USER'S MANUAL
Rolling Steam Cleaner
EP24668
SHOP EASY.SAVE MONEY.

Important
I
T
a
m
1
2
3
4
5
6
7
8
9
1
Rolling Steam Cleaner
Model No.: EP24668
Please read this user manual before using this steam
cleaner, and store it after reading in order for future reference.
PRODUCT ASSEMBLY

Important Safety Instructions
Please carefully read the safety instruction as below:
INTENDED USE: this product is intended to be used indoors for household cleaning.
This product is not intended for commercial or industrial uses. The manufacture
assumes no responsibility for damage or injury due to unauthorized use of product
modification. Failure to follow these directions will void the product warranty.
Directions to reduce risk of fire, electric shock, and injury:
1. Read all instructions before use.
2. Before plugging power cord into electrical outlet, be sure that all electrical
information on rating label agrees with your power supply.
3. To reduce likelihood of circuit overload, DO NOT operate another high wattage
appliance in the same circuit as this unit.
4. To protect against risk of electric shock
electric shock
, do not immerse unit in water or other
liquids. DO not use power cord as handle, let it hang over edges of counters, or
be crimped or closed in doors.
5. Never yank power cord to disconnect from outlet; instead, grasp plug and pull to
disconnect.
6. Do not operate unit with a damaged power cord or if the unit has been dropped
or damaged. To avoid risk of electric shock, do not disassemble unit; must
contact designated service center staff or equally qualified electrician people
confirm replacement. Incorrect reassembly can cause a risk of
when unit is used.
7. A loose fit between wall outlet and plug may cause overheating and distortion of
the plug. Discontinue use of the product in this outlet. Contact a qualified
electrician to replace loose or worn outlets.
8. Do not leave unit unattended while plugged in.
9. Do not use unit where aerosol-based products are being used, or where oxygen
is being administered.
10. Unit is only meant to be used with recommended (model PEROLSTM)
accessories. Using other types of attachments may cause damage to unit or
injury.
.
PRODUCT ASSEMBLY
1

PRODUCT ASSEMBLY
11. If lighted On/Off switch does not illuminate when set to “ON”position while
power cord is plugged in, unit is not operating normally. Immediately disconnect
cord from power supply, and then refer to troubleshooting guide on Page of this
manual for assistance.
12. Always turn unit off and unplug power cord before filling boiler with water. Do not
attempt to use unit without properly filling boiler.
13. When filling boiler, only water should be used in unit-other cleaning agents could
damage unit or cause injury. Distilled or de-mineralized water is highly
recommended, in order to minimize potential build-up of mineral deposits. Do not
fill boiler with more than 1500ml of water.
14. Not allow using any cleaner or chemicals in the water tank.
15. Before adding water to the tank, please turn off the power switch first, pulled out
the plug from outlet.
16. Please place the power cord far away from any hot surfaces.
17. In order to avoid scald, please do not touch the nozzle part when it is under
operation.
18. When appliance is under operation, must pay attention to watch it to prevent
steam spray from burn danger and avoid injury.
19. In order to avoid scald, please do not let the children or someone operate the
appliance that is not familiar with the method of use.
20. Please store this machine indoors and do not let this machine outdoor in the rain
or the wind.
21. Do not attempt to repair, dismantle the appliances, when found that appliances
have a problem; please send it to designated service center to repair timely.
22. The appliance has to be unplugged after use and before cleaning or user
maintenance of the appliance.
23. Liquid or steam must not be directed towards equipment containing electrical
components, such as the interior of ovens.
2

PRODUCT ASSEMBLY
ct
is
ot
ld
ot
ut
ain
s
Important Safety Instructions
24. : Hot steam.
25. To avoid burns from escaping steam when removing boiler cap to refill unit:
Always allow unit to cool for 5-10 minutes.
Press and hold steam button to release all remaining steam pressure
26. To reduce risk of contact with hot water emitting from the nozzle, check appliance
before each use by positioning it away from body and turning it on. Do not
operate unit if the nozzle is blocked.
27. Burns can occur from touching hot metal parts, hot water, or steam. Do not touch
the Nozzle or attempt to connect accessories while unit is in use. Do not touch
bottom of mop head or attempt to attach a microfiber pad by hand while unit is in
use. Be careful
Be careful
when you turn unit upside-down – there may be hot water in
boiler.
28. when using unit on uneven surfaces, such as stairs.
29. When steaming any surface for the first time, it is recommended that you consult
the manufacturer’s guidelines for material being steamed. For items in question,
test on an inconspicuous area before proceeding.
30. Steaming unsealed hardwood or unglazed ceramic surfaces is not
recommended, and may result in warping or damage to the surface. Steam may
remove the sheen from surfaces treated with wax.
31. When steam mopping, never leave unit resting in one spot on any surface for
any period of time – prolonged exposure to heat and moisture may damage floor
surface.
32. Do not allow power cord to touch hot surfaces during use. Bundle cord loosely
when storing.
Always allow Steam cleaner to cool (at least 30mins for complete cooling) and
empty boiler before storing. Do not store unit with a damp microfiber pad still
attached.
WARNING: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
3

