Crestron Air Series User manual

quickstart guide
AIR_SR4/AIR_SR6/AIR_SR8
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
AIR_SR4/AIR_SR6/AIR_SR8
AIR®2-Way Surface Mount Outdoor Speakers
a. Route the audio source’s (and a second speaker’s) wiring through
the supplied weather boot (if used). Strip the wires 1/4 in
(~6 mm), twist the strands, insert them into the terminal block,
and tighten the screws to secure them.
b. Reattach the terminal block to the speaker connector.
c. The weather boot press-fits securely into the connector housing
recess.
4. Carefully mount the speaker onto the QuickBall mounting bracket,
ensuring that the ball is fully inserted into the cavity. Rotate and set
the speaker at the desired angle, and raise the ball socket clamp
lever into position against the bottom of the speaker to secure the
speaker in position. Use the supplied security screw to prevent the
lever from being accidentally pulled, which releases the speaker.
5. Attach a security cable (SPKA-ST-15, sold separately) to the security
cable attachment point. The other end of the cable must be attached
to a secondary support point able to support several times the weight
of the speaker.
QUICKSTART DOC. 7129C (2029452) 08.14
1
1Installation
Front View
(Grill Removed)
2Physical Views (AIR_SR8 Shown)
10.73 in
(273 mm
)
2.16 in
(55 mm)
Side View
Rear View
(Mounting Bracket
Removed)
6.94 in
(177 mm)
9.05 in
(230 mm)
Bottom View
9.57 in
(244 mm)
13.31 in
(338 mm)
NOTE: Before starting installation, ensure the wall and wall material are capable of supporting the
combined weight of the speakers and the wall mount assemblies. Refer to section  for speaker
weights.
AIR®speakers by Crestron®offer superior sound quality and flexible
installation in a range of popular sizes for all types of indoor and outdoor
applications. Solid construction and high-end components are hallmarks
of the complete AIR speaker line. Each AIR model provides a pair of
weatherized 2-way surface mount outdoor loudspeakers with polypropylene
woofers for deep, solid, bass, optimized dual front ports for enhanced low
frequency response, and titanium dome tweeters for crisp, clear high-end
extension.
Featuring a unique “QuickBall” mounting system, the AIR speakers can be
mounted to any solid,flat surface, with the ability to orient and aim the
speaker in virtually any position. The QuickBall bracket achieves a very clean
and stable installation using a tool-free ball-and-socket mechanism. Simply
position the speaker as desired and flip the clamp lever closed. A security
screw is included to deter theft by preventing the lever from being released.
AIR speakers, supplied in pairs, are available in black or white and can be
painted to blend with the surrounding architecture.
Security
Cable
Attachment
Point
Security
Screw Speaker
Cable
Access
Hole
Ball Socket
Clamp Lever
Detachable
Screw Terminal Block
QuickBall
Mounting
Bracket
From
Audio
Source
To
Parallel
Speaker
+ + - -
IN
THRU
Refer to the illustration to the right as necessary, and install the speakers as
follows:
1. Route the cables from the audio source to the intended speaker locations
while following all appropriate local codes.
2. Attach the QuickBall mounting bracket directly to the wall or to a flush
mounted 1-gang US, UK, or European electrical box, allowing the cable
coming through the wall (and the electrical box, if used) to exit through the
speaker cable access hole of the mounting bracket.
NOTE: If the mounting bracket is to be attached to an electrical box, be
sure it is also attached to surrounding framing to provide the support
needed to hold the weight of the speaker.
The QuickBall mounting bracket can also be mounted to a light pole or post
using pole mounting straps (not included).
3. Detach the 4-pin screw terminal block connector from the speaker. Connect
the audio source’s + and - outputs to the connector’s outer + and -(IN)
terminals. Maximum wire size is 12 AWG. Use the inner + and - (THRU)
terminals to connect a second speaker in parallel.
NOTE: The number of speakers that can be added is limited only by the
specifications of the amplifier.

