Cornwell Tools CTGPL User manual

CTGPL 8/4/14
CTGPL
26 LED
Pivot Work Light
Instructions • Warning Information
Main Work Light LED .................................... 21
Base Light LED ......................................... 5
Main Work Light Lumens ........................... 60 Lumens
Base Light Lumens................................ 15 Lumens
Rechargable Battery........................3.6V 1600m Ah Ni-Mh
Runtime approximately...............................4-5 hours
Recharging time approximately ..........................5 hours
SPECIFICATIONS
Always read instructions
before using tools
Always wear
safety goggles
WARNING
Copyright © Professional Tool Products, 2014
All rights reserved

CTGPL 2 8/4/14
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. READ THIS INSTRUCTION
MANUAL CAREFULLY AND UNDERSTAND ALL INFORMATION BEFORE OPERATING THIS TOOL.
• It is the responsibility of the owner to make sure all personnel read this manual prior to using the device.
It is also the responsibility of the device owner to keep this manual intact and in a convenient location
for all to see and read. If the manual or product labels are lost or not legible, contact Cornwell Tools®
for replacements. If the operator is not fluent in English, the product and safety instructions shall be read
and discussed with the operator in the operator's native language by the purchaser/owner or his
designee, making sure that the operator comprehends its contents.
• Whenusingthisproduct,basicsafetyprecautionsincludingthefollowingshouldalwaysbefollowedtoreduce
risk of fire, electric shock, personal injury and material damage.
• Alwayswearimpact-resistanteyeandfaceprotectionwhenoperatingorperformingmaintenanceonthistool.
•Keepthetoolinefficientoperatingcondition.
• Donotuseorchargethelightwhenthetemperatureisover104°F(40°C)orlowerthan-4°F(-20°C).
•Donotstorelightattemperatureabove120°F(49°C).
• Donotputtheworklightnearover-heatedobjects.
• Keepawayfromacidandalkalineobjects.
•Donotoperatelightinexplosiveatmospheres,suchasinthepresenceofflammableliquids,gasesordust.
Lights create sparks which may ignite the dust or fumes.
• Avoidbumpsanddropping.
•Batterypackspresentariskoffire,explosionandelectricshockwhichcancausepersonalinjury
• Thisunitisnotwaterproofandisnotintendedforuseinshower,sauna,orinpotentiallywetlocations.Always
keep this unit away from sink, tub, shower and etc.
• Thisunitisintendedforgeneralindooruseonly.
• Keepoutofreachofchildren.
• Donotlookdirectlyintothelightduringoperationoftheunit.Thiscanbeharmfultotheeyesevenforabrief
period due to intense light.
• Chargebatterypackonlywithchargerprovided.Othertypesofbatteriesmayburst,causingpropertydamage
and personal injury.
•Donotdiscardusedbatteries–returnthemtoyourlocalrecyclingproviderforrecycling.
• CAUTION: Magneticforcescanbeharmfultopersonalpropertyandequipmentincludingcellphones,
computers,diagnosticequipmentandcreditcards.
•ThisproductmaycontainoneormorechemicalsknowntotheStateofCaliforniatocausecancerandbirth
defects or other reproductive harm. Wash hands thoroughly after handling.
•Failuretoheedanyofthesewarningsmayresultinpersonalinjuryand/orpropertydamage.
FAILURE TO OBSERVE THESE WARNINGS COULD RE SULT IN IN JU RY.
WARNING

CTGPL 3 8/4/14
CTGPL
26 LED
Pivot Light
Ref. # Item # Description Qty
 1 CTGPL PivotLight 1
 2 CTGPLH Hanger/Hook 1
 3 CTGPLENS LensCover 1
 4 CTGPLCHACA ACCharger 1
 5 CTGPLCH12 DCPortableCharger 1
Alsoavailable:RSCTGPLWLWarningLabel
4
2
5
1
3

CTGPL 4 8/4/14
Routine Maintenance
Battery Pack-Once in every three months, remove the
battery pack from the work light and visually inspect
for signs of gas or chemical leakage. If any signs are
observed the battery pack should be removed from
service to prevent chemical damage to inside the work
light.
• Remove dirt and grease as soon as it accumulates.
Use a soft, damp cloth and a mild soap.
•NEVER submerge any part of the light in any solution
to clean it.
• DO NOT USE solvents such as gasoline, turpentine,
etc. to clean the unit.
Mounting the charger
AC and DC power cords are available. To charge the
work light, switch off and insert the charge plug firmly
into the work light receptacle. Connect the charger to an
appropriate power source.
AC Charging Adaptor
Connect the adaptor cord to the work light charging
receptacle, only with the AC power source in the
“OFF”position.Otherwise,itmayresultin the damage
of the recharging system. Refer to specifications for
detailsregardingchargingtime.ThereisindicatoronAC
charger. When the indicator changes from red to green,
pull the charger plug out and store properly.
Installing the DC Option
TheDCAdaptorisofferedasanoptionforthosewholike
to mount 26 LED Pivot Work Light system in their vehicles.
When installing or using the 26 LED Pivot Work Light in a
vehicle, always make sure that the work light case does
not touch the chassis. This can result in damage to the
work light.
PlugtheDCpowercordAdaptorintothecigarettelighter
receptacle of the vehicle. Do not leave adaptor plugged
inforanyextendedperiodwhileengineis“OFF”toavoid
draining battery.
Operation
1. Depresstheupperswitchforworklight
2. Depress the lower switch for base light
Warranty
LIMITED12-MONTHWARRANTY
Cornwell Tools warrants to the original purchaser that the company’s 26 LED Pivot Work Light are free from defects in
material or workmanship during the one year warranty period. We will replace any 26 LED Pivot Work Light which fails to
give satisfactory service due to defective workmanship or materials for 12 months from the date of original purchase.
Products must be returned with proof of purchase, to an authorized Cornwell dealer.
Thiswarrantyexcludes26LEDPivotWorkLightwhichhavebeensubjectedtoabnormaluse,accident,neglect,orlackof
maintenance.Anymodification,disassemblyofthis26LEDPivotWorkLightorrepairbyanunauthorizedservicecenterwill
void the warranty.
Thiswarrantygivesyouspecificrights.Youmayalsohaveotherrightswhichvaryfromstatetostate.
The foregoing obligation is Cornwell Tools' sole liability under this or any implied warranty and under no circumstances shall
CornwellToolsbeliableforanyincidentalorconsequentialdamages.
Note:Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamagessotheabovelimitation
orexclusionmaynotapplytoyou.
