Cozy N Safe COMET EST-136 User manual

CHILDINFORMATION
(KEEPWITH CAR SEAT AT ALL TIMES IN CASE OF EMERGENCY)
NAME:
..................................................................................................................................................
DATE OF BIRTH (DD/MM/YYYY):
..................................................................................................................................................
ADDRESS:
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
ALLERGIES/MEDICAL CONDITIONS:
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
EMERGENCYCONTACT 1:
NAME:
...............................................................................................................................
...................
PHONE NUMBER:
...............................................................................................................................
...................
EMERGENCYCONTACT 2:
NAME:
...............................................................................................................................
...................
PHONE NUMBER:
...............................................................................................................................
...................
www.cozynsafe.com
Without Compromise...
Cozy N Safe
Oxford Street, Wolverhampton, West Midlands, WV14 7DP, UK
Tel: [phone] |Email: [e-mail]
C o m e t
i-Size
InstructionManual
Without Compromise...
We’d love to see your pics! Share them using #imcozynsafe
C O M E T i-Size
B E Y O N D T H E H O R I Z O N
S I G N A T U R E
EST-316

Contents
1. Critical information - Please read immediately............................. 2-4
2. Install location................................................................................................................5
3. Parts and interior equipment...........................................................................6
4.Technical Pparameter............................................................................................. 7
5. Product information............................................................................................... 8
6. Using the buckle.........................................................................................................8
7. Adjust the headrest.................................................................................................9
8. Adjust safety belt length...................................................................................10
9. Romoving sleeping pad........................................................................................10
10. Adjust the rotation of the seat.................................................................11
11. Adjust the angle of the child safety car seat................................12
12. Adjust the length of support leg..............................................................13
13. How to use the isofix guide............................................................................14
14. How to use the isofix ...........................................................................................14
15. Installation(40-105cm)..........................................................................................15
16. Installation(76-105cm)..........................................................................................16
17. Installation(100-150cm).......................................................................................17-19
18. Maintenance and cleaning...................................................................................20
19. List of approved cars............................................................................................21-24�

Notice
If in doubt, consult either the Enhanced Child Restraint System manufacturer
or the retailer.
This is an i-Size Enhanced Child Restraint System.It is approved according
to UN Regulation No.129/03, for use in i-Size compatible vehicle seating
positions as indicated by vehicle manufacturers in the vehicle user’s manual.
NOTICE - NOT TO USE REARWARD FACING ECRS (ECRS= Enhanced
Child Restraint System) IN SEATING POSITIONS WHERE THERE IS AN
ACTIVE FRONTAL AIRBAG INSTALLED.
IMPORTANT -DO NOT USE FORWARD FACING BEFORE THE CHILD’S
AGE EXCEEDS 15 MONTHS (Refer to instructions).
Notice : Regarding i-Size category Enhanced Child Restraint Systems
(40-150cm)
1. Critical information - Please read immediately.
To ensure the safety of your child, it is imperative that you carefully review and
comprehend these instructions before utilizing the product. Additionally, we
strongly advise you to retain this manual for future reference. Neglecting to adhere
to the guidelines outlined in this document may lead to severe harm or injury to
your child.
1. The utilization of the harness is limited to children within the height range of
40-105cm when using this child safety seat.
2. You may store this instruction manual within the designated compartment of the
child seat throughout its entire lifespan
3. Please refrain from using this child safety seat in a home setting. It has been
exclusively designed for use in vehicles and should not be utilized outside of this
intended purpose.
4. It is imperative that you never leave your child unattended in the child restraint
system, even for a brief period.
5. The child safety seat should be changed when it has been subject to
violent stresses in an accident.
6. For the safety of all occupants, it is vital to securely fasten this child restraint in the
vehicle, even when it is not being used. In the event of a collision or abrupt stop, an
unsecured child safety seat can pose a risk of injury to other individuals in the vehicle.
7. Always make sure that any straps holding the seat restraint to the vehicle
shall be tight,any straps restraining the child should be adjusted to the child’s
body,and check that the straps shall not be twisted.
8. IMPORTANT: It is crucial to ensure that any lap straps are worn in a low position,
firmly engaging the pelvis.
9. Please refrain from utilizing any load-bearing contact points that are not explicitly
outlined in the provided instructions or marked on the child restraint. In case of
uncertainty, we strongly advise reaching out to the manufacturer of the child restraint
for further guidance.
10. Ensure that all luggage or other objects which have the potential to cause injury in
the event of a collision are securely fastened or properly secured.
11. During the routine use of the vehicle, it is crucial to position and install the rigid items
and plastic components of a child restraint in a manner that prevents them from getting
trapped by a movable seat or vehicle door.
12. In order to mitigate the risk of falls, it is imperative to always secure your child by
fastening them appropriately.
13. Making any alterations or additions to the device without the approval of the
competent authority is perilous. Furthermore, failing to closely adhere to the installation
instructions provided by the child restraint manufacturer can also pose a significant risk.
14. This child safety seat is specifically designed for children ranging from 40 to 150cm
in height. It is crucial to never exceed the recommended capacity of the child safety
seat by placing more than one child or additional loads on it.
15. It is imperative to always utilize the child restraint with its cover and never use it
without it.

