Costway Petsite PW10037US-BK User manual

PW10037US-BK
Pet Treadmill
Tapis Roulant pour Animaux de Compagnie
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
If you're having difficulty, our friendly
customer team is always here to help.
USA office: Fontana AUS office: Truganina GBR office: Ipswich FRA office: Saint Vigor d'Ymonville
USA:[email protected]
AUS:[e-mail]
GBR:[e-mail]
FRA:[e-mail]

Before You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from babies
and children as they potentially pose a serious choking hazard.
FR
Veuillez lire attentivement toutes les instructions.
Conservez les instructions pour vous y référer ultérieurement.
Vérifiez toutes les pièces et les accessoires.
Lisez attentivement chaque étape et suivez l’ordre correct.
Nous recommandons que, dans la mesure du possible, tous les produits
soient assemblés à proximité de la zone où ils seront utilisés, afin d’éviter tout
déplacement inutile du produit une fois assemblé.
Placez toujours le produit sur une surface plane et stable.
Conservez toutes les petites pièces de ce produit et les matériaux d’emballage
hors de portée des bébés et des enfants, car ils pourraient présenter un risque
d’étouffement.
Avant de Commencer
EN
Pet Treadmill
Tapis Roulant pour Animaux de Compagnie
02 03

SAFETY INSTRUCTIONS
CAUTION: User weight on this product should not exceed 220lbs.
IMPORTANT:
Read all instructions carefully before using this product. Retain this
owner’s manual for future reference. Instructions for assembly, including
correct fitting of guards and other device, and warnings about the likely
injuries to young children if exercise equipments are operated in their
without properly fitted guards.
WARNING:
If any discomfort should result from your use of this product, stop
exercising and consult your doctor. Proper usage of this product is
essential. Please read your manual carefully before exercising.
Please keep all children and pets away from the equipment during use
and when equipment is unattended. The appliance is not intended for
use by young children or infirm persons without supervision. Young
children should be supervised to ensure that they do not play with the
appliance.
Always wear appropriate clothing, including athletic shoes when
exercising.
Do not wear loose clothing that could become caught during exercise.
Make sure that all bolts and nuts are tightened when equipment is in use.
Periodic maintenance is required on all exercise equipment in order to
keep it in good condition.
● Never leave the treadmill unattended when plugged in. Disconnect
by turning off the master has been dropped or damaged or if it has
been exposed to water.
● Do not attempt any maintenance or adjustments other than those
described in this manual power switch, and unplugging from outlet.
● Never operate this treadmill if it has a damaged cord or plug, is not
working properly, if it. Should any problems arise, discontinue use and
consult the qualified technician.
● Do not use outdoors.
● Do not operate where aerosol(spray can) products are being used
or where oxygen is being administered.
● Do not pull the treadmill by its power cord or use the cord as a
handle.
● Close supervision is necessary if this treadmill is used by, or near
children, persons with disabilities, or pets.
● Keep dry, do not operates in a wet or moist condition. Save these
instructions.
● Do not operate under a blanket. Excessive heating can occur and
cause fire, electrical shock, or injury to persons.
● Keep electrical cord away from heated surfaces.
● Never insert any object into any opening.
● Only one pet at a time should use the machine.
● Use the machine only for its intended use as described in this
manual. Do not use attachment not recommended by the
manufacturer.
● Do not place any sharp object around the machine.
● Never operate this machine if it is not functioning properly.
● This machine should not be used for medical purposes.
● On your equipment yourself other than the assembly maintenance
described in this manual.This equipment is for home use only.
● If the supply cord is damaged, it must be replaced by the
manufacturer, or similarly qualified persons in order to avoid a hazard.
● Injuries to health may result from incorrect or excessive training.
● Keep the treadmill with sides at least 2ft from any walls, and
always allow a clear space measuring 10ft wide by 20ft length for this
equipment on a stable horizontal surface. Be sure that the area
around the treadmill remains clear during use and has adequate
clearance.
Observe the following prior to use of the treadmill:
DANGER: To reduce the risk of electric shock, please observe the
following:
Always unplug the treadmill from the electrical outlet immediately
after using and before cleaning, assembling or servicing.
NOTE: Failure to follow these instructions may lead to personal injury
and cause damage to the treadmill.
EN
04 05

