Crane 633 Instruction Manual

Page 1 of 6 9989699 - May, 1996
INSTRUCTIONS FOR INSTALLING A NEW CONTROLLER BOARD AND INITIALIZING
RAM IN THE FOLLOWING MACHINES:
HOT DRINK CENTER
EURO-DRINK
SNACK CENTER
SHOPPERTRON
ICE CREAM CENTER
Change the controller board:
WARNING
Lethal voltages are present inside the machine. Remove
all electrical power from the machine to avoid personal
injury or death.
1. Turn off the machine power switch, or unplug the machine.
2 . Make note of where all wiring connects to the controller for ease of reas-
sembly. Remove all connectors from the controller board.
CAUTION
Wear a grounding wrist strap to avoid causing electro-
static discharge damage to components.
3. Remove the controller board.
NOTE
If you have ordered a new controller board without an EPROM, and/or
without standoffs, retain those parts for installation in your new board.
4. Install parts in the new controller board, if applicable.
5. Install and connect the new controller board.
6. Proceed to the appropriate set of steps for your machine.
© CRANE National Vendors 3/96

Page 2 of 69989699 - May, 1996
HOT DRINK CENTER OR EURO-DRINK MACHINE (Models 633, 634, 635, 636, 637)
NOTE
When you installed the new controller board, chances are good that its
memory (the RAM) is scrambled. If that is the case, you may be locked out
of the functions you need to access in order to program the machine. To
get around this, you will need to clear the entire RAM. This not only erases
any stray supervisor codes, but eliminates accumulated sales totals, and
your custom programming, such as ingredient and water throw times. YOU
DO NOT WANT TO DO THIS TO A MACHINE WHICH HAS NOT HAD ITS
CONTROLLER BOARD CHANGED!! (Unless you enjoy doing a lot of
unnecessary programming, that is.)
Initialize the RAM:
1. The machine must be on and in "ready" mode. This is when a message - any message (or part of one)
is scrolling across the display.
2. While holding , press on the service keypad. The display will show PROD TEST.
3. Press . The display shows the current software version.
4. Press . The display shows CLEAR ALL.
5. Press and hold . The display shows CLEARING, then the beeper sounds and the display shows
FINISHED. You have now cleared RAM.
6. Press . The display shows CONF 0. This is the configuration code. Refer to your setup manual
to find the correct configuration code for your machine. Enter that configuration according to your
manual.
7. Press . The display shows COUNTRY US. This lets you tell the machine what country it is in, and
which preferences apply. Press to step through the various country choices: US (United States),
UK (United Kingdom), GR (Germany), FR (France), and SP (Spain). When your country is displayed,
press . You may now access all programming steps described in the setup manual.

Page 3 of 6 9989699 - May, 1996
8. Press . The display shows: DOOR OFF. This lets you tell the machine if it has an automatic
delivery door. Press to switch back and forth between DOOR OFF and DOOR ON.
9. Press . The display shows: DUMB MECH. This lets you tell the machine what kind of coin mecha-
nism is installed. Press until your coin mechanism is displayed.
10 Press . The display shows: NO VALIDTR. This lets you tell the machine if a bill validator is
installed, and if so, what kind of bills it will accept. Press to switch between NO VALIDTR and
OK. $1, - , - , - - , - - ,. When a monetary value is displayed after OK, the bill validator will accept that
denomination of bill. Press the 1, 2, 5, 6, or 7 keys on the selection switch panel or the service
keypad to switch $1, $2, $5, $10, or $20 on and off. If you turn off all values, NO VALIDTR is automati-
cally selected.
11. Press . The display shows: MON 12.00. This allows you to set the correct time of day. In this
example, it is Monday at 12:00 (noon). Press to change the day of the week, or use the number
keys on the selection switch panel or the service keypad to enter the correct time (24-hour format).
12. Press . The display shows: SEP 30- 96. This allows you to set the correct month, date, and year.
In this example, it is September 30, 1996. Press to change the month. Use the number keys on
the selection switch panel or the service keypad to: Enter the date as two digits (30) and enter the last
two digits of the year (96).
13. Press . You have finished the preliminary steps for configuring your machine. Now refer to your
setup manual for programming all the other data into RAM, such as cup size, time of day events,
pricing, winners, etc.

Page 4 of 69989699 - May, 1996
SNACK CENTER (Models 157, 158, 464, 465, 484, 485, 486, 487, 488, 489)
NOTE
When you installed the new controller board, chances are good that its
memory (the RAM) is scrambled. If that is the case, you may be locked out
of the functions you need to access in order to program the machine. This
is caused by a supervisor code in RAM that you may not know. To get
around this, you will need to bypass that code.
1. On the service keypad, press . The display shows CODE.
2. On the service keypad, press . The display shows ENTER CODE.
3. On the selection keypad, enter ACGJ and press . The display shows ASSEMBLY.
4. Press . The display shows DUMB MECH. RAM is clear.
5. Turn power OFF and wait several seconds. Turn power ON; you may now access all programming
functions as described in the setup manual.

Page 5 of 6 9989699 - May, 1996
SHOPPERTRON (Model 431)
NOTE
When you installed the new controller board, its memory (the RAM) is not
initialized for any particular model of machine.
To initialize the RAM:
1. The machine must be on and in "ready" mode. This is when a message - any message (or part of one)
is scrolling across the display.
2. While holding , press on the service keypad. The display will show PROD TEST.
3. Press . The display shows the current software version.
4. Press . The display shows CLEAR ALL.
5. Press and hold . The display shows CLEARING, then the beeper sounds and the display shows
FINISHED. You have now cleared RAM.
6. Press . You may now access all programming steps described in the setup manual.

Page 6 of 69989699 - May, 1996
ICE CREAM CENTER (Model 411)
1. Press and hold
CONFIG
, and at the same time press 3on the selection keypad. The display shows
CODE.
2. Press
*
. The display shows ENTER CODE.
3. On the selection keypad, enter 0000.
4. Press
*
. The beeper sounds and the display shows UNLOCKED.
5. You may now access all programming functions as described in your Operator's Guide.
6. It is suggested that you clear all resettable counters (RAM CLEAR) as outlined in your Operator's
Guide.
