Croydex PA670100 User manual

PA670100
LOTION BOTTLE WALL
MOUNTED 1L TRANSPARENT
S&H 078 R01
1
ALL PRODUCT DIMENSIONS DETAILED IN THIS
INSTALLATION AND MAINTENANCE MANUAL
ARE APPROXIMATE
ALL ILLUSTRATIONS OF THE PRODUCT ARE FOR
REFERENCE ONLY. COMPONENTS SUPPLIED
WITH INDIVIDUAL PRODUCTS MAY DIFFER
CONTACT DETAILS
Croydex
Central Way
Andover
Hampshire
SP10 5AW
UK
Tel: [phone]
Email: [e-mail]
www.croydex.com
INTRODUCTION
Thank you for purchasing this Croydex product. Please follow all assembly and product care instructions
to ensure that your product is assembled safely and retains it's high quality finish.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
x1
SAFETY & PRODUCT CARE
1. ALWAYS take care when using power tools, particularly if there is any water in the working area.
2. ALWAYS wear eye protection when using power tools.
3. ALWAYS check for pipes and cables before drilling into walls.
4. ALWAYS use a ceramic drill bit when drilling into tiled surfaces.
5. ALWAYS use a drill bit that is suitable for the surface that is being drilled.
6. The wall plugs supplied are for use on solid walls only. For cavity walls or plasterboard ALWAYS
use specialist fixings that are suitable for the type of wall construction.
7. DO NOT use abrasive or chemical cleaners as these may damage the product.
PRODUCT CAPACITY
This product has a capacity of
1 LITRE
MAX
1L
PRODUCT FITTING
IMPORTANT! : Before attempting to fit or use this product. Ensure that it fits and functions in
the desired location.
7
mm
TOOLS REQUIREDWALL FIXING PACK
x2 wall
screws
x2 wall
plugs

S&H 078 R01
2
1. Place the bracket against the wall in the desired
position. Place the spirit level along the top of the
bracket, level and mark the hole centres for drilling.
(See Fig. 1)
fig. 1
2. Drill the holes to a depth of 34mm in the
marked positions using a 7mm masonry drill. If the
product is being fitted onto a ceramic tiled wall - a
ceramic drill bit should be used. (See Fig. 2)
fig. 2
fig. 4
4. Insert the wall screws into the wall plugs.
Tighten with a cross head screwdriver until the
screw heads are approximately 5mm from the wall
surface. (See Fig. 4)
3. Insert the wall plugs flush to the wall surface.
If fitting to a tiled surface the wall plugs should
be inserted below the surface of the tile to avoid
cracking. (See Fig. 3)
fig. 3
5mm
5. Slide the wall bracket down onto the screws to
lock into place. (See Fig. 5)
fig. 5
6. Tighten the screws to lock the bracket in place.
Do not overtighten. (See Fig. 6)
fig. 6
7. Slide dispenser unit down onto the wall bracket.
Check that the product is securely fixed to the
mounting surface before use. (See Fig. 7)
fig. 7
