Craftex CX series User manual

MODEL CX123
9" WOOD BAND SAW WITH LASER
USER MANUAL
Version 1.0

2
TABLE OF CONTENTS
Specifications………………………..……………………………………………………………………………..………..3 & 4
General Safety Instructions & Rules……………………………………………………………………………..………..5 & 6
Power Supply........................................................................................................................................................ 7
Plug and Grounding Requirements....................................................................................................................... 8
Unpacking............................................................................................................................................................. 9
Bench Mounting....................................................................................................................................................10
Assembly..............................................................................................................................................................11
Blade Tracking......................................................................................................................................................13
Dust Collection......................................................................................................................................................15
Blade Tensioning..................................................................................................................................................16
The Flutter and Deflection Method........................................................................................................................17
Adjusting Blade Support Bearings.........................................................................................................................18
Adjusting the Blade Guide Bearings......................................................................................................................19
Adjusting Miter Slot Parallelism.............................................................................................................................21
Fence Alignment...................................................................................................................................................22
Types of Cuts........................................................................................................................................................23
Disabling Paddle Switch........................................................................................................................................24
Tilting Table & Choosing Blades for CX123 ..........................................................................................................25
Tooth Type ..........................................................................................................................................................26
Blade Care & Blade Changing Instructions ...........................................................................................................27
Ripping & Cross Cutting........................................................................................................................................29
Maintenance.........................................................................................................................................................30
Checking Belt Tension..........................................................................................................................................31
Belt Replacement .................................................................................................................................................32
Inspecting Wheel Alignment..................................................................................................................................33
Shimming..............................................................................................................................................................34
Adjusting Shaft Position on Lower Wheel..............................................................................................................35
Laser Sight Adjustments.......................................................................................................................................37
Parts Diagram & Parts List………………………………………………..…………………………………..……….….39 & 40
Wiring Diagram.....................................................................................................................................................44
Warranty...............................................................................................................................................................45

3
Specifications:
Electrical:
Power Requirement................................................................ 120V, Single-Phase, 60 Hz
Full-Load Current Rating............................................................................................ 2.8A
Minimum Circuit Size................................................................................................... 15A
Connection Type..............................................................................................……….Plug
Power Cord Length………………................................................................................. 6 ft.
Motor:
Horsepower................................................................................................ ……….(320W)
Phase........................................................................................................... Single-Phase
Amps.......................................................................................................................... 2.8A
Speed............................................................................................................... 1720 RPM
Type........................................................................................................... ODP Induction
Main Specifications:
Band saw
Size............................................................................................................................ 9 in.
Max Cutting Width (Left of Blade).............................................................................. 9 in.
Max Cutting Width (Left of Blade) Max Cutting Height (Resaw height)............... 3-5/8 in.
Blade Speeds.................................................................................................. 2460 FPM
Wheels…………………………………………………………………….Balanced Aluminum
Tire....................................................................................................................... Rubber
Dust Port Size............................................................................................................ 2 in.
Wheel Diameter................................................................................................. 9-5/16 in.
Wheel Width............................................................................................................ 3/4 in.
Number of Dust Ports.................................................................................................... 1
Blade Information:
Standard Blade
Length....................................................................................................................... 62 in.
Blade Length Range........................................................................ 61-13/16 - 62-3/16 in.
Blade Width Range.......................................................................................... 1/8 - 3/8 in.
Blade Guides:
Guides........................................................................................................... Ball Bearing
Guide Post Adjustment Type...................................................................... Rack & Pinion

4
Table:
Table Length............................................................................................................ 12 in.
Table Width.............................................................................................................. 12 in.
Table Thickness...................................................................................................... 5/8 in.
Table Tilt........................................................................................................... 0 - 45 deg.
Table Tilt Adjustment Type......................................................................... Rack & Pinion
Floor-to-Table Height................................................................................................ 13 in.
Fence Locking Position............................................................................................ Front
Table......................................................................................................... Cast Aluminum
Trunnion.................................................................................................... Cast Aluminum
Fence..................................................................................................................Aluminum

