Cosen C-420NC User manual

COSEN SAWS







C-420NC
SNC‐100ProgrammableAutomatic
MassProductionHorizontalBandsaw



InstructionManual




ThePinnacleofCuttingPerformance
CosenMechatronicsCo.,Ltd.




NOTE:
Readthisinstructionmanualcarefullytofamiliarizeyourselfwiththeinstallation,operation
andmaintenanceofyourCOSENbandsawmachine.
Operatethemachinefollowingtheproceduresdescribedinthemanualtopreventpersonal
injuriesormachinedamage.
Keepthismanualhandyandrefertoitwheneveryouareuncertainofhowtoperformanyof
theprocedures.
Fortechnicalsupportorpartspurchase,pleasecontactyournearestCOSENrepresentativeor
ourservicecenter:
ForUS,Mexico,andCanada:
email:[email protected].
phone:+1‐704‐943‐1030
tollfree:+1‐877‐SAWING1
fax:+1‐704‐943‐1031

ForTaiwanandothercountries:
email:[email protected]
phone:+886‐3‐5332143
fax:+886‐3‐5348324
ForEurope:
email:
[email protected]
phone:+31‐77‐7600280
fax:+31‐77‐7600288
ForChina:
email:[email protected]
phone:+86‐152‐50127815



InstructionManual: C‐420NC
SNC‐100ProgrammableAutomaticMassProductionHorizontalBandsaw
Ver.52017/1/23

©2013byCOSENMECHATRONICSCO.,LTD.
NopartofthispublicationmaybephotocopiedorotherwisereproducedwithoutthepriorwrittenpermissionofCOSEN.


PrintedinTaiwan
FROMTHEMANUFACTURER

ThankyouforyourpurchaseofCOSEN’sbandsawmachineandyourtrustinthe
COSENbrand.

Weareexcitedtohaveyouasourvaluedcustomerandlookforwardasmuchasyou
dototheacceleratedproductivity,long‐lastingenduranceandsuperb
cost‐effectivenessthismachineisabouttobringtoyou.

Toensureyouarefullyutilizingourmachineandbeingadvantagedineverypossible
way,pleasedotakeyourtimeandreadthroughthisinstructionmanual.

Anycommentorsuggestioninmakingourservicebetter,pleasedonothesitateto
letusknow.Thankyouagain!


Safety rules
Makesureyourworkareaisclearedofuninvitedpeopleandobstacleseverytimebeforeyoustart
operatingthemachine.
Neverwearglovesorlooseclothingwhenoperatingthemachine.Itmayleadtoseriousinjuryifthey
arecaughtintherunningmachine.Wraporcoverlonghair.
Useawater‐solublecuttingfluidonthismachine.Oil‐basedcuttingfluidsmayemitsmokeorcatch
fire,dependingonhowtheyareused.
Nevercutcarbonoranyothermaterialthatmayproduceanddisperseexplosivedust.Itispossible
thatsparksfrommotorsandothermachinepartswilligniteandexplodetheair‐bornedust.
Makesureanyuseoffireisprohibitedintheshopandinstallafireextinguisherorotherfirecontrol
devicenearthemachinewhencuttingtitanium,magnesium,oranyothermaterialthatproduces
flammablechips.Neverleavethemachineunattendedwhencuttingflammablematerials.
Neveradjustthewirebrushorremovechipswhilethesawbladeisstillrunning.Itisextremely
dangerousifhandsorclothingarecaughtbytherunningblade.
Nevertouchtherunningsawbladewithglovesornot.Itisdangerousifyourhands,clothingor
glovesarecaughtbytherunningblade.
Stopthesawbladebeforeyoucleanthemachine.Itisdangerousifhandsorclothingarecaughtby
therunningblade.
Neverstartthesawbladeunlesstheworkpiecehasbeenclampedfirmly.Iftheworkpieceisnot
securelyclamped,itwillbeforcedoutoftheviseduringcutting.
Takepreventivemeasureswhencuttingthinorshortpiecesfromtheworktokeepthemfrom
falling.Itisdangerousifthecutpiecesfall.
Userollertablesatthefrontandrearsidesofthemachinewhencuttinglongwork.Itisdangerousif
theworkpiecefallsoffthemachine.
Neversteporstandontherollertable.Yourfootmaysliportripontherollersandyouwillfall.
Turnofftheshopcircuitbreakerswitchbeforeperformingmaintenanceonthemachine.
Postasignindicatingthemachineisundermaintenance.


