MICROWAVE OVEN
COS-3012ORLP1SS
USER MANUAL
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
IMPORTANT:
INSTALLER:
OWNER:
OVER THE RANGE LOW PROFILE
MICROWAVE OVEN
Rev. 22.10

1
THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO Appliances are designed according to the strictest safety and
performance standard for the North American market. We follow the most
advanced manufacturing philosophy. Each appliance leaves the factory after
thorough quality inspection and testing. Our distributors and our service
partners are ready to answer any questions you may have regarding how to
install, use and case for your products. We hope that this manual will help you
learn to use the product in the safest and most effective manner.
Before using this product, please read through this manual carefully.
Keep
this user manual in a safe place for future reference. Please ensure that other
persons using this product are familiar with these instructions as well.
If you have any questions or concerns, please contact the dealer from whom you
purchased the product, or contact our Customer Support at:
1-888-784-3108
Reach us online at:
www.cosmoappliances.com

2
TABLE OF CONTENTS
MICROWAVE OVEN SAFETY............................................................................... 4
Important Safety Instructions ................................................................................. 5
PRODUCT OVERVIEW ......................................................................................... 9
Control Panel ........................................................................................................... 10
Display.........................................................................................................................11
FEATURES ...........................................................................................................12
Clock ........................................................................................................................... 12
Timer........................................................................................................................... 12
Settings (User Preferences).....................................................................................13
Turntable ...................................................................................................................14
USING THE MICROWAVE OVEN........................................................................14
Control Lock...............................................................................................................14
Cookware and Dinnerware ...................................................................................15
Manual Cook (Cook Time)......................................................................................16
Express Cook ............................................................................................................. 17
Popcorn...................................................................................................................... 17
Potato......................................................................................................................... 18
Sensor Reheat........................................................................................................... 18
Sensor Cook...............................................................................................................19
Snack Menus .............................................................................................................19
Melt/Soften ..............................................................................................................20
Auto Cook.................................................................................................................20
Auto Cook Recipes .............................................................................................. 21
Time Defrost ............................................................................................................. 26
Weight Defrost......................................................................................................... 27
Vent Fan.................................................................................................................... 28
Cooktop Light........................................................................................................... 28

3
MICROWAVE OVEN CARE ................................................................................ 29
General Cleaning.................................................................................................... 29
Installing/Replacing Filters and Lights ................................................................30
Grease Filters.......................................................................................................30
Charcoal Filters .................................................................................................... 31
Cooktop Lights .................................................................................................... 32
Cavity Light.......................................................................................................... 33
TROUBLESHOOTING......................................................................................... 34
LIMITED WARRANTY ........................................................................................ 36

4
MICROWAVE OVEN SAFETY
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
This device complies with Part 18 of the FCC Rules.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on
your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards
that can kill or hurt you and others.
All safety messages will follow the safety alert
symbol and either the word "WARNING" or
"CAUTION." These words mean:
You can be killed or seriously injured if you
don't follow instructions.
A potentially hazardous situation which, if not
avoided, could result in minor or moderate
injury.
All safety messages will tell you what the potential hazard is, tell you how
to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
California Proposition 65 Warning
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
WARNING
CAUTION

5
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of burns, electric shock, fire, injury to persons,
or exposure to excessive microwave energy:
•Read all instructions before using
the microwave oven.
•Read and follow the specific
"PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY" found in this section.
•The microwave oven must be
grounded. Connect only to
properly grounded outlet. See
"GROUNDING INSTRUCTIONS"
found in this section and in the
provided Installation Instructions.
•Install or locate the microwave
oven only in accordance with the
provided Installation Instructions.
•Some products such as whole
eggs in the shell and sealed
containers – for example, closed
glass jars – are able to explode
and should not be heated in the
microwave oven.
•Use the microwave oven only for
its intended use as described in
the manual. Do not use corrosive
chemicals or vapors in the
microwave oven. This type of
oven is specifically designed to
heat, cook, or dry food. It is not
designed for industrial or
laboratory use.
•As with any appliance, close
supervision is necessary when
used by children.
•Do not operate the microwave
oven if it has a damaged cord or
plug, if it is not working properly,
or if it has been damaged or
dropped.
•The microwave oven should be
serviced only by qualified service
personnel. Call an authorized
service company for examination,
repair, or adjustment.
•Do not cover or block any
openings on the microwave oven.
•Do not store this microwave oven
outdoors. Do not use the
microwave oven near water - for
example, near a kitchen sink, in a
wet basement, near a swimming
pool, or similar locations.
•Do not immerse cord or plug in
water.
•Keep cord away from heated
surfaces.
•Do not let cord hang over edge of
table or counter.
•See door surface cleaning
instructions in the "Microwave
Oven Care" section.
READ AND SAVE THESE INSTRUCTIONS

