Creative Muvo_2_qsg User manual

English

A Tour of Your Player

On/Off and

Play/Pause button

Liquid Crystal

Display (LCD)

Menu button

Front view

Earphones / wired

remote (optional) jack

USB

port

Power adapter

jack

To p v i e w

Multi_cle.book Page 1 Monday, September 20, 2004 12:36 PM

Using the Menu Button

Select

The Menu button (Figure 1) is one of the most important features of your

player. In this document, we will use the term, “Select”, to mean that you

should move the Menu button towards the left or right to browse through

options, and then select the option by pressing the Menu button.

Volume

You can also adjust volume levels with the Menu button.

Move the Menu button upward to increase volume or downward to decrease volume.

Using Your Player

Button What It Does Usage Tips

Menu • Displays Menu options on

the LCD.

• For more information on using the Menu

button, see "Using the Menu Button"

above.

Play/Pause • Turns your player on and

off.

• Enables playing and pausing

of tracks.

• Press and hold to turn your player on and

off.

• In Music mode, press this button to start

playing tracks, and press again to pause

playback.

Figure 1

Multi_cle.book Page 2 Monday, September 20, 2004 12:36 PM

Indicator What It Does Usage Tips

Previous • Goes to the previous track. • Move and hold the Menu button towards

to move back within a track.

Next • Goes to the next track. • Move and hold the Menu button towards

to move ahead within a track.

Volume Increase • Increases the volume. • Move and hold the Menu button towards

to increase the volume quickly.

• Move and release the Menu button towards

to increase volume incrementally.

Volume Decrease • Decreases the volume. • Move and hold the Menu button towards

to decrease the volume quickly.

• Move and release the Menu button towards

to decrease volume incrementally.

Jack / Port What It Does Usage Tips

Power adapter jack • Connect your power

adapter to this jack.

USB port • Connect your USB cable to

this port.

Earphones /

wired remote

(optional) jack

• Connect your earphones or

wired remote (optional) to

this jack.

Multi_cle.book Page 3 Monday, September 20, 2004 12:36 PM

Getting Started

1Setting Up Your Computer

1. Ensure that your player is NOT connected to your computer.

2. Insert the Creative MuVo2 CD into your CD-ROM/DVD-ROM drive. Your CD should

start automatically. If it does not, follow the steps below:

i. Start Windows Explorer.

ii. On the left pane, click the My Computer icon.

iii. Right-click the CD-ROM/DVD-ROM drive icon, and then click AutoPlay.

3. Follow the instructions on the screen to complete the installation. Creative

MediaSource™ and Windows 98 SE drivers (only if applicable) will be installed on your

computer.

4. When prompted, restart your computer.

Do not charge your player’s battery via the USB port until after you have installed

the software.

Multi_cle.book Page 4 Monday, September 20, 2004 12:36 PM

2Inserting the Battery

Insert the supplied battery into your player as shown below.

3Charging the Battery

You can charge your battery by connecting your player to a power outlet using the supplied

power adapter, or by connecting your player to your computer’s USB port using the

supplied USB cable.

Using the power adapter

Connect one end of the power adapter to the wall outlet

and the other end to your player’s power adapter

connector, as shown in Figure 2. Charging your battery for

the first time takes about three hours. When appears

on your player's LCD, your player is fully charged.

You can also charge your player’s battery using the supplied USB cable. For more

information, see “Using the USB Cable” in your User’s Guide. Do not charge your

player’s battery via the USB port until after you have installed the software.

Figure 2

Multi_cle.book Page 5 Monday, September 20, 2004 12:36 PM

44 Transferring Audio and Data

Audio selections have been preloaded to your player to get you started quickly.

If you wish to listen to music immediately, simply press the Play/Pause button .

If you wish to download additional music tracks to your player, you can either download

music tracks from Internet music sites (see "Downloading from the Internet" in your User’s

Guide) or rip them from your audio CDs to create digital files on your computer. For more

information, see "Ripping Audios CDs" in your User’s Guide.

Data files can also be transferred to and stored in your player, for example, you can transfer

a large data file from one computer to another. Data can be transferred to your player with

the Creative MediaSource application.

To transfer audio and data with Creative MediaSource

1. Connect your player to your computer’s USB port using the supplied USB cable.

2. Launch Creative MediaSource on your computer.

3. On the left pane, locate and select the files you want to transfer to your player. Using

the standard drag-and-drop method, transfer the files to your player.

For information about transferring DRM-protected WMA files, see “Frequently Asked

Questions” on page 12.

4. After the transfer is complete, stop your player properly before disconnecting it from

your computer. For more details, see “Step 5: Stopping Your Player Properly” on

page 7.

Do not disconnect your player while file transfer is in progress.

