Cosmo COS-BIM22SSB User manual

COS-BIM22SSB USER MANUAL
MICROWAVE
COS-BIM22SSB
SAFETY & USER
InstrUCtIOns
I N S P I R I N G T H E W O R L D ’ S K I T C H E N
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the following Important information redarding installation
safety and maintenance. Keep these instruction for future reference.

2 3
IMPORTANT SAFETY INSTRUCTIONS
BEFORE YOU BEGIN:
Please Read all instructions completely and carefully.
Save these instructions for future references.
THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO appliances are designed according to the strictest safety and performance
standard for the North American market. We follow the most advanced
manufacturing philosophy. Each appliance leaves the factory after thorough
quality inspection and testing. Our distributors and our service partners are
ready to answer any questions you may have regarding how to install, use and
care for your products. We hope that this manual will help you learn to use the
product in the safest and most effective manner .
If you have any questions or concerns, please contact the dealer from whom you
purchased it, or contact our Customer Support at:
1-888-784-3108.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since
operation can result in harmful exposure to microwave energy.
It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allows
soil or cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that
the oven door closes properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACE
(d) The oven should not be adjusted or repaired by anyone except properly
qualified service personnel.
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
COS-BIM22SSB
Approx. 43.4 lbs
120V~60Hz
1700W
1200W
62L / 2.19 cu ft
420mm / 16.5 "
24.4" x 19.6" x 13.6"
Table of Contents
Specifications IMPORTANT SAFETY INSTRUCTIONS .................................................................... 3-6
Instructions | Radio Interference | Utensils .......................................... 5-6
MICROWAVE USAGE
Materials you can use | Materials to be avoided ..................................................... 7
SETTING UP ............................................................................................................ 8
Turntable installation | Counter top installation ................................................... 9
OPERATION
Power levels | Clock settings | Microwave cooking ......................................... 10
TIMER .................................................................................................................... 11
Rapid cooking | Weight Defrost | Time Defrost .......................................... 12
PRESETS ........................................................................................................................ 13
Sensor cook | Memory Function .............................................................................. 13
FUNCTIONS
Multi Stage Cooking | Inquiring Function ............................................................. 14
Language Settings | Silence Mode
LOCKING ................................................................................................................ 15
Child Lock | Door Lock
OTHER FUNCTIONS
Cooking Finish
MENU CHART ......................................................................................................... 16
MAINTENANCE ...................................................................................................... 17
WARRANTY ........................................................................................................... 19

4 5
WARNING -
1. Read all instructions before using the appliance.
2. Read and follow the specific:
EXCESSIVE MICROWAVE ENERGY" found on page 3.
combustible materials are placed inside the oven to facilitate cooking.
only to properly grounded outlet. See
found on page
accordance with the provided installation
instructions.
To reduce the risk of burns, electric shock, fire, injury to persons or exposure
to excessive microwave energy:
3. This appliance must be grounded. Connect
"PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
"GROUNDING INSTRUCTIONS"
4. Install or locate this appliance only in
5. Some products such as whole eggs and sealed containers - for example, closed glass
jars - are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
supervision is necessary when used
by children.
7.As with any appliance, close
damaged cord or plug, if it is not
working
properly, or if it has been
damaged or dropped.
8. Do not operate this appliance if it has a
by qualified service personnel.
Contact nearest
authorized service
facility for examination, repair, or
adjustment.
9. This appliance should be serviced only
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for
example,
near a kitchen sink, in a wet
basement, near a swimming pool, or
similar location.
1 . Do not immerse cord or plug in water.2
1 . Keep cord away from heated surface.
14. Do not let cord hang over edge of
table or counter.
3
15. When cleaning surfaces of door and oven that comes together on closing the door,
16. To reduce the risk of fire in the oven cavity:
disconnect the power cord, shut off power at the fuse or circuit breaker panel.
utensils, or food in the cavity when not in use.
point without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed
including the following:
use only mild, nonabrasive soaps, or detergent applied with a sponge or soft cloth.
or
5.
(1). Do not overcook food. Carefully attend appliance when paper, plastic, or other
(2). Remove wire twist-ties from paper or plastic bag before placing bag in oven.
(3). If material inside of the oven ignite, keep oven door closed, turn oven off, and
(4). Do not use the cavity for storage purposes. Do not leave paper products, cooking
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER
WHEN THE CONTAINER IS DISTURBED OR A UTENSIL
IS INSERTED INTO THE LIQUID
This appliance must be grounded. In the event of an electrical short circuit, grounding
of electric shock by providing an escape wire for the
appliance is equipped with a cord having a
plugged into an outlet that is properly installed and grounded.
grounding wire with a grounding plug.
reduces the risk electric current. This
The plug
WARNING - Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely or if doubt exists as to whether the appliance is properly grounded.
extension cord, use only a 3-wire extension cord that has a
The marked rating of the extension cord shall be equal to or greater than the electrical
appliance.
understood,
If it is necessary to use an
3-blade grounded plug, and 3-slot receptacle that will accept the plug on the appliance.
rating of the
Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death.
disassemble this appliance.
DANGER -
Do not
Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
WARNING -
1. A short power supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use.
3. If a long cord or extension cord is used:
(1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
(2) The extension cord must be a grounding-type 3-wire cord.
(3) The longer cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.
-
must be
GROUNDING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
//continued on next page..
17. Continued..
To reduce the risk of injury to persons:
- DO NOT OVERHEAT the liquid
- Stir the liquid both before and halfway through heating it.
- Do not use straight-sided containers with narrow necks.
- After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
- Use extreme care when inserting a spoon or other utensil into the container.