6
IMPORTANT SAFETY INSTRUCTIONS
•To reduce the risk of fire in the
oven cavity:
-Do not overcook food.
Carefully attend the
microwave oven when paper,
plastic, or other combustible
materials are placed inside the
oven to facilitate cooking.
-Remove wire twist-ties from
paper or plastic bags before
placing bags in oven.
-If materials inside the oven
ignite, keep oven door closed,
turn oven off, and disconnect
the power cord, or shut off
power at the fuse or circuit
breaker panel.
-Do not use the cavity for
storage purposes. Do not leave
paper products, cooking
utensils, or food in the cavity
when not in use.
•Do not mount over a sink.
•Do not store anything directly on
top of the microwave oven when
the microwave oven is in
operation.
•Clean Ventilating Hoods
Frequently - Grease should not
be allowed to accumulate on
hood or filter.
•When flambéing foods under the
hood, turn the fan on.
•Suitable for use above both gas
and electric cooking equipment.
•Liquids, such as water, coffee, or
tea are able to be overheated
beyond the boiling point without
appearing to be boiling. Visible
bubbling or boiling when the
container is removed from the
microwave oven is not always
present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A
SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to
persons:
-Do not overheat the liquid.
-Stir the liquid both before and
halfway through heating it.
-Do not use straight-sided
containers with narrow necks.
-After heating, allow the
container to stand in the
microwave oven for a short
time before removing the
container.
-Use extreme care when
inserting a spoon or other
utensil into the container.
•Intended to be used above
ranges with maximum width of
36" (91.44 cm).
•Use care when cleaning the vent-
hood filter. Corrosive cleaning
agents, such as lye-based oven
cleaners, may damage the filter.
READ AND SAVE THESE INSTRUCTIONS

7
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
•Do not attempt to operate this
oven with the door open since
open-door operation can result
in harmful exposure to
microwave energy. It is important
not to defeat or tamper with the
safety interlocks.
•Do not place any object between
the oven front face and the door
or allow soil or cleaner residue to
accumulate on sealing surfaces.
•Do not operate the oven if it is
damaged. It is particularly
important that the oven door
close properly and that there is
no damage to the:
(a) Door (bent),
(b) Hinges and latches (broken
or loosened),
(c) Door seals and sealing
surfaces.
•The oven should not be adjusted
or repaired by anyone except
properly qualified service
personnel.
READ AND SAVE THESE INSTRUCTIONS

8
ELECTRICAL REQUIREMENTS
•Plug into a grounded 3 prong outlet.
•Do not remove ground prong.
•Do not use an adapter.
•Do not use an extension cord.
•Failure to following these instructions can result in death, fire, or
electrical shock.
Observe all governing codes and ordinances.
Required:
•A 120 V, 60 Hz, AC only, 15 or 20 A electrical supply with a fuse or circuit
breaker.
Recommended:
•A time-delay fuse or time-delay circuit breaker.
•A separate circuit serving only this microwave oven.
GROUNDING INSTRUCTIONS
For all cord connected appliances:
The microwave oven must be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an escape
wire for the electric current. The microwave oven is equipped with a cord
having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
WARNING: Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualified electrician or serviceman if the grounding
instructions are not completely understood, or if doubt exists as to whether
the microwave oven is properly grounded.
Do not use an extension cord. If the power supply cord is too short, have a
qualified electrician or serviceman install an outlet near the microwave
oven.
READ AND SAVE THESE INSTRUCTIONS
WARNING ELECTRIC SHOCK HAZARD

9
PRODUCT OVERVIEW
EXTERIOR
1. Microwave Door
2. Microwave Door Handle (Recessed)
3. Cooktop Light
4. Vent Fan

10
CONTROL PANEL
1. POPCORN
2. POTATO
3. SENSOR REHEAT
4. SENSOR COOK
5. TIMER/CLOCK
6. USER PREF
7. SNACK MENUS
8. MELT/SOFTEN
9. AUTO COOK
10. WEIGHT DEFROST
POPCORN POWER
LEVEL START
+30 SEC.
STOP
CLEAR
1
6 7 8 9 0
2 3 4 5
COOK
TIME
SNACK
MENUS
MELT/
SOFTEN
AUTO
COOK
WEIGHT
DEFROST
TIME
DEFROST
TURNTABLE
ON/OFF
POTATO SENSOR
REHEAT
SMART SENSOR
SENSOR
COOK
TIMER/
CLOCK
USER
PREF
11. TIME DEFROST
12. TURNTABLE ON/OFF
13. DISPLAY
14. POWER LEVEL
15. COOK TIME
16. NUMBER PADS
17. VENT FAN
18. COOKTOP LIGHT
19. START/+30 SEC
20.STOP/CLEAR