PRODUCT PARTS:
MAIN PARTS OF NAME:
WARNING: Connect the treadmill to properly grounded outlet only.
● This product must be grounded. If it should malfunction or break
down, grounding provides a path of least resistance for electric
current reducing the risk of electric shock. This treadmill is equipped
with a cord having equipment grounding connector and a grounding
plug. The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local codes
and ordinances.
DANGER: Improper connection of the treadmill grounding connector
can result in the risk of electric shock. Check with a qualified
electrician, if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the treadmill. If it will
not fit your outlet, have a properly grounded outlet installed by a
qualified electrician.
● Keep hands clear of all moving parts. Never place hands, feet
under the treadmill.
● Do not use the treadmill on a carpet.
● Before each use, check that the running belt is aligned and
centered on the treadmill deck and all visible fasteners on the
treadmill are sufficiently tightened and secure.
Main frame X1
Panel X1
Panel
Safety key
Power
cord Power
Switch
Protection pad X2
Protection pad Under cover
U-tube X1
U-tube
L-tube X2
L-tube
Side rail
Running belt
End caps
Motor cover
Wheel X2 Hex
wrench X1 Silicone oil X1 Screw X1 Screw X1
Extra accessories
Knob X1
Safety
key X1
Remote
control X1
06 07

Warning: Do not connect the Treadmill to a power source before
completing assembly.
Open the carton, remove the main frame and the components and
place it on the floor in an open area.
Assemble U-tube using the
pre-installed screws as Fig 1
Assemble L-tube using the
pre-installed screws as Fig 2
and Fig 3
Assemble Panel using the pre-installed screws as Fig 4
Plug in wiring as Fig 5
Adjust the velco fastener on
the tube to proper place,
then stick Protection pads
as shown in the picture.
ASSEMBLY INSTRUCTIONS
3
1 2
4
5
08 09

1. Plug the power, then place the safety key on the computer and
turn on the power switch which is located at the front of the treadmill.
2. The window will display “0.0”. Then press the “START/STOP” key
to start the treadmill, after 5 second countdown, the treadmill will
start at the speed of 0.5MPH.
3. You may press the speed“+”or speed“-” key to increase or
decrease the running speed during exercise. Each increment or
reduction will be of 0.1 MPH. The speed range is from 0.5 MPH to
7.5 MPH.
4. You may also use the Quick Speed keys (2/3/4/5) on the console
to directly access a preset speed.
5. Press the “START/STOP ” key to stop the treadmill. For
emergency stop, remove the Safety Key. The Running Belt will stop
automatically and the all window will display “E07”.
Note:
The default duration of the operation is 30 minutes. The operation
will automatically be turned off when time is up, you can press the
start button to operate the device again.
Assemble Wheels using the pre-installed knob as shown in the picture.
Place the Safety key on the panel and put the Remote control as shown
in the picture.
6
7
PANEL OPERATION INSTRUCTION
10 11
Read the owner's manual carefully before
using the product.
Remove the safety key when the unit is
not in use.
To avoid injury, stand on the side rails
before starting the unit.
Keep children away from the treadmill
during operation.