16. To maintain the intended performance of the restraint, it is crucial to avoid
replacing the seat cover with any other alternative not recommended by the
manufacturer. The cover is an integral component that contributes to the overall
effectiveness of the restraint system.
17. Prior to adjusting any movable or adjustable parts of your child safety seat, it is
essential to remove your baby from the seat.
18. If the child safety seat does not have a textile cover, it is important to keep it
away from direct sunlight to prevent excessive heat that could potentially
discomfort or harm the child's skin.
19. It is strongly advised to refrain from using second-hand products, as it is
impossible to ascertain their complete history or what may have occurred to them.
20. Attention: It is crucial to strictly adhere to the configurations and setups
illustrated in the provided instructions and avoid using any other unlisted
configurations.
21. Important Notice: Prior to using the ISOFIX child restraint system, it is essential to
thoroughly read the manual provided by the automobile manufacturer for specific
instructions regarding the ISOFIX fix points.
22. The support leg must be fully in contact with the ground of the vehicle.
2. Install location
ISOFIX Attachments
3-point Safety Belt
When using as i-Size
The ECRS system is designed for vehicles that meet the R16 requirements.
It can only be used after installing ISOFIX in the vehicle.
Installation in this position is allowed and feasible.
Installation in this particular position is not feasible or permitted.
Installation of the seat in a location where the front airbag is active
is strictly prohibited.
Installation in this location is only permissible when using ISOFIX
attachments.

3. Parts and interior equipment
Headrest cushion
(Only suitable for
babies 8 months age）
Headrest
Belt route slot
Manual storage tank
(Back of cloth cover)�
Sleeping pad
(Back of cloth)
Buckle
Crotch Pad
Belt adjustment
button (Under the
cover)
Adjustment belt
360°rotate adjuster
Support leg
display window
Backrest
Shoulder pad
Belt route slot
Recline position
adjustment lever
Headrest
Height Adjuster
Base
ISOFIX
ISOFIX
attachment
point
ISOFIX insert guide
(If you don’t have ISOFIX
insert guide, Please
ignore this)
Adjust button
Support leg
Belt route slot
Manual
storage tank
4.Technical Parameter
Length: 500mm
Width: 438mm
Height: 585-790mm
Side Impact Protection

