FLOODLIGHTING
553
COOPER LIGHTING
COOPER LIGHTING - LUMARK®
ORDERING INFORMATION
SAMPLE NUMBER: QZ3L
Lamp Type
Q=Quartz
Fixture
Z=Wedge
Lamp Wattage
3=300W
5=500W
Lamp
L=Lamp
Included
Options (add as suffix)
WHT=White
Accessories (order separately)
NKS-BZ=2" Slipfitter—Bronze
NKS-WHT=2" Slipfitter—White
9" [229mm]
4"
[102mm]
6 1/4"
[159mm]
NOTES: 1 Standard unit has 1/2" NPT threaded knuckle for mounting. 2" slipfitter is available as an accessory. 2120 Volt operation only. 3Specifications and dimensions
subject to change without notice.
SPECIFICATION FEATURES
DESCRIPTION
The Lumark LQL1500 has a
heat- and impact-resistant clear
glass lens, mounted in a
gasketed, die-cast hinged
aluminum door with captive
screw fasteners for positive
latching. U.L. listed and labeled
for wet locations. CSA certified.
• Captive screw fasteners
provide positive
weatherproof seal
• Finished in dark bronze
paint
• Clear tempered glass lens is
heat- and impact-resistant
• Quartz lamp provides white
light for excellent color
rendition
• Die-cast aluminum door
is sealed with full-
circumference gasketing to
die-cast aluminum housing
installation to J-box and can
be wall or eaves mounted
• Integral hinge design
permits hands-free
relamping and easy
door removal
• Adjustable stem mounting
arm fits 1/2" NPT outlet box
cover
• U.L. listed for wet
locations. CSA certified
• Approximate net weight:
4.5 lbs. (2.5 kgs.)
SPECIFICATION FEATURES
DESCRIPTION
The Lumark QZ Wedge is a
compact, economical alternative
to traditional outdoor
floodlighting. The black or white
finishes provide lasting durability
with optics that deliver optimum
beam control. U.L. listed
and labeled for wet locations.
CSA certified.
• Die-cast aluminum
housing finished in black or
white paint for lasting
durability
• Adjustable stem mounting
arm fits 1/2" NPS outlet box
cover
• Anodized aluminum
reflector provides maximum
beam control and efficiency
• Porcelain lamp sockets for
300-500W quartz lamp
• Heat- and weather-
resistant gasketing seals out
external contaminants
• Hinged door frame has
toolless entry latch
• U.L. listed for wet
locations. CSA certified
• Approximate net weight:
3 lbs. (1 kgs.)
LQL1500
QUARTZ FLOOD
1500W (Max.)
Quartz
FLOODLIGHT
[240V LAMP INCLUDED]
QZ
WEDGE
300-500W
Quartz
FLOODLIGHT
ORDERING INFORMATION
SAMPLE NUMBER: LQL1500WL240
Catalog Lamp Lamp
Number Wattage Type Voltage Color
LQL1500WL240 1500W T3 Quartz 240V Bronze
14 1/2" [362mm]
8 3/4"
[222mm]
8 1/4"
[210mm]
NOTES: 1 240V T3 lamp included. 2Specifications and dimensions subject to change without notice. 3Products also available in non-US voltages and frequencies for
international markets. 4Consult your Cooper Lighting Representative for availability and ordering information.