PRODUCT ASSEMBLY
33.
Attention: In replace any accessories operating, please make sure
machines have shut off the power and no steam extrusive. And let the
machine cooling 30 minutes, to prevent burns.
SAVE THESE INSTRUCTIONS
Pr
This appliance is not intended to be used by children and persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge unless they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
4

PRODUCT ASSEMBLY
Product Information
The following features and accessories are included with your steamer cleaner,.
Carefully inspect the packing material for all parts listed below.
08. Main Nozzle
09. Steam Hose
10. Steam Jet Nozzle
11. Extension Wands
19. Brass Utility Brush
20. Scrub Pad
21. CarpetGlider
01. Lighted On/Off Switch
02. Boiler & Safety Cap
03. Back Cord Wrap
04. Handle
05. Steam Lock Switch
06. Steam Button
07. Carrying Handle
12. Mop Head
13. Microfiber Pads
14. Water Funnel
15. Measuring Cup
16. Squeegee
17. Triangle Brush
18. Nylon Utility Brushes
10
16 21
11
12 13 1514
9
8
5
6
7
4
1
2
3
1817 20
19
5

PRODUCT ASSEMBLY
1. The Lighted On/Off Switch (1) activates and deactivates the unit, and illuminates
to provide a clear visual indication of whether the unit is powered on.
2. The Boiler with Cap (2) is the internal reservoir in which water is stored and
heated. It is accessed by removing the boiler cap. There must be a sufficient
amount of water in the boiler in order for the unit to properly function.
3. The Back Cord Wrap (3) is designed to hold the power cord when not in use, and
includes a compartment for storing small accessories.
4. The Handle (4) is designed to stay cool while providing the optimum amount of
safety and user comfort.
5. The Steam Lock Switch (5) is pushed forward to lock the steam button down
and provide continuous, hands-free steaming.
6. The Steam Button (6) provides full steam-on-demand control, releasing hot,
penetrating steam from the Main Nozzle when pressed.
7. The Carry Handle (7) functions as a convenient holder for the Main Nozzle, and
is designed for carrying the unit up stairs and over obstacles.
8. The Main Nozzle (8) emits a powerful flow of steam when the Steam Button is
pressed.
9. The Steam Hose (9) safely channels the flow of steam from the Boiler to the
Main Nozzle.
10. The Steam Jet Nozzle (10) focuses the flow of steam from the Main Nozzle, and
serves as the base to which the Utility Brushes and Scrub Pad connect.
11. The Extension Wands (11) connect to the Main Nozzle, allowing for floor
mopping as well as easier cleaning in high or hard-to-reach places.
12. The Mop Head (12) connects to the Extension Wands, and is designed for steam
cleaning a variety of hard floor surfaces.
13. The Microfiber Pads (13) attach to the Mop head, and are designed for removing
scuffs and stains from hard floors. The Pads are reusable and machine
washable.
P
1
1
1
1
1
N
B
s
s
in
1
6

PRODUCT ASSEMBLY
tes
and
of
nd
s
nd
am
ing
Product Information
14. The Water Funnel (14) and the Measuring Cup (15) are provided to assist in
easily and consistently filling the Boiler with the optimum amount of water (17-52
oz. /500-1,500ml.).
15. The Squeegee (16) connects to either the Main Nozzle or Extension Wands, and
can be used to clean mirrors, windows and other smooth glass surfaces.
16. The Triangle Brush (17) connects to the Main Nozzle or Extension Wands, and is
designed for cleaning corners and other difficult angles.
17. The assorted Nylon Utility Brushes (18) connect to the Steam Jet Nozzle,
providing extra scrubbing power for removing exceptionally tough dirt and stains.
18. The Brass Utility Brush (19) connects to the Steam Jet Nozzle and is designed
for removing tough stuck-on grease and grime from durable surfaces such as
ovens and grills.
NOTE: Use careful judgement when deciding what surface to clean with the
Brass Utility Brush. Some delicate surface, such as stainless steel, may be
scratched or damaged by the brass bristles. If you are unsure whether or not a
surface will be damaged, it is recommended that you test a small
inconspicuous spot before proceeding.
19. The Scrub Pad (20) connects to the Steam Jet Nozzle and is designed to scrub
tough dirt and scuffs from surfaces.
7