6 7
1. Operation of the microwave oven may cause interference to your radio, TV
or similar
2. When there is interference, it may be reduced or eliminated by taking the
following
RADIO INTERFERENCE
equipment.
measures:
Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic
pierced before cooking.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave
4. Do not exceed 1 minute cooking time.
UTENSILS
See the instructions on "Materials you can use in microwave oven or to be avoided in
There may be certain non-metallic utensils that are not safe to use for microwaving. If
utensil in question following the procedure below.
CAUTION -
pouches should be
microwave oven."
in doubt, you can test the
utensil in question.
cooking.
Utensils Remarks
Follow manufacturer* instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer* instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer* instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Clean door and sealing surface of the oven
Reorient the receiving antenna of radio or television.
Relocate the microwave oven with respect to the receiver.
Move the microwave oven away from the receiver.
Plug the microwave oven into a different outlet so that microwave oven
and receiver are on different branch circuits.
Do Not Use in Microwave
Microwave Safe Materials

8 9
Turntable Installation
Installation
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
Remove all packing material and
accessories. Examine the oven for any
damage such as dents or broken door.
Do not install if oven is damaged.
Countertop Installation Cabinet: Remove any protective film
found on the microwave oven cabinet
surface.
Do not remove the light brown
Mica cover that is attached to the oven
cavity to protect the magnetron.
1. Select a level surface that provides enough open space for the
intake and/or outlet vents.
Never place the glass tray upside down. The glass
tray should never be restricted.
Both glass tray and turntable ring assembly must
always be used during cooking.
All food and containers of food are always placed
on the glass tray for cooking.
If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
A minimum clearance of 3.0 inches (7.5cm) is required between
the oven and any adjacent walls. One side must be open.
- Leave a minimum clearance of 12 inches (30cm) above the oven.
- Do not remove the legs from the bottom of the oven.
2. Plug your oven into a standard
household outlet. Be sure the voltage
and the frequency are the same as
the voltage and the
frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other
heat-producing appliance. If installed near or over a heat source,
the oven could be damaged and the warranty would be void.
Blocking the intake and/or outlet
openings can damage the oven.
Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or
TV reception.
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
Turntable shaft

