Costan EPTAGLOO Operating instructions

INSTALLATION, USER
AND MAINTENANCE MANUAL
READ CAREFULY
AND KEEP WITH THE MACHINE
refrigerating systems
EPTAGLOO
Number of document : QSM000458E
Revision status: D
Daye of 1st issue: 30.Jan.08
Date of the present issue: 11.Nov.10

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 1 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
DOC. no. QSM0000406A CHAP. No.: 010 C 23.Feb.2010 RANGE EXTENSION ORIGINAL 13/June/07
CHAPTER: GENERAL INFORMATION/
TABLE OF CONTENTS D 11.Nov..2010 SAFETY VALVE
ADDED ISSUED BY MKT
INSTALLATION, USE AND MAINTENANCE
MANUAL
010 - GENERAL INFORMATION/TABLE OF CONTENTS
This manual has been compiled in a simple and easy-to-read manner so our units can be installed, set
up and serviced correctly. Please read its contents carefully and keep it near the machine at all
times.
The following points are of capital importance:
•The equipment must be installed, tested and serviced by skilled and legally qualified personnel.
•Local safety regulations applicable at the time of installation must be observed.
•The refrigerating equipment must only ever be used for the purpose for which it was designed. Uses
other than those specified shall in no way be binding for the Manufacturer.
•Any packaging components included (plastic bags, polystyrene, wood, etc.) represent a potential
hazard and must be kept out of the reach of children. Sort them out and dispose of them according
to local applicable regulations.
•Power supply specifications must comply with the details shown on the serial plate of the machine.
•In the event of failure or of malfunction, always switch off the machine.
•Modifications to the power system or unauthorized alterations in general, which are not
contemplated in this manual, shall invalidate the warranty.
•To service or repair the machine, always contact an authorized Costan after-sales service center and
ask for original spare parts. Failure to do so could jeopardize machine and operator safety.
THE MANUFACTURER DISCLAIMS ALL LIABILITY FOR DIRECT OR INDIRECT
DAMAGE TO PROPERTY AS WELL AS FOR ANY PERSONAL INJURY ARISING FROM
FAILURE TO COMPLY WITH THE INSTRUCTIONS CONTAINED IN THIS MANUAL.
Table of contents
This manual consists of the following sections representing an integral part thereof and which must not
be separated.
CHAP.
NO. CHAPTER NUMBER OF PAGES: REVISION STATUS
010 General information/table of contents 1 “ D “
020 Description / Technical
details/Refrigerating diagrams 28 “D“
030 Handling and positioning 5 “ C “
040 Installation 20 “ D “
050 Electrical panel technical specifications 7 “ A “
060 Wiring diagrams 1 + 151“ - “
1The wiring diagrams and settings sheets attached are integral with the present manual and must be kept with this.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 2 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
DOC. no. QSM0000406A CHAP. No.: 010 C 23.Feb.2010 RANGE EXTENSION ORIGINAL 13/June/07
CHAPTER: GENERAL INFORMATION/
TABLE OF CONTENTS D 11.Nov..2010 SAFETY VALVE
ADDED ISSUED BY MKT
070 Regulation 1 + 251“ A “
080 Outstanding risks 3 “ - “
090 Maintenance 4 “ C “

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 1 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
020 – DESCRIPTION / TECHNICAL DETAILS
General
Eptagloo refrigerating units are available in a three and a four-compressor version, featuring parallel-
connected semi-hermetic compressors by Bitzer (“Octagon” series) or Frascold. These compressor
packs are appropriate for positive and negative-temperature applications using refrigerant gas R404a,
they are meant to be installed indoors in suitable plant rooms or either outdoors when fitted out the
appropriate weather protective enclosure.
