Cornell CTF-PD65ECO User manual

0
Tower Fan
CTF-PD65ECO

1
Read all the instruction carefully. Keep this user manual for
future reference.
This appliance in not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
the use of appliance by a person responsible for their safety.
Use only original accessories supplied.
The current voltage which indicates on the plate must
correspond to your local voltage.
The appliance should be used only on condition that the type
of power supply corresponds to the marking label. Otherwise,
it will not work or even bedamaged.
Never use the appliance inside the bath, under a shower or
over a wash basin full of water.
If the appliance falls into water, pull the power plug out from
the power socket immediately.
Never use the appliance unless it is fully assembled.
Do not overload outlets or extension cords. It can result in fire
or electric shock.
Do not use the appliance if the power supply cord or plug has
been damaged.
Unplug from outlet when not in use, before putting on or
taking off parts, and before cleaning.
SAFETY REGULATION

2
The use of accessory attachments not recommended by
the appliance manufacturer may cause injuries.
Do not immerse the cord, plug or appliance in water or other
types of liquid and do not pour water onto it to avoid from fire,
electrical shock or personal injury.
To protect against risk of electrical shock, do not force any
foreign objects such as pins and wires into any openings.
PARTS IDENTIFICATION
2
Main Body
Control Panel
LED
Display
Panel
Base
Remote control

3
Before Using
Please read these instructions carefully before using and
keep them for future reference.
Check your local main voltage whether it is the same as
stated on the rating label.
Before using for the first time, remove any protective
films or stickers from the table fan.
Ensure the power switch is at the “0” position.
Always attach plug to appliance first, then plug cord into
the wall outlet. To disconnect, turn OFF any control,
then remove plug from wall outlet.
How to Assembly Tower Fan
1. Take out parts for assembling.
2. Please complete the installation following the below
pictures and instructions:
①Take out the rear base and front base, match the pole of
rear base with the hole of front base and join together
according to PICTURE 1.
②Put the main body into the assembled base along the
Model
CTF-PD65ECO
Voltage
220-240V~
Frequency
50Hz
Power
65W
SPECIFICATION
OPERATING INSTRUCTIONS

4
locating pole, according to PICTURE 2
③After assembling, put the machine in a suitable place,
plug in and operate according to the user’s manual.
How to Use Tower Fan
CONTROL PANEL:
“ON, OFF” button
Press the ON button once, the fan will start at low speed,
normal style and normal mode.
Press the OFF button again will turn the fan off.
“Mode”button：
To select normal mode, natural mode, sleep mode, air
condition mate and ECO mode:
NORMAL mode: unit operates in selected fan speed, High,
Medium or Low.
NATURAL mode: unit operates according to computerized
intervals of changing speeds.
SLEEP mode: unit operates according to computerized
intervals of changing speeds
Picture 1
Picture 2

5
AIR CONDITION MATE: When it turns to this mode, the fan
can help adjust and circulate air in the room when working
together with your air conditioner.
ECO mode: Under this mode, unit would adjust the wind
speed upon the current temperature: when its ＜25℃, the
low speed; hi speed when＞29℃; med speed between
25℃～29℃
“OSC” button
Press “SWING” to start the oscillation function, within 90°angle.
“TIMER” button
When the fan is in use, you can set the time to close the
appliance. Press the TIMER button, the default time is
1h.You can press the timer buttons continually to set the
timer off function between 1,2, 4, 8 hours timing.
“SPEED” button:
To adjust fan speed, press once for medium speed, and
twice for high speed.
Press the third time to return to low fan speed.
REMOTE CONTROL:
ON/OFF button
Press once to turn on the fan. Unit will start at Low fan
speed.
Press again to turn the fan off.

6
Mode button
To select normal mode, natural mode, sleep mode, air
condition mate and ECO mode:
NORMAL mode: unit operates in selected fan speed, High,
Medium or Low.
NATURAL mode: unit operates according to computerized
intervals of changing speeds.
SLEEP mode: unit operates according to computerized
intervals of changing speeds
AIR CONDITION MATE: When it turns to this mode, the fan
can help adjust and circulate air in the room when working
together with your air conditioner.
ECO mode: Under this mode, unit would adjust the wind
speed upon the current temperature: when its ＜25℃, the
low speed; hi speed when＞29℃; med speed between
25℃～29℃
Speed button
To adjust fan speed, press once for medium speed, and
twice for high speed.
Press the third time to return to low fan speed.
Timer button
When the fan is in use, you can set the time to close the
appliance. Press the TIMER button, The default time is
1h.You can press the timer buttons continually to set the
timer off function between 1, 2, 4, 8 hours timing.

7
Always unplug the product from the wall socket and shut down
completely prior to cleaning.
Do not use abrasive sponge, scouring pads or stiff brush to
clean the appliance.
Please be cautious when cleaning the product near to the heater
housing area.
Use only damp cloth to wipe the exterior surfaces of the unit. Do
not immerse the main body in water.
Do not allow the electricalcomponentsto be exposed towater.
For proper storage, always place the unit in a low humidity
environment.
“OSC” button
Press “SWING” to start the oscillation function, within 90°angle.
CARE AND CLEANING

8