Multi_cle.book Page 6 Monday, September 20, 2004 12:36 PM

5Stopping Your Player Properly

Before disconnecting your player from your computer, use the Windows Eject or Safely

Remove Hardware icon on the Taskbar to safely disconnect your player. If your player

is not disconnected safely, the content may become corrupted and the player will not

function correctly. Follow these steps below to safely disconnect your player:

Windows XP, Windows Me and Windows 2000

1. Click the Safely Remove Hardware icon on the Taskbar and click Safely

remove USB Mass Storage Device as shown.

2. Unplug your player when you are prompted to do so.

Windows 98 SE

1. Wait at least 10 seconds after all file transfers are completed.

2. In Windows Explorer, right-click the Removable Disk icon and click Eject.

3. Unplug your player after 10 seconds.

Multi_cle.book Page 7 Monday, September 20, 2004 12:36 PM

Some Basic Functions

Playing Audio Tracks

Audio selections have been preloaded to your player to get you started quickly.

If you wish to listen to music immediately, simply press the Play/Pause button .

To add audio tracks to your player, see “Transferring Audio and Data” on page 6.

To p l ay t r a c k s

1. Press the Menu button.

2. Select the Music icon (Figure 3).

3. Select the track you want to play and press the Play/

Pause button .

To pause a track

Press the Play/Pause button .

Managing Audio Tracks

For more advanced song management tasks, such as creating and managing playlists, you

can use Creative MediaSource Organizer. Creative MediaSource Player/Organizer is your

digital audio center for playing, creating, organizing and transferring digital audio. To launch

Creative MediaSource Player/Organizer, double-click the Creative MediaSource Player/

Organizer icon on your desktop.

For more information, read the User’s Guide on the Installation CD.

Go to d:\manual\<language>\manual.pdf (replace d:\ with the drive letter of your CD-ROM/

DVD-ROM drive, and <language> for the language the document is in)

Figure 3

Multi_cle.book Page 8 Monday, September 20, 2004 12:36 PM

Usage Precautions

What to do if your player was disconnected

improperly

If your player was disconnected improperly, one of two possible error messages may appear

on your player's screen:

In this case, to recover files on your player, do the following:

1. Reconnect your player to your computer.

2. In Windows Explorer, right-click the Removable Disk icon and select the

Properties option. Depending on your computer's settings, you may see an icon with

the name of your player, instead of a Removable Disk icon.

3. Click the To o l s tab, and then click the Check Now button. A dialog box appears.

4. Be sure that the Automatically fix file system errors option is selected. All other

options should not be selected.

5. Click the Start button.

When error checking is complete, safely unplug your player from your computer. See

“Stopping Your Player Properly” on page 7.

Scenario A

Multi_cle.book Page 9 Monday, September 20, 2004 12:36 PM

In this case, to recover files on your player, do the following:

1. Press the Menu button (follow steps 1-6 on page 11).

The Recovery Mode screen (Figure 4) appears.

2. Select the Run PC ScanDisk option.

3. Connect your player to your computer, via the USB

cable.

4. In Windows Explorer, right-click the Removable Disk icon and select the

Properties option. Depending on your computer's settings, you may see an icon with

the name of your player, instead of a Removable Disk icon.

5. Click the To o l s tab, and then click the Check Now button.

6. Be sure that the Automatically fix file system errors option is selected. All other

options should not be selected.

7. Click the Start button.

8. When error checking is complete, safely unplug your player from your computer. See

“Stopping Your Player Properly” on page 7.

Scenario B

Figure 4

If you continue to experience problems with your player, you may need to select the

Format all option to clean your player's storage memory. Doing so will erase all the

files on your player.

Multi_cle.book Page 10 Monday, September 20, 2004 12:36 PM

What to do if your player stops functioning

normally

Your player may stop functioning normally if any or all of the

following occurs:

• Your computer stops responding during file transfers.

• There is a power outage during file transfers.

• Your player was unplugged, or files were being deleted during file transfers.

When this happens, you can try to recover your player using the

unique Recovery Mode:

1. Press and hold the Play/Pause button until your player turns off. If you are

unable to turn off your player, proceed to the next step.

2. Disconnect all cables from your player and remove the player's battery.

3. Re-insert the battery and turn your player on to see if it starts functioning normally. If

it does not, remove the battery again and proceed to the next step.

4. Press and hold the Menu button. While holding down the Menu button, re-insert the

battery, or connect your player to a power outlet using the supplied power adapter.

5. Release the Menu button when the Recovery Mode

screen appears (Figure 5). If the Recovery Mode

message does not appear, repeat steps 2 and 3.

6. Select the recovery actions. Figure 5

Multi_cle.book Page 11 Monday, September 20, 2004 12:36 PM

Frequently Asked Questions

Where can I get official information on my player?

Visit www.creative.com for updates and downloads relating to your player, Creative’s

digital audio players and accessories.

How can I get accessories for my player?

Visit www.creative.com for the latest news on accessories.

Can I jog with my player?

You should not subject your player to continuous shocks, such as those that are likely to

occur while you jog or run.

Can I use the player for portable data storage?

Yes. You can use the supplied USB cable for speedy transfers to and from your player. Use

the Creative MediaSource application or Windows Explorer to help you manage data files.

