136 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
NOTE: 1 Natural aluminum finish, other colors available. Consult your Streetworks Representative. 2When ordering “A” must be applied to end of catalog number. 3HPS not available. 4120V only.
PHOTOCONTROL
Optional NEMA twistlock
photocontrol.
REFLECTOR
Spun anodized aluminum reflector.
Standard with photocontrol
receptacle.
LENS
Light stabilized acrylic prismatic
refractor efficiently controls and
directs light.
HOUSING
Die-cast aluminum housing for
structural rigidity also protects
integral ballast and wiring, provides
offset mounting feature.
DOOR
Quick release access cover on
underside for ease of servicing and
installation. ANSI wattage/source
label.
ORDERING INFORMATION
SAMPLE NUMBER: VAN70SR255LV5A
OPTIONS
(See Below)
ROADWAY LUMINAIRE
OPTIONS (add as suffix)
5=120V Photocontrol
AP=Grey
B=Terminal Block
H=Plug-in Starter Receptacle
L=Lamp
P=Polycarbonate Refractor
S=Shorting Cap
U=U.L. Listed
V=(2) 5' #14 Leads
PRODUCT FAMILY 1, 2
VAN LAMP
WATTAGE
70=70W
10=100W
15=150W
17=175W
20=200W
25=250W
40=400W 3
LAMP TYPE
S=High Pressure
Sodium
M=Metal Halide
V=Mercury
BALLAST TYPE
H=Reac./HPF 4
P=Hi. Reac./HPF
R=Reac./NPF 4
W=CWA
C=CWI
N=Hi. Reac./NPF
VOLTAGE
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
VAN VANGUARD III 70-400W
MH/HPS/MERCURY
ROADWAY
EPA:
Effective Projective Area: .85
SHIPPING DATA
Approximate Net Weight:
34 lbs. (15 kgs.)
OPTIONS [Must be listed in the order shown and separated by a dash] MOUNTING HOLE PATTERN
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
STREETWORKS™
DISTRIBUTION
33=Type III
55=Type V
5 5/8"
[143mm]
11/16"
dia. hole
[18mm]
1/2"
dia. hole
[13mm]
8 3/4"
[222mm]
6"
[152mm]
VAN25S33.IES
250-Watt HPS
27,500-Lamp Lumens
Type III
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
A
BCD
E
VAN25S55.IES
250-Watt HPS
27,500-Lamp Lumens
Type V
4
3
2
1
0
1
2
3
4
5 4 3 2 1 0 1 2 3 4 5
A
B
C
D
E
FOOTCANDLE TABLE
Select mounting height and read
across for footcandle values of each
isofootcandle line. Distance in units of
mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABC DE
VAN25S33.IES
25' 2.88 1.44 0.72 0.36 0.14
30' 2.00 1.00 0.50 0.25 0.10
35' 1.50 0.75 0.38 0.19 0.07
VAN25S55.IES
25' 2.88 1.44 0.72 0.36 0.14
30' 2.00 1.00 0.50 0.25 0.10
35' 1.50 0.75 0.38 0.19 0.07
16 5/16"
[414mm]
26 7/8" [684mm]
OPTIONAL COLOR
AP
Grey