The range was designed and constructed to the applicable laws and EU Directives. This equipment is
available in a baseline version for indoor installation, including the components strictly required to
guarantee total reliability and correct performance of the machine, in compliance with Epta’s
renowned quality standards: On-board electrical panel for compressor control and regulation,
compressors installed on a stout galvanized and painted metal-sheet undercarriage, suction header
designed to ensure the return of oil to the compressors, suction filter, filter dryer on the liquid line with
liquid and humidity indicator, liquid receiver vessel. High customizability results from the possibility
to choose - as an option from the baseline version up – among as many as five different types of
electronic controllers and a switchboard that can be fitted with overcurrent protection or overcurrent
plus residual current protection. Installation options (either for indoor installation in plant rooms or
outdoors) can be associated to an enclosure soundproofing option. Accessories range from the sole
inspectable oil-separator option, directly discharging into the suction line, to the complete oil-return
option including separator, oil reservoir, distribution header and float regulators. Pulse dampers
(mufflers) are fitted to every single compressor, as well as external pressure-gauge connections,
glycerin-dip high and low pressure gauges, compressor power-factor correction, liquid subcooling for
low-temperature systems (when associated to a medium-temperature unit).
Main features (standard version)
•Power supply panel constructed to EN 60204-1, integrated in the equipment and pre-wired. The
electrical panel is test-run at the factory before the equipment is released. Master circuit-breaking
handle on the outside.
•Controller unit pull-out box, with access door from outside the equipment. Controller type to be
selected among five different alternatives.
•Suction header also acting as anti-liquid bottle; insulation of the entire suction line, of circuit
suction stretches (header – compressor) and of the suction filters.
•Replaceable mechanical-cartridge filter on the suction line, upstream of the suction header (two
filters for four-compressor systems).
•On-board liquid receiver complying with the requirements of EU Directive 97/23, capacity 40L.
(for 3 compressors ) and 60L. (for 4 compressors).
•Safety valve complying with EU Directive 97/23/EC to protect the liquid receiver against pressure
rise caused by external heat (fire)
•High-capacity anti-acid drier filter with replaceable core on the liquid line, with liquid and moisture
indicator.
•Pressure-switch and probe panel including:
Two high-pressure switches (manual-reset for system safety) to protect from high pressure
caused by mismaneuvering or other causes. When test-run as per operational instruction
QOP019110A, correct tripping of safety pressure-switches was simulated and verified
One high pressure switch for each compressor (compressor safety)

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 2 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
One low pressure switch for compressor/system safety
One back-up low pressure-switch.
One back-up high pressure-switch (including high-pressure control electronics only)
Three or four high pressure switches to control condenser fans (including low-pressure control
electronics only)
Low pressure transducer (probe) and, depending on the controller, high pressure transducer
Accessories
Housing for indoor installation, with standard sound-proofing (lining of housing made of double-layer
expanded polyurethane sheet embossed on the outside plus bituminous coating). Easily-to-remove
panels fitted with 90° angle tabs and fall-proof pins.
Housing suitable for outdoor installation with standard sound-proofing (housing lining made of
double-layer expanded polyurethane sheet embossed on the outside and bituminous coating). Easily-
to-remove panels fitted with 90° angle tabs and fall-proof pins. IP44 ingress protection rating.
Forced-ventilation by helical extracting fan; fan control by electric thermostat with programmable set
point. Temperature probe in the compressor compartment.
¼” SAE HP and LP pressure-gauge connections (available only when the machine is supplied with
housing)
External HP and LP glycerin-dip pressure gauges (available only when the machine is provided with
an enclosure)
Inspectable-type oil separator with suction line discharge.
Complete oil-return system (inspectable-type oil separator, reservoir, manifold, float regulators)
Optical liquid-level sensor on the receiver vessel.
Discharge muffler (one per compressor)
Compressor power-factor correction.
Liquid subcooling for low-temperature systems.