Should I leave my power adapter plugged into my player?

No, you should not. After charging the battery or using the player, disconnect it from the

power adapter. Leaving it plugged in leads to heat buildup, which is not good for the player

or the battery.

If I damage or lose my power adapter, can I buy a similar, off-the-shelf adapter?

No. The adapter may not be compatible with your player, and may even damage it. You

should get a replacement adapter from Creative at www.creative.com, or your local

Creative office/distributor.

Multi_cle.book Page 12 Monday, September 20, 2004 12:36 PM

I have to recharge the battery quite often. Is there anything I can do to make it

last longer?

Generally, any operation requiring the player to access the hard disk uses battery power.

Consequently, filling your player to capacity is not recommended. However, some

operations consume more battery power:

• a long backlight timeout setting. A shorter timeout conserves battery power.

• a high contrast setting. Position the player so that you can read the display without using

a high contrast setting.

• too much use of fast forward/reverse.

• turning the player on/off too many times.

• prolonged use at high volumes.

Can I transfer DRM-protected WMA files to my player?

Yes. To transfer DRM-protected WMA files to your player, you can use Creative

MediaSource or Windows Media Player.

Multi_cle.book Page 13 Monday, September 20, 2004 12:36 PM

More Information

Enjoy a host of benefits by registering your product during installation, or at

www.creative.com/register. Benefits include:

• Service and product support from Creative

• Exclusive updates on promotions and events.

Customer Support Services and Warranty

You can find Customer Support Services, Warranty and other information in the

Installation CD.

(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, <region> with the region that you

are in, and <language> with the language that your document is in)

Customer Support Services d:\support\<language>\support.pdf

Warranty d:\warranty\<region>\<language>\warranty.pdf

Please keep your Proof of Purchase for the duration of the warranty

period.

User’s Guide d:\manual\<language>\manual.pdf

Creative Knowledge Base

Resolve and troubleshoot technical queries at Creative's 24-hour self-help

Knowledge Base. Go to www.creative.com and select your region.

trademarks or registered trademarks of Creative Technology Ltd. in the United States and/or other countries. Microsoft,

Windows and the Windows logo are registered trademarks of Microsoft Corporation. All other products are trademarks

or registered trademarks of their respective owners and are hereby recognized as such. All specifications are subject to

change without prior notice. Actual contents may differ slightly from those pictured.

Multi_cle.book Page 14 Monday, September 20, 2004 12:36 PM

Safety Advice

As with any digital media-based storage device, data should be backed up regularly. We

strongly recommend that you observe the usage precautions laid out in this booklet, and

also back up the data in your player regularly. In no event will Creative be liable for any

indirect, incidental, special or consequential damages to any persons caused by Creative's

negligence, or for any lost profits, lost savings, loss of use, lost revenues or lost data

arising from or relating to this device, even if Creative has been advised of the possibility

of such damages. In no event will Creative’s liability or damages to you or any other

person ever exceed the amount paid by you for the device, regardless of the form of the

claim. Some countries/states do not allow the limitation or exclusion of liability for

incidental or consequential damages, so the above limitation or exclusion may not apply

to you.

Multi_cle.book Page 15 Monday, September 20, 2004 12:36 PM

Français

Présentation générale du lecteur

Bouton Marche/

Arrêt et

Lecture/Pause

Ecran à cristaux

liquides (LCD)

Bouton Menu

Vue avant

Prise pour écouteurs /

télécommande câblée (en option)

Port

USB

Prise pour

adaptateur

secteur

Vue du dessus

Multi_cle.book Page 16 Monday, September 20, 2004 12:36 PM

Utilisation du bouton Menu

Sélection

Le bouton Menu (Figure 1) est l'une des principales fonctions du lecteur.

Dans ce document, le verbe « sélectionner » indique que vous devez

déplacer le bouton Menu vers la gauche ou la droite pour parcourir les

options puis sélectionner celle de votre choix en appuyant sur ce bouton.

Volume

Vous pouvez également régler le niveau de volume à l'aide du bouton Menu.

Déplacez le bouton Menu vers le haut pour augmenter le volume ou vers le bas pour le

diminuer.

Utilisation du lecteur

Bouton Fonction Conseils d'utilisation

Menu • Affiche les options du menu

sur l'écran LCD.

• Pour plus d'informations sur l'utilisation du

bouton Menu, voir « Utilisation du bouton

Menu » ci-dessus.

Lecture/Pause • Permet de mettre le lecteur

sous et hors tension.

• Permet de lire des pistes et

d'interrompre leur lecture.

• Appuyez sur ce bouton et maintenez-le

enfoncé pour mettre le lecteur sous et hors

tension.

• En mode Musique, appuyez sur ce bouton

pour commencer la lecture des pistes et

rappuyez dessus pour interrompre la

lecture.

Figure 1

Multi_cle.book Page 17 Monday, September 20, 2004 12:36 PM
