Craftsman C583-930360 User manual

®
C
OPERATING
INSTRUCTIONS
®
ELECTRIC NAILGUN
Model C583-930360

2
Safety Information
WARNING
Follow all safety precautions outlined in these operating instruc-
tions. Improper use of this tool can cause severe injury or death
from fire, electrical shock, or firing nail into body.
!
WARNING ICON G 001
Before Operating Tool
1. Read and understand these operating instructions before operating tool.
2. Only well-instructed adults should operate tool. Never allow children to operate tool.
3. Do not operate tool
•where highly flammable liquids or gases are present
•while under the influence of alcohol, medication, or drugs
•if exposed to rain or in damp or wet areas
•while tired or in a hurry
•if tool is damaged
•if trigger does not turn tool on and off. Have faulty switch replaced by factory
service center.
4. Make sure tool is grounded while in use. This will protect the operator from
electrical shock. This tool has a three-wire cord and a three-prong, grounded
plug. Only connect tool to a three-prong, grounded outlet. The green (or green
and yellow) wire in the cord is the grounding wire. Never connect the grounding
wire to a live terminal. If you have a two-prong outlet, use an adapter (see Figure
1). Attach the green-colored lug (extending from the adapter) to a permanent
ground. You can attach lug to a properly grounded outlet box with a metal screw
(see Figure 1). Cover of
Grounded
Outlet Box
Metal
Screw
Adapter
Grounding
Pin
Green Colored Lug
(Grounding Means)
Figure 1
5. Use only three-prong, grounded extension cords marked for outdoor use.
6. Never use this tool
•where heavy-duty tool is needed
•where not intended - for example - don’t use tool on concrete, metal, or glass
7. Wear snug-fitting clothing when operating tool. Do not wear loose clothing or
jewelry. They can get caught in moving parts.
8. Wear the following safety gear when operating tool.
•rubber gloves and footwear with non-skid soles (outdoors)
•eye protection conforming to CSA regulations. Make sure anyone in the vicinity
of tool wears eye protection.
•hair covering to contain long hair

3
9. Keep work area well lit.
10.Move trigger lock to the OFF position and unplug tool
•when loading tool
•when not in use
•when moving from one place to another
•before maintenance
•when changing accessories
11.Do not alter this tool in any way.
During Operation of Tool
1. Keep all parts of body away from nail opening on tool.
2. Never point tool at anyone.
3. Keep children, animals, and bystanders away from tool and extension cord at all
times. Only tool user should be in work area.
4. Stay alert. Use common sense while operating tool.
5. Keep trigger lock in the OFF position and finger off trigger until ready to drive nail.
6. Keep work area clean. Cluttered work areas invite injuries.
7. Secure work before using tool. Use both hands to operate tool.
8. Do not touch any metal part of tool when nailing into areas where electrical wiring
may be present. These areas include walls, floors, and ceilings. If nail contacts
electrical wire, electric shock may occur.
9. Avoid body contact with grounded objects such as pipes, fences, and metal posts.
10.Do not force tool. Use tool at rate for which it was designed.
11.Do not overreach. Keep proper footing and balance at all times.
12.Carry tool from one place to another
•with tool unplugged
•with trigger lock in the OFF position
•with finger off the trigger
General
1. Inspect tool before and after each use. Check tool closely if it has been damaged.
Check for any damage that may affect operation of tool. Check for alignment or
binding of moving parts. Check for broken or damaged parts. Do not use tool if
damage affects operation. Have damage repaired by factory service center.
2. When servicing, use only identical replacement parts.
3. Maintain tool with care.
•Never fire tool when empty of nails. This may damage tool.
•Keep tool clean.
•Keep handles dry, clean, and free of oil and grease.
•Inspect power cord often. If damaged, have repaired by factory service center.
•Never carry tool by power cord.
•Never yank power cord to unplug it.
•Keep power cord away from heat, oil, and sharp edges.
•Inspect extension cords often and replace if damaged.
• Never oil or grease any part of tool.
4. Always store tool
•with nails removed from chamber
•out of children’s reach
•in a high or locked place that is dry
Keep these operating instructions for reference. It is your guide to safe and proper
operation of this tool.