5
GENERAL SAFETY INSTRUCTIONS
Extreme caution should be used when operating all power tools. Know your power tool, be
familiar with its operation, read through the owner’s manual and practice safe usage
procedures at all times.
ALWAYS read and understand the user
manual before operating the machine.
CONNECT your machine ONLY to the
matched and specific power source.
ALWAYS wear safety glasses
respirators, hearing protection and safety
shoes, when operating your machine.
DO NOT wear loose clothing or jewelry
when operating your machine.
A SAFE ENVIRONMENT is important.
Keep the area free of dust, dirt and other
debris in the immediate vicinity of your
machine.
BE ALERT! DO NOT use prescription or
other drugs that may affect your ability or
judgment to safely use your machine.
DISCONNECT the power source when
changing blade and / or making
adjustments.
NEVER leave a tool unattended while it
is in operation.
NEVER reach over the table when the
tool is in operation.
ALWAYS keep blades, knives and bits
sharpened and properly aligned.
ALL OPERATIONS MUST BE
performed with the guards in place to
ensure safety.
ALWAYS use push sticks and feather
boards to safely feed your work through
the machine.
ALWAYS make sure that any tools used
for adjustments are removed before
operating the machine.

6
CX123 Specific Safety Instructions
CX123 is designed for cutting wood only.
ALWAYS INSPECT the blade for any
cracked or missing teeth before operating
the band saw.
ALWAYS ENSURE that the blade tension
is properly set for the type and width of
blade installed.
NEVER place your fingers or hands in the
line of cut. If you slip, your hands or fingers
may come into contact with the blade.
Always use a push stick when ripping
narrow pieces.
DO NOT back the work-piece away from
the blade while cutting. Always turn off the
machine if you are backing out a cut.
ALL GAURDS must be in place while
operating the band saw to ensure safety.
ALWAYS FEED the stock smoothly. Do
not force or twist the work-piece while
cutting.
MAKE SURE that the band saw blade
guard is no more than 1/2” above the
stock.
MAKE SURE before making any
adjustments, the switch is in the “OFF”
position and the cord is un-plugged from
the power source.
NEVER LEAVE the band saw unattended while
it is running.
DO NOT attempt to remove jammed pieces
unless the band saw has come to a
complete stop and the power switch has
been turned to the OFF position.
NEVER TURN ON the band saw if the
blade is in contact with your stock.
ALWAYS ENSURE that the guide blocks
are properly set to prevent blade wander.
ALWAYS MAKE CERTAIN that the
bearings are properly adjusted to guide the
blade.
MAINTAIN AND SERVICE your band saw
regularly as instructed in the user manual.
MAKE SURE you have read and
understood all the safety instructions in the
manual and you are familiar with your band
saw, before operating the CX123. If you fail
to do so, serious injury could occur.

7
POWER SUPPLY
AVAILABILITY OF POWER
Before Installation of this machine you will
need to consider the proximity of your
power supply circuit. If available circuits do
not meet the requirements for this machine
you will have to get a new circuit installed by
a licensed electrician. Use of a licensed
electrician will minimize the risks of fire,
electrocution, damage to equipment, and
will insure everything is wired in accordance
to the applicable codes and standards.
FULL LOAD CURRENT RATING
This is the amount of Amps a machine
draws under 100% of the rated output
power.
FULL LOAD RATING FOR 120V
15AMPS
The full load current is not the maximum
amount of amps the machine will draw. The
machine has potential to draw current
beyond the full load rating if it is overloaded.
Overloading of the machine for an extended
period of time can cause damage,
overheating, or even fire. The risk is higher
if the machine is on an undersized circuit.
To help avoid these issues insure you are
connected to a circuit in which meets the
specified circuit requirements for this piece
of machinery.
WARNING!!!
Do not connect machine to power
before setup has been fully
completed to avoid risk of personal
injury or property damage.
CIRCUIT REQUIREMENTS FOR
CX123 Band Saw
The CX123 has been prewired at the factory
for operation on an electrical circuit that has
a verified ground and meets the below
requirements:
Voltage: 110V –120V
Cycle: 60Hertz
Phase: Single
Circuit Breaker Size: 15Amps
Please Note:
1. An electrical circuit includes all electrical
equipment between the breaker panel
and the machine. This is why it is
important to have the proper circuit size
so it can safely accommodate this
machine under full load for an extended
period of time.
2. The circuit requirements laid out in this
manual are for a dedicated circuit in
which only one machine will be
operational or installed at a time.
3. If you choose to connect to a shared
circuit where more than one machine