HT-treatment certified wood packing.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 3 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Dimensional diagrams – Systems with three-compressor systems

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 4 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Dimensional diagrams – Systems with three-compressors and enclosure
SL
DL
LL RC
RV
Note: the position of system-connecting pipework is the same for both versions. The air-expelling fan on the right side is featured as an optional extra.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 5 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Dimensional diagrams – Systems with four-compressors

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 6 OF 2
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Dimensional diagrams – Systems with four-compressor and enclosure
SL
DL
LL RC
RV
Note: the position of system-connecting pipework is the same for both versions. The air-expelling fan on the right hand side is featured as an optional
extra.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 7 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 3 Bitzer compressors
TAB.1A
Pack model 3 X 2EC-2.2Y 3 X2DC-2.2Y 3 X2CC-3.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3 3
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 17940 20940 26000
Power input1(W) 7650 8820 10740
Maximum power2(W) 9750 11190 13770
Maximum power input3(A) 17,1 20,7 25,5
Pipework
Cond. discharge diameter ( mm ) 22 28 28
Diameter of condenser return line ( mm ) 22 22 28
Diameter of suction line (mm) 42 42 42
Dimensions and weights4
Length (mm) 2070 2070 2070
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 691 692 699
Compressor 2EC-2.2Y 2DC-2.2Y 2CC-3.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer Bitzer
Series Octagon Octagon Octagon
Bitzer lube BSE 32 BSE 32 BSE 32
Power input under operation1(A) 4,59 5,55 6,46
Max. power input3(A) 5,7 6,9 8,5
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40 40
Diameter of liquid line (in/out) (mm) 22 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AM6E UQ391AM7E UQ391AM8E
Code of el.panel with RCBO UQ391AD6E UQ391AD7E UQ391AD8E
Range of overcurrent device to protect
compressors (4,5 – 6,3)A (5,5 - 8)A (7 – 10)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 8 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 3 Bitzer compressors
TAB.2A
Pack model 3 X 4FC-3.2Y 3 X 4EC-4.2Y 3 X4DC-5.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3 3
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 28560 35610 43560
Power input1(W) 12300 14800 17850
Maximum power2(W) 15450 18390 22200
Maximum power input3(A) 27,6 32,1 40,5
Pipework
Cond. discharge diameter (mm) 28 35 35
Diameter of condenser return line (mm) 28 35 35
Diameter of suction line (mm) 42 54 54
Dimensions and weights4
Length (mm) 2070 2070 2070
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 735 742 756
Compressor 4FC-3.2Y 4EC-4.2Y 4DC-5.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer Bitzer
Series Octagon Octagon Octagon
Bitzer lube BSE 32 BSE 32 BSE 32
Power input under operation1(A) 7,48 8,34 10,47
Max. power input3(A) 9,2 10,7 13,5
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40 40
Diameter of liquid line (in/out) (mm) 22 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AM8E UQ391AM9E UQ391AM8E
Code of el.panel with RCBO UQ391AD8E UQ391AD9E UQ391AD8E
Range of overcurrent device to protect
compressors (7 - 10)A (9 – 12,5)A (11 - 16)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor
3Technical data for Bitzer compressors as in document KP-100-5i
4The data in the table refer to the version with enclosure and complete oil circuit

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 9 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 3 Bitzer compressors
TAB.3A
Pack model 3 X4CC-6.2Y 3 X4VCS-6.2Y 3 X4TCS-8.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3 3
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 52300 56000 68400
Power input1(W) 21500 22350 27200
Maximum power2(W) 27300 24420 30180
Maximum power input3(A) 47,7 42 51
Pipework
Cond. discharge diameter ( mm ) 35 35 42
Diameter of condenser return line ( mm ) 35 35 42
Diameter of suction line (mm) 54 54 66
Dimensions and weights4
Length (mm) 2070 2070 2070
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 771 889 904
Compressor 4CC-6.2Y 4VCS-6.2Y 4TCS-8.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer Bitzer
Series Octagon Octagon Octagon
Bitzer lube BSE 32 BSE 32 BSE 32
Power input under operation1(A) 13,24 8,34 14,70
Max. power input3(A) 15,9 10,7 17
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40 40
Diameter of liquid line (in/out) (mm) 22 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AMBE UQ391AM9E UQ391AMBE
Code of el.panel with RCBO UQ391ADBE UQ391AD9E UQ391ADBE
Range of overcurrent device to protect
compressors (14 – 20)A (9 – 12,5)A (14 – 20)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 10 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 3 Bitzer compressors