4
Product Identification
The CRAFTSMAN®Electric Nailgun is a multi-purpose tool. This tool is
designed for home and workshop. It performs basic nailing jobs from installing
paneling, weatherstripping, and molding to making crafts.
Trigger This tool has an easy squeeze trigger. The trigger is located on the
underside of the hand grip. Each squeeze of the trigger fires one nail. Make sure
your finger is not on the trigger when connecting or loading the tool.
Safety Lock The safety lock is located on the nail exit of tool. The safety lock
must be depressed for this tool to operate. Do this by pressing the nail exit of
tool against your work surface. This tool will not fire unless this is done.
ON/OFF Trigger Lock This tool is equipped with a sliding ON/OFF trigger lock.
The trigger lock is located at the front of the hand grip, just above the trigger.
This safety feature helps prevent accidental firing. Make sure the trigger lock
reads OFF when plugging in or loading the tool. Also, make sure the trigger lock
reads OFF when tool is not in use. To release, slide the trigger lock to read ON.
Product Features
Head
On/Off Trigger
Lock Hand Grip
Safety
Lock
Nail Exit
Trigger
Power
Cord
Nail
Chamber

5
Extension Cords
CAUTION
!
WARNING ICON G 001
Useonlythree-prong,groundedextensioncordsmarkedforoutdooruse.
1. Move trigger lock to the OFF position. See PRODUCT IDENTIFICA-
TION on page 4 to locate trigger lock.
2. Unplug tool.
3. Remove nail pusher from nail chamber. Access nail pusher at rear of
nail chamber. Push end of nail pusher in and down to release it (see
Figure 2). Pull nail pusher from nail chamber (See Figure 3).
Loading Tool
Never load tool while it is plugged in. Accidental discharge may
occur. Before loading, move trigger lock to the OFF position and
unplug tool.
WARNING
!
WARNING ICON G 001
Figure 3
Be sure to use the right size extension cord. If cord size is wrong, tool may
be damaged. Tool performance may also be affected. Use only a three-
prong, grounded extension cord.
Extension Cord Size Requirement
1 to 12 feet, use 16 AWG rated cord
12 to 50 feet, use 14 AWG rated cord
Inspect extension cord often. Replace cord if worn or damaged.
Figure 2
Nail Pusher
2
1
Nail Pusher

6
4. Insert nails into nail channel
through rear of nail chamber
(see Figure 4). Make sure nail
points are towards bottom of
tool.
Note: We recommend that you
only use CRAFTSMAN®brad
nails in this tool. Wrong brad
nails can cause jamming.
5. Replace nail pusher into nail
chamber. Do this by inserting
flat metal end of nail pusher into
nail channel (see Figure 5).
Fully push nail pusher into nail
chamber. Push hook end of nail
pusher up and latch it to nail
chamber.
Brad Nails
Keep trigger lock in the OFF position and finger off trigger until
ready to drive nail.
WARNING
!
WARNING ICON G 001
Keep all body parts away from nail exit opening on tool.
WARNING
!
WARNING ICON G 001
1. Make sure trigger lock is in the OFF
position.
2. Plug tool into a 115 Volt/60 Hertz outlet.
3. Grip tool firmly and hold against work
surface. Use enough pressure to depress
safety lock. The safety lock is located on
nail exit of tool (see Figure 6).
IMPORTANT: The safety lock must be
depressed for this tool to operate. This
tool will not fire unless this is done.
Operating Tool
Safety Lock
Figure 6
Nail Channel Figure 4
Nail Channel
Figure 5

7
Figure 7
4. Slide trigger lock to the ON
position.
5. Place palm of free hand firmly
on head of tool (see Figure 7).
6. Squeeze trigger to fire.
7. IMPORTANT: Do not repeat-
edly fire this tool when empty
of nails. This may damage tool.
!
WARNING ICON G 001
Do not alter this tool in any way. Only use accessories designed
for this tool.
WARNING
Maintenance
WARNING
!
WARNING ICON G 001
Never perform steps listed below while tool is plugged in.
Accidental discharge may occur. Move trigger lock to the OFF
position and unplug tool.
Tool Jam
1. If tool jams, move trigger lock to the OFF position and unplug tool.
2. Remove nail pusher (see LOADING TOOL, page 5).
3. Remove unused nails.
4. Remove nail(s) causing jam.
5. If unable to clear jam, remove two screws at front of tool above nail exit to
remove plates at front of tool. Remove nail(s) causing jam. Reassemble
plates at front of tool.
6. Reload tool (see LOADING TOOL, page 5).
Cleaning
Use a clean cloth to remove dirt from tool. Do not use solvents when cleaning
plastic parts.
Lubrication
Do not oil or grease any part of tool. This may damage tool.
IMPORTANT: Do not attempt to repair tool or replace broken parts. Any
servicing, except what is listed above, should be done by factory service center.