PRODUCT ASSEMBLY
Assembling Your Steam Cleaner
STEAM MOPPING ACCESSORIES
WARNING: Do not try to connect accessories while unit is emitting steam.
EXTENTION WANDS
1. Select one of the Extension Wands, and align rear end of wand with Main
Nozzle.
Rectangular hole in wand should align with orange
lock / release button on nozzle.
2. Press down on orange lock/release button. While continuing to hold button down,
slide Extension Wand onto Main Nozzle (FIGURE 1-A).Push wand over button,
and continue pushing until button snaps through hole on wand.
3. Slide second Extension Wand onto end of the one you just connected, this time
lining up rectangular hole of second wand with orange lock/release button of first
wand. Press and hold button, and firmly push second wand onto end of first
wand until button snaps through hole (FIGURE 1-B).Both Extension Wands
should now be connected to the Main Nozzle.
MAINNOZZLE
FIGURE 1
A
M
M
8

PRODUCT ASSEMBLY
le.
wn,
,
e
irst
Assembling Your Steam Cleaner
MOP HEAD
1. Align Mop Head with end of second Extension Wand, so that rectangular hole in
Mop Head neck aligns with orange lock/release button on wand.
2. Press down on orange lock/release button. While continuing to hold button down,
slide Mop Head neck onto Extension Wand FIGURE 2-A).Press on firmly until
button snaps through hole (FIGURE 2-B).
MICROFIBER PADS
1. Lay on Microfiber Pad on flat surface, with two fastener strips for facing upward.
2. Align Mop Head above Microfiber Pad. Make sure Mop Head is oriented with pad
as shown, and centered as best as possible (FIGURE 3-A).
3. Fastener strips will adhere to pad grips on underside of Mop Head. Microfiber
Pad should now be attached and ready for use (FIGURE 3-B).
CAUTION: Use care when handling a recently used Microfiber Pad, as it may
still be hot.
NOTE: Microfiber Pads are machine washable. To avoid picking up lint, washing
separately from other fabrics is recommended. Only use liquid detergent. Avoid using
any fabric softeners or bleach. Air drying is recommended; machine drying on a low
heat or air dry setting is acceptable as well.
FIGURE 2
9

PRODUCT ASSEMBLY
A
S
W
S
1
2
N
t
t
d
c
The Mop Head and Microfiber Pads are perfect for use on these hard floor
surfaces:
IMPORTANT: Do not use on unsealed hardwood or unglazed ceramic surfaces.
Surfaces that are not properly sealed may be warped or damaged by exposure
to heat and moisture.
Care should also be taken when steaming sealed hardwood floors, as
prolonged exposure to steam in a single spot may cause damage and
discoloration. To avoid this, keep the Mop Head in constant motion on these
surfaces.
Steam may remove the sheen from some floors that have been treated with
wax. Extremely rough textured floors may tear or damage Microfiber Pads.
Sealed Hardwood
Stained Concrete
Sealed Laminate
Marble
Vinyl
Tile
Linoleum
Ceramic
Granite
FIGURE 3
10

PRODUCT ASSEMBLY
Assembling Your Steam Cleaner
STEAM CLEANING ACCESSORIES
WARNING: Do not try to connect accessories while unit is emitting steam.
STEAM JET NOZZLE/SQUEEGEE/TRIANGLE BRUSH
1. Select one of the three accessories (Steam Jet Nozzle, Squeegee or Triangle
Brush-Steam Jet Nozzle shown as example), and align rear end of accessory
with Main Nozzle. Rectangular hole in accessory should align with orange
lock/release button on Main Nozzle.
2. Press down on orange
lock/release button (FIGURE 4-A).While continuing to hold
button down, slide accessory onto Main Nozzle(FIGURE 4-B).Push accessory
over button, and continue pushing until button snaps through rectangular hole.
NOTE: The Steam Jet Nozzle, Squeegee and Triangle Brush can be connected
to the end of an Extension Wand for reaching high or difficult spots. Connect
the Extension Wand (or Wands) as outlined on Page 8, then connect your
desired accessory to the Wand in the same way as you would normally
connect it to the Main Nozzle.
FIGURE 4
s.
re
ith
11

