Craftex CT103N User manual

CHANGING SPEEDS for CT103N
The motor has a 3-step pulley which will give you the 3 feed-speeds. The belt tension is
adjusted by loosening the nut “A” (see figure-1), and the motor bracket lock “B” under
the motor (see figure-1) and moving the motor slightly.
Figure-1 Shows the Nuts and the Motor Bracket Lock
Idler pulley is a 4-step pulley “C” (see figure-2). The 3 steps are to line up with the
motor pulley for the 3 feed-speeds and the 4th one is to drive the pulley behind the
wheel. The idler pulley can be adjusted by loosening the nut “D” (see figure-1) at the
back of the machine and adjusting it.
Figure- 2 Shows the Pulleys and the Wheel Inside the Cabinet
