Core Eclipse CR-ECP-04-KNX Series User manual

Eclipse Room Controller
Quick Start Guide
Processor: Arm Cortex-A7 900MHz
512 MB DDR3 RAM
Embedded Linux Operating System
IPS TFT
4″ – 720px X 720px
400 cd/m2
HD Display
Temperature & Humidity
CO2
Proximity & Light
Aluminium, Brass and Stainless Steel
depending on the finish selection
12- 30 VDC - via KNX Auxiliary Power Supply or
separate PS
< 70 mA from KNX Auxiliary Power Supply
< 5 mA from KNX Bus-line
All Installations should only be performed by qualified
personnel following applicable regulations on preventing
accidents, as required by law.
• Do not connect the main voltage (230 V AC) or any other
external voltages to any point of the KNX bus.
• Connecting an external voltage might put the KNX system at
risk.
• Ensure that there is enough insulation between the 230 V AC
voltage cables and the KNX bus.
• Do not expose this device to direct sunlight, rain or high
humidity.
• Clean the product with a clean, soft, damp cloth.
• Do not use aerosol sprays, solvents or abrasives that might
damage the device.
6. Power Connector (12V-30V)
7. KNX Programming Button
8. KNX Connector
1. HD Display
2. Position of CO2 Sensor
3. Position of Temperature and
Humidity Sensor
4. SD Card Slot
5. Proximity sensor
9. Mouting Clips
86mm X 86mm X 11mm
KNX-TP
German IEC/EN 60670 In wall Box
Max. Page: 12
Max. Control Element: 64
ETS
Display:
Sensors:
Dimensions:
Casing Material:
Power:
Consumption:
Connectivity:
Programming Tool:
KNX Figures:
Installation:
Technical Specification
Dimensional Drawing Safety Introduction
1
9
23
5
4
876
24V
-
+
KNX
-
+
www.core.com.tr
CR-ECP-04-KNX-XXX

Use screws included
in the box (M3x15 mm)
A. Place over the lower clips
B. Attach the top clips
1. Tilt the cover away from the wall
Mounting Remove
The device should be positioned approximately 150
cm above the ground and 50 cm away from the door.
The device should not be installed close to the heat
source. The wall opposite the heat source will be
appropriate for the installation.
Contact with fluids to the device is to be avoided.
1. Mount the metal mounting
support. (Included in the box.)
3. Simply align the device
and press through the wall.
Mounting clips will be fixed
to the installation frame.
2. Connect power cable
and KNX cable to the
device. Check that polarity
is correct.
Dimensional Drawing Mounting, Electrical Connection
150
50
B
A
1
Pushing the room controller
straight into the clips might
damage
Do not overtighten
the screw
