Core SWX HyperCore 98R User manual

Warranty:
This product is warranted to the Original Purchaser against all defects in material and or workmanship
for the period herein. The purchaser must activate the warranty, either at the time of purchase or within
ten calendar days after the purchase. Completing the warranty card, enclosed in the box with the
product, activates this warranty. The warranty card must be completed and delivered to Core SWX by the
above-mentioned period of time.
The warranty period shall be, 2 years for parts and labor, unless otherwise noted.
Core SWX agrees to pay equal return freight costs to return the product the same method it was received.
Customer must take this procedure stated below for Core SWX to acknowledge warranty.
Procedure:
1. Provide Bill of Sale in the event service is needed.
2. If service is needed on a product, at the time contact Switronix, Inc. and request a return
authorization number through our online RMA system.
3. Ship defective product to Switronix,Inc. with return authorization number on outside of package.
Core SWX reserves the right to repair or replace any defective product under warranty after Core SWX
determines which is more practical.
If Core SWX receives defective product for warranty repair and they are found to be defective as a result of
misuse or other damage, not caused by normal wear and tear, Switronix, Inc. will notify the customer of an
estimate of repair. Customer will incur costs. There are no further warranties, either expressed or implied,
including warranties of merchantability or fitness for a particular purpose that has any bearing upon this
transaction.
Specifications:
HyperCore 98R
Lithium Ion Brick Battery
INSTRUCTION MANUAL
Core SWX.
91B Commercial St Tel: [phone]
Plainview, NY 11803
[email protected]
Website: http://www.coreswx.com
Capacity: 98Wh
Designed Voltage: 14.8v
Size: 3.8"(W) x 5.87"(H) x 2"(D)
Weight: 2 lbs.
Hypercore 98R Lithium Ion Battery Pack
Hypercore 98R Air Transport Compliance
The battery pack listed above is suitable for air transport as a non-hazardous article
under the regulations of the IATA, the ICAO, and the UN. The HC98S contains less
than 8 grams of equivalent lithium content. This quantity is in compliance
with section A45-2* of the Hazardous Substance Standards of the ICAO. The
HC98S is suitable for air transport as a non-hazardous article.
* Section A45-2: Lithium cells and lithium batteries are not subject to these instructions
if they meet the following requirements:For a lithium ion battery the aggregate equivalent
content is not more than 8g.

Thank you for your choice in purchasing a Core SWX Lithium Ion
Battery Pack. The battery is designed to improve and assist you in your
mobile powering requirements. Please read this manual to help you
understand and capitalize on the features of this battery.
Features:
•Intellicom RunTime LCD
• Fuel Computer communicates % data to RED Cameras
• On-Board Microprocessor stores: Name, Serial Number, Voltage,
Temperature, Current, Chemistry Type, Charge Cycles, and
Date of Manufacturing. When used with a Switronix digital
charger, this information can be displayed.
• The Viewfinder Capacity Display communicates with the camera
to display your remaining battery capacity in your camera’s
viewfinder. *(select camera models)
• Four Stage, accurate, LED power gauge.
• No memory effect.
• Temperature, current, and voltage protection.
• NEW DuraCase provides a shock absorbing, non-slip shell to
protect the battery pack.
• Incorporated 2-pin powertap provides unregulated power, as
well as a 5v USB.
Charging the Battery:
•Core SWX HC batteries were designed to be used Core SWX
chargers. Any other charger may damage the battery and/or
the charger. Please contact us before using other chargers.
•Core SWX batteries can be recharged in any charge condition.
• Charge the battery in ambient temperature range of between
0 C ~ 45 C. For best results, charge in an environment between
10 C ~ 30 C. Charging in any other conditions will not allow the
battery to reach maximum charge capacity.
Discharging the battery:
• Maximum continous discharge for the is 10A(120W) for the
HC98R.
• The 2-pin connector can be used to simultaneouly power a
camera and a 12vdc accessory. However, prior to using this
option combine the total draw of the camera and accessory to
make sure you are not drawing more than the recommended
discharge amount.
Intellicom RunTime LCD:
• The LCD automatically switches between 3 different phases;
Normal RT(based on default 30wh draw), Remaining RT(based
on actual draw, when in use), and Remaining Charge Time(when
connected to a charger).
• Press and hold the“Light” button for 1-2 seconds to activate the
backlight feature.
• During operation, the battery samples the current entering or
exiting the battery in 7 second intervals. During the charging
process,the charge current fluctuates, causing the Charge Time
readings to vary.
Power Gauge LEDs:
Remaining LED1 LED2 LED3 LED4
0% Off Off Off Off
less than 10% Blinking Off Off Off
10-25% On Off Off Off
26-50% On On Off Off
51-75% On On On Off
76-100% On On On On
The RunTime LCD and power gauge’s accuracy is dependent upon a
full charge and discharge. At least once every 2 months the battery
should be fully discharged and charged so the battery can relearn
the capacity of the battery.
Storage:
• Store the battery 25% charged in an environment between
10 C ~ 30 C. Every 2 months the battery should be
charged due to minimal self-discharge.
Notes On Use:
• An increase in temperature is normal during charging and
discharging.
• Make sure to keep battery contacts clean.
• Do not attempt to disassemble the battery. Please contact
Switronix for any service issues.
• Keep batteries seperated when transporting.
• Keep battery pack dry and avoid use in humid environments.
