX15S2EG OVX15S3EG OVX10S2DF OVX15S3DF N/A
(ED23 1/2) (150W) (150W) (100W) (150W)
200-400 HPS Glass OVX25S2EG OVX25S3EG OVX25S2DF OVX25S3DF OVX25S7E
(ED-18) (250W) (250W) (250W) (250W) (250W)
175 MV/MH Acrylic OVX17M2E OVX17M3E N/A N/A N/A
(ED-28) (175W) (175W) (175W)
175-250 MV/MH Glass N/A OVX17M3EG N/A N/A N/A
(ED-28) (175W) (175W)
250-400 MH Glass N/A OVX40M3EG OVX40M2DG N/A N/A
(ED-28) (400W) (400W)
NOTE: 1 All light sources are clear unless noted otherwise. 2 Prismatic refractor.
PHOTOMETRIC DISTRIBUTION [Curve Number]
SWING-DOWN BALLAST MODULE
