Cree FLEX Series User manual

FLEX Series
Commercial Specification Troffers with Emergency Driver
Includes: FLX14™, FLX22™ and FLX24™
INSTALLATION INSTRUCTIONS
1 of 4 LPN00439X0001A1_C
FLX14™
FLX22™
FLX24™
• The FLEX Series of specification troffers is for non-insulated
ceiling applications using T-Bar ceiling grid, drywall grid adaptors,
and suspended mount.
• Designed for use in 120-277V 50-60 Hz or 347V 60Hz protected
circuit (fuse box, circuit breaker). Supply wire sized as per NEC or
governing code(s), 90C rated.
• Make sure to cap off all unused leads.
• Lens and removable end cap may shift during installation. To seat
lens press end caps and squeeze lens to engage with back panel.
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER - RISQUE DE CHOC - COUPER L’ALIMENTATION
AVANT L’INSTALLATION
2. CAUTION – Installation and servicing should be performed by
qualied personnel only. De-energize before opening.
ATTENTION – L’installation et l’entretien doivent être effectués
par du personnel qualié seulement. Mettre hors tension avant
l’ouverture
3. To reduce the risk of electric shock, disconnect both standard
and emergency power supplies and converter connector of the
emergency driver before servicing.
Pour réduire le risque de décharge électrique, vous devez
déconnecter à la fois le disjoncteur divisionnaire ou les fusibles et
les alimentations d’urgence avant l’entretien.
4. Do not use outdoors.
Ne pas utiliser à l’extérieur.
5. Do not let power supply cords touch hot surfaces.
Ne laissez pas les cordons d’alimentation toucher les surfaces
chaudes.
6. Do not mount near gas or electric heaters.
Ne montez PAS près des appareils de chauffage de gaz ou
électriques.
7. Do Not use this equipment for other than its intended use.
NE PAS utiliser cet équipement à d’autres ns que celle qui est
prévue
8. Equipment should be mounted in locations and heights where it will not readily be subjected to tampering by unauthorized
personnel.
L’équipement doit être monté dans des endroits et à des hauteurs où il ne sera pas soumis à des altérations par des personnes
non autorisées.
9. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
L’utilisation d’accessoires non recommandés par le fabricant peut causer une situation dangereuse.
10. Suitable for suspended ceilings.
11. Max. mounting height: 15 ft.
Hauteur de montage max.: 15 pieds.
12. Access above ceiling required. Do not install insulation within 3” (76mm) of any part of the luminaire.
Accès requis au-dessus du plafond. Ne pas mettre l’isolant à moins de 3 po (76 mm) de toute partie du luminaire
13. Suitable for suspended ceilings.
Convient aux plafonds suspendus.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

2 of 4 LPN00439X0001A1_C
3
Power Supply
Junction Box Cover
Dimming Wire
Junction Box Cover
TO INSTALL:
T- BAR CEILING MOUNTING
STEP 1:
Bring the FLEX troffer up into the T-Bar grid.
STEP 2:
Locate the luminaire hooks and bend them out 90 degrees for
installation. See Figure 1.
NOTE: The luminaire hooks ship bent in and need to be bent out for
installation.
STEP 3:
Then bend the luminaire hooks against the T-Bar to secure the
luminaire. See Figure 1.
SUSPENDED MOUNTING
STEP 1:
Attach customer supplied cables to the (2) cable slots on each side of
the housing. See Figure 2.
STEP 2:
Attach customer supplied cables to mounting surface using customer
supplied hardware. Ensuring that mounting surface can support the
luminaire.
0 - 10V DIMMING OPTION
STEP 1:
Remove the cover of the junction box and bring in appropriate power
supply to the junction box using one of the knock-outs. See Figure 3.
STEP 2:
Remove the cover of the dimming junction box and bring dimming
conduit into dimming wire compartment using the knock-out. See
Figure 3.
STEP 3:
Wire luminaire per “Electrical Connections” section and push all leads
into the junction box. Reattach junction box cover that was removed in
Step 1 , make sure no wires are pinched.
STEP 4:
Install test switch assembly into ceiling by drilling a 1” hole into the
ceiling.
STEP 5:
Unscrew the small trim ring and place test switch assembly through the
ceiling. See Figure 4.
STEP 6:
Secure the test switch assembly by screwing the small trim ring
removed in Step 5 back onto the test switch assembly. Tighten the larger
trim ring above the ceiling until it is snugged tight against the ceiling.
See Figure 4 on the next page.
2
Cable Slots
1
Luminaire Hooks
T-bar
1st:
90° Bend
2nd: Bend
Against T-bar
T-bar