5. Product information 7. Adjust the headrest
This product is a child restraint system with a 360-degree rotating feature. The
following information will provide you with a better understanding of this product.
Tested and approved according to ECE R129/03
I-size
Body size
40-105cm≤18kg
76-105cm≤18kg
15kg≤100-150cm≤36kg
Installation method
Isofix+support leg
Installation direction
Rearward Facing
Forward facing
Forward facing
Isofix+
3-point safety belt
3-point safety belt
6. Using the buckle
Locking Method：
Align the left and right buckle tongues into a single
tongue and insert it into the buckle until you hear a
distinct "Click" sound.
Unlocking Method：
To release the buckle, press the red button downward,
causing the two metal sections to pop up.
The Headrest are adjusted as follows:
To make adjustments to the child seat, begin by loosening the shoulder straps to
their maximum extent. Then, pull the headrest height adjuster and choose the
appropriate height for the shoulder straps. Secure the straps in a position that fits
your child by releasing the adjuster. Finally, pull the headrest to ensure it is properly
locked into place after the adjustment.
ATTENTION!
Ensuring the headrest is properly adjusted is crucial for providing optimal protection
to your child in the safety seat.
It is essential to adjust the headrest in a manner that aligns the shoulder straps with
your child's shoulders.
Adjust the headrest to the appropriate position where the
distance between the child's shoulder and the bottom of the
headrest allows for a one-finger gap.
Isofix+support leg Forward facing
Lorem ipsum

8. Adjust safety belt length
9. Removing New Born Insert
10. Adjust the rotation of the seat
To loosen the shoulder harness, simultaneously
press the adjuster button located beneath the
cover and pull both shoulder straps forward.
To tighten the shoulder harness, pull the
adjuster strap until the harness is securely
and completely tightened.
Once your child's height exceeds 60cm,
it is necessary to remove the New Born Insert.
Using your thumb, pull the rotation adjuster outwards. Set the switch to the unlock
mode, and proceed to rotate the safety car seat to a 360° angle. (refer to picture a).
ACTION: After each rotation, firmly push the rotation adjuster back into place
to ensure that the seat is securely fixed.
(1)Rearward Direction:(40~105cm), must use rearward direction (see picture 1)
(2)Forward Direction: (76-150cm), must use forward direction (see picture 2)
WARNING: When the seat is rotated to a 90-degree angle, it is permissible to place
the child in this position. However, it is important to note that this angle should not be
used while driving. (see picture 3)
Picture 1 Picture 2 Picture 3
Unlock Mode
Lock Mode

11. Adjust the angle of the child safety car seat 12.Adjust the length of support leg
To adjust the seat, push the recline
handle upward and pull the seat
outward as shown in the picture.
This allows for adjustment in 4
positions when using the seat in a
forward-facing direction. However,
when rotating the seat to the
rearward direction, only the 4th gear
can be used. Please note that the
upright position is recommended for
children
between 100-150cm in height.
Installation of
rearward facing
Installation of forward facing
Installation of
forward facing
40-105cm,≤18kg 76-105cm,≤18kg 15kg≤,
100-150cm,≤36kg
Fourth Level First Level Second Level Third Level Fourth Level First Level
(Lying level) (Lying level)
Note: Do not use forward facing before the child’s age exceeds 15 months
STEP 1: Pull out the support leg to
the maximum angle.�
STEP 2: Pull out display window completely
STEP 3: Press the adjust button of support leg, hold
the support leg using the other hand and then
adjust the length of support leg.
STEP 4: When support leg is
in full contact with the ground
of vehicle so that can release
the adjust button. Pull the
support leg to make sure it is
locked.
Notice: After finishing the
installation of support leg,
display window turns into
green color.

13. How to use the isofix guide
14. How to use the isofix
15. Installation (40-105CM)
In order to lock the isofix connector to the steel point successfully,
it can use isofix guide.
Step 1 : Locate the ISOFIX connection
points in your car and insert the ISOFIX
guides to facilitate the installation
process.
Step 2 : Ensure that both ISOFIX
connectors are firmly and securely
attached to their respective ISOFIX
anchor points.
If you do not have an ISOFIX insert guide, you may disregard this step.
To retract or unlock the ISOFIX interface,
press and hold the switch in place.
Installed in Rearward facing position with ISOFIX and support leg (40-105cm)
STEP 1 : Set the seat tilt angle to the
fourth Level position.
STEP 2: Press the ISOFIX button to
release the two locking arms from
the base bottom.
STEP 3 : Insert the locking arms into the
ISOFIX attachment points until you hear
an audible CLICK, signifying that they
are fully engaged. Additionally,
ensure that the buttons on both
sides of the locking arms turn
into a green safety color.
STEP 4 : Extend the support leg
and adjust it to ensure full contact
with the ground of the vehicle.
Verify that the display window of
the support leg turns into a green color.
STEP 5 : Place the child into the seat and
securely fasten the harness. Pull the adjuster
strap until the harness is fully tightened.