11
DISPLAY
Indicator Icon Description
PRESS AGAIN FOR OPTIONS Press the same button again to toggle and
select more options.
PRESS START Press START to begin cycle or accept the
change/input.
TIMER Timer is running.
DEFR. Defrost mode is running.
LOCK Control lock is activated.
MICRO Microwave is running.
SENSOR COOK
kg oz lb Weight unit being used.
Sensor mode is running.
Warning Message Description
"Food" The door has been closed for 5 minutes or
more without the microwave oven being
started. This occurs to avoid unintended
starting of the microwave oven.
•Open and close the door, then start the
cycle.
"E04" Humidity sensor failure.
•Contact your appliance servicer for
assistance.

12
FEATURES
CLOCK
The clock is a 12-hour clock. It can be disabled with the STOP/CLEAR keypad
when the microwave oven is reconnected to the power.
Setting the Clock
1. Press TIMER/CLOCK twice. The default time 12:00 is shown in the display.
2. Press the numbers to enter the correct time of day. For example, to set
12:34, press the numbers 1, 2, 3, and 4.
3. Press Start. This accepts the time entered and starts the clock.
NOTE:
•When the microwave oven is running, pressing TIMER/CLOCK will
recall the current clock in the display for 2 seconds.
TIMER
The timer must be set before the microwave oven is running, and cannot be
stopped or cancelled while the microwave oven is running.
Setting the Timer (Up to 99 minutes and 99 seconds)
1. Press TIMER/CLOCK once. The "TIMER" indicator lights up in the display.
2. Press the numbers to enter the length of time. For example, to set a 30-
minute timer, press the numbers 3, 0, 0, and 0.
3. Press TIMER/CLOCK to start the timer.
4. When the set time has run out, the alarm rings until any key is pressed.
NOTE:
•When the microwave oven is running, pressing TIMER/CLOCK will
recall the remaining time in the display for 2 seconds.
Cancelling the Timer
1. Press TIMER/CLOCK. When the oven is in standby state, the display
returns to the time of day.

13
SETTINGS (USER PREFERENCES)
The microwave oven has additional settings which can be accessed using the
USER PREF keypad. These additional settings can only be adjusted while the
microwave oven is not running or the display is showing the time of day. They
will restore to default after reconnecting power or a power failure.
Settings Touch
USER PREF
Description Default
Volume 1 time Adjust the tone volume Low
Weight Unit 2 times Change weight input unit Lb
Clock Display 3 times Enable/Disable clock display On
Demo Mode 4 times
Activate to practice using the
control without actually turning
on the magnetron.
Off
Adjusting the Volume
1. Press USER PREF 1 time, and wait for volume options to show in the
display.
2. Press USER PREF to toggle and select Low, Med, High, or Off.
3. Press START to confirm.
Selecting the Weight Unit
1. Press USER PREF 2 times, and wait for weight options to show in the
display.
2. Press USER PREF to toggle and select Lb or Kg.
3. Press START to confirm.
Setting the Clock Display
1. Press USER PREF 3 times, and wait for clock display options to show in the
display.
2. Press USER PREF to toggle and select On or Off.
3. Press START to confirm.

14
Setting the Demo Mode
1. Press USER PREF 4 times, and wait for demo mode options to show in the
display.
2. Press USER PREF to toggle and select On or Off.
3. Press START to confirm.
TURNTABLE
For best cooking results, do not operate the microwave oven without having
the turntable in place. Turntable may be turned off for manual cooking only
by pressing TURNTABLE ON/OFF.
USING THE MICROWAVE OVEN
CONTROL LOCK
The control panel can be locked to avoid unintended use of the oven.
NOTE:
•The control lock can only be activated while the microwave oven or the
timer is idle or inactive.
To Lock Control Panel:
•Press and hold STOP/CLEAR for 3 seconds or until "LOCK" appears in the
display.
NOTE:
•When locked, touching any keypad on the control panel (except
STOP/CLEAR) will not work.
To Unlock Control Panel:
•Press and hold STOP/CLEAR for 3 seconds or until "LOCK" disappears in
the display.