104066-01
REV. A
05/97
Nails
We recommend that you only use CRAFTSMAN®brad nails. These 1" brad
nails are available in four nail-head colors. You can choose a nail-head
color that will best match the color of your finished project. CRAFTSMAN®
brad nails can be found where you purchased your nailgun.
Part Nail-Head
Number Color
93190 Off White
93191 Light Brown
93192 Medium Brown
93193 Dark Brown
FULL ONE YEAR WARRANTY ON CRAFTSMAN®
ELECTRIC NAILGUN
If this CRAFTSMAN®ELECTRIC NAILGUN fails to give complete
satisfaction within one year from date of purchase, RETURN IT TO THE
NEAREST STORE IN CANADA, and Sears will replace it, free of charge.
If this CRAFTSMAN®ELECTRIC NAILGUN is used for commercial or
rental purposes, this warranty applies for only 90 days form the date of
purchase.
This warranty gives you specific legal rights, and you may also have other
rights which vary regionally within Canada.
Sears Canada, Inc.
Toronto, ON
M5B 2B8
Printed In Taiwan

®
C
PISTOLET CLOUEUR
ÉLECTRIQUE
Modèle C583-930360
MODE D’EMPLOI
®

2
Consignes de sécurité
Préliminaires à l’utilisation
1. Lire et comprendre ce mode d’emploi avant d’utiliser l’outil.
2. L’outil ne doit être utilisé que par des adultes qui ont appris comment s’en servir.
Ne jamais laisser des enfants s’en servir.
3. Ne pas utiliser l’outil
•en présence de liquides ou de gaz hautement inflammables
• lorsque l’on se trouve sous l’influence de l’alcool, de médicaments ou de drogues
•sous la pluie ou dans des endroits humides ou mouillés
• sous l’emprise de la fatigue ou de contraintes de temps
•si l’outil est abîmé
•s’il n’est pas possible de mettre en marche ou d’arrêter l’outil à l’aide de la détente.
Faire remplacer l’interrupteur défectueux par le service après-vente de l’usine.
4. S’assurer que l’outil est mis à la terre lors de son utilisation afin de se protéger
contre le risque de choc électrique. Cet outil est muni d’un cordon trifilaire et d’une
fiche à trois broches, terre comprise. Ne brancher cet outil que dans une prise
double avec terre. Le fil vert (ou vert et jaune) du cordon est le fil de terre. Ne
jamais connecter le fil de terre à une borne sous tension. Si l’on a affaire à une
prise àdeux trous sans terre, utiliser un adaptateur (voir la figure 1). Rattacher la
patte verte (qui dépasse de l’adaptateur) à une terre permanente. La patte peut
être fixée à l’aide d’une vis métallique à une boîte à prises avec mise à la terre
conforme (voir la figure 1).
5. Utiliser uniquement des cordons prolongateurs à trois broches, terre comprise,
indiqués pour l’utilisation à l’extérieur.
Broche
de terre
Vis métallique
Adaptateur
Patte verte (de
mise à la terre)
Figure 1
Couvercle de
boîte de prises
mise à la terre
6. Ne jamais utiliser cet outil dans des conditions de service sévère pour des usages
non prescrits, notamment sur du béton, du métal ou du verre.
7. Porter des vêtements ajustés durant l’utilisation de l’outil. Ne pas porter de
vêtements lâches ou des bijoux qui pendent, car ils risquent de s’accrocher dans
les pièces mobiles.
8. Porter l’équipement de protection suivant lors de l’utilisation de l’outil:
•gants de caoutchouc et chaussures avec semelle anti-dérapante (pour
utilisation extérieure)
AVERTISSEMENT
Veiller à suivre toutes les précautions de sécurité figurant dans ce
mode d’emploi. L’utilisation incorrecte de cet outil risque
d’entraîner des blessures graves ou mortelles par incendie, choc
électrique ou enfoncement d’un clou dans le corps.
!
WARNING ICON G 001