i
T
able of Contents

Section1–SafetyInformation1‐1
SafetyInstructions……………………………………………………………………………………………………… 1‐1
SafeguardDevices………………………………………………………………………………………………………. 1‐3
EmergencyStop…………………………………………………………………………………………………………. 1‐4
Illustration:EmergencyStop……………………………………………………………………………………… 1‐5
SafetyLabels………………………………………………………………………………………………………………. 1‐6
Illustration:SafetyLabels………………………………………………………………………………………..… 1‐7
HearingProtection……………………………………………………………………………………………………… 1‐8
CECompliance……………………………………………………………………………………………………………. 1‐8
RiskAssessment…………………………………………………………………………………………………………. 1‐8
Section2–GeneralInformation2‐1
Specifications……………………………………..………………………………………………………………………. 2‐2
MachinePartsIdentification………………………………………………………………………………………. 2‐3
FloorPlan…………………………………………………………………………………………………..………………. 2‐5
Section3–Moving&Installation3‐1
Location&Environment………………………………..…………………………………………………………… 3‐1
Unpacking&Inspecting……..………………………………………………………………………………………. 3‐2
Lifting…………………………………………..………………………………………………………………….…………. 3‐3
Illustration:LiftingPoints…………………………………………………………………….……………….…… 3‐4
RemovingShippingBracket…………………………..……………………………………………….…………… 3‐6
Cleaning…………………………………………..…………………………………………………………….…………… 3‐6
Installing…………………………...………………………………………………………………………….……………. 3‐6
SupplyingHydraulicOil…………………………………………………………………….……………. 3‐6
SupplyingCoolant………..………………………………………………………………….…………….. 3‐7
ConnectingElectricPower……………………………………………………………….…………….. 3‐7
Leveling…………………………………………………………………….…………………………………… 3‐8
AnchoringtheMachine…………………………………………………………………….…………… 3‐9
InstallingRollerTable(Optional)………………………………………………….…………………. 3‐9
InstallingFireControlDevice………………………………………………….……………………… 3‐9
Relocating………………………...…………………………………………………………………….…………………. 3‐9
Section4–OperatingInstruction4‐1
SafetyPrecautions…………………..…………………..……………………………………….……………………. 4‐2
BeforeOperating…………………………..……………………………………………………………………………. 4‐3
ControlPanel……..……………………………………..………………………………………….……………………. 4‐4
ControlPanel………………….………………………………………………………………………..……. 4‐4

ii
T
able of Contents
ControlButtons……………………………………………………………………………………….…….. 4‐5
BladeDescendPressure&SpeedControlPanel………..…………..………………….…… 4‐7
HMITouchScreen&Functions…………………………………………………………….………… 4‐7
HMIErrorCodes………………………..……………………………………………………….…………. 4‐18
StandardAccessories………….………………………..……………………………………………….…………… 4‐19
OptionalAccessories…….…….………………………..…………………………………………….……………… 4‐21
Unrolling&InstallingtheBlade…………………………………………………………………….……………. 4‐23
AdjustingWireBrush………..……………………………………………………………………….………………. 4‐25
AdjustingSawArm………..……………………………………………………………………….………………….. 4‐25
AdjustingCoolantFlow………..………..…………………………………………………………………..…….… 4‐26
PlacingWorkpieceOntoWorkbed………..………..…………………………………….……………………. 4‐26
PositioningWorkpieceforCutting………..………..………………………………….…………………….… 4‐27
AdjustingBladeSpeed………..………..………………………………………………………………………….… 4‐28
Breaking‐IntheBlade………..………..…………………………………………………………………..……….… 4‐28
Test‐RunningtheMachine………..………………..…..…………………………………………………………. 4‐28
CuttingOperation………..………..……………………………………………..……………………………………. 4‐29
StartinganAutomaticOperation………..………..………………………….………………………………… 4‐30
UsingTopClampforBundleCutting………..……….………………………………………………………… 4‐30
TerminatingaCuttingOperation………..………..…………………………………….………………………. 4‐31
Section5–ElectricalSystem5‐1
ElectricalCircuitDiagrams……….…………………..…………………………………………………………….. 5‐1
Section6–HydraulicSystem6‐1
HydraulicDiagrams……….…………………..……………………………………………………………….………. 6‐1
Section7–BandsawCutting:APracticalGuide7‐1
Introduction……………………….…….…………………..……………………………………………………………. 7‐1
SawBladeSelection………………….…………………..…………………………………………………………… 7‐1
SomeSawingPractices…………….…………………..………………………………………….………………… 7‐4
SawPitchSelection……………………………………………………………………….……………….. 7‐4
MaterialSizeandSawPitch………………………………………………….….……………………. 7‐4
Section8–Maintenance&Service8‐1
Introduction……………………….…….…………………..……………………………………………………………. 8‐1
BasicMaintenance………………….…………………..…………………………………………….………………. 8‐1
MaintenanceSchedule…………….…………………..……………………………………………………………. 8‐2
BeforeBeginningaDay’sWork………………………………………………………………………. 8‐2
AfterEndingaDay’sWork…………………………………………………….……………………….. 8‐2
EveryMonth………………………………………………………………………….………………………. 8‐2

