Corsair iCUE ELITE LCD UPGRADE KIT User manual

iCUE ELITE LCD UPGRADE KIT
LCD ACCESSORY KIT FOR ELITE CAPELLIX AIO CPU COOLERS
ENGLISH
EN ITALIANO IT PУССКИЙ
RU
FRANÇAIS
FR ESPAÑOL ES 简体中文
SC
ةيبرعلا
AR
DEUTSCH
DE PORTUGUÊS PT
NEDERLANDS
NL POLSKI PL

1
ENGLISH
ENGLISH
A
B C
LCD Module
x4 Mounting Screws x1 USB Y-Splitter
INCLUDED HARDWARE

2
ENGLISH
ENGLISH
COMMANDER CORE UPDATE
Please ensure you’ve updated your Elite Capellix’s rmware PRIOR
to installation. Failure to update rmware will result in Commander CORE
not recognizing the LCD Kit. The LCD will then return a general
fault (!) error.
Please ensure you power down your entire PC before installation.
This product, the pump, and the Commander CORE are sensitive to
hotplugging and ESD.
In iCUE, click on your Commander CORE or
ELITE CAPELLIX cooler and select ‘Device
Settings’.
Under ‘Device Settings’ you will have the
ability to check for rmware updates.

3
ENGLISH
ENGLISH
1
3
2
4
PREPARING COOLER
MOUNTING SCREW
INSTALLATION
ELITE LCD MODULE
INSTALLATION

4
ENGLISH
ENGLISH
6 5 4 3 2 1
65 4 3 2 1
RGB HUB
FANS
65 4 3 2 1
654321
RGB HUB
FANS
PLUG INTO COMMANDER CORE
PLUG IN USBs
Connect Commander CORE and LCD Kit to 2x USB 2.0 Headers.
Use included USB Y-Splitter to reduce required USB ports from 2x to 1x.