PRODUCT ASSEMBLY
U
F
UTILITY BRUSHES
NOTE: Utility Brushes connect to the Steam Jet Nozzle, not the Main Nozzle.
1. Align guide tab on inside of Utility Brush (FIGURE 5-A) with groove in bottom of
Steam Jet Nozzle tip (FIGURE 5-B).
2. Firmly press Utility Brush onto tip of Steam Jet Nozzle. Press it on as far as
possible to prevent steam leakage (FIGURE 5-C).
3. To remove Utility Brush, simply grip it firmly and pull it off of Steam Jet Nozzle.
SCRUB PAD
NOTE: Scrub Pad connects to the Steam Jet Nozzle, not the Main Nozzle.
1. Place Scrub Pad over tip of Steam Jet
Nozzle, and firmly press it on Steam Jet
Nozzle as far as possible. (FIGURE 6)
2. To remove Scrub Pad, simply grip it firmly
and pull it off of Steam Jet Nozzle.
FIGURE 5
FIGURE 6
12

PRODUCT ASSEMBLY
Using Your Steam Cleaner
FILLING BOLIER
1. Place Steam Cleaner on a flat, level surface.
2. Make sure Lighted On/Off Switch is set to “OFF” position and grounded power
cord is unplugged from electrical outlet.
3. Cautiously unscrew and remove Boiler cap, an dd rain any water remaining inside
Boiler into a sink or tub.
NOTE: Boiler should be emptied after each use-this will help minimize
mineral build-up and prevent over-filling.
4. Fill Measuring Cup to maximum fill line (17 oz./ 500ml.) with water.
NOTE: In order to significantly reduce mineral build-up and prolong the life
of your Steam Cleaner, use of distilled or de-mineralized water in the unit is
highly recommended. Refer to Page 16 for more information about mineral
build-up.
5. Using Water Funnel, carefully pour water from Measuring Cup into Boiler through
fill hole.
CAUTION: Water Funnel should always be used to fill Boiler, to prevent
spilled water from entering unit housing and damaging electrical
components.
6. Depending on how long you intend to steam, you may repeat steps 4 & 5 up to
two more times, up to a maximum of 52 oz.(1,500 ml.)of water. See chart for a
comparison of the amount of water vs. approximate steam time.
Amount of water Duration of Steam
17 oz (500ml.) Approximately 15mins
35 oz (1000ml.) Approximately 30mins
52 oz (1500ml.) Approximately 45mins
7. Replace Boiler cap, ensuring that it is screwed on tightly to prevent hot steam
from escaping and causing injury.
.
of
.
13

PRODUCT ASSEMBLY
4
REFILLING BOILER
If unit has been in use, always use the following safety precautions before
removing the Boiler cap to add water:
Allow unit to cool for 5-10 minutes.
Press and hold Steam Button to release all remaining steam. Steam can
remain pressurized inside Boiler for up to an hour after use.
WARNING: Failure to follow these precautions may result in burns from
escaping steam when the Boiler cap is removed.
GENERAL OPERATION
NOTE: Be sure that Boiler has been filled and that all desired accessories are
connected before following these steps.
1. For first time use, remove protective plastic cover from electrical plug. Plug
power cord into a convenient electrical outlet.
2. Switch Lighted On/Off Switch to “ON” position.
3. The water will heat 8-10 minutes (depending on how much water in Boiler),
and then ready to begin steaming.
4. Direct nozzle (and any connected accessories) towards surface you desire to
steam, and press Steam Button. To sanitize surfaces, point nozzle, press Button
and hold approximately 1/2 inch from surface for at least 5 seconds. This will
insure that you have killed germs and bacteria.
CAUTION: Always be sure that nozzle and any accessories are pointed in a
safe direction (away from yourself, other people, pets, and plants) before
pressing Steam Button.
5. Keep Steam Button pressed for a continuous flow of steam. You may also slide
the Steam Lock Switch forward while pressing the Steam Button to lock it down.
This will allow a continuous flow of steam without need of holding the Button
down manually.
6. Using a slight back-and-forth motion over the area you are steaming will further
enhance the cleaning process. Wipe steamed areas with a clean cloth to remove
loosened dirt and grime. Wiping the area while it is still wet is recommended, but
use caution when wiping surfaces such as metal that may still be hot.
14