iii
T
able of Contents
EveryThreeMonths………………..…………………………………………….………………………. 8‐2
EverySixMonths……………….………………………………………………….………………………. 8‐3
StorageConditions…………………………....………..…………………………………………………………….. 8‐3
TerminatingtheUseofMachine……..…………..…………………………………………………………….. 8‐3
OilRecommendationforMaintenance………………………………………………………………………. 8‐4
Section9–Troubleshooting9‐1
Introduction……………………….…….…………………..……………………………………………………………. 9‐1
Precautions………………….…………………..……………………………………………………………………..... 9‐2
GeneralTroubles&Solutions………………………..……………………………………………………………. 9‐2
MinorTroubles&Solutions………………………..………………………………………………..……………. 9‐3
MotorTroubles&Solutions………………………..…………………………………………………..…………. 9‐3
BladeTroubles&Solutions………………………..……………………………………………………………….. 9‐4
SawingProblems&Solutions………………………..…………………………………………………………… 9‐5
Re‐AdjustingtheRollerTable………………………..……………………………………………………………. 9‐6
Section10–Parts10‐1
SparePartsRecommendations…………………..………………………………………………………………. 10‐1
PartList………………………………………………………………………………………………………………………. 10‐2
Section11–Warranty11‐1
Warranty…………………..……………………………………………………………………………………………….. 11‐1




1‐1
Section1
SAFETY
INFORMATION

SAFETYINSTRUCTIONS
SAFEGUARDDEVICES
EMERGENCYSTOP
SAFETYLABELS
HEARINGPROTECTION
CECOMPLIANCE
RISKASSESSMENT


Safetyisacombinationofawell‐designedmachine,operator’sknowledgeaboutthemachineand
alertnessatalltimes.COSEN’sbandmachinehasincorporatedmanysafetymeasuresduringthe
designprocessandusedprotectivedevicestopreventpersonalinjuriesandpotentialrisks.Warning
labelsalsoserveasaremindertotheoperator.

Throughoutthismanual,youwillalsoseevarioussafety‐relatedsymbolsindicatingimportant
informationthatyoushouldtakenoteofpriortouseofthemachineorpartofitsfunctions.These
importantsafetyinstructionsdonotcoverallpossiblesituationsthatmightoccur.Itisyour
responsibilitytotakecautionandfollowproceduresstatedinthismanualwheninstalling,
maintainingandoperatingyourmachine.Cosenwillnotbeliablefordamagesresultingfrom
improperuse.


SAFETYINSTRUCTIONS
Whattheiconsandsignsinthisusermanualmean:

ThisiconmarksDANGER;hazardsorunsafepracticesthatmayresultinsevere
personalinjuryordeath.

ThisiconmarksWARNING;hazardsorunsafepracticesthatmayresultin
personalinjuryordamagetothemachine.

ThisiconmarksCAUTION;informationthatshouldbereadbeforeusetoprevent
damagetothemachine.
Supplementaryinformationtotheproceduresdescribedinthismanual.
Callyourlocalagentorourservicecenterforhelp.

1‐2


Thismanualhasimportantsafety
information.Readthroughitcarefully
beforeoperatingthismachinetoprevent
personalinjuryormachinedamage.Learn
theoperation,limitationandthespecific
potentialhazardspeculiartothisband
saw.

Donotoperatethismachineunlessitis
completelyassembled.

Makesurethepowerswitchisoffbefore
plugginginpowercord.

