Cornell CJX-E500 User manual

JUICE CJX-E500
EXTRACTOR

General Safety Precautions
When using electrical appliances, basic safety precautions should always be followed:
1. The input voltage of this appliance is AC 220-240V 50Hz. Please make sure
before use.
2. Disconnect the power before dismantling, assembling or adjusting any parts of the
appliance.
3. If the appliance is not working or damaged, contact the Customer Care Centre for
further assistance. Do not perform self-repair as doing so will void the warranty
and may cause injuries.
4. Make sure the sieve, top cover and other detachable parts are installed properly
before powering on the appliance.
5. Do not push fruits or vegetable into the feeding chute with hands or with other
objects. Always use the pusher provided.
6. To prevent any personal injuries or damages to the appliance, do not interrupt the
sieve and the coupler with hands or other objects while it is running.
7. Before dismantling the detachable parts of the appliance, wait until the motor and
the sieve have stop running. Turn off the power and proceed.
8. Avoid operating the appliance without ingredients in it or overloading the
operation of the appliance.
9. If the appliance stops working while in operation, it may be caused by the motor’s
thermal control protection. Turn off the power and allow the appliance to cool
down for 20-30 minutes before restarting.
10. Do not put and wash the main body in the water or with other liquid. Clean it with
a soft cloth.
11. Do not clean the appliance with steel wool, abrasive cleaners or corrosive fluids
(e.g. gasoline or acetone).
12. Keep the appliance out of child’s reach and also people who are mentally and
physically impaired unless proper guidance is provided during operation.
13. Remove kernel, hard seeds, thick skin or hard shell from fruits and vegetables
before processing.

Parts Identification
1. Pusher 2. Top cover 3. See-through window
4. Sieve 5. Central holder 6. Juice flowing nozzle
7. Coupler 8. Main body 9. “Unlock” button
10. Power switch 11. Safety switch 12. Pomace container
13. Power cord
Specifications
Model
CJX-E500
Voltage
220-240V~
Frequency
50Hz
Power
250W

Operating Instructions
Clean the parts that will have direct contact with ingredients before using the juicer.
Always make sure the juicer is unplugged before assembling.
I. Using the juicer
This juicer is equipped with dual safety locking system and it will not start unless all
parts are installed properly. Please install and use the juicer as follows:
1
Align the juice flowing nozzle with the juice outlet of the
central holder and install it (if it is already installed,
proceed to the next step).
2
Put the central holder onto the main body.
·“P” :Pulse mode is used for a short timing such 2-3 sec
where by the speed will be under the users control.
·“0” :Off
·“1” :Low speed (suitable for processing soft juicy fruits &
vegetables)
such as watermelon, tomato, cucumber, strawberry
etc.)
·“2” :High speed (suitable for hard texture fruits and
vegetables.)
Such as pineapple, apple, carrot, pumpkin, etc.)
As to the detailed description of the selection of fruits and
vegetables with speed, please refer to the “Fruit Selection
Tips”.

3
Put the sieve into the central holder and make sure it in the
right place of the coupler.
Before using, check if there is any damage on the sieve.
If found, stop using and get assistance from the
Customer Care Centre immediately.
4
Put the top cover onto the central holder and press it down
until it clicks shut.
The juicer will not work if the top cover is not properly
installed.
5
Slightly lean the pomace container to place it under the
pomace outlet of central holder;
Follow up the first step; snap the screen at the bottom of
the pomace container into the corresponding screen of
main body.
6
Power on, start working, need to run for 1 minute before
actual usage.
Before powering on, make sure the switch is off.
7
Wash the fruits and vegetables. Then, slice them into
pieces suitable for the feeding chute.
Remove kernel, hard seeds, thick skin or hard shell
from the fruits and vegetables.

8
Place a juice glass under the juice outlet. (It is
recommended to use a juice glass which has similar height
to the juice outlet to prevent splashing.)
Switch on the juicer. Select the speed according to fruit
type (refer to Fruit Selection Tips). For the sake of service
life, it is recommended that working time does not exceed
one minute.
9
Put the fruit and vegetable pieces into the feeding chute.
Push the fruits and vegetables gently into the feeding chute
with the pusher. Otherwise, it may affect the juicing effect.
After juicing for some time, if residues are found in
outlet of juice glass is filled, disconnect power. Clean it
up before using it again.
10
After completion of processing and no juice flowing from
the nozzle, turn off the switch and power. Remove the
juice glass from under the nozzle after the motor and sieve
stop running completely.
Drink juice while it is still fresh as its taste and
nutrients may be affected by long exposure to the air.
II. Fruit Selection Tips
1. Select fresh fruits and vegetables that have high juice level. Suitable fruits include:
pineapple, beetroot, celery, apple, cucumber, spinach, melon, tomato, orange, grape
etc.
2. Fruits and vegetables with thin skin do not require peeling but those with thick ones
such as orange, pineapple and raw beetroot need peeling. Citrus fruits' seeds, which
may cause bitter taste after juicing, must be removed.
3. Freshly-squeezed apple juice may turn brown quickly. Few drops of lemon juice
can be added to slow down discolouring.
4. Leaves and stems (such as lettuce) can be put into food processor for juicing.
5. Fruits containing starch such as banana, papaya, avocado, figs and mango are not
suitable to be put into food processor to make juice, but they can be processed with
the blending function (optional).