8
may be running at a time please consult
with a qualified electrician to insure the
circuit is properly sized for safe
operation.
PLUG AND GROUNDING
REQUITEMENTS
This machine must be grounded so that in
the event of certain malfunctions it will
reduce the chances of electrical shock by
providing a path of lesser resistance for the
electric current to travel through. For this
reason the CX123 comes with a cord
equipped with an equipment grounding wire
that leads in to the grounding prong on the
plug.
NOTE:
The three prong plug is only to be plugged
in to the matching receptacle that is properly
installed according to the local electrical
codes and standards. Under no
circumstances should you modify the plug
to make it fit in a receptacle that it is not
meant for this configuration. ( see figure 1)
Figure 1
If there is an improper connection of a
machine grounding wire it may result in a
heightened risk of electric shock. If repair or
replacement of the power cord is necessary
in the future please consult a licensed
electrician.
NOTE:
If ever you notice damage or ware to either
the cord or plug disconnect it immediately
from the power supply and have it replaced
by a licensed electrician or service tech
before any further use of the machine.
USE WITH EXTENSION CORDS
If you absolutely must require the use of an
extension cord with your machine do so, on
a temporary short term basis only.
NOTE:
1. We recommend that you do not use an
extension cord with this machine. Also the
longer the extension cord the greater the
possibility of voltage drop causing the motor
to work harder under powered which in turn
will cause it to draw more amps. This may
cause the thermal overload to trip or even
the breaker in your electrical panel. It may
also cause the extension cord to heat up
which can be a potential fire hazard.
2. If an extension cord is used with this
machine it must have a ground wire with a
plug that matches the one currently installed
on your machine. The extension cord must
also meet the following specifications below:
Minimum Wire Gauge: 16 AWG
Maximum Cord Length: 50 ft.

9
Unpacking
This machine has been carefully packed
prior to leaving our warehouse. If you
discover the machine has been damaged
after you have signed for delivery, please
immediately call Customer Service or your
local Busy Bee Outlet. Save all containers
and packing materials for possible
inspection by the carrier or its agent. When
completely satisfied with your shipment
you should inventory the contents.
Inventory
Before beginning setup, ensure that all of
the listed items have been received with
your package. If any non-proprietary parts
are missing (e.g. a nut or washer), we will
gladly replace them; or for the sake of
expediency can be purchased from your
local hardware store.
Inventory QTY
A. Band Saw Body 1
B. Table Assembly 1
C. Rubber Feet 4
D. Chip Blower Hose 1
E. Hex Wrenches 2.5mm & 4.5mm 1 ea.
F. Fence 1
G. Miter Gauge 1
H. Open End wrench 10 x 12mm 1
I. Push Stick 1
J. Table Lift Lock Lever 1
K. Flat Washer 8mm (Lock Lever) 1
NOTE:
If you cannot find an item on the list,
carefully check around/inside the machine
and packaging materials. Often, these items
get lost in the packaging materials while
unpacking or they are pre-installed at the
factory.
Setup Tools Needed
Safety Glasses
Small Machinist Square
Dust Collection System
Dust Hoe 2” Diameter
Hose Clamps 2”
Site Considerations
Weight Load
The surface that you place your machine on
must be able to bear the weight of the
machine, accessories that may be attached
and the heaviest work piece that may be
used. The machine weight can be found on
the Machine Specification Sheet. For the
weight of your accessories consult their
manufacturer’s operator’s manuals. Also to

10
consider is the weight of the operator and
dynamic loading when operating the
machine.
Space Allocation
When considering the space you need to
allocate for a safe and effective operation
you must take into account to provide
enough space for adequate material
handling or the installation of accessories.
In a permanent installation, leave enough
space around the machine to open or
remove doors as required for maintenance
etc.
Physical Environment
The physical environment where the
machine is operated is important for the
safe operation of any machine. Operate the
machine in a dry environment, free from
excessive moisture, hazardous chemicals,
airborne abrasives, or extreme conditions.
Extreme conditions for this machine are
those where the ambient temperature
range exceeds 5-40 degrees Celsius; the
relative humidity range exceeds 20%-95%
(non-condensing); or the environment
subject to vibration, shocks or bumps.
Electrical Installation
Make sure to place the machine near an
adequate power source. Ensure all power
cords are protected from traffic, material
handling, moisture, chemicals or other
hazards. Leave enough room around the
machine to disconnect the power supply or
apply a lockout device, if required.
Lighting
Shadows, glare or strobe lighting effects can
be distracting to an operator so the sources
must be eliminated. Good lighting is
essential for a safe operation of any
machine.
Bench Mounting
Note:
4 mounting holes each being 3/8” diameter
are required.
To prevent the machine from moving during
operation it is recommended to fasten the
machine to a workbench or other like
mounting surface. The machine has 4 pre-
drilled mounting holes in the base to
accommodate this. The strongest option is
a “Through Hole Mount” where holes are
drilled all the way through the workbench
or surface, securing in place with hex bolts,
washers and Hex Nuts. (Figure A)
Figure A
The other option is a “Direct Mount” (Figure
B) where the machine is secured directly
into the workbench with lag screws &
washers.