3 of 4 LPN00439X0001A1_C
5
Lens
Test Switch
Large Trim Ring
Small Trim Ring
Ceiling
4
CLEANING LENS
STEP 1:
Remove lens and end cap assembly by pulling
straight downward gently. See Figure 5.
STEP 2:
After cleaning is complete insert lens and end cap
assembly back into the luminaire housing. Check
end caps for any visible gap between the end cap and
end panel. If necessary push end cap against the end
panel to eliminate gaps.
Check lens for any visible gap between the lens and
luminaire.
EMERGENCY DRIVER CHECK
NOTE: For short-term testing of the emergency function, the battery
must be charged for at least one hour. The emergency driver must be
charged for at least 24 hours before conducting a long-term test.
STEP 1:
When AC power is applied, the charging indicator light is illuminated,
indicating the battery is being charged. When power fails, the
emergency driver automatically switches to emergency power,
operating the LED array. When AC power is restored, the emergency
driver returns to the charging mode.
STEP 2:
Although no routine maintenance is required to keep the emergency
driver functional, it should be checked periodically to ensure that it is
working. The following schedule is recommended:
• Visually inspect the charging indicator light monthly. It should
be illuminated.
• Test the emergency operation of the fixture at 30-day intervals
for a minimum of 30 seconds. When the test switch is
depressed, the LED array should operate.
• Conduct a 90-minute discharge test once a year. The LED array
should operate for at least 90 minutes.
If the luminaire fails any of these checks, consult service personnel.
REFER ANY SERVICING INDICATED BY THESE CHECKS TO
QUALIFIED PERSONNEL
EMERGENCY DRIVER AND AC DRIVER MUST BE FED FROM THE
SAME BRANCH CIRCUIT.
FCC NOTICE
CAUTION: Changes or modifications not expressly approved could void
your authority to use this equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CAN ICES-005 (A)/NMB-005 (A)
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.

4 of 4 LPN00439X0001A1_C
© 2018 Cree, Inc. All rights reserved. For informational purposes only. Content is subject to change.
See http://lighting.cree.com/warranty for warranty and specifications. Cree®and the Cree Logo are registered trademarks, and
FLX14™, FLX22™ and FLX24™ are trademarks of Cree, Inc. Armstrong®is a registered trademark of AWI Licensing LLC.
lighting.cree.com
ELECTRICAL CONNECTIONS
NOTE: The emergency driver must be fed from
the same branch as the AC Driver.
STEP 1:
Using customer supplied 90°C minimum rated wire
connectors, make the following electrical connections:
a. Connect the black luminaire lead to the
unswitched voltage supply lead.
b. Connect the white/red luminaire lead to
the switched supply switched.
c. Connect white luminaire lead to the neutral supply lead.
d. Connect ground bare or green/yellow wire
lead to the supply ground lead.
e. If 0/1-10V Dimming is used, connect the violet lead
to the supply positive dimming lead. If dimming is
not being used ensure to cap off the violet lead.
f. If 0/1-10V Dimming is used, connect the gray lead
to the supply negative dimming lead. If dimming is
not being used ensure to cap off the gray lead.
g. Secure incoming dimming leads to the existing strain
relief, to prevent contact with primary wiring.
STEP 2:
Locate the two red leads in the junction box and connect them using
customer supplied connector.
WHITE
DIM (-) GREY
DIM (+) VIOLET VIOLET
GREY
SUPPLY WIRING
(DIMMING OPTIONAL)
LUMINAIRE
GROUND
BARE OR
GREEN/YELLOW
WHITE/RED
SWITCHED HOT
BLACK
UNSWITCHED HOT
** NOTE: DO NOT mate leads until installation
is complete and AC power is supplied
**RED
**RED
WHITE
NEUTRAL