TAB.4A
Pack model 3 X 4PCS-10.2Y 3 X 4NCS-12.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3
Refrigerant R404A R404A
Heat extraction rate1(W) 79500 91800
Power input1(W) 31400 37000
Maximum power2(W) 34710 41070
Maximum power input3(A) 63 72
Pipework
Cond. discharge diameter ( mm ) 42 42
Diameter of condenser return line ( mm ) 42 42
Diameter of suction line (mm) 66 66
Dimensions and weights4
Length (mm) 2070 2070
Width (mm) 990 990
Height (mm) 1380 1380
Weight (kg) 919 925
Compressor 4PCS-10.2Y 4NCS-12.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer
Series Octagon Octagon
Bitzer lube BSE 32 BSE 32
Power input under operation1(A) 17,22 20,60
Max. power input3(A) 21 24
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40
Diameter of liquid line (in/out) (mm) 22 22
electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent protection) UQ391AMCE UQ391AMCE
Code of el.panel with RCBO UQ391ADCE UQ391ADCE
Range of overcurrent device to protect compressors (20 - 25)A (20 – 25)A
Carel Controller IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T
Carel Controller PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530
Carel Controller mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 11 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Low-temperature applications – 3 Bitzer compressors
TAB.5A
Pack model 3 X 4FC-3.2Y 3 X 4EC-4.2Y 3 X 4DC-5.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3 3
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 8370 10350 12750
Power input1(W) 6700 7950 9660
Maximum power2(W) 15450 18390 22200
Maximum power input3(A) 27,6 32,1 40,5
Pipework
Cond. discharge diameter ( mm ) 16 22 22
Diameter of condenser return line ( mm ) 22 22 22
Diameter of suction line (mm) 42 54 54
Dimensions and weights4
Length (mm) 2070 2070 2070
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 734 741 745
Compressor 4FC-3.2Y 4EC-4.2Y 4FC-3.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer Bitzer
Series Octagon Octagon Octagon
Bitzer lube BSE 32 BSE 32 BSE 32
Power input under operation1(A) 5,18 5,17 6,84
Max. power input3(A) 9,2 10,7 13,5
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40 40
Diameter of liquid line (in/out) (mm) 22 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AM8E UQ391AM9E UQ391AMAE
Code of el.panel with RCBO UQ391AD8E UQ391AD9E UQ391ADAE
Range of overcurrent device to protect
compressors (7 – 10)A (9 – 12,5)A (11 – 16)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-35ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 12 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Low-temperature applications – 3 Bitzer compressors
TAB.6A
Pack model 3 X 4CC-6.2Y 3 X4TCS-8.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3
Refrigerant R404A R404A
Heat extraction rate1(W) 15720 19560
Power input1(W) 11820 13980
Maximum power2(W) 27300 30180
Maximum power input3(A) 47,7 51
Pipework
Cond. discharge diameter (mm) 28 28
Diameter of condenser return line (mm) 28 28
Diameter of suction line (mm) 66 66
Dimensions and weights4
Length (mm) 2070 2070
Width (mm) 990 990
Height (mm) 1380 1380
Weight (kg) 761 891
Compressor 4CC-6.2Y 4TCS-8.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer
Series Octagon Octagon
Bitzer lube BSE 32 BSE 32
Power input under operation1(A) 9,36 8,43
Max. power input3(A) 15,9 17
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40
Diameter of liquid line (in/out) (mm) 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent protection) UQ391AMBE UQ391AMBE
Code of el.panel with RCBO UQ391ADBE UQ391ADBE
Range of overcurrent device to protect compressors (14 – 20)A (14 – 20)A
Carel Controller IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T
Carel Controller PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530
Carel Controller mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-35ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 13 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Low-temperature applications – 3 Bitzer compressors
TAB.7A
Pack model 3 X 4PCS-10.2Y 3 X 4NCS-12.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3
Refrigerant R404A R404A
Heat extraction rate1(W) 22560 26220
Power input1(W) 15900 18570
Maximum power2(W) 34710 41070
Maximum power input3(A) 63 72
Pipework
Cond. discharge diameter (mm) 28 42
Diameter of condenser return line (mm) 28 42
Diameter of suction line (mm) 66 66
Dimensions and weights4
Length (mm) 2070 2070
Width (mm) 990 990
Height (mm) 1380 1380
Weight (kg) 907 923
Compressor 4CC-6.2Y 4NCS-12.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer
Series Octagon Octagon
Bitzer lube BSE 32 BSE 32
Power input under operation1(A) 10,13 12,47
Max. power input3(A) 21 24
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40
Diameter of liquid line (in/out) (mm) 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent protection) UQ391AMCE UQ391AMCE
Code of el.panel with RCBO UQ391ADCE UQ391ADCE
Range of overcurrent device to protect compressors (20 – 25)A (20 – 25)A
Carel Controller IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T