11
Figure B
Assembly
Before operating the machine it must be
completely assembled. Prior to beginning
the assembly process refer to Needed for
Setup and gather the listed items. First
clean all of the parts that are coated in
heavy-duty rust preventative.
Caution!
Band saw blades and parts are sharp. Wear
heavy leather gloves for protection.
1. Attach the (4) rubber feet to the
machine base. (Figure C) these rubber
feet simply press onto the corners of
the base.
Figure C
2. Loosen the Scale indicator and turn
it downwards, then remove the
table lock lever, flat washer, table
tilt adjustment knob, and shoulder
bolt with spring. (Figure D)
Figure D
3. Turn the guide post adjustment knob
(Feg.3) counterclockwise and raise the
guide post all the way up.
4. Remove the wing bolt, lock washer, flat
washer, and D-nut from the table
assembly for reinstallation later.
5. Using the gap in the table (Figure E),
slide the table assembly through the
blade and rotate the assembly 90 deg.
Position the assembly as shown in
(Figure F).
Figure E

12
Figure F
6. Re-install the components you
removed in step 2. DO NOT fully
tighten yet.
7. Completely raise the upper blade
guide assembly, then place a
machinist’s square flat on the table,
against the side of the blade. (Figure
G)
8. Using the adjustment knob, tilt the
table until the square is flat against
the side of the blade as in (Figure G).
9. Replace the lock lever to secure the
table perpendicular to the blade,
then set the scale indicator to “0” on
the tilt scale and tighten the screw.
Figure G
10. Re-install the wing bolt, lock washer,
flat washer, and D-nut (removed in
step 4) on the table assembly.
11. With the fence lock lever in the up
position install the fence on the
fence rail (Figure H). Once the fence
snaps into place, lower the fence
lock lever into the down position.
This will secure the fence to the rail.
Figure H
12. Snap the chip blower nozzle to the
nozzle base (Figure I).

13
Figure I
The band saw has multiple components
that must be properly adjusted for the best
cutting results. For practical and safety
reasons, some adjustments and test
operation must be performed before
making other necessary adjustments. Below
is an overview of all the adjustments and
the order in which they should be carried
out.
1. Blade Tracking
2. Dust Collection
3. Test Run
4. Blade Tensioning
5. Blade support Bearing Adjustments
6. Blade Guide bearings Adjustments
7. Table Alignment
8. Fence Alignment
Blade Tracking
“Tracking” is the term for how the blade
runs on the band saw wheels. Correct
tracking is important to maintain band saw
adjustments, achieving the correct blade
tension, and to cutting accurately. Incorrect
tracking setting can reduce cutting
accuracy, cause excess vibration, and place
stress on the blade amongst other
components. The wheel shape and
orientation in relation to each other will
determine how the blade tracks.
Band saw wheels are either flat or crowned
and both will track differently. This saw has
crowned wheels and as the wheels spin, a
properly tracking blade will naturally track
in the centre of the wheel. (Figure J)
Figure J
Band saw wheels must be aligned with each
other for optimal performance. Properly
aligned wheels are parallel and coplanar.
(Figure K)
Factors negatively affecting blade tracking
are improper blade tension, and cutting
practices. Familiarize yourself with the ideas
and conditions described in (Figure K), as
this will help you recognize when your
wheel alignment may need adjustment.

14
Figure K
The wheels on this machine has been
factory set, so centre tracking is the only
adjustment that needs to be performed
when the saw is new. This adjustment is
necessary before turning the saw on or
performing other adjustments.
1. DISCONNECT MACHINE FROM
POWER
2. Adjust the upper & lower blade
guides away from the blade, and
raise the upper guides all the way
up. (Refer to Adjusting Blade Guide
Bearings for detailed instructions).
Note:
For this test run, the blade must
have approximately the same
amount of tension as when under
operating conditions. After the test
run is successfully completed, you
will be instructed on how to more
accurately tension the blade for
optimum results.
3. Standing at the rear of the machine,
turn the quick release lever
clockwise to apply tension to the
blade.
Figure L
4. Open the upper wheel cover.