Press " START/Enter/Add 30 Sec. " to start cooking.
STOP/Clear
10 11
OPERATION
10 power levels are available.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
Press "COOK TIME" once, the screen will display "00:00".
Press " START/
Clock
Off/Cancel
Clock
Enter/Add 30 Sec. " to start cooking.
Press " " once, "00:00" will display.
Press the number keys and enter the current time. For example,
time is 10:12 now, please press "1,0,1,2" in turn.
Press " " to finish clock setting. ":" will flash and the clock will be lighted.
If the numbers input are not within the range of 1:00--12:59, the setting will be invalid
until valid numbers are input.
Note: (1) In the process of clock setting, if the " " button is pressed or if
there is no operation within 1 minute, the oven will go back to the former setting
automatically.
If the clock needs to be reset, please repeat step 1 to step 3.
Press number keys to input the cooking time; the maximum cooking time is 99
minutes and 99 seconds.
Press "POWER LEVEL" once, screen will display "PL10". The default power is 100%
power. Now you can press number keys to adjust the power level.
4. Timer
- Press "Timer" once, the screen will display 00:00
- Press the number keys and enter the desired time (max cooking time is
99 mins. 99 secs.)
- Press "START/Enter/Add 30 Sec." to confirm settings. Timer begins
count down.
- When the set time is up, buzzer will ring 3 times and the screen will
display "End".
* Timer and cooking modes (including microwave, defrosting, presets) are
independent and can be set while the other is in operation.
(You can set timer while cooking or cook while timer is on)
Example: While oven is cooking at 50% power for 15 minutes, the screen
displays cooking time count down. You want to set a timer for 10 minutes:
- Press "Timer" once, the screen will display 00:00
- Press the number keys and enter the desired time
if nothing is entered in 10 seconds, timer set is canceled and oven returns to
counting down cooking time.
- Press "START/Enter/Add 30 Sec." to start timer. Timer counts down on screen.
If "START/Enter/Add 30 Sec." is not pressed in 10 seconds, timer is canceled
and the oven returns to it's previous countdown.
-- If Timer finishes before the end of the cooking process, the buzzer sounds 3
times. After the buzzer finishes, the screen will display remaining cooking time.
If the cooking process finishes before the timer, the buzzer sounds 5 times &
the screen will display countdown timer. When the timer is up, the buzzer will
sound 3 times and the screen will display "End."
If the cooking process and the timer finish at the same time, the buzzer sounds
5 times and the screen will display "End."
1. Power Level
2. Setting the Clock
3. Cooking
Example: to cook the food with 50% microwave power for 15 minutes.
Press "COOK TIME " once."00:00" displays.
Press "1","5","0","0" in order.
Press "POWER LEVEL"once,then press "5" to select 50% microwave power.
Note:(1) In the process of setting, if the " " button is pressed or if there is
no operation within 1 minute, the oven will go back to the former setting automatically.
* You can skip the third step and cook at 100% microwave power.

12 13
(1) Press " " once, screen will display "00:00".
(2) Press number pads to input defrosting time.
(3) Press " " to start defrosting. The remaining cooking time
displayed.
(1) Press " " once,
(2)Press numerical buttons to input weight to be defrosted. Input the weight ranged between
0.3~6.3lbs. If the weight input is not within 0.3~6.3, the input will be invalid.
(3) Press " " to start defrosting and the cooking time remaining
displayed.
"lbs" light.
Weight Defrost screen will display "0.0", and
will be
START/Enter/Add 30 Sec
Time Defrost
START/Enter/Add 30 Sec
will be
.
(1) In idle status, press "Popcorn", "Dinner Plate", "Pizza Reheat", "Frozen Entree",
"Beverage", "Soup", "Fresh Vegetable" ,"Frozen Vegetable" or "Potato" to choose the
auto menu.
(2) Press the same pad repeatedly to choose the weight of the food.
(3) Press " S
T A
RT / E
n t er
/A
d d 3 0 S
ec " to start cooking.
POWER LEVEL
as the
START/Enter/Add 30 Sec.
START/Enter/Add 30 Sec.
START/Enter/Add 30 Sec.
Example: to set the following procedure as the second memory, that is memory 2.
to cook the food with 80% microwave power for 3 minutes and 20 seconds.
The steps are as follow:
a. In idle status, press "Favorite" twice, stop pressing until the screen displays "2".
b. Press "COOK TIME " once,then press "3","2","0" in order.
c. Press " " once,"PL10" display, then press "8" and "PL8" displays.
d. Press "Favorite" to save the setting. Buzzer sounds once then turn back to
idle status. If you press " " again, the procedure will be
saved memory 2 and operated.
e. If the electricity is not cut off, the procedure will be saved all the time. If it is, the
procedure needs to be reset.
f. When you want to run the saved procedure, in idle status, press " Favorite" twice,
screen displays "2", then press " " to start cooking
Note: Defrosting and Auto menu can not be set in memory function.
8. Presets Menu
9. Sensor Cook
START/Enter/Add 30 Sec. it will start cooking at once and save the procedure too.
(1) In idle status, press "Dinner Plate", "Fresh Vegetable" or "Frozen Vegetable",
the screen will display "SC".
(2) Press " S TAR
T/En
t er/ A
d d 3 0 S
ec" to start sensor cooking. "SC" will flash in the
display.
(3) The sensor will sound when steaming starts and the remaining time will be displayed.
10. Memory Function
(1) Press "Favorite" to choose memory 1-3 procedure. The screen will display 1,2,3.
(2) If the procedure has been set, press " " to use it. If not
continue to set the procedure. Only one or two stages can be set.
(3) If the procedure has not been set, after finishing the setting, press " Favorite" once
to save the procedure and go back to idle status. If you press
" "
7. Time Defrost
5
6
7
5. Rapid Cooking
1) In idle status, you can start Instant Cooking at 100% power level for 30 seconds
at a time by pressing "START/Enter/Add 30 Sec." Each subsequent press of the
button adds 30 seconds cooking time. The max cooking time allowed is 99 minutes
and 99 seconds.
2) In idle status, press the number pad to set cooking time, then press "START" to
begin cooking at 100% power level.
** Note: during microwave cooking and defrost modes, time can be added by press-
ing "Add 30 Sec." button with ease.
6. Weight Defrost