15
COOKWARE AND DINNERWARE
Microwave-Safe
•Browning dish (Follow manufacturer recommendations)
•Ceramic glass, glass
•Earthenware (Follow manufacturer recommendations)
•Melamine (Follow manufacturer recommendations)
•Paper towels, paper plates, napkins (Use non-recycled paper)
•Plastic wraps, bags, covers, dinnerware, containers (Follow manufacturer
recommendations)
•Pottery and clay (Follow manufacturer recommendations)
•Silicone bakeware (Follow manufacturer recommendations)
•Wax paper
Do Not Use
•Metal cookware and bakeware
•Straw or wicker
•Gold, silver, or pewter
•Non-approved meat thermometers, skewers
•Twist ties
•Foil liners, such as sandwich wrappers
•Staples
•Objects with gold or silver trim or with metallic glaze
To Test Cookware/Dinnerware:
Place dish in microwave oven with 1 cup (250 mL) of water beside it. Program 1
minute of cook time at 100%. If dish becomes hot and the water stays cool, do
not use the dish in the microwave oven.

16
MANUAL COOK (COOK TIME)
The microwave oven can accept cooking time up to 99 minutes and 99
seconds (99:99). Always enter the seconds even if they are both zeros.
1. Press COOK TIME after placing food and closing the door.
2. Press the numbers to enter the length of time.
For example, to set a 3-minute cooking, press the numbers 3, 0, and 0.
3. (Optional) Press POWER LEVEL once. Then press the corresponding power
level number key or POWER LEVEL repeatedly to select the power level
desired. Refer to the Power Level table below.
For example, to select 90% power, Press 9 or POWER LEVEL twice.
NOTE:
•The default power level is 100% (PL-HI) if POWER LEVEL is not
pressed.
4. Press START.
Power Level Touch POWER LEVEL Shortcut Number Key Display
100% 1 time 1 0 PL-HI
90% 2 times 9 PL-90
80% 3 times 8 PL-80
70% 4 times 7 PL-70
60% 5 times 6 PL-60
50% 6 times 5 PL-50
40% 7 times 4 PL-40
30% 8 times 3 PL-30
20% 9 times 2 PL-20
10% 10 times 1 PL-10
*0% 11 times 0 PL-0
* At 0% power level the microwave oven will not be heating but the internal fan will be
operating. It can be used as a quick timer to rest the hot food just cooked with the microwave
oven, or it can help reduce food odors right after cooking.
NOTE:
•When the microwave oven is running, pressing POWER LEVEL will
display the current power level for 2 seconds.

17
EXPRESS COOK
Press one of the numbers from 1 to 9 once will start the microwave oven in 2
seconds at 100% power level directly for the minutes entered.
For example, to set a 6-minute cooking at 100% power level directly:
1. Press the number 6 after placing food and closing the door. The
microwave oven will automatically start in 2 seconds.
NOTE:
•If "Food" is shown in the display after the number is pressed, open and
close the door once and the number entered should appear in the
display. The microwave oven uses a 5-minute timer from last closing of
the door to help avoid running without any food inside.
POPCORN
Pop only 1 package of popcorn at a time. Cooking results may vary by brand
and fat content.
Touch POPCORN Popcorn Options
1 time 3.3 oz
2 times 3.0 oz
To Use Popcorn Program:
1. Place food and close the door.
2. Press POPCORN to toggle and select the best matching popcorn options.
3. Press START. Listen for popping to slow to 1 pop every 1 or 2 seconds, then
press STOP/CLEAR to stop the cycle.

18
POTATO
Cooks 1-4 potatoes, 4-10 oz (113-283 g) each, in similar size. Pierce each potato
several times with a fork. Place on paper towel, around turntable edges, at
least 1" (2.5 cm) apart. Place single potato to the side of the turntable. Let
stand 5 minutes after cooking.
To Use Potato Program:
1. Press POTATO after placing food and closing the door.
2. Press START.
SENSOR REHEAT
Touch SENSOR REHEAT Sensor Reheat Options Preset Portion Size
1 time Beverage Select: 1-3 cups
2 times Soup/Sauce 1 cup
3 times Dinner Plate 1-2 plates
4 times Casserole/Lasagna 10.5 oz
5 times Roll/Muffin 1-3 slices
To Use Sensor Reheat Program:
1. Place food and close the door.
2. Press SENSOR REHEAT to toggle and select different sensor reheat
options.
3. (For Beverage only) Press START and enter the number within the range
allowed to select the best matching portion size. (e.g. Enter 2 for 2 cups.)
4. Press START.