15
5. With moderate pressure push the
blade toward the fence. There
should be approximately ¼”
deflection. If not, then rotate the
tension adjustment knob as need
until the blade is properly tensioned.
6. Manually rotate the upper wheel
several times and watch how the
blade rides on the wheel (Figure J).
If the blade rides in the centre of the
upper wheel, it is tracking properly
and you are done. Now proceed to
Dust Collection following this
section.
If the blade does not ride in the
centre of the upper wheel, it is not
tracking properly, then proceed to
the next step.
7. Manually spin the upper wheel with
one hand while slowly adjusting the
tracking knob with the other until
the blade consistently tracks in the
centre of the wheel.
8. Close and secure the upper wheel
cover before operating the band
saw.
Dust Collection
CAUTION!
Wood chips and dust is the byproduct of
using this machine. Breathing airborne dust
may result in respiratory illness. To reduce
this risk, wear a respirator and connect the
machine to a dust collecting system.
Recommended CFM at the Dust Port: 100
CFM. The CFM recommendation is not to
be confused with the dust Collector rating.
To determine the CFM at the dust port,
there are variables that need to be
considered.
a) CFM rating of the dust collector
b) Type and length of hose between
the collector and the machine
c) Number of branches and Y
connections
d) The amount of other open lines in
the system
The calculation of these variables is not
covered in this manual however there are a
number of excellent books published on
this matter that deal specifically with dust
collection.
This machine has a 2” dust port. Connect
the hose as shown in (Figure L) and secure it
in place with a hose clamp. Gently pull on
the hose to ensure it does not come off. A
tight fit is necessary for proper
performance.
Figure L

16
Test Run
Once you have completely assembled your
machine, test run it to ensure it is properly
connected to the power and all safety
components are functioning properly.
If you encounter a problem during the test
immediately stop the machine, disconnect
it from the power, and fix the problem
before operating the machine again. Check
the Troubleshooting table in the SERVICE
section of this manual for help.
WARNING!
Serious injury or death can result from using
this machine BEFORE understanding its
controls and related safety information. DO
NOT operate or allow others to operate the
machine until the information is
understood.
WARNING!
DO NOT start the machine until all
preceding setup instructions have been
carried out. Operating an improperly set up
machine may result in a malfunction or
unexpected results that can lead to a
serious injury, death, or machine /property
damage.
1. Clear all tools away from the
machine
2. Connect the machine to the power
supply
3. Turn the machine ON, and verify
motor operation, then turn the
machine OFF.
The motor should run smoothly,
without problems and unusual
noises.
4. Remove the key, as shown in (Figure
M)
Figure M
5. Try to start the machine with the
ON/OFF paddle switch. The machine
should not start.
If the machine does not start,
the switch is working as
designed.
If the machine starts,
immediately stop the
machine. The switch is not
working correctly. This is a
safety feature and it must
work properly before
proceeding with operations.
Bade Tensioning
A band saw blade when tensioned correctly
is essential for making accurate cuts and
maximizing blade life. However other

17
factors such as improper feed rate,
hardness, variations between work pieces,
and improper blade selection affect the
performance of the machine in a negative
way.
To achieve the best results on any type of
work piece are achieved by proper blade
selection, tension, proper blade guide
adjustment, along with proper feed rate.
Improper blade tension is not only an
unsafe condition but produces inaccurate
and inconsistent results. This also can cause
unnecessary wear on the band saw
components. Over-tensioning increases the
chance of blade breakage or wheel
misalignment. Under-tensioned blades
wander excessively and will not track
properly during operation.
Blade tensioning methods can be a matter
of preference. We will describe two
methods here: the flutter method and the
deflection method, both of which will aid in
properly tensioning the blade. As you gain
experience you can decide which you find
preferable.
Note:
Tensioning the blade during the test run
was an approximate tension. The following
procedures fine-tune the blade tension.
The Flutter Method
With this method, you will loosen the blade
until it just passes the point of being too
loose (it will begin to flutter). Then you
gradually tighten the blade until the proper
tension is reached.
1. DISCONNECT THE POWER FROM
THE MACHINE
2. Check that the blade is tracking
properly (see Blade Tracking
section)
3. Raise the guide post all the way then
move upper and lower guide
bearings away from the blade.
4. With the quick-release lever, engage
the tension on the blade
5. Connect the band saw to the power
and turn it ON.
6. Turn the blade tension knob to
slowly decrease the blade tension
until you see it start to flutter.
7. Slowly increase the tension until the
fluttering stops. Then turn the knob
an additional 1/8 to ¼ of a turn.
8. DISCONNECT THE MACHINE FROM
POWER
9. Adjust the guides as described in
Adjust Blade Support Bearings /
Adjusting Blade Guide Bearings
sections.
The Deflection Method
Band saw blades vary in width and
thickness therefore this method is more
subjective than the flutter method. The
user will have to determine what
“moderate pressure” means.
1. DISCONNECT THE MACHINE FROM
THE POWER