Carel Controller PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530
Carel Controller mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-35ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 14 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 4 Bitzer compressors
TAB.8A
Pack model 4 X 4TCS-8.2Y 4 X4PCS-10.2Y 4 X4NCS-12.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 4 4 4
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 91200 106000 122400
Power input1(W) 36200 41800 49320
Maximum power2(W) 40240 46280 54760
Maximum power input3(A) 68 84 96
Pipework
Cond. discharge diameter (mm) 42 54 54
Diameter of condenser return line (mm) 42 42 42
Diameter of suction line (mm) 80 80 80
Dimensions and weights4
Length (mm) 2570 2570 2570
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 1184 1210 1218
Compressor 2TCS-8.2Y 4PCS-10.2Y 2TCS-8.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer Bitzer
Series Octagon Octagon Octagon
Bitzer lube BSE 32 BSE 32 BSE 32
Power input under operation1(A) 14,70 17,22 20,60
Max. power input3(A) 17 21 24
Liquid receiver vessel
Volume of liquid receiver vessel (L) 60 60 60
Diameter of liquid line (in/out) (mm) 28 28 28
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AMBE UQ391AMCE UQ391AMCE
Code of el.panel with RCBO UQ391ADBE UQ391ADCE UQ391ADCE
Range of overcurrent device to protect
compressors (14 – 20)A (20 - 25)A (20 – 25)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor
3Technical data for Bitzer compressors as in document KP-100-5i
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 15 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Low-temperature applications – 4 Bitzer compressors
TAB.9A
Pack model 4 X 4TCS-8.2Y 4 X 4PCS-10.2Y 4 X 4NCS-12.2Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 4 4 4
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 26080 30080 34960
Power input1(W) 18640 21200 24760
Maximum power2(W) 40240 46280 54760
Maximum power input3(A) 68 84 96
Pipework
Cond. discharge diameter (mm) 35 35 35
Diameter of condenser return line (mm) 28 28 35
Diameter of suction line (mm) 80 80 80
Dimensions and weights4
Length (mm) 2570 2570 2570
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 1185 1206 1214
Compressor 4TCS-8.2Y 4PCS-10.2Y 4NCS-12.2Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Bitzer Bitzer Bitzer
Series Octagon Octagon Octagon
Bitzer lube BSE 32 BSE 32 BSE 32
Power input under operation1(A) 8,43 10,13 12,47
Max. power input3(A) 17 21 24
Liquid receiver vessel
Volume of liquid receiver vessel (L) 60 60 60
Diameter of liquid line (in/out) (mm) 28 28 28
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391DMBE UQ391DMCE UQ391AMCE
Code of el.panel with RCBO UQ391DDBE UQ391DDCE UQ391ADCE
Range of overcurrent device to protect
compressors (14 – 20)A (20 - 25)A (20 – 25)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Bitzer 5.0 at conditions Te=-35ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K (pursuant to
Directive EN12900).
The value for the power input does not include condenser fans, which are optionally fitted on the enclosure; it only refers to compressors and does
not consider power-factor improving capacitors.
2 Data calculated using software Bitzer 5.0 at limit use conditions for the specified compressor.
3Technical data for Bitzer compressors as in document KP-100-5i.
4The data in the table refer to the version with enclosure and complete oil circuit.

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 16 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 3 Frascold compressors
TAB.1B
Pack model 3 XC 2 12Y 3 XD 2 13.1 Y 3 XD 3 16.1 Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3 3
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 20394 21612 26634
Power input1(W) 8496 9234 12015
Maximum power2(W) 10926 11997 15651
Maximum power input3(A) 20,7 21,3 29,7
Pipework
Cond. discharge diameter (mm) 22 28 28
Diameter of condenser return line (mm) 22 22 28
Diameter of suction line (mm) 42 42 42
Dimensions and weights4
Length (mm) 2070 2070 2070
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 645 660 673
Compressor C 2 12 Y D 2 13.1 Y D 3 16.1 Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Frascold Frascold Frascold
Series Series C Series D Series D
Frascold Lube Oil Frascold POE 32 Oil Frascold POE 32 Oil Frascold POE 32
Power input under operation1(A) 5,6 5,89 7,67
Max. power input3(A) 6,9 7,1 9,9
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40 40
Diameter of liquid line (in/out) (mm) 22 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AM7E UQ391AM7E UQ391AM9E
Code of el.panel with RCBO UQ391AD7E UQ391AD7E UQ391AD9E
Range of overcurrent device to protect
compressors (5,5 – 8)A (5,5 - 8)A (9 – 12,5)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Frascold version 1.2.0.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K
(pursuant to Directive EN12900). The value for the power input does not include condenser fans nor the one that is optionally fitted on the hood; it
only refers to compressors and does not consider power-factor improving capacitors.