Disconnectthepowercordbeforemaking
adjustment,maintenanceorblade
changes.

Keepallguardsandshieldsinplacebefore
installingorstartingupthemachine.

Wearproperapparelduringoperation
andwhenservicingthemachine.
Keepunauthorizedpersonnelaway.

Donotreachoverorstandonanypartof
themachine.

Neverholdthematerialbyhandfor
cutting.Alwaysusetheviseandmake
surethematerialisclampedsecurely
beforecutting.

Itisdangeroustooperatethemachine
whenthefloorisslippery.Keepthefloor
cleananddry.Checkforice,moisture,or
greasebeforeentering.

Donotusethemachinetocutexplosive
materialorhighpressurevesselsasitwill
generategreatamountofheatduringthe
sawingprocessandmayignitean
explosion.

Keeptheworkenvironmentsafe.Donot
usebandsawinadamporwetlocation.

Neveroperatewhileundertheinfluence
ofdrugs,alcoholormedication.

Allusersmustreaditbeforeperformingany
activityonthemachine,suchasreplacing
thesawbandordoingregularmaintenance.
Somepersonalprotectiveequipmentis
requiredforthesafeuseofthemachine,e.g.
protectiongoggles.
Keepbladeprotectioncoverandwheel
coversinplaceandinworkingorder.
Userecommendedaccessories.Improper
accessoriesmaybehazardous.
Keepyourworkareawellilluminatedat
minimum500lumen.
Keepyourworkareaclean.Clutteredand
slipperyfloorsinviteaccidents.
Removeadjustingkeys,wrenchesorany
loosepartsoritemsfromthemachine
beforeturningonpower.
Checkfordamagedparts.Beforecontinuing
usingthemachine,thedamagedpartshould
becheckedandreplaced.
Movingpartsshouldbekeptinproper
alignmentandconnectionwiththemachine.
Checkforbreakage,mountingandanyother
conditionsthatmayaffectitsoperation.Any
damagedpartorguardshouldbeproperly
repairedorreplaced.
Whenaworkpieceistoolongorheavy,
makesureitissupportedwitharollertable
(recommended).
Alwaysremembertoswitchoffthemachine
whentheworkiscompleted.
Useasharpsawbladeandkeepthemachine
initsbestandsafestperformanceby
followingaperiodicalmaintenanceschedule.
Donotforcethebandsawbeyondits
intendeduse.Itissafertooperatewiththe
cuttingrateforwhichitwasdesigned.


1‐3
SAFEGUARDDEVICES
Thesafeguarddevicesincorporatedinthismachineincludethefollowingtwomainparts:
1. Protectioncovers&guards
2. Safety‐relatedswitches

ProtectionCovers&Guards
1. Idlewheelhousingcover
2. Drivewheelhousingcover
3. Gearreducercover
4. Wirebrushbeltcover
5. Bladeguardcover(left&right)

Theprotectiondevicesshouldalwaysbemountedonthemachinewheneverthemachineisrunning.
Donotremoveanyofthesesafeguarddevicesunderanycircumstancesexceptwhenservicingthe
machine.Evenskilledservicetechniciansshouldstilltakecautionswhenperformingrepairsorservice
onthemachinewithanyoftheseprotectorsremoved.Itistheresponsibilityoftheusertomakesureall
theseelementsarenotlostanddamaged.
Takenoteofthefollowingmainmovingpartsonthemachinepriortoandduringmachineoperation:
Sawbowassembly
Driveandidlewheels
Bladeguidearm
Sawbladeguiderollers
Quickapproachdevice
Wirebrush
Chipconveyor(optional)
Workpiececlampingvises
Shuttlevisesandworkbedrollers
Topclamps(optional)
Gearreducer










1‐4
SafetyRelatedSwitches
Toprotecttheoperator,thefollowingsafetyrelatedswitchesonthemachineareactuatedwhenthe
machineisinoperation.

