IMPORTANT:THESEINSTRUCTIONSSHOULDBEREADCAREFULLYANDRETAINEDFORFUTUREREFERENCE
Important Safety Advice
DONOT COVEROR OBSTRUCTthe air inlet oroutlet grille.
Always disconnect supply before working on the product.
Always ensure combustible materials such as drapes or
otherfurnishings are keptclear of theair inlet andair outlet.
Neverfit and usethis heater in theimmediate surroundings
of a bath, shower or swimming pool.
Never leave the heater unattended when switched on near
to children, the aged or infirm.
Donot use thisheater inareas where excessivedust exists.
This heater must not be located immediately above or
below a fixed socket outlet or connection box.
This product should be mounted safely to a solid wall.
Ensure the supply cables are of adequate current carrying
capacity and are protected by a suitable fuse.
Thisappliance should onlybe connected tothe fixed wiring
of the premises by means of conduit.
This product must not be subjected to water spray or
immersion.
WARNING: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched
on and off by the utility.
General
The CFS3 is a high powered wall mounted fan heater providing
environmental heating for smaller commercial environments
such as garages and workshops.
The heater works by gradually raising the air temperature and
should be positioned at head height approximately (1.8m - 2.3m
- see Fig. 2) .
The CFS3 heater has an output of 3kW.
The angle the appliance is mounted at may be adjusted
horizontally and vertically - (see Fig. 1 and Fig. 4).
Electrical
The installation of this appliance should be carried out by a
competent electrician and be in accordance with the current IEE
wiring regulations. The supply cable is not supplied with the
appliance.
Note: A suitable local isolating switch must be provided in the
electrical supply circuit as close as possible to the heater with at
least 3mm clearance on each pole.
Wall Mounting
Removethescrew (see ‘z’ in Fig. 3C)toremovethecover bracket.
Use the wall mounting bracket (see ‘x’ in Fig. 3A) as a guide to
mark off the hole positions on a suitable wall (a minimum height
of 1.8 metres is required from the floor level to the bottom hole of
the bracket - (see Fig. 2). Solid brick or concrete block walls
must be drilled and plugged using the screws and wall plugs
provided. Fix the wall mounting bracket to the wall and slide the
heater down on to the bracket as shown in Fig. 3A.
Note: Ensure there is enough clearance above the wall mounting
bracket for the user to slide the heater onto the bracket.
The heater is held in place to the wall mounting bracket with 2
screws - (see Fig. 3B).
Onceelectricalconnectionshavebeen completed - see ‘Electrical
Installation’, re-attach the bracket cover (see ‘y’ in Fig. 3C) by
sliding into place and secure with the screw - (see ‘z’ in Fig. 3C).
Pivot and rotate the heater into the desired position and tighten
the screw to secure - (see ‘w’ in Fig. 4).
Electrical Installation
Before undertaking electrical installation, ensure the electricity
supply is disconnected from any relevant fixed wiring. With the
bracket cover removed proceed to feed the supply cord through
the cable entry at the bottom of the mounting bracket (drill knock-
out to suit).
Remote Control - (see Fig. 5 &6)
Remove the wall mounting bracket from the remote control unit.
Feed the supply cord through the desired cable entry (1-4 see
Fig. 6). Connect the mains lead (ML) to terminal block - (see Fig.
5). Connect the 4 core cable (not supplied) from the remote
control to the appliance - (see Fig. 5).
Key - see Wiring Diagram Fig. 5
TB1 Terminal Block 1 RC Remote Control
ML Mains Lead TB2 Terminal Block 2
S1 Switch 1 TThermostat
S2 Switch 2 LLive
EL Element EEarth
NNeutral L out Live Out
Lin Live In NEON Neon
MMotor SH SolFan Heater
Note: All 4 core cable wires must be 1.5mm2
Controls
The CFS3 is supplied with a wall mounted control unit complete
with thermostat. This may be mounted on a wall in a convenient
location away from direct sunlight or draughty areas.
Using the mounting bracket as a guide, (see Fig. 6)mark the
hole positions and drill and plug the wall to suit using the screws
and wall plugs provided.
The heat output is controlled by the thermostat, according to the
room temperature.
Turn the thermostat knob fully clockwise to maximum setting
initially.Whentheroomis warm enough, reduce the setting slowly
until the heater just clicks off.
The heater will now cycle on and off to maintain your selected
room temperature. An audible click may be heard when the
thermostat operates - this is normal.
Note : If the heater does not come on when the thermostat is at
a low setting, this is normally because the room is warmer than
the thermostat setting and is not a fault.
* When the heat control is set to ‘ ’ for cool blow, set the
thermostat control to maximum.
Position ‘ ’ will turn the heater on and off to maintain a
temperature of approximately 5°C.
Creda SolFan Heater
Model : CFS3
