Craft+Main MARINA User manual

COPY THE MODEL NUMBER FOR YOUR RECORDS HERE #
SLIDING
SHOWER & TUB DOOR
MARINA
READ THE INSTRUCTIONS CAREFULLY
Familiarize yourself with all the parts as shown in the exploded
view. The exploded view will also provide a helpful reference
when relating to the location of the various parts and how
they are mounted.
by
Toll Free Customer Assistance 1-888-620-3667 US Customers
1-888-256-7551 Canada Customers
Monday-Friday, 7:30 a.m. To 5:00 p.m. CST
Please visit us on YouTube and view our shower door installation videos.
One may be available for your installation. www.youtube.com/c/CRAFTANDMAIN
© 2022 FGI Industries, Ltd. | CRAFT + MAIN™, Marina™ and logo designs are trademarks or registered trademarks of FGI Industries, Ltd.
6241 Northwind Parkway, Hobart, IN USA 46342
USA: www.craftandmain.com
5970 Chedworth Way, Unit B, Mississauga, Ontario, Canada L5R 4G5
CANADA: www.craftandmain.ca
TM

- 1 -
1 1/2” Pan Head Screw
1 1/2” Pan Head Screw
3/8” Pan Head Screw

PART LIST
WARNING: Safety glass should alway be worn
when working with tempered glass.
- 2 -
RECOMMENDED TOOLS
1/4" (6mm)
1/8" (3mm)
1 1/2” PAN HEAD SCREW
(6 pcs)
3/8” PAN HEAD SCREW
(2 pcs)

- 3 -
INSTALLATION PROCEDURE / STEP 1 / STEP 2
1Attach rollers to hanger clips on outside panel (with horizontal towel bar holes). Rollers should be
mounted so that the nut that holds it in place is on the same side of the panel as the screw head set
into the hanger clip (see inset drawings) .
NOTE: The various holes in the hanger clip are used to fine tune the adjustment of the panel to make
up for walls that are slightly out of square or plumb. For best results start with all rollers in the second
hole from the top and then make adjustments as needed.
2Attach rollers to hanger clips on the Inside panel, rollers should be mounted so that when the glass is
positioned with the (vertical) holes in the glass on the same end of your opening as your shower head,
the rollers are to the inside of your tub or shower.

INSTALLATION PROCEDURE / STEP 3 / STEP 4 / STEP 5 / STEP 6
3Measure opening on bottom and cut bottom track (2) 1/8" shorter than opening.
- 4 -
Run a thin bead of silicone caulk down the entire length of both bottom ledges on the bottom track.
Place the bottom track into position and press down firmly along the length of the track.
6
4Place wall jamb down over bottom track so that the back of the jamb is between the bottom track
and the wall. Using a level to ensure jamb is plumb, mark hole locations. Remove jamb and drill
holes about 1 1/2" deep at each of the marked locations.
NOTE: When drilling into ceramic, glass or stone use a 1/4" (6mm) MASONRY drill bit.
NOTE: When installing on fiberglass or acrylic use a 1/8" (3 mm) drill bit and discard the wall plugs.
Repeat Step 4 on the other side.
5

INSTALLATION PROCEDURE / STEP 7 / STEP 8
- 5 -
8Dab silicone into all 3 holes on each side. Run 1 1/2" pan head screws through wall bumper and use to
attach wall jamb to wall in top and bottom holes only on both sides.
7Push wall plugs into holes drilled in Step 4 and tap them in with a rubber mallet.
NOTE: If you are installing on fiberglass or acrylic, skip this step and discard the wall plugs.
1 1/2"PAN HEAD SCREW

INSTALLATION PROCEDURE / STEP 9 / STEP 10 / STEP 11
- 6 -
9Use 1 1/2" pan head screws to anchor wall bumper and bumper guide into center hole on each side.
10 Measure opening at top of wall jamb, cut top track (1) 1/16" shorter than opening.
11 Place top track down over wall jambs as shown.
1 1/2"PAN HEAD SCREW
1
8
7
13
L=actual opening - 1/16"
13
1
13
STEP 9
STEP 10
STEP 11

- 7 -
INSTALLATION PROCEDURE / STEP 12
12 Install outer door panel by lifting up and into top track (1).
(Do not lift by towel bar, be careful not to bump panel against metal track.)
INSTALLATION PROCEDURE / STEP 13
13 Insert inner door panel by lifting
up and into top track.

Install towel bar (5A).
INSTALLATION PROCEDURE / STEP 14 / STEP 15
14
- 8 -
Install handle (5B).
15
3/8"PAN HEAD SCREW
Position panel guide in center
of bottom track. Drill two 1/8"
holes through screw holes in
guide and into bottom track.
Position panels in guide as
shown in inset drawing and
attach guide to bottom track
using 3/8" pan head screws.
INSTALLATION PROCEDURE / STEP 16
16
1/8"(3 mm) DRILL BIT

- 9 -
INSTALLATION PROCEDURE / STEP 17
Install safe slider clip (9).
To install safe slide clip, put install bar into clip and lift onto clip hanger
pull down leaving clip in place.
17
FINAL STEP:
Caulk both sides of the shower door frame to seal.
Keep the entire area dry for a minimum of 24 hours.
SAFE SLIDER CLIP
9CAULK ALL SIDES
TRIM SAFE SLIDER
CLIP IF NECESSARY
16
SAFE SLIDER INSTALL ROD
Put install bar into clip and
lift onto clip hanger
pull down leaving clip in place.