1.Plug the power, then place the safety key on the computer and
turn on the power switch which is located at the front of the treadmill,
the window will display “0.0”.
2.After installing the battery, press the “ ” on the remote control
near the treadmill to start the treadmill, after 5 second countdown,
the treadmill will start at the speed of 0.5MPH.
3.You may press the speed “+” or speed “-” key to increase or
decrease the running speed during exercise. Each increment or
reduction will be of 0.1 MPH. The speed range is from 0.5 MPH to
7.5 MPH.
1. Press the “MODE” key to access countdown Mode. You may set
a target Time, or Distance, or Calores burned by using the speed “+”
or “-” key to adjust to the desired amount. Press the “START/STOP”
key to start your set workout.
2. Press “START/STOP” key to stop the treadmill.
3. The system will shut down and stop after your desired goal has
been reached and the machine will stop.
1. Before starting treadmill, press the “PROG.” button to select
program, you may select P1, P2, P3, P4, P5, P6, P7, P8, P9, P10,
P11, P12.
2. The TIME window will display a flashing preset time 30:00
minutes, press the “+” or “-” to increase or decrease desired workout
time. The TIME range is from 8:00 to 99:00 minutes.
3. Press the “START” button to start the treadmill and Press the
“STOP” button to stop the treadmill.
4. Under program mode, the preset workout time is 30 minutes, 1/20
minutes per interval.
Note: “MODE” key and “PROGRAM” key must be selected before
starting.
1. LCD display window: SPEED, TIME, DISTANCE, CALORIE,
PROGRAM.
2. Functional keys: SPEED+, SPEED-, START / STOP, MODE,
PROGRAM.
3. Quick keys for speed selection: 2,3,4,5.
4. When the display window shows “E07”, place the Safety key on
the computer for activate operations.
NOTE 1: The treadmill will make a "BI" sound under any valid press.
NOTE 2: The battery is not pre-installed.
Remote Control: Place AAA battery in the remote control.
Start/Stop
Speed+
Speed-
REMOTE CONTROL OPERATION MODE KEY
PROGRAM(PROG.) KEY
DISPALY WINDOW AND KEY
12 13

WARNING:
Turn off and unplug the treadmill before proceeding with any
maintenance or visual inspections. Failure to do so may result in
serious injury.
AT THE END OF EVERY EXERCISE SESSION ALWAYS
1. Use the Power Switch to turn the treadmill off.
2. Always position and store the Power Cord where it is clear from
all pathways.
3. Unplug the Power Cord from the electrical outlet. This is
especially important if you are not going to use your treadmill for
extended periods.
4. Wipe all treadmill surface with a dry cloth or towel especially
perspiration on the handlebars, console, running belt or other
treadmill components.
5. Check and tighten screws at fixing point.
6. Do not hang clothes or other objects on the machine.
STORAGE
● Store your treadmill in a clean and dry environment. Ensure that
the Power Switch is off and is unplugged from the electrical outlet.
MOVING
● The treadmill has been designed and equipped with wheels (11)
for easy mobility. Before moving, ensure that the Power Switch is in
the "OFF" position and the power cord is unplugged from the
electrical outlet. Tilt the base frame of the treadmill and then roll the
treadmill to the desired position.
DAILY MAINTENANCE
14 15

The treadmills have already been spread with "Silicone Oil" in
advance before leaving the manufacturing plant. Silicone oil is
without volatility and has gradually permeated through the running
belt. There will be no need to re-spread the oil in normal
circumstances.
To maintain the running belt, we have included a small bottle of
"Silicone Oil ". The "Silicone Oil" may be re-spread once the
resistance has been increased and the running belt starts rubbing
against the running deck. To hold open the center of the running
deck. Allow the silicone oil to "set" for one minute before using the
treadmill.
a) Adjust speed to 1.86 mph.
b) If the running belt is deflecting to the right, adjust the bolt on the
right one half turn clockwise using the Allen key, and adjust the bolt
on the left one half turn anti-clockwise (see pic 1)
c) If the running belt is deflecting to the left, adjust the bolt on the left
one half turn clockwise using the Allen key, and adjust the bolt on
the right one half turn anti-clockwise (see pic 2)
d) If the running belt is not deflected, but is slipping, adjust both left
and right bolts one half turn clockwise to tighten, or one half turn
anti-clockwise to loosen if the belt is too tight. (See pic 3 and 4)
e) After adjustment, check the running belt, and adjust further if
required.
NOTE: Only use the "Silicone Oil" lubricants for this equipment. In
addition, do not add any other oil ingredient; otherwise the treadmill
will be damaged. Do not over-lubricate the walking board. Excess
lubricant should be wiped off with a clean towel.
LUBRICATION YOUR TREADMILL RUNNING BELT ADJUSTMENT
16 17

OVERVIEW DRAWING PARTS LIST
18 19