L
o
r
e
16. Installation (76-105CM) 17. Installation (100-150CM)
Installed in forward facing position with ISOFIX and support leg (76-105cm)
IMPORTANT : Do not use forward facing before the child’s age exceeds 15 months.
STEP 1: Press the ISOFIX button to
release the two locking arms from
the base bottom.
.
STEP 2: Insert the locking arms into the
ISOFIX attachment points until you hear
an audible CLICK, indicating they are fully
engaged. Verify that the buttons on both
sides of the locking arms turn into
a green safety color.
STEP 3: Extend the support leg and
adjust it to ensure full contact with
the ground of the vehicle. Verify that
the display window of the support leg
turns into a green color.
STEP 4: Place the child into the seat and
securely fasten the harness. Pull the adjuster
strap until the harness is fully tightened.
17.1 Hide five-point safety belt system:
Step 1: Open the fabric cover of the backrest and thread the harness through the hole.
Step 2: Position the buckle in the booster, which is located under the cover.
17.2 Hide support legs:
Press the adjust button of the support leg.
Retract the support leg.
Press the display panel button icon "PUSH" with your thumb.
Push the panel forward to hide it.
Fold the support leg in half for storage.

17.2 Install the baby car seat(100-150cm)
1. Using ISOFIX:
Connect the ISOFIX connectors to the anchorage points on the car seat.
2. Not using ISOFIX:
Conceal the ISOFIX connectors in the booster. Position the seat against
the car seat and use the 3-point car seat belt for installation.
STEP 1 : Ensure that the support leg is concealed and adjust the seat
tilt angle to the first gear. Position the seat against the car seat.
STEP 2: Place the child in the seat and secure them by following the
path ①②③. Ensure that the seat belt is tightened adequately.
Important: It is crucial to emphasize that the lap straps should be worn
low down, ensuring that the pelvis is securely engaged..

18. Maintenance and cleaning 19. List of approved cars
CARE AND MAINTENANCE
Regularly examine your child seat for signs of wear or damage. If any damaged parts
are detected, replace the child seat immediately. Maintain cleanliness of the child seat
by avoiding the use of lubricants on any parts. To extend the lifespan of your nursery
product, ensure it is kept clean and protected from prolonged exposure to direct
sunlight. For removable fabric covers and trims, clean them with warm water and a
mild detergent. Allow them to dry completely, preferably away from direct sunlight.
CARE AND MAINTENANCE
To maintain the proper functioning of the harness buckle, it is important to keep it
clean and free from any food, drink, or debris that may accumulate inside. You can
wash the buckle in warm water until it is clean. Always ensure that you can hear an
audible click when using the buckle to ensure it is working correctly.
CLEANING THE HARNESS AND SHELL
To clean the child safety seat, use a sponge with warm water and mild soap. Avoid
using any other cleaning agents, as they may damage the seat or its components.
Gently wipe the surfaces of the seat with the sponge to remove dirt or stains.
After cleaning, allow the seat to air dry completely before using it again.
STORAGE
For proper storage of the child safety seat, choose a safe and dry location away from
heat sources and direct sunlight. It is important to avoid placing heavy objects on top
of the seat, as this can cause damage. By storing the seat in a secure and protected
area, you can help maintain its integrity and prolong its lifespan.
The following vehicle list is only for reference. If your vehicle
does not in the list, before using, please consult with the retailer
or manufacturer.
This car seat is approved for stature height 40-150cm, but it could
not fit all seating positions at a stature of 135cm.
Hand wash, Do not bleach Dryclean,any Do not tumble dry Do not iron
water solvent except
temperature trichloroethylene
below 30℃
Saloon No. of doors
Estate
Convertible
Hatchback
MPV
Coupe
Before you purchase the vehicle,
check that it is equipped with the
appropriate anchorages
Year of manufacture
Approved seats
No. of seat
Maximum body height