WheelmotiondetectorThisisaproximitysensorusedtodetectthemotion
ofthedrivewheel.Oncethesawbladeisbrokenor
assoonasitstartsslipping,thesensorwilldetect
andstopthedrivewheelandthemachine.
PowerswitchLocatedonthecoverofelectricalcabinet,thepower
switchcontrolsthemainpowerofthemachine.Up
toyourcompany’sinternalrules,thispowerswitch
canbelockedwithapadlockoraluggagelockto
protecttheoperatorandthemachine.
EmergencystopbuttonLocatedonthecontrolpanel,thebuttonwhen
pressedwillstopthemachinecompletely.
ViseclampswitchThisswitchassuresfirmclampingoftheworkpiece.If
theworkpieceisnotclampedproperly,thesaw
bladeisnotallowedtorun.
Wheelcoverinterlockswitches
(CEmodelonly)
Locatedonthetwowheelhousings,theseswitches
areusedtoassurethatthemachinewillstop
wheneverthewheelcoversareopen.Thisdeviceis
toprotectusersfrombeingcutbytherunningsaw
blades.

Amongallthesesafetyswitches,someofthemareusedtoprotecttheusersandsomeofthemare
usedtopreventdamagetosawblades,theworkpieceandthemachineitself,etc.Wehavetaken
everyprecautiontopreventinjuryordamageandtoprovidesafeandeconomicaloperationofthe
machine.


EMERGENCYSTOP
Designedtobeeasilyaccessible,theemergencystopbuttonislocatedontheleftbottomcorneron
thecontrolpanelandismadeinredcolorandrubbermaterial.ForCEmodels,supplementary
emergencystopbuttonmaybeavailableatotherarea(s)ofthemachinedependingonmachinetype.
PleaserefertoIllustration:EmergencyStop.
Whenyoupressthebutton,themachinewillimmediatelycometoafullstoptoavoidinjuryor
damagewhenanaccidentoccurs.Thebuttonwillbelockedwhenyoupressit.Tounlockit,pullit
upward.
Youshouldpressitimmediatelywithoutanyhesitationwhenobserving:
Anemergencysituationthatwouldcauseanyinjuryordamage
Anabnormalsituationorproblemsuchasfire,smoke,abnormalnoiseandetc.

1‐5
Illustration:EmergencyStop










Emergency
StopButton

1‐6
SAFETYLABELS
Pleasereadthroughandunderstandthesesafetylabelsbeforeoperatingthemachine.Referto
Illustration:SafetyLabels.

LabelMeaningLabelMeaning

ImpactHazard

WEARSAFETYSHOES.Do
notapproachdroppingarea
duringoperation.
ReadOperator’sManual

Thismanualhasimportantsafety
information.Readthroughit
carefullybeforeoperatingthis
machinetopreventpersonalinjury
ormachinedamage.

KeepUnauthorized
PersonnelAway



Donotstep.

Donotstandonthemachineoron
theaccessories!

DANGER:RunningBlade

Bladerunsthroughthis
area.Keepyourhandsaway
fromarunningbladeto
avoidsevereinjury.The
arrowindicatesdirectionof
theblade.

CuttingHazard

KEEPCOVERCLOSED/KEEPHAND
OFFwhilethebladeisrunning.
Turnpoweroffbeforeopening
cover.Failuretofollowthewarning
canresultinsevereinjury.

HazardousVoltage

TURNPOWEROFFbefore
servicing.Failureto
followingthewarningcan
resultinsevereinjury.

BurnHazard/HotSurface

HandCrush/Forcefrom
Above

Crushhazardbyvise

LooseHandHazard

KEEPHANDOFF.Donot
touchchipconveyor.Failure
tofollowthewarningcan
resultinsevereinjury.

PinchPoint/HandEntanglement





1‐7
Illustration:SafetyLabels



1‐8
HEARINGPROTECTION
Alwaysuseearprotection!
Whenyourmachineisrunning,noisegeneratedbythemachinemaycomefromthefollowing:
Sawbladeduringcuttingormaterialfeedmechanism
Wirebrushunit
Chipconveyorunit
Speedreducer
Hydraulicmotor/pump
Belttransmissionsvariablespeedmotors
Blademotor
Coolantpump
Drivewheel
Partsnotassembledtightlycausingmechanicalvibration

Ourproductspassnoisetestinglessthan78dBA.Noiselevelvaryaccordingtoworkingconditions
andwerecommendearplugsorotherhearingprotectionatalltime.Ifyourmachineproducesan
undesirablenoisewhileitisrunning,youshould:
1. Makesureallmaintenancetaskshavebeenperformedfollowingtheprescribedmaintenance
schedule(RefertoSection8).
2. Ifmaintenancedoesnotseemtosolvetheproblem,followthetroubleshootingprocedures
underSection9.