18
2. Check that the blade is tracking
properly (see Blade Tracking
section)
3. Raise the guide post all the way then
move upper and lower guide
bearings away from the blade.
4. With the quick-release lever, engage
the tension on the blade
5. Using moderate pressure, push the
centre of the blade sideways with
just one finger.
If the blade deflects
approximately ¼”, it is
properly tensioned. Proceed
to Step 6.
If the blade deflects less than
¼”, it is over-tensioned. Turn
the blade tensioning knob
counterclockwise two full
turns and repeat Step 5.
If the blade deflects more
than ¼”, it is not properly
tensioned. Apply tension to
the blade incrementally and
repeat Step 5 until properly
tensioned.
6. Adjust the guides as described in
Adjust Blade Support Bearings /
Adjusting Blade Guide Bearings
sections.
Adjusting Blade Support
Bearings
The blade support bearings (located behind
the blade near the blade guides) prevent
the blade from pushing backward during
any cutting operations. When proper
adjustment is maintained it helps you make
accurate cuts and prevents the teeth of the
blade from coming in contact with the
Blade Guides when cutting. This can ruin
the tooth set on your blade and greatly
reduce the blades ability to make a good
cut.
There are support bearings on both the
upper and lower guide assemblies. Both
adjust in the same manner. The following
instructions refer to the upper support
bearings. Access to the lower support
bearings you need to open the lower wheel
cover.
Important:
Make sure the blade is tracking and
tensioned properly before performing this
procedure.
Required Tools
One 4mm Hex Wrench
0.016” Feeler gauge
1. DISCONNECT THE MACHINE FROM
THE POWER
2. Open the blade cover and loosen
the support bearing adjustment cap
screw (Figure N)

19
Figure N
3. Using the feeler gauge, position the
support bearing approximately
0.016” away from the back of the
blade, as in (Figure O)
Note:
The purpose of this adjustment is to
prevent the blade from being pushed
backward far enough that the blade guides
contact (and ruin) the” tooth set” of the
blade during cutting operations.
Figure O
4. Tighten the adjustment cap screw to
lock the support bearing in place
Note:
When securing the lower support
bearing, make sure it is parallel with
the blade.
Adjusting the Blade Guide
Bearings
Properly adjusted blade guide bearings
provide side-to-side support, from just
behind the gullets to the back of the blade,
to help keep the blade straight while
cutting. These bearings can be adjusted left-
to-right, as well as front to back.
Both the upper and lower blade guide
assemblies have these bearings and both
adjust in the same manner. The following
refers to the upper bearings.
Important: make sure the blade is tracking
and tensioned properly before performing
this procedure.
1. DISCONNECT THE MACHINE FROM
THE POWER
2. Loosen the guide block cap screw
(Figure P), and then laterally
position the guide bearings just
behind the blade gullets as in (Figure
Q), then retighten the cap screw to
secure seating.
Note:
The guide bearings should be
positioned behind the gullets a
distance equal to that of the support
bearing behind the blade.

20
Figure P
Figure Q
Note:
With wider blades, it may not be possible to
bring the guide bearings just behind the
blade gullets. Position them as far forward
as possible without allowing the guide
bearing housing to touch the back of the
blade.
NOTICE
The band saw blade teeth are angled out
slightly, protruding wider than the blade
thickness; this is known as the “tooth set”
(Figure R). If teeth contact the guide
bearings during operation, damage may
occur. Therefore, the support bearing must
be set to prevent teeth from contacting the
guide bearings during operation.
Figure R
3. Loosen the guide bearing lock
screws (Figure P)
4. Loosen both guide bearing
adjustment screws (Figure P), and
then position the guide bearings so
they evenly and lightly touch the
sides of the blade (Figure S) without
deflecting it one way or the other.
Note:
When the blade guide bearings are
properly adjusted against the blade,
they should lightly rotate as the
blade moves.
Figure S
5. Tighten the guide bearing lock
screws.