11. Multi-stage cooking
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is
defrosting, then defrosting shall be placed at the first stage automatically.
Note: Auto menu cannot work in the multi-stage cooking.
Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave
power for 10 minutes. The cooking steps are as following:
(1) Press "COOK TIME " once,then press "5","0","0" to set the cooking time;
(2) Press " " once,then press "8" to select 80% microwave power.
(3) Press "COOK TIME" once,then press "1","0","0","0" to set the cooking time;
(4) Press " " once,then press "6" to select 60% microwave power.
(5) Press " " to start cooking.
14 15
12. Inquiring Function
" to inquire microwave power
the current microwave power will be displayed. After three seconds, the oven
to the previous state.
(1) In the microwave cooking state, press "
POWER LEVEL
POWER LEVEL
level, and
will turn back
(2) In cooking state, press " CLOCK ", the oven will display clock for three seconds.
Door
Text English mode French mode
End
door
End Fin
Prte
START/Enter/Add 30 Sec.
The default language mode is English. To switch language to French; from the
idle status, open the door and then press number "1" for 3 seconds. There are
only two languages to choose from.
13. English/French Mode
POWER LEVEL
The default mode is OFF Mode. The buzzer will sound under special circum-
stances. In the idle status, open the door and press number "2" for 3 seconds
to enter Silence Mode. In this mode, the buzzer will not sound.
14. Silence Mode
16. Door Lock Function
15. Child Lock Function
17. Cooking Complete Function
18. Other Specifications
Lock: In idle status, press "STOP/Clear" for 3 seconds. There will be a long
beep to signal entering Child-Lock state and the lock indicator will light.
The screen will display the current time or "0:00".
Unlock: In locked state, press "STOP/Clear" for 3 seconds. There will be a
long beep to signal that lock is released.
If the oven has been idle for over 5 minutes, it will automatically activate the Door
Lock function. You can not press "START" to begin cooking unless you open and
close the door again.
Note: The "Timer" function is not affected by the Door Lock function.
When cooking has finished, the buzzer will beep for 5 seconds to signal cooking
ended.
The maximum cooking time is 99 minutes and 99 seconds.
When cooking has finished, the screen will display "End" or "Fin". Opening the
door or pressing "Off/Cancel" can make the oven enter idle status.

16 17
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
TROUBLE
Oven will not start
POSSIBLE CAUSE POSSIBLE REMEDY
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try
again.
c. Check instructions.
Arcing or sparking
a. Materials to be avoided in
microwave oven were
used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
Unevenly cooked
foods
a. Materials to be avoided in
microwave oven were
used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suit ble.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is
not suitable. Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Check to see that oven venti-
lation ports are not restricted.
d. Use correct cooking time,
power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
MAINTENANCE
a
MENU CHART
FRESH
VEGETABLE
Menu  WeightDisplay
4-16 OZ SC
PIZZA
REHEAT
1 (SLICE) 1
22
3 3
1(8.00 Oz) 1
22
33
4
4
BAKED
POTATO
DINNER
PLATE
BEVERAGE
SOUP
FROZEN
VEGETABLE
FROZEN
ENTREE
POPCORN
4-16 OZ SC
1 cup
(about 8.8 OZ)
1
2 CUPS 2
22
33
4
4
1
1
8-16 OZ SC
20 OZ 20 OZ
10 OZ 10 OZ
1.75 OZ 1.75 OZ
3.00 OZ 3.00 OZ
3.3 OZ 3.3 OZ

18 19
WARRANTY AND SERVICE
For full warranty details on this product please visit:
http://www.cosmoappliances.com/warranty
TO RECEIVE WARRANTY SERVICE, YOUR
PRODUCT MUST BE REGISTERED. TO REGISTER, VISIT:
WWW.COSMOAPPLIANCES.COM/WARRANTY
IMPORTANT
Do Not Return This Product To The Store If
you have a problem with this product, please con-
tact Cosmo Customer Support at
[phone]
DATED PROOF OF PURCHASE, MODEL #, AND SERIAL
# REQUIRED FOR WARRANTY SERVICE
NOTES

Electronic version of this manual is available at:
www.cosmoappliances.com
Cosmo is constantly making efforts to improve the quality and
performance of our products, so we may make changes to our
appliances without updating this manual.
Correct Disposal of this product:
This marking indicates that this appliance should not
be disposed with other household wastes. To prevent
possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.
