Copernicus MK100 User manual

Please Recycle
Released October 4, 2021 - Copernicus Educational Products Inc.
Owners Manual, 2021 Rev A
Outdoor Mud Kitchen
(MK100)
MK100
Outdoor Mud Kitchen

2
Released October 4, 2021 - Copernicus Educational Products Inc.
Customer Service & Warranty Information
Lifetime
Warranty

3
Released October 4, 2021 - Copernicus Educational Products Inc.
Before You Begin:
 Lay out and identify all of the included parts.
 The hardware has been packed together in one bag
 Read the assembly guide over once to familiarize yourself with them.
As You Assemble the Unit:
 Follow the steps in sequence.
 Before beginning each step, find the part(s) that you need for that step.
 The title of each step states what you will be doing. Review the text and
the pictures as you build the unit.
Please read the warnings below for important safety information regarding your product. Failure to read these
warnings or to follow the instructions below could result in personal injury or damage to your product that could
void your warranty.
Small Parts
Adult
Supervision
In its unassembled state, this product contains parts that can be hazardous to small children.
This product should be assembled by an adult.
This product is to be used under the supervision of an adult.
Before beginning, you should have:
Parts
Tips for Assembly
Watch for These Helpful Symbols:
For safety, please have
someone help you when
working on steps
2-Person Task
displaying this symbol.
The symbol denotes a
step needing extra
attention to ensure it is
done correctly.
Important Information! Warning!
Additional tools required:
Adjustable wrench 2x
OR
7/8" wrench
+
Mk100
Pre Assembled MK100
Rubber Mallet 1x
Hardware (Actual Size)
5/16”-18 x 1-1/2” Carriage Bolt, Galv.
A
1x
Side Table
1x
(43307)
4x
Open Tub
(CC4068-ECO-G)
1x
B
In Box 1
Really Big Tub
(CC4073-B)
1x
C
5/16 Flat washer x 3/4 OD Galv.
(4301942)
4x
5/16 Split Lock Washer, Galv.
(430250)
4x
S Hook
(31017)
5x
D
5/16”-18 x Galvanized Nut
(4302143)
4x

4
Released October 4, 2021 - Copernicus Educational Products Inc.
1
Actual Size:
You will need: (Not to Scale)
A 4x
B 4x
C 4x
D 4x
Side Table
1x
Fasten Side Table onto Mud Kitchen
Insert Carriage Bolts into Side Table
Mounting Plates
(use hole positions 2 and 4
(see diagram below))
Fasten Side Table onto cabinet
Mounting Plate Diagram
Install Accessories onto Mud Kitchen
Insert Open Tub into counter top 3
Place Really Big Tub inside cabinet
Install S Hooks onto Back Board
1
2
1
2
1
2
3
Back
View
Front
View
DO NOT
OVER TIGHTEN
CARRIAGE BOLT
NUTS
D
C B
A
table top
4
3
mounting
plate
2
1
2
You will need: (Not to Scale)
Open Tub
1x
Really Big Tub
1x
S Hook
5x
