Creativity Elf Core XY User manual

ShenZhen Creative3D Technology Co.,Ltd

E L F
Core XY
3D Printer

USER MANUAL

Do not place the Printer near flammables, explosives or heat sources. It is best to place it in a
well-ventilated, low-dust environment.
Do not expose the Printer to violent vibration or any unstable environment. This will cause poor
print quality.
The filaments recommended by the manufacturer are preferred as to avoid clogging in the
hot end and/or Printer damage.
Do not use any other power cable than the one supplied. Use a grounded three-prong power
outlet.
Do not touch the nozzle or hot bed during printing. Keep hands away from machine while in
use to avoid burns or personal injury.
Do not wear gloves or loose clothing when operating the Printer. These loose articles can
become caught in moving parts and cause personal injury or Printer damage.
Clean off filament from the nozzle tip with the provided pliers before the nozzle cools. Do not
touch the nozzle directly. This can cause personal injury.
Clean the Printer frequently. With the machine powered off, clean the printer body with a dry
cloth to remove dust, adhered printing materials and foreign objects on guide rails. Use glass
cleaner or isopropyl Alcohol to clean the print surface before every print for consistent results.
Children under 12 years of age should not use the Printer without supervision.
Attentions

Safety Instructions

1

2

Preparation List
M5*25
*4
M5*10
*4
2020-L560
*4
2020-L440
*2
Main
controller
*1
Step 1
3

Preparation List
M4*8
*16
M3*8
*6
Anti-Backlash
Nuts-1
*2
Flange
bearing
*4
Hot Bed
Support part
*2
4
Step 2

Preparation List
M5*20-P
Coupling
*2
Optical
axis
*4
Secure
blocks
*2
Setp2 part
*2
5
Step 3

Preparation List
Z- L Limit
*1
Z- R Limit
*1
T8*8
*2
Anti-Backlash
Nuts-2
*2
Anti-Backlash
Nuts-3
*2
6
Step 4

Preparation List
M5*14-P
*4
M3*5
*2
Extrusion&
34motor
*1
Top part
*1
7
Step 5

Preparation List
M4*40-P
*4
Spring
*4
Pltaform
nut
*4
Heat Bed
*1
Rack
*1
8
Step 6

9
Step 7

1. Auto Home All Disable xy
2. Test with A4 paper, adjust the nuts under the platform up and down, to make the nozzle just
presses the A4 paper, and ensure that the four corners are the same distance. Repeat steps
1-2 times if necessary
If you want the printer to shut down automatically after printing, please do the following:
10
Bed Leveing
Automatic shutdown

1. Open the SD card,find the CURA(or download online), After installing the software:Add a
printer Settings
Software Installation
11

2. Import the profile from the SD card
Software Installation
12

13

Follow us
https://www.facebook.com/Creative3Dprinter/
https://vk.com/creative3dprinter
https://twitter.com/creative3dprint
https://www.instagram.com/creative.3dprinter/
https://www.pinterest.com/Creative3Dprinter/
https://creative3dprinter.tumblr.com/
[e-mail]
www.creative3dprinter.com