Nutrition constituent of common fruits and vegetable and the speed selection are
shown as follows:
Fruits /
Vegetables
Vitamin/Mineral substance
KJ/Calorie
Speed
Selection
Apple
Vitamin C
200g=150 KJ(72 calorie)
2
Apricot
Rich in DF, containing potassium.
30g=85KJ(20 calorie)
1
Beet
Source of folic acid, DF, vitamin
C and potassium.
160g=190KJ(45 calorie)
2
Blueberry
Vitamin C
125g=295KJ(70 calorie)
1
Brussel
Sprouts
Vitamin C, B, B6, E, folic acid
and DF.
100g=110KJ(26 calorie)
1
Cabbage
Vitamin C, folic acid, potassium,
B6 and DF.
100g=110KJ(26 calorie)
2
Carrot
Vitamin A, C, B6, E and DF.
120g=125KJ(30 calorie)
2
Celery
Vitamin C and potassium
80g=55KJ(7 calorie)
2
Cucumber
Vitamin C
280g=120KJ(29 calorie)
1
Fennel
Vitamin C and DF.
300g=145KJ(35calorie)
1
Grape
Vitamin C, B6, and DF.
125g=355KJ(85calorie)
1
Kiwi
Vitamin C and potassium
100g=100KJ(40calorie)
1
Melon
Vitamin C, folic acid, DF and
vitamin A
200g=210KJ(50calorie)
1
Nectarine
Vitamin C, B3, potassium and DF.
180g=355KJ(85calorie)
2
Peach
Vitamin C, B3, potassium and DF.
150g=205KJ(49calorie)
2
Pear
DF
150g=250KJ(60calorie)
2
Pineapple
Vitamin C
150g=245KJ(59calorie)
2
Raspberry
Vitamin C, iron, potassium and
magnesium
125g=130KJ(31calorie)
1
Potato
Vitamin C, DF, vitamin E, folic
acid and vitamin A
100g=90KJ(22calorie)
1

Care and Cleaning
1
Shut down the switch and power off before cleaning.
2
Immediate cleaning is necessary after using the product.
3
Use a damp cloth to clean the outer part of the main body.
Do not place or wash in water or other liquids.
4
Place the juicer in dry place and away from ultraviolet
rays.
5
Ensure the juicer is clean and dry before storage.
6
Each detachable part can be cleaned according to the
following steps:
1
Take out the pomace container;
Take down the food pusher.
2
Press the “Unlock” button and open the top cover.
3
Take off the top cover, sieve and central holder in a
proper order. (Note: When cleaning the juicer, add
cleaning agent into the water. Clean the sieve with a
brush and wash it clean with clear water. Other parts can
be cleaned with water directly.)
4
Take off the juice nozzle on central holder for better
cleaning.

Troubleshooting
Problem
Analysis
Solution
Unable to
start switch.
Juicer fails to
work.
1. Improper installation of central
holder.
2. Top cover installed in wrong
place.
3. Cup, central holder and main
body installed in incorrectly.
1. Install central/middle holder in
the proper place.
2. Install top cover in the proper
place.
3. Install each part in the proper
place.
Motor gives
off
unpleasant
smell at the
first few
times of use.
It is normal.
If after repeated use and the smell
persists, send the juicer to the
nearest Customer Care Centre.
The juicer
stops when
operating.
1. Voltage is too low.
2. Excessive ingredients.
3. Pushing the pusher with
excessive force.
4. Motor overheat protection
activated.
1. Check if the voltage is too low.
2. Disconnect the power and take
out the surplus ingredients.
3. Push the food pusher gently.
4. Restart operation after stopping
for 20-30 minutes.
Excessive
juice pulp
contained in
the juice.
1. The sieve might be broken.
2. Too much juice pulp gathered
in the central holder.
1. Check and replace the sieve.
2. Clean the central holder.
Abnormal
vibration or
noisy.
1. Improper installation of sieve
and causing poor running
balance.
2. Unstable placement of juicer or
the juicer is released off its
footing.
3. Voltage is too high.
4. Excessive ingredients.
5. Central holder and sieve are
not tightened.
1. Install the sieve in proper
position.
2. Place the juicer and fix the feet
properly on a stable surface.
3. Check if the voltage is too high.
4. Disconnect power to take out
the surplus ingredients.
5. Tighten sieve and central holder.
Too less juice
1. Too much juice pulp trapped in
the central holder.
2. Food pusher pressed with
excessive force.
1. Clean the central holder.
2. Press the pusher with proper
force.
Note: The above mentioned contents are common fault analysis and troubleshooting.
For other issues, please contact the Customer Care Centre or send directly for repair at
the company designated maintenance point. Do not self-repair or disassemble the
appliance.
