FLOODLIGHTING
1192 COOPER LIGHTING
MCGRAW-EDISON®
• Formed aluminum flush
draw-action latches offer
easy access to lamp
compartment without
tools and maintain
integrity of seal when
closed
• Die-cast aluminum with
integral cast hinges for
removal without tools
• Heat- and impact-resistant
tempered glass. Lens is
mounted flush with door
surface to reduce wind
drag and prevent dirt or
moisture from
accumulating
• Computer designed
reflector systems deliver
superior beam control
and efficiency.
• Door gasket is closed-cell
silicone, providing
maximum protection of
interior components from
the elements
• Available in two (2)
mounting variations.
Slipfitter: Die-cast
aluminum integral
slipfitter mounts on 2 3/8"
to 3" O.D. tenon. Yoke:
Heavy-duty (.25" minimum
thickness) steel yoke
provides flexibility in
mounting and aiming
from a variety of surfaces
• Approximate net weight:
71 lbs. (32 kgs.)
ALF
ACURA LARGE
FLOOD
1000-1500W
Metal Halide
High Pressure Sodium
LARGE SLIPFITTER-, OR
YOKE-MOUNTED
FLOODLIGHT
NOTES: 1 All lamps are mogul-base. 2Product also available in non-US voltages and 50Hz for international markets. Consult factory for availability and ordering
information. 3Multi-Tap ballast is 120/208/240/277V wired 277V. Triple-Tap ballast is 120/277/347V wired 347V. 4Available in Metal Halide only. 5Available in High
Pressure Sodium only. 6Add as suffix in the order shown. 7Order separately, replace XX with color suffix. 8Vertical Louvers must be used with vertical lamp
positions. 9Horizontal Louvers must be used with vertical lamp positions. 10 Specifications and dimensions subject to change without notice.
DIMENSIONS
DESCRIPTION
The McGraw-Edison Acura
floodlight utilizes a
soft-cornered aerodynamic
design to provide excellent
EPA ratings and an
aesthetically pleasing
appearance. Black polyester
powder coat finish assures
corrosion resistance and
long-lasting aesthetics.
U.L. listed for 40°C ambient
temperature operation.
CSA certified.
The Acura features a variety
of optical designs which
deliver maximum beam
control for architectural
facades, signage,
monuments, airport aprons
and building perimeters.
Options 6
F=Single Fuse (120, 277 or 347V)
FF=Double Fused (208, 240 or 480V)
Q=Quartz Restrike
R=NEMA Twistlock Photocontrol Receptacle
L=Lamp Included
Accessories 7
OA/RA1016=NEMA Twistlock Photocontrol—Multi-Tap
OA/RA1027=NEMA Twistlock Photocontrol—480V
OA1201=NEMA Twistlock Photocontrol—347V
VS/AL=Vandal Shield
WG/AL=Wire Guard
IL/AL/VET=Vertical Internal Louver Kit 8
IL/AL/HOR=Horizontal Internal Louver Kit 9
TV/AL-XX=Top/bottom Visor
SV/AL-XX=Side Visor
SAB-XX=Steel Angle Bracket for Yoke
RAB-XX=Right Angle Pipe Bracket for Slipfitter
TYS-XX=Trunnion and Yoke Slipfitter Adapter
E.P.A. 3.7
ORDERING INFORMATION
SAMPLE NUMBER: ALF-Y-1000-MH-120-55-BK
Product
Family
ALF=Acura
Large
Flood
Lamp
Wattage 1
1000=1000W
1500=1500W
Mounting
Method
F=Slipfitter
Mount
Y=Yoke
Mount
Lamp Type
MH=Metal
Halide
HPS=High
Pressure
Sodium
Voltage 2
120=120V
208=208V
240=240V
277=277V
347=347V
480=480V
MT=Multi-Tap 3
TT=Triple-Tap 3
Beam
Spread
13=1x3 4
14=1x4 5
24=2x4 4
35=3x5 5
55=5x5 Cutoff 5
62=6x2
65=6x5 Cutoff 4
66=6x6
67=6x7
Colors
AP=Grey
BZ=Bronze
BK=Black
WH=White
DP=Dark Platinum
GM=Graphite Metallic
Options &
Accessories
(See Below)
12 1/4"
[324mm]
23 1/4"
[591mm]
31 1/4"
[794mm]
29 1/4" [743mm] 12 3/4"
[324mm]
30 1/2" [775mm]
23 1/4"
[591mm]
26 7/8"
[683mm]
Slipfitter Mount Yoke Mount
Yoke Drilling Pattern
3 3/4" [95mm] 1 7/8" [48mm]
9/16" [14mm]
dia. hole (2)
7/8" [22mm]
dia. hole
1 1/16"
[27mm]
Beam Availability + Lamp Position
Distribution Lamp Position
Type (HxV) HPS MH
6x7 V V
6x6 V V
6x5 Cutoff H
6x2 H H
5x5 Cutoff H
3x5 V
2x4 V
1x4 V

FLOODLIGHTING
1193
COOPER LIGHTING
MCGRAW-EDISON®
ACCESSORIES [LOUVERS KITS/VISORS/VANDAL SHIELDS/WIRE GUARD]
IL/AS=Internal Louver Kit (small) 1
IL/AM=Internal Louver Kit (medium) 1
IL/AL=Internal Louver Kit (large) 1
Two Horizontal Louvers Shown
IL/AS=Internal Louver Kit (small) 1
IL/AM=Internal Louver Kit (medium) 1
IL/AL=Internal Louver Kit (large) 1
Two Vertical Louvers Shown
IL/AS=Internal Louver Kit (small) 1
IL/AM=Internal Louver Kit (medium) 1
IL/AL=Internal Louver Kit (large) 1
Four Horizontal Louvers Shown
IL/AS=Internal Louver Kit (small) 1
IL/AM=Internal Louver Kit (medium) 1
IL/AL=Internal Louver Kit (large) 1
Four Vertical Louvers Shown
SV/AS=Side Visor (small) 2
SV/AM=Side Visor (medium) 2
SV/AL=Side Visor (large) 2
TV/AS=Top/bottom Visor (small) 2
TV/AM=Top/bottom Visor (medium) 2
TV/AL=Top/bottom Visor (large) 2
Two Side Visors and
Top Visor Shown
Two Side Visors, Top and
Bottom Visor Shown
WG/AS=Wire Guard (small)
WG/AM=Wire Guard (medium)
WG/AL=Wire Guard (large)
TV/AS=Top/bottom Visor (small) 2
TV/AM=Top/bottom Visor (medium) 2
TV/AL=Top/bottom Visor (large) 2
VS/AS=Vandal Shield (small)
VS/AM=Vandal Shield (medium)
VS/AL=Vandal Shield (large)
Two Side Visors Shown
NOTES: 1 Must specify horizontal or vertical (each kit contains four (4) louvers. 2Each kit contains one (1) visor only. Must specify color.
MOUNTING ACCESSORIES
TYS=Trunnion and Yoke Slipfitter
Adapter (2 3/8", 3", & 3 1/2" O.D.)
SAB=Steel Angle Bracket 3RAB=Right Angle Pipe Bracket 3
(2 3/8" O.D.)
4 15/16"
[125mm]
4" [101mm]
20"
[508mm]
45°
1 1/2"
[38mm]
15 1/2"
[394mm]
3"
[76mm]
5 5/8"
[143mm]
8 1/2"
[216mm]
5 5/8"
[143mm]
8"
[203mm]
NOTE:3Must specify color.