2 Data calculated using software Frascold version 1.2.0.0 at limit use conditions for the specified compressor.
3Technical data for Frascold compressors as in document FCAT01-15
4The data in the table refer to the version with enclosure and complete oil circuit

COSTAN TECHNICAL DOCUMENTATION REVISION STATUS TRUE COPY PAGE 17 OF 22
PRODUCT: EPTAGLOO ORD DATE CHANGE ORDER OF THE SIGNED DATE OF 1st ISSUE
A 18.Dec.2008 UPDATING ORIGINAL 13/June/07
DOC. no. QSM0000406A CHAP. No.: 020 B 28.July.2009 UPDATE OF. SF ENTERING
OF. NC
CHAPTER: DESCRIPTION / TECHNICAL C 23.Feb.2010 RANGE EXTENSION
DETAILS D 11.Nov..2010 SAFETY VALVE ADDED ISSUED BY MKT
Medium-temperature applications – 3 Frascold compressors
TAB.2B
Pack model 3 XQ 4 19.1 Y 3 X Q 4 21.1 Y 3 X Q 5 28.1 Y
Power voltage 400 / 3 / 50 400 / 3 / 50 400 / 3 / 50
Number of compressors 3 3 3
Refrigerant R404A R404A R404A
Heat extraction rate1(W) 29787 33684 45492
Power input1(W) 11742 13425 18849
Maximum power2(W) 14622 16542 23580
Maximum power input3(A) 27,3 30 42
Pipework
Cond. discharge diameter (mm) 28 35 35
Diameter of condenser return line (mm) 28 35 35
Diameter of suction line (mm) 42 54 54
Dimensions and weights4
Length (mm) 2070 2070 2070
Width (mm) 990 990 990
Height (mm) 1380 1380 1380
Weight (kg) 754 770 779
Compressor Q 4 19.1 Y Q 4 21.1 Y Q 5 28.1 Y
Type semi-hermetic reciprocating semi-hermetic reciprocating semi-hermetic reciprocating
Brand Frascold Frascold Frascold
Series Series Q Series Q Series Q
Frascold lubricant Oil Frascold POE 32 Oil Frascold POE 32 Oil Frascold POE 32
Power input under operation1(A) 7,41 8,15 10,87
Max. power input3(A) 9,1 10 14
Liquid receiver vessel
Volume of liquid receiver vessel (L) 40 40 40
Diameter of liquid line (in/out) (mm) 22 22 22
Electrical panel (400/3/50)
Code of el.panel with OCD (overcurrent
protection) UQ391AM9E UQ391AM9E UQ391AMAE
Code of el.panel with RCBO UQ391AD9E UQ391AD9E UQ391ADAE
Range of overcurrent device to protect
compressors (9 – 12,5)A (9 – 12,5)A (11 - 16)A
Carel Controller IR32Z3 IR32Z3 IR32Z3
Danfoss Controller EKC331/T EKC331/T EKC331/T
Carel Controller PCO3 PCO3 PCO3
Danfoss Controller AK-PC530 AK-PC530 AK-PC530
Carel Controller mRACK mRACK mRACK
1Data calculated using software Frascold version 1.2.0.0 at conditions Te=-10ºC ; Tc=+40ºC ; Suction gas temp. =20ºC ; liquid subcooling 0K
(pursuant to Directive EN12900). The value for the power input does not include condenser fans nor the one that is optionally fitted on the hood; it
only refers to compressors and does not consider power-factor improving capacitors.
2 Data calculated using software Frascold version 1.2.0.0 at limit use conditions for the specified compressor.
3Technical data for Frascold compressors as in document FCAT01-15
4The data in the table refer to the version with enclosure and complete oil circuit.
