Seada G4K User manual

G4K User Guide
This user guide provides basic instructions for setting up SEADA G4K Creative video wall controllers
and how to create eye catching video wall layout using its management software.
Document No. SD-MA-013
Document Version: 04

G4K User Guide
Contents
1. Hardware overview
2. Software installation on control PC
3. G4K management Software
3.1.Device
3.1.1. Connect through IP
3.1.2. Connect multiple G4Ks
3.2.Output
3.2.1. Choose the resolution of the screens
3.2.2. Enter the parameters of screens
3.2.3. Create video wall layout
3.2.3.1. Add screens onto the wall
3.2.3.2. Delete screens from the wall
3.2.3.3. Change the layout of the screens
3.3.Input
3.3.1. Manage the input
3.3.1.1. Lock aspect ratio
3.3.1.2. Open input source window
3.3.1.3. Close input source window
3.3.1.4. Resize input source window
3.3.1.5. Move input source window
3.3.2. Daisy chain with multiple G4Ks
3.3.2.1. Change Mode
3.3.2.2. Change EDID
3.4.Tool Bar
3.4.1. Home
3.4.2. Show Measurements
3.4.3. Snap to Display
3.4.4. Snap to Grid
3.4.5. EDID Editor
3.4.6. Save as
3.4.7. Load Layout
3.4.8. Language
4. Troubleshooting
4.1.No Connection
4.2.No Output

G4K User Guide
1. Hardware Overview
Model: G4K-DVI-FL
Model: G4K-HDMI-FL
Model: G4K-DP-FL
Model: G4K-HD-FL
Front
Panel
Back
Panel
1. RS232 Serial Port
2. RJ45 Ethernet Port
3. Power Socket
4. Dual Link DVI Input Connector
5. HDMI Input Connector
6. DisplayPort Input Connector
7. DVI Output Connectors
8. Daisy Chain HDMI Input Connector
9. Daisy Chain HDMI Output Connector
1 2 3
6
1 2 3
4
1 2 3
5
7
8 9
1 2 3
5
7
8 9
7
8 9
7
8 9

G4K User Guide
2. Software installation on control PC
Insert the SEADA Software CD into your control PC’s CD-ROM drive to begin the installation. Double
click the G4K management software in software folder to start the installation.
Click the drop down menu to choose the
language for the software.
The default language is English.
After choosing the language, click OK to
continue
Click I Agree to accept the License Agreement
Check and uncheck the items for installation.
And then click Next.
Choose the path for installation as you wish and
then click Install to start the installation process.
Note: The installation may take several minutes
to finish
Click Close to complete the installation

G4K User Guide
3. G4K management software
There are three main groups of tools in this software to help users design a creative video wall layout.
3.1. Device
Users are able to configure G4K devices and connect the devices to control PC in this section.
3.1.1. Connect through IP
The default IP address of G4K is 172.21.102.65. Users need to change the IP address of control
PC to the same IP group of G4K.
Open the ‘Ethernet Properties’ windows on Control PC
Highlight the TCP/IPv4 in Networking and click the Properties button to open the TCP/IPv4
Properties window
Change the ‘Obtain an IP address automatically’ to ‘Use the following IP address to set up
a static IP address
IP address: any address between 172.21.102.1 and 172.21.102.255 except the
address which has been taken by the G4Ks
Subnet mask: 255.255.255.0
Default Gateway: 172.21.102.1

G4K User Guide
Once the control PC IP address having been set up, press the Connect button to connect
the G4K.
The Connect button changes to Disconnect button and the very last video wall layout used
in this device is shown in grid area indicating the connection has been set up successfully.
If a dialog window as below comes up, the connection was failed.
Please check if control PC IP address is correctly set up
Please check the network cable connection between PC and G4K.

G4K User Guide
3.1.2. Connect multiple G4K as daisy chain
Connecting multiple G4K in one system can only be done in IP connection mode. Since the
default IP address of each G4K is same, users need to change the IP addresses of these devices
to avoid conflict.
Users need to connect the G4K one by one using default IP address: 172.21.102.65 to set
up the connection between device and control PC.
Right click the Device Name and then choose Change Device IP Address to open the
‘Change Device IP Address’ dialog window.
Please give a unique IP address for each device in the same system.
e.g.
Device 1 172.21.102.65
Device 2 172.21.102.66
Device 3 172.21.102.67
Device 4 172.21.102.68

G4K User Guide
After the IP addresses have been set up, add the quantity of the G4Ks into Device Count
and press Apply button.
Give a name for each device
Type the unique IP address for each device
Set the Port to 1024 for all devices
Use a network switcher to connect all the G4Ks to the control PC
Press Connect button to connect all the G4Ks into one system
If a G4Ks daisy chain system needs to be set up, please go to ‘3.3.2 Daisy chain with
multiple G4K’ to set up each G4K

G4K User Guide
3.2. Output
In Output section, users are able to choose the resolution of each screen in video wall and set
up the creative video wall layout.
3.2.1. Choose the resolution of the screens
Users are able to choose the resolution of screens from the drop down menu in
Resolution. The default output resolution is 1920 x 1080@60.
Or users are able to create custom resolution if the resolution needed is not in the list.
By clicking ‘+’ in Resolution, a dialog window will be shown for users to customise the
resolution.

G4K User Guide
3.2.2. Enter the parameters of screens
Dot Pitch Display area Length (L) ÷ Quantity of Horizontal pixel (e.g. 1920)
L