CECOMPLIANCE
Cosen’sCEmodelisdesignedtosatisfyregulationsoftheCouncilDirectiveontheapproximationof
thelawsoftheMemberStatesrelatingtomachinery(2006/42/EC)‐AnnexIEssentialhealthand
safetyrequirementsrelatingtothedesignandconstructionofmachinery.


RISKASSESSMENT
Riskassessmentgenerallytakesaccountofintendeduseandforeseeablemisuse,includingprocess
controlandmaintenancerequirements.Wemadeeveryefforttoavoidanypersonalinjuryor
equipmentdamageduringthemachinedesignstage.However,theoperator(orotherpeople)still
needstotakeprecautionswhenhandlinganypartofthemachinethatisunfamiliarandanywhereon
themachinethathaspotentialhazards(e.g.theelectricalcontrolbox).




2‐1
Section2
GENERAL
INFORMATION

SPECIFICATION
MACHINEPARTSIDENTIFICATION
FLOORPLAN


ThisbandsawmachineisdesignedbyCosen’sR&Dengineerstoprovideyouthefollowingfeatures
andadvantages:
Safety
Thismachineisdesignedtofullyprotecttheoperatorfromitsmovingpartsduringcutting
operation.
Themachineandeachcompomenthaspassedstricttesting(CouncilDirectiveonthe
approximationofthelawsoftheMemberStatesrelatingtoMachinery).
Themachinewillshutoffautomaticallywhenthesawbladeisbroken,protectingboththe
operatorandthemachine.
Convenience&High‐Performance
Themachineisdesignedinthewaythattheoperationandadjustmentcanbeeasily
performed.
Themachinewillstopautomaticallywhenoutofstock.
Dualvalvesystemisdesignedtoachieveoptimalcuttingperformancewiththesimple
settingoffeedrateandperspectivecuttingpressurefordifferentmaterial.
Durability
Theintendedlife‐spanofthemachineiscountedbasedonregulardailyoperation.Itis
calculatedwiththelifeexpectancyof10yearsundernormaloperatingconditionandexact
attentiontothemaintenanceschedule.
8hours×5days×52weeks×10years＝20,800hours



2‐2
SPECIFICATION

Model
C‐420NC
SNC‐100ProgrammableAutomaticMassProductionHorizontal
Bandsaw
Capacity
Round 16.5” (420 mm)
Square16.5” (420 mm)
Rectangular(HxW)16.5” x16.5” (420x420 mm)
BundleCutting W:7.5” ~14.2”(190 ~360mm)
H:3.9”~7.1”(100~180mm)
SawBlade
Speed66~328
f
pm(20 ~100m/min)
Size187.8”x1.6” x0.05” (4,770 x41 x1.3 mm)
TensionHydraulicwithautomaticbladebreakagedetection
GuideInterchangeabletungstencarbide
CleaningSteelwirebrushwithflexibledriveshaftdrivenbymainmotor
Motor
Output
SawBlade7.5HP(5.6kW)
Hydraulic2HP(1.5kW)
CoolantPump1/8 HP(0.1kW)
Tank
Capacity
Hydraulic10.6 gal (40 L)
Coolant22.5 gal (85 L)
Feeding
Length
ModeHydraulic,NCAutomatic
SingleStroke19.8” (503 mm)
MultiStrokeMax.999”(99 m)
RestPiece2.4” (60 mm)
WorkbedHeight28.9” (735 mm)
Weight
Net4,664 lb (2,120kg)
Gross4,891 lb (2,223 kg)
FloorSpace(LxWxH)110.4” x100.8” x74.9”(2,805 x2,560 x1,903mm)








2‐3
MACHINEPARTSIDENTIFICATION




















Machinefrontview





Machinesideview
Gear Reducer
Workbed Feed Roller
Vertical Alignment Roller
Roller Table (Optional)
Coolant pump
Cleaning Hose

Top Clamp (optional)
Double Column
Wire Brush Assembly
Quick Approach Bar
Idle Wheel
Drive Wheel
Chip Conveyor
(optional)
Blade Guide Arm
Blade Tension Controlle
r
Blade Tension Meter
Control Panel with
dual control valve
Front Vise Cylinder
Electrical Compartment
Front Vise Bed
Cross Link

2‐4


Machinetopview













Chip Conveyor (optional)
Blade Motor
Rear Vise Feed Cylinder
Length Setting Stopper
Rear Vise Assembly
Rear Vise Cylinder
Control Panel
Discharge
Table