PRODUCT ASSEMBLY
Using Your Steam Cleaner
7. Once steaming tasks are complete, immediately set Lighted On/Off Switch to
“OFF” position and unplug grounded power cord from electrical outlet. Follow
steps under Proper Storage procedure on Page 16 of this manual.
STEAM MOPPING
NOTE: Be sure that Boiler has been filled and that all steam mopping
accessories are connected before following these steps.
It is recommended to sweep or vacuum hard floors before mopping.
1. Follow STEPS 1-3 of General Operation section above.
Refer to Page 10 for a listing of hard floor surfaces that are recommended
for cleaning with the Steam Cleaner.
2. For best results, use a steady back-and-forth motion over floor surface, pushing
the Mop Head away and pulling it back towards you. Work your way backwards
over the floor, in order to avoid walking over freshly mopped areas.
NOTE: To avoid warping or damage caused by heat and moisture, do not
use on unsealed hardwood or unglazed ceramic surfaces. Steam may
remove the sheen from some floors that have been treated with wax.
3. To effectively kill bacteria and microorganisms, repeatedly mop a single small
area (approximately 3’ x 3’ for best results) for at least 2 minutes.
4. The Microfiber Pad will absorb dirt and moisture during mopping. However, when
you are finished you may find some residual moisture has been left behind. In
this case, it is recommended to allow floor time to air-dry. A fan may be directed
towards mopped area to facilitate drying.
re
tton
in a
e
de
wn.
Using a slight back-and-forth motion over the area you are steaming will further
enhance the cleaning process. Wipe steamed areas with a clean cloth to remove
loosened dirt and grime. Wiping the area while it is still wet is recommended, but
15

PRODUCT ASSEMBLY
Storage, Care & Product Support
PROPER STORAGE
Preparing your Steam Cleaner for storage is quick and simple. When you have
finished your steaming tasks, follow the steps listed below.
1. Set Lighted On/Off Switch to “OFF” position and unplug power cord from
electrical outlet.
2. Allow unit to cool (at least 30 minutes for complete cooling).
3. Press and hold Steam Button to release all remaining steam pressure.
4. Remove all accessories from unit.
5. Remove Boiler cap, drain any remaining water from Boiler into a sink or tub-this
will help to minimize mineral build-up and prevent over-filling during your next
use. Loosely replace Boiler cap.
6. Store accessories safely away, near Steam Cleaner. Utility Brushes can be
conveniently stored in the Back Cord Warp.
7. Store Steam Cleaner in a cool ,dry location .
MINERAL BUILD-UP
A common maintenance need for steam appliances is the removal of build-up
caused by high mineral content in many municipal water supplies. This mineral
build-up may limit the effectiveness and reduce the life of your Steam Cleaner.
The best way to minimize mineral build-up is to use distilled or de-mineralized
water when using your Steam Cleaner. If you are unable to use distilled water, it is
recommended that the following procedure be followed monthly to help remove any
mineral build-up:
16

PRODUCT ASSEMBLY
his
t
ed
it is
ny
Storage, Care & Product Support
1. Set Lighted On/Off Switch to “OFF” position and unplug power cord from
electrical outlet.
2. Allow unit to cool (at least 30 minutes for complete cooling).
3. Press and hold Steam Button to release all remaining steam pressure.
4. Remove all accessories from unit.
5. Remove Boiler cap and drain water from Boiler into a sink or tub.
6. Fill Measuring Cup with 17 oz.(500 ml.) distilled vinegar.
7. Carefully pour vinegar into Boiler. Slowly shake or move unit around to agitate
vinegar.
8. Allow to stand for at least 40 minutes, or more if possible.
9. Drain vinegar from Boiler.
10. Rinse Boiler with fresh water, drain and repeat until vinegar odor dissipate.
11. Loosely replace Boiler cap and follow steps under Proper Storage procedure on
Page 16 of this manual.
Troubleshooting
PROBLEM POSSIBLE CAUSE SOLUTION
Unit fails to heat up.
Lighted On/Off
Switch DOES NOT
illuminate when set
to “ON” position.
Unit is not plugged in. Plug power cord into electrical outlet.
Household circuit
breaker/ ground fault
interrupter has tripped or
blown a fuse.
Reset circuit breaker/ground fault
interrupter, or replace fuse. If you need
assistance, contact a licensed
electrician.
Unit is damaged or
otherwise in need of
repair.
Immediately cease usage and unplug.
Contact Consumer Service for further
assistance
12. Replace the boiler safety cap.
17