AIR®2-Way Surface Mount Outdoor Speakers
quickstart guide
AIR_SR4/AIR_SR6/AIR_SR8
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
AIR_SR4/AIR_SR6/AIR_SR8
QUICKSTART DOC. 7129C (2029452) 08.14
2
3Specifications
SPECIFICATION AIR_SR4
Drivers
Woofer
Tweeter
Crossover Frequency
Impedance
Frequency Range
Frequency Response
Power Handling
Sensitivity
Environmental
Temperature
Humidity
Construction
Enclosure
Grille
Mounting
Positioning
Yaw (Horizontal)
Pitch (Vertical)
Roll
Dimensions
Height
Width
Depth
Weight
AIR_SR4, AIR_SR6, and AIR_SR8 Specifications
4 inch (102 mm) polypropylene with
rubber surround and steel basket
0.79 inch (20 mm) titanium dome
2.5 kHz
8 ohms nominal
65 Hz to 20 kHz (-10 dB)
70 Hz to 20 kHz (±3 dB)
100 watts program
87 dB @ 1 W/1 m
-2º to 120º F (-19º to 49º C)
5% to 95% RH (non-condensing)
ABS plastic, textured finish, paintable
Aluminum, powder coated, paintable
Surface mount to a solid flat surface
with option to position over a
flush-mounted 1-gang electrical box,
1-gang UK (BS 4662) electrical box, or
1-gang European (DIN 49073)
electrical box;
Pole mount (straps not included);
Rigging point for safety tether
(SPKA-ST-15 sold separately);
Theft-resistant security screw
± 30°
± 30°
360°
8.67 in (220 mm)
5.91 in (151 mm)
6.55 in (167 mm), 8.66 in (220 mm)
with mounting bracket
4.5 lb (~2 kg)
AIR_SR6 AIR_SR8
Further Inquiries
To locate specific information or resolve questions after reviewing this guide, contact Crestron's
True Blue Support at 1-888-CRESTRON [1-888-273-7876] or, for assistance within a particular
geographic region, refer to the listing of Crestron worldwide offices at www.crestron.com/offices.
To post a question about Crestron products, log onto Crestron’s Online Help at
www.crestron.com/onlinehelp. First-time users must establish a user account to fully benefit from
all available features.
Future Updates
As Crestron improves functions, adds new features, and extends the capabilities of the AIR_ SR4,
AIR_ SR6, and AIR_ SR8 speakers , additional information may be made available as manual
updates. These updates are solely electronic and serve as intermediary supplements prior to the
release of a complete technical documentation revision.
Check the Crestron website periodically for manual update availability and its relevance. Updates
are identified as an “Addendum” in the Download column.
4Problem Solving
Troubleshooting
The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, and AIR are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or
other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is
not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2014 Crestron Electronics, Inc.
6.5 inch (165 mm) polypropylene with
rubber surround and steel basket
0.98 inch (25 mm) titanium dome
2 kHz
8 ohms nominal
55 Hz to 20 kHz (-10 dB)
60 Hz to 20 kHz (±3 dB)
150 watts program
88.5 dB @ 1 W/1 m
-2º to 120º F (-19º to 49º C)
5% to 95% RH (non-condensing)
ABS plastic, textured finish, paintable
Aluminum, powder coated, paintable
Surface mount to a solid flat surface
with option to position over a
flush-mounted 1-gang electrical box,
1-gang UK (BS 4662) electrical box, or
1-gang European (DIN 49073)
electrical box;
Pole mount (straps not included);
Rigging point for safety tether
(SPKA-ST-15 sold separately);
Theft-resistant security screw
± 30°
± 30°
360°
11.19 in (284 mm)
8.08 in (205 mm)
8 inch (203 mm) polypropylene with
rubber surround and steel basket
0.98 inch (25 mm) titanium dome
2 kHz
8 ohms nominal
50 Hz to 20 kHz (-10 dB)
55 Hz to 20 kHz (±3 dB)
200 watts program
89.5 dB @ 1 W/1 m
-2º to 120º F (-19º to 49º C)
5% to 95% RH (non-condensing)
ABS plastic, textured finish, paintable
Aluminum, powder coated, paintable
Surface mount to a solid flat surface
with option to position over a
flush-mounted 1-gang electrical box,
1-gang UK (BS 4662) electrical box, or
1-gang European (DIN 49073)
electrical box;
Pole mount (straps not included);
Rigging point for safety tether
(SPKA-ST-15 sold separately);
Theft-resistant security screw
± 30°
± 30°
360°
13.31 in (338 mm)
9.57 in (243 mm)
6.94 in (177 mm), 9.05 in (230 mm)
with mounting bracket
8.7 lb (4 kg)
The following table provides corrective action for possible trouble situations. If further assistance is
required, please contact a Crestron customer service representative.
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION
There is either no sound
or the sound from the
speakers is intermittent.
There is a cable connection
error. Verify the cable connections between the amplifier and speakers.
The amplifier is not
receiving an input signal
or there is an amplifier
malfunction.
Verify that the amplifer is functioning
correctly, that it is receiving an input signal,
and that the correct input source is selected.
There is a faulty device in
the system. Verify that all devices in the system are functioning properly.
Constant noise such as
buzzing, humming,or
hissing comes from the
speakers. There is a system grounding
fault. Verify the system grounding connection.
The low frequency output
is poor. The connection polarity at the speaker is incorrect. Verify speaker connection polarity (i.e., + on speaker to + on amplifier).
6.75 in (172 mm), 8.86 in (225 mm)
with mounting bracket
6.6 lb (3 kg)
